Pioneer deh-p3590mp User manual

Operation Manual
Manual de instrucciones
Multi-CD control High power CD/MP3 player with RDS
tuner
Reproductor de CD/MP3 de alta potencia con sintoni-
zador de RDS y control de CD múltiple
DEH-P3590MP
English Español

Thank you for buying this Pioneer product.
Please read through these operating instructions so you will know how to operate
your model properly. After you have finished reading the instructions, put them away
in a safe place for future reference.
Before You Start
About this unit 4
About this manual 4
Precautions 4
In case of trouble 4
Features 4
Protecting your unit from theft 5
Removing the front panel 5
Attaching the front panel 5
Whats What
Head unit 6
Power ON/OFF
Turning the unit on 7
Selecting a source 7
Turning the unit off 7
Tuner
istening to the radio 8
Introduction of advanced tuner operation 9
Storing and recalling broadcast
frequencies 9
Tuning in strong signals 9
Storing the strongest broadcast
frequencies 10
RDS
Introduction of RDS operation 11
Switching the RDS display 11
Receiving PTY alarm broadcasts 11
Selecting alternative frequencies 1
Using PI Seek 1
Using Auto PI Seek for preset
stations 1
imiting stations to regional
programming 1
Receiving traffic announcements 13
Responding to the TP alarm 13
Using news program interruption 14
PTY list 14
Built-in CD Player
Playing a CD 15
Introduction of advanced built-in CD player
operation 16
Repeating play 16
Playing tracks in a random order 16
Scanning tracks of a CD 16
Pausing CD playback 17
Selecting the search method 17
Searching every 10 track in the current
disc 17
Using disc title functions 18
Entering disc titles 18
Displaying disc titles 18
Using CD TEXT functions 19
Displaying titles on CD TEXT
discs 19
Scrolling titles in the display 19
MP3 Player
Playing a MP3 0
Introduction of advanced built-in CD player
(MP3) operation 1
Repeating play 1
Playing tracks in a random order
Scanning folders and tracks
Pausing MP3 playback 3
Selecting the search method 3
Searching every 10 track in the current
folder 3
Switching the ID3 tag display on MP3
disc 3
Displaying text information on MP3 disc 4
Scrolling text information in the display 4
Contents
En

Multi-CD Player
Playing a CD 5
50-disc multi-CD player 5
Introduction of advanced multi-CD player
operation 6
Repeating play 6
Playing tracks in a random order 6
Scanning CDs and tracks 7
Pausing CD playback 7
Using ITS playlists 7
Creating a playlist with ITS
programming 7
Playback from your ITS playlist 8
Erasing a track from your ITS
playlist 8
Erasing a CD from your ITS
playlist 9
Using disc title functions 9
Entering disc titles 9
Displaying disc titles 30
Using CD TEXT functions 30
Displaying titles on CD TEXT
discs 30
Scrolling titles in the display 30
Using compression and bass emphasis 30
Audio Adjustments
Introduction of audio adjustments 31
Using balance adjustment 31
Using the equalizer 31
Recalling equalizer curves 3
Adjusting equalizer curves 3
Fine adjusting equalizer curve 3
Adjusting loudness 33
Front image enhancer (F.I.E.) 33
Adjusting source levels 34
Initial Settings
Adjusting initial settings 35
Setting the FM tuning step 35
Switching Auto PI Seek 35
Switching the warning tone 35
Switching the auxiliary setting 36
Other Functions
Using the AUX source 37
Selecting AUX as the source 37
Setting the AUX title 37
Additional Information
Understanding built-in CD player error
messages 38
Cellular telephone muting 38
CD player and care 38
CD-R/CD-RW discs 39
MP3 files 39
About folders and MP3 files 40
Terms 41
Specifications 4
En 3
English
Contents

About this unit
The tuner frequencies on this unit are allo-
cated for use in Western Europe, Asia, the
Middle East, Africa and Oceania. Use in other
areas may result in improper reception. The
RDS function operates only in areas with FM
stations broadcasting RDS signals.
About this manual
This unit features a number of sophisticated
functions ensuring superior reception and op-
eration. All the functions have been designed
for the easiest possible use, but many are not
self-explanatory. This operation manual will
help you benefit fully from this units potential
and to maximize your listening enjoyment.
We recommend that you familiarize yourself
with the functions and their operation by read-
ing through the manual before you begin
using this unit. It is especially important that
you read and observe precautions on this
page and in other sections.
Precautions
!ACLASS 1 LASER PRODUCT label is af-
fixed to the bottom of this unit.
CLASS 1
LASER PRODUCT
!The Pioneer CarStereo-Pass is for use only
in Germany.
!Keep this manual handy as a reference for
operating procedures and precautions.
!Always keep the volume low enough so you
can hear sounds outside of the car.
!Protect this unit from moisture.
!If the battery is disconnected or dis-
charged, the preset memory will be erased
and must be reprogrammed.
In case of trouble
Should this product fail to operate properly,
contact your dealer or nearest authorized Pio-
neer Service Station.
Features
CD playback
Music CD/CD-R/CD-RW playback is possible.
MP3 file playback
You can play back MP3 files recorded on CD-
ROM/CD-R/CD-RW (ISO9660 evel 1/ evel 2
standard recordings).
!Supply of this product only conveys a li-
cense for private, non-commercial use and
does not convey a license nor imply any
right to use this product in any commercial
(i.e. revenue-generating) real time broad-
casting (terrestrial, satellite, cable and/or
any other media), broadcasting/streaming
via internet, intranets and/or other net-
works or in other electronic content distri-
bution systems, such as pay-audio or
audio-on-demand applications. An inde-
pendent license for such use is required.
For details, please visit
http://www.mp3licensing.com.
Before You Start
En
4
Section
01

