Pioneer DEH-3900MP User manual

ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2006
DEH-3900MP/XN/EW5
CRT3804
CD RDS RECEIVER
DEH-3900MP
/XN/EW5
This service manual should be used together with the following manual(s):
Model No. Order No. Mech.Module Remarks
CX-3195 CRT3815 S10.5COMP2 CD Mech. Module : Circuit Descriptions, Mech. Descriptions, Disassembly
For details, refer to "Important Check Points for Good Servicing".
K-ZZA.NOV. 2006 Printed in Japan

DEH-3900MP/XN/EW5
2
1234
1234
C
D
F
A
B
E
SAFETY INFORMATION
CAUTION:
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
CLASS 1
LASER PRODUCT
WARNING!
The AEL (accessible emission level )of the laser power output is less than CLASS 1
but the laser component is capable of emitting radiation exceeding the limit for
CLASS 1.
A specially instructed person should do servicing operation of the apparatus.
Laser diode characteristics
Wave length : 785 nm to 814 nm
Maximum output : 1 190 μW(Emitting period : unlimited)
Additional Laser Caution
Transistors Q101 in PCB drive the laser diodes.
When Q101 is shorted between their terminals, the laser diodes will radiate beam.
If the top cover is removed with no disc loaded while such short-circuit is continued,
the naked eyes may be exposed to the laser beam.
-Safety Precautions for those who Service this Unit.
• When checking or adjusting the emitting power of the laser diode exercise caution in order to get safe, reliable
results.
Caution:
1. During repair or tests, minimum distance of 13 cm from the focus lens must be kept.
2. During repair or tests, do not view laser beam for 10 seconds or longer.
This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely
repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
If you are not qualified to perform the repair of this product properly and safely, you should not risk trying to do so
and refer the repair to a qualified service technician.

DEH-3900MP/XN/EW5 3
5678
5678
C
D
F
A
B
E
-Service Precaution
1. You should conform to the regulations governing
the product (safety, radio and noise, and other
regulations), and should keep the safety during
servicing by following the safety instructions
described in this manual.
2. Before disassembling the unit, be sure to turn off
the power. Unplugging and plugging the connectors
during power-on mode may damage the ICs inside
the unit.
3. To protect the pickup unit from electrostatic discharge
during servicing, take an appropriate treatment
(shorting-solder) by referring to "the DISASSEMBLY".
4. After replacing the pickup unit, be sure to check the
grating.
5. Be careful in handling ICs. Some ICs such as MOS
type are so fragile that they can be damaged by
electrostatic induction.

DEH-3900MP/XN/EW5
4
1234
1234
C
D
F
A
B
E
[Important Check Points for Good Servicing]
In this manual, procedures that must be performed during repairs are marked with the below symbol.
Please be sure to confirm and follow these procedures.
1. Product safety
Please conform to product regulations (such as safety and radiation regulations), and maintain a safe servicing environment by
following the safety instructions described in this manual.
1Use specified parts for repair.
Use genuine parts. Be sure to use important parts for safety.
2Do not perform modifications without proper instructions.
Please follow the specified safety methods when modification(addition/change of parts) is required due to interferences such as
radio/TV interference and foreign noise.
3Make sure the soldering of repaired locations is properly performed.
When you solder while repairing, please be sure that there are no cold solder and other debris.
Soldering should be finished with the proper quantity. (Refer to the example)
4Make sure the screws are tightly fastened.
Please be sure that all screws are fastened, and that there are no loose screws.
5Make sure each connectors are correctly inserted.
Please be sure that all connectors are inserted, and that there are no imperfect insertion.
6Make sure the wiring cables are set to their original state.
Please replace the wiring and cables to the original state after repairs.
In addition, be sure that there are no pinched wires, etc.
7Make sure screws and soldering scraps do not remain inside the product.
Please check that neither solder debris nor screws remain inside the product.
8There should be no semi-broken wires, scratches, melting, etc. on the coating of the power cord.
Damaged power cords may lead to fire accidents, so please be sure that there are no damages.
If you find a damaged power cord, please exchange it with a suitable one.
9There should be no spark traces or similar marks on the power plug.
When spark traces or similar marks are found on the power supply plug, please check the connection and advise on secure
connections and suitable usage. Please exchange the power cord if necessary.
0Safe environment should be secured during servicing.
When you perform repairs, please pay attention to static electricity, furniture, household articles, etc. in order to prevent injuries.
Please pay attention to your surroundings and repair safely.
2. Adjustments
To keep the original performance of the products, optimum adjustments and confirmation of characteristics within specification.
Adjustments should be performed in accordance with the procedures/instructions described in this manual.
4. Cleaning
For parts that require cleaning, such as optical pickups, tape deck heads, lenses and mirrors used in projection monitors, proper
cleaning should be performed to restore their performances.
3. Lubricants, Glues, and Replacement parts
Use grease and adhesives that are equal to the specified substance.
Make sure the proper amount is applied.
5. Shipping mode and Shipping screws
To protect products from damages or failures during transit, the shipping mode should be set or the shipping screws should be
installed before shipment. Please be sure to follow this method especially if it is specified in this manual.

DEH-3900MP/XN/EW5 5
5678
5678
C
D
F
A
B
E
CONTENTS
SAFETY INFORMATION......................................................................................................................................2
1. SPECIFICATIONS.............................................................................................................................................6
2. EXPLODED VIEWS AND PARTS LIST.............................................................................................................8
2.1 PACKING ....................................................................................................................................................8
2.2 EXTERIOR ...............................................................................................................................................10
2.3 CD MECHANISM MODULE .....................................................................................................................12
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM ..........................................................................................14
3.1 BLOCK DIAGRAM....................................................................................................................................14
3.2 OVERALL CONNECTION DIAGRAM(GUIDE PAGE) ..............................................................................16
3.3 KEYBOARD UNIT ....................................................................................................................................22
3.4 CD MECHANISM MODULE(GUIDE PAGE).............................................................................................24
4. PCB CONNECTION DIAGRAM ......................................................................................................................32
4.1 TUNER AMP UNIT ...................................................................................................................................32
4.2 KEYBOARD UNIT ....................................................................................................................................36
4.3 CD CORE UNIT(S10.5COMP2) ...............................................................................................................38
5. ELECTRICAL PARTS LIST .............................................................................................................................40
6. ADJUSTMENT ................................................................................................................................................44
6.1 CD ADJUSTMENT ...................................................................................................................................44
6.2 CHECKING THE GRATING AFTER CHANGING THE PICKUP UNIT.....................................................46
6.3 ERROR MODE.........................................................................................................................................48
7. GENERAL INFORMATION .............................................................................................................................49
7.1 DIAGNOSIS..............................................................................................................................................49
7.1.1 DISASSEMBLY......................................................................................................................................49
7.1.2 CONNECTOR FUNCTION DESCRIPTION ..........................................................................................52
7.2 PARTS ......................................................................................................................................................53
7.2.1 IC ...........................................................................................................................................................53
7.2.2 DISPLAY................................................................................................................................................61
7.3 OPERATIONAL FLOW CHART................................................................................................................62
8. OPERATIONS .................................................................................................................................................63

DEH-3900MP/XN/EW5
6
1234
1234
C
D
F
A
B
E
1. SPECIFICATIONS

DEH-3900MP/XN/EW5 7
5678
5678
C
D
F
A
B
E

DEH-3900MP/XN/EW5
8
1234
1234
C
D
F
A
B
E
2. EXPLODED VIEWS AND PARTS LIST
2.1 PACKING
N
OTES : • Parts marked by " * " are generally unavailable because they are not in our Master Spare Parts List.
• The >mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
• Screw adjacent to mark on the product are used for disassembly.
• For the applying amount of lubricants or glue, follow the instructions in this manual.
(In the case of no amount instructions,apply as you think it appropriate.)
"
18
17
16
18
13
12
15
14
2
10
3
11
6
8
7
5
4
9
1