Protecting your unit from
theft
The front panel can be detached from the
head unit and stored in the protective case
provided to discourage theft.
!If the front panel is not detached from the
head unit within five seconds of turning off
the ignition, a warning tone will sound.
!You can turn off the warning tone. See
Switching the warning tone on page 35.
Important
!Never use force or grip the display and the
buttons tightly when removing or attaching.
!Avoid subjecting the front panel to excessive
shocks.
!Keep the front panel out of direct sunlight and
high temperatures.
Remo ing the front panel
1 Press OPEN to open the front panel.
2 Grip the left side of the front panel and
pull it gentl outward.
Take care not to grip it tightly or to drop it.
3 Put the front panel into the protective
case provided for safe keeping.
Attaching the front panel
%Replace the front panel b holding it
upright to this unit and clipping it securel
into the mounting hooks.
Before You Start
En 5
English
Section
01

Head unit
1TA button
Press to turn traffic announcements func-
tion on or off.
Press and hold to turn NEWS function on or
off.
2DISPLAY button
Press to select different displays.
3PAUSE button
Press to turn pause on or off.
4AUDIO button
Press to select various sound quality con-
trols.
5OPEN button
Press to open the front panel.
6a/b/c/dbuttons
Press to do manual seek tuning, fast for-
ward, reverse and track search controls.
Also used for controlling functions.
7FUNCTION button
Press to select functions.
8BAND button
Press to select among three FM and MW/
W bands and cancel the control mode of
functions.
9LOUDNESS button
Press to turn loudness on or off.
a16 buttons
Press for preset tuning and disc number
search when using a multi-CD player.
bSOURCE button
This unit is turned on by selecting a source.
Press to cycle through all of the available
sources.
cVOLUME
Press to increase or decrease the volume.
dEQ button
Press to select various equalizer curves.
123
45
6
7
8
9a
bc
d
Whats What
En
6
Section
0

Turning the unit on
%Press SOURCE to turn the unit on.
When you select a source the unit is turned
on.
Selecting a source
You can select a source you want to listen to.
To switch to the built-in CD player, load a disc
in this unit (refer to page 15).
%Press SOURCE to select a source.
Press SOURCE repeatedly to switch between
the following sources:
Built-in CD playerTelevisionTuner
Multi-CD playerExternal unit 1Exter-
nal unit AUX
Notes
!In the following cases, the sound source will
not change:
When a unit corresponding to each source
is not connected to this unit.
When no disc is set in this unit.
When no magazine is set in the multi-CD
player.
When the AUX (auxiliary input) is set to off
(refer to page 36).
!External unit refers to a Pioneer product (such
as one available in the future) that, although
incompatible as a source, enables control of
basic functions by this unit. Two external units
can be controlled by this unit. When two exter-
nal units are connected, the allocation of
them to external unit 1 or external unit 2 is
automatically set by this unit.
!When this units blue/white lead is connected
to the cars auto-antenna relay control term-
inal, the cars antenna extends when this
units source is turned on. To retract the an-
tenna, turn the source off.
Turning the unit off
%Press SOURCE and hold until the unit
turns off.
Power ON/OFF
En 7
English
Section
03

Listening to the radio
124
3
These are the basic steps necessary to operate
the radio. More advanced tuner operation is
explained starting on the next page.
This units AF (alternative frequencies search)
function can be turned on and off. AF should
be off for normal tuning operation (refer to
page 12).
1Band indicator
Shows which band the radio is tuned to,
MW, W or FM.
2Frequenc indicator
Shows to which frequency the tuner is
tuned.
3Stereo (5) indicator
Shows that the frequency selected is being
broadcast in stereo.
4Preset number indicator
Shows what preset has been selected.
1 Press SOURCE to select the tuner.
Press SOURCE until tuner is selected as the
source.
2 Use VOLUME to adjust the sound level.
Press to increase or decrease the volume.
3 Press BAND to select a band.
Press BAND until the desired band is dis-
played, F1,F2,F3 for FM or MW/LW.
4 To perform manual tuning, press cor
dwith quick presses.
The frequencies move up or down step by
step.
5 To perform seek tuning, press and hold
cor dfor about one second and release.
The tuner will scan the frequencies until a
broadcast strong enough for good reception is
found.
#You can cancel seek tuning by pressing either
cor dwith a quick press.
#If you press and hold cor dyou can skip
broadcasting stations. Seek tuning starts as soon
as you release the buttons.
Note
When the frequency selected is being broadcast
in stereo the stereo (5) indicator will light.
Tuner
En
8
Section
04