DEH-3900MP/XN/EW5 9
5678
5678
C
D
F
A
B
E
PACKING SECTION PARTS LIST
Owner's Manual,Installation Manual
Mark No. Description Part No.
1 Cord Assy CDP1015
2 Accessory Assy CEA6707
3 Screw BPZ20P080FTC
4 Screw Assy CEA3849
5 Screw CBA1650
* 6 Polyethylene Bag CEG-127
7 Screw CRZ50P090FTC
8 Screw TRZ50P080FTC
9 Polyethylene Bag CEG1160
10 Handle CND3707
11 Bush CNV3930
12 Polyethylene Bag CEG1373
13 Carton CHG5978
14 Contain Box CHL5978
15 Protector CHP3279
16 Protector CHP3280
17-1 Owner's Manual CRD4129
17-2 Owner's Manual CRD4130
17-3 Installation Manual CRD4131
* 17-4 Passport CRY1013
* 17-5 Warranty Card CRY1157
18 Case Assy CXB3520
Mark No. Description Part No.
Part No. Language
CRD4129 English, Spanish, German
CRD4130 French, Italian, Dutch, Russian
CRD4131 English, Spanish, German, French, Italian, Dutch, Russian

DEH-3900MP/XN/EW5
10
1234
1234
C
D
F
A
B
E
2.2 EXTERIOR
62
39
40 40
40
40
50
61
60
42
46
46
45
47
44
59
48
43
49
41
54
51
55
56
57
52 67 58
65
64
66
63
63
38
34
35
30
33
37
32
31
36
A
A
7
11
12
23
25 14
13
2
2
19
22
18
20
29
24
21
28
16
17
15
1
1
1
1
4
26
27
10
8
9
3
2
6
5
53
A
B

DEH-3900MP/XN/EW5 11
5678
5678
C
D
F
A
B
E
EXTERIOR SECTION PARTS LIST
Mark No. Description Part No.
1 Screw BSZ26P060FTC
2 Screw BSZ26P100FTC
3 Screw BSZ26P180FTC
4 Cable CDE8336
5 Cord Assy CDP1015
6 Cap CKX-003
7 Case CNB2793
8 Holder CND3598
9 Insulator CNN1385
10 Panel CNS8762
11 Tuner Amp Unit CWN2033
12 Screw BSZ26P060FTC
13 Screw BPZ26P080FTC
14 Screw BSZ26P160FTC
> 15 Fuse(10 A) CEK1208
16 Pin Jack(CN351) CKB1059
17 Plug(CN901) CKM1376
18 Connector(CN651) CKS3829
19 Connector(CN871) CKS4124
20 Connector(CN831) CKS5664
21 Antenna Jack(CN401) CKX1056
22 Holder CND3545
23 Holder CND3705
24 Holder CND3706
25 Heat Sink CNR1668
26 FM/AM Tuner Unit CWE2024
27 Holder CND3466
28 Terminal(CN402) VNF1084
29 Terminal(CN601) VNF1084
30 Chassis Unit CXC6728
31 Button(DETACH) CAC4836
32 Spring CBH2367
33 Spring CBH2961
34 Spring CBH2962
35 Cover CNN1665
36 Panel CNS8760
37 Arm CNV9311
38 Arm CNV9312
39 Detach Grille Assy CXC6989
40 Screw BPZ20P100FTC
41 Button(Detach) CAC9941
42 Button(AUDIO,FUNC) CAC9942
43 Button(1-6) CAC9943
44 Button(EJECT,TA) CAC9949
45 Button(EQ,BAND) CAC9950
46 Button(<,>) CAI1180
47 Button(UP) CAI1181
48 Button(DOWN) CAI1182
49 Spring CBH2210
50 Cover CNS8758
51 LCD CAW1930
52 Jack(CN1802) CKN1047
53 Connector(CN1801) CKS5663
54 Holder CND3646
55 Connector CNV9306
56 Lighting Conductor CNV9308
57 Rubber CNV9310
58 Cushion YNM5029
59 Grille Unit CXC7062
60 Knob Unit(SOURCE, VOLUME) CXC7656
61 Spring CBL1761
62 CD Mechanism Module(S10.5) CXK5760
63 Screw ISS26P055FTC
64 Transistor(Q991) 2SD2396
65 IC(IC301) PAL007C
66 IC(IC911) BA4918-V12
67 IC(IC1802) GP1UX51RK
Mark No. Description Part No.

DEH-3900MP/XN/EW5
12
1234
1234
C
D
F
A
B
E
2.3 CD MECHANISM MODULE

DEH-3900MP/XN/EW5 13
5678
5678
C
D
F
A
B
E
CD MECHANISM MODULE SECTION PARTS LIST
Mark No. Description Part No.
1 CD Core Unit(S10.5COMP2) CWX3350
2 Connector(CN101) CKS4182
3 Connector(CN701) CKS4808
4 Screw BMZ20P025FTC
5 Screw BSZ20P040FTC
6 Screw(M2 x 3) CBA1511
7 Screw(M2 x 4) CBA1835
8 Washer CBF1038
9 •••••
10 Spring CBH2609
11 Spring CBH2612
12 Spring CBH2614
13 Spring CBH2616
14 Spring CBH2617
15 Spring CBH2620
16 Spring CBH2855
17 Spring CBH2937
18 Spring CBH2735
19 Spring CBH2854
20 Spring CBH2642
21 Spring CBH2856
22 Spring CBH2857
23 Spring CBH2860
24 Spring CBH2861
25 Spring CBL1686
26 Arm CND1909
27 Frame CND2582
28 Bracket CND2583
29 Arm CND2584
30 Lever CND2585
31 Arm CND2586
32 Bracket CND2587
33 Arm CND2588
34 Lever CND2589
35 Holder CNV7201
36 Gear CNV7207
37 Gear CNV7208
38 Gear CNV7209
39 Gear CNV7210
40 Gear CNV7211
41 Gear CNV7212
42 Rack CNV7214
43 Arm CNV7216
44 Roller CNV7218
45 Gear CNV7219
46 Guide CNV7361
47 Gear CNV7595
48 Guide CNV7799
49 Arm CNV7805
50 Rack CNV8342
51 Roller CNV8343
52 Holder CNV8344
53 Arm CNV8345
54 Guide CNV8347
55 Arm CNV8348
56 Arm CNV8349
57 Arm CNV8350
58 Clamper CNV8365
59 Arm CNV8386
60 Guide CNV8396
61 Arm CNV8413
62 Collar CNV8938
63 Motor Unit(M2) CXC4026
64 Arm Unit CXC4027
65 Chassis Unit CXC4028
66 Gear Unit CXC4029
67 Frame Unit CXC4031
68 Motor Unit(M1) CXC7134
69 Screw Unit CXC6359
70 Screw JFZ20P020FTC
71 Screw JGZ17P022FTC
72 Washer YE20FTC
73 Pickup Unit(P10.5)(Service) CXX1942
74 Screw IMS26P030FTC
Mark No. Description Part No.

DEH-3900MP/XN/EW5
14
1234
1234
C
D
F
A
B
E
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM
3.1 BLOCK DIAGRAM
PICKUP UNIT
(P10.5)(SERVICE) D
CD CORE UNIT(S10.5COMP2)
C
BRST,BRXEN,BSRQ
CN701
Q101
M
LASER
DIODE
MONITOR
DIODE
S903
DSCSNS
SPINDLE
MOTOR
M
CARRIAGE
MOTOR
LOAD/
LD-
MD
15
5
HOLOGRAM
UNIT
IC301
BA5839FP IC201
PE5547A
RF-AMP, CD DECODER,
MP3/WMA DECODER,
DIGITAL SERVO /
DATA PROCESSOR
CD
DRIVER
2
VD
VD
13
LOUT
9
CN101
16 SOP
15 SOM
18 LCOP
17 LCOM
21
CLCONT
55
LOUT
9
CONT
TD,FD
AC,BD,F,E
SD,MD
IC202
S-93C56BD0I-J8
EEPROM CS,SK
DI,DO
S901
HOME
S904
12EJ S905
8EJ
LD+ 14
141 LD
142 PD
12EJ
CONT
CLCONT
HOME
8
9
43
41
VDD
1
VDD
BDATA,BSCK
Q102
39
/PUEN
VDD
15
5
FOCUS ACT.
TRACKING ACT.
FOP
TOP 2
1TOP
FOP
11 FOP
14 TOP
2
1
14
8EJ
7
DSCSNS
6
VCC
16
/RESET 8
/RESET
88
VREF REFO 133 REFOUT
33
FOM FOM
12 FOM
44
TOM TOM
13 TOM
22
LOEJ LOEJ
5
52
50
X201
XTAL
/XTAL 16.93MHz
VDSENS 11
VD
IN1_
L
IN2_
L
1
ELE
C
SO
U
TUNL
2
CN401
1
2
CN651
TUNER AMP UNIT
LOUT
A
SYS+B
ANTENNA
IFA
IFB
CDRESET
3
B.UP
VDD
5
VD
Q991
14
7
SWVDD
SWD5V 6
5
IC 911
BA4918-V12
BSENS
SYSPW
POWEROFF
2
1
36
47
15
SWVDD
41
15 Q992
BRST,BRXEN,BSRQ,BDATA,BSCK
8RESET 16
FM/AM TUNER UNIT
AM_ANT
SL-IN
REFA
REFB
LDET
SWVDD
DI
CK
CE1
DO
CE2
SLOUT
SL-IN
IFA
IFB
REFA
REFB
LDET
DI
CK
CE1
DO
CE2
SLOUT
VDCONT
126
CD VD
CDL
3
REGULATOR IC
B.UP
10
9
VDD
SYS+B 8
7
IC 601(
2
PN500
9
SYSTEM
M
COMPU
T
SYSPW
DREG
85
SWVDD
Q601
PLL_VDD
DVDD3
REGC(M)
55
9
57
DVDD2
94
DVDD4
121
VD
ATT ATT
TANK
ATT RF LFP
LFPVCO
CF
IC1
MIX / IF / PLL
IC2
EEPROM
1 2 3 4 5 6 7 8 9 10 1213 14 15 1617 1819 2011
ANT
VCC
SLIN
IFOUTA
IFOUTB
DGND
REFINA REFINB
LDET
VDD
DI
CK
CE1
DO
CE2
SLOUT
RFGND1 RFGND2 RFGND3 RFGND4

DEH-3900MP/XN/EW5 15
5678
5678
C
D
F
A
B
E
IN1_L
IN2_L
1
IC 151
PML014A
ELECTRONIC VOLUME/
SOURCE SELECTOR
TUNL
2
7
Rear_L
B.UP
35
44
MUTE
21
23
3
5
FL−
VCC
VCC
FL+
RL−
RL+
FL−
FL+
RL−
RL+
B.REMOTE
ACC
22
IC 601(1/2)
PN5009A
AMP
IC 301
PAL007C
Q931
MUTE
CN831
VCK, VDT, VST
Q201(1/2)
Q201(2/2)
B.UP
Q821
SYSTEM MICRO
COMPUTER
FL−
FL+
RL−
RL+
ACC SENSE
3
9
11
12
10
1
3
9
11
12
10
1
6
22
CN901
BACK UP
GND
RR
+
RR
−
FR
+
FR
−
FL
+
FL
−
RL
+
RL
−
ACC
GND
BACK
UP
B.
REM
ACC
B.REM
3
9
10
11
4
13
14
12
SWVDD
SOURCE
DSENS
ILM+B
ROT1
ROT0
DPDT
KYDT
SRC
DSENS
ILL+B
ROT1
ROT0
DPDT
KYDT
SRC 33
34
ILMPW 2
ROT1 111
ROT0 110
DPDT/SELF 23
KEYDT/SELF 24
CN351
RLIn
12
DSENS
Q822
ASENS
6
Front_L FLIn
14
XOUT
XIN
82
X601
74.1MHz
81
Q351
MUTE
20
6
25
NC/BREM
ASENS
2
RL
TEL
26
TELIN VDD
Q851
6
8
IC 1801
PD6340A
LCD DRIVER/
KEY CONTROLLER
KEY DATA
LCD1801
3
CN1801
KEYBOARD UNIT
10
11
18
20
DPDT
KYDT
B
13
12
D1803-D1810
D1812-D1821
D1823-D1825
SWVDD
SWVDD
4
X0
X1
22
X1801
5MHz
23
KEY MATRIX
FUNC
S1817
S1821 S1818
LEFT
S1815
S1820
S1819
S1807
4
S1809
S1808
UP
S1811
S1816
RIGHT
S1813
DOWN
S1810
S1814
S1822
S1812
S1802 S1803 S1805
10
56 VLCD
VDD
9
14
17
1
3IC1802
GP1UX51RK
REM.CON.
REM
S1801
S1804
DISP
S1806
3
AUDIO
S1823
VOLUME
PUSH:SOURCE
S1827
1
2
4
CDRESET
8
B.UP
BSENS
SYSPW
POWEROFF
36
47
15
SWVDD
1
16
EJECT TA LOUD
21
65EQ
BAND
SL-
62
SL-IN
IF_INA
77
IFA
IF_INB
78
IFB
FREF_A
96
REFA
FREF_B
97
REFB
LOCK
99
LDET
DI
100
DI
CK
101
CK
CE
102
CE1
DO
103
DO
CE2
109
CE2
SL
136
SLOUT
KEYAD
KEYD
CN871
2
3
KEYAD
142
130
KEYD WIRED
REMOTE
L_OUT
59
VDCONT
126
CDL
B.UP
IC 601(2/2)
PN5009A
SYSTEM MICRO
COMPUTER
4STBY
SYSPW
B.UP
CN1802
AUX G
6
AUX L
2
SWD5V
AUX G
1
AUX L
7
AUX-G 6
AUX-L 7
AUX-L
4
AUX-G
5
IN4+_L
IN4-_L
ILMPW
DREG
85
SWVDD
PLL_VDD
DVDD3
REGC(M)
55
9
57
DVDD2
94
DVDD4
121
MUTE
TEL IN
AUX IN

DEH-3900MP/XN/EW5
16
1234
1234
C
D
F
A
B
E
3.2 OVERALL CONNECTION DIAGRAM(GUIDE PAGE)
A-a
A
A-a
A-a
A-b
A-b
A-a
A-a
A-b
A-b
A-b
A-b
A-a
A-a
Large size
SCH diagram
Guide page
Detailed page
Note: When ordering service parts, be sure to refer to " EXPLODED VIEWS AND PARTS LIST" or
"ELECTRICAL PARTS LIST".
R022
SYSPW
SL
KEYAD
KEYD
FLMD1
VDCONT
VCK
VDT
VST
SELFOUT
ROMCS
ROMCK
ROMDATA
ROT1
CE2
ROT0
MODELAD
NC TELIN
Decimal points for resistor
and capacitor fixed values
are expressed as :
2.2 t2R2
0.022 tR022
The >mark found on some component parts indicates
the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of
identical designation.
Symbol indicates a resistor.
No differentiation is made between chip resistors and
discrete resistors.
NOTE :
Symbol indicates a capacitor.
No differentiation is made between chip capacitors and
discrete capacitors.
CCN701
B
CN1801
FM/AM TUNER UNIT
SYSTEM MICRO COMPUTER

DEH-3900MP/XN/EW5 17
5678
5678
C
D
F
A
B
E
A-b
A
A-a A-b
A-a A-b
A-b
A-a
1000/6R3
22K
R022
RR
+
RR
-
FR
+
FR
-
FL
+
FL
-
RL
+
RL
-
ACC
GND
BACK
UP
B.
REM
ATUNER AMP UNIT
>
>
RCA

DEH-3900MP/XN/EW5
18
1234
1234
C
D
F
A
B
E
A-a A-b
A-b 12345
ATUNER AMP UNIT
>
RCA

DEH-3900MP/XN/EW5 19
5678
5678
C
D
F
A
B
E
A-a A-b
A-b
5
67
1000/6R3
22K
RR
+
RR
-
FR
+
FR
-
FL
+
FL
-
RL
+
RL
-
ACC
GND
BACK
UP
B.
REM
>

DEH-3900MP/XN/EW5
20
1234
1234
C
D
F
A
B
E
A-bA-a
A-a
A-b 12345
R022
FLMD1
VDCONT VCK VDT VST
SELFOUT ROMCS ROMCK ROMDATA ROT1
CE2 ROT0
CCN701
FM/AM TUNER UNIT