Introduction of ad anced
tuner operation
123
1LOC indicator
Shows when local seek tuning is on.
2Function displa
Shows the function status.
3Preset number indicator
Shows what preset has been selected.
%Press FUNCTION to displa the function
names.
Press FUNCTION repeatedly to switch be-
tween the following functions:
BSM (best stations memory)REG (regional)
LOCAL (local seek tuning)TA (traffic an-
nouncement standby)AF (alternative fre-
quencies search)NEWS (news program
interruption)
#To return to the frequency display, press
BAND.
#If MW/ W band is selected, you can only se-
lect BSM or LOCAL.
Note
If you do not operate the function within about 30
seconds, the display is automatically returned to
the frequency display.
Storing and recalling
broadcast frequencies
If you press any of the preset tuning buttons
16you can easily store up to six broadcast
frequencies for later recall with the touch of a
button.
%When ou find a frequenc that ou
want to store in memor press a preset
tuning button 16 and hold until the preset
number stops flashing.
The number you have pressed will flash in the
preset number indicator and then remain lit.
The selected radio station frequency has been
stored in memory.
The next time you press the same preset tun-
ing button 16the radio station frequency is
recalled from memory.
Notes
!Up to 18 FM stations, 6 for each of the three
FM bands, and 6 MW/ W stations can be
stored in memory.
!You can also use aand bto recall radio sta-
tion frequencies assigned to preset tuning
buttons 16.
Tuning in strong signals
ocal seek tuning lets you tune in only those
radio stations with sufficiently strong signals
for good reception.
1 Press FUNCTION to select LOCAL.
Press FUNCTION until LOCAL appears in the
display.
2 Press ato turn local seek tuning on.
ocal seek sensitivity (e.g., LOCAL 2) appears
in the display.
Tuner
En 9
English
Section
04

3 Press cor dto set the sensitivit .
There are four levels of sensitivity for FM and
two levels for MW/ W:
FM: LOCAL 1LOCAL 2LOCAL 3
LOCAL 4
MW/ W: LOCAL 1LOCAL 2
The LOCAL 4 setting allows reception of only
the strongest stations, while lower settings let
you receive progressively weaker stations.
4 When ou want to return to normal
seek tuning, press bto turn local seek tun-
ing off.
LOCAL:OFF appears in the display.
Storing the strongest
broadcast frequencies
BSM (best stations memory) lets you automa-
tically store the six strongest broadcast fre-
quencies under preset tuning buttons 16and
once stored there you can tune in to those fre-
quencies with the touch of a button.
1 Press FUNCTION to select BSM.
Press FUNCTION until BSM appears in the
display.
2 Press ato turn BSM on.
BSM begins to flash. While BSM is flashing
the six strongest broadcast frequencies will be
stored under preset tuning buttons 16in
order of their signal strength. When finished,
BSM stops flashing.
#To cancel the storage process, press b.
Note
Storing broadcast frequencies with BSM may re-
place broadcast frequencies you have saved
using 16.
Tuner
En
10
Section
04

Introduction of RDS operation
12 3
RDS (radio data system) is a system for provid-
ing information along with FM broadcasts.
This inaudible information provides such fea-
tures as program service name, program type,
traffic announcement standby and automatic
tuning, intended to aid radio listeners in find-
ing and tuning in to a desired station.
1Program service name
Shows the type of broadcast program.
2TP ( ) indicator
Shows when a TP station is tuned in.
3News ( ) indicator
Shows when the set news program is re-
ceived.
%Press FUNCTION to displa the function
names.
Press FUNCTION repeatedly to switch be-
tween the following functions:
BSM (best stations memory)REG (regional)
LOCAL (local seek tuning)TA (traffic an-
nouncement standby)AF (alternative fre-
quencies search)NEWS (news program
interruption)
#To return to the frequency display, press
BAND.
#If MW/ W band is selected, you can only se-
lect BSM or LOCAL.
Notes
!If you do not operate the function within about
30 seconds, the display is automatically re-
turned to the frequency display.
!RDS service may not be provided by all sta-
tions.
!RDS functions like AF and TA are only active
when your radio is tuned to an RDS station.
Switching the RDS display
When you tune in an RDS station its program
service name is displayed. If you want to know
the frequency you can.
%Press DISPLAY.
Press DISPLAY repeatedly to switch between
the following settings:
Program service namePTY information
Frequency
PTY (program type ID code) information is
listed on page 14.
#PTY information and the frequency of the cur-
rent station appears on the display for eight sec-
onds.
#If a PTY code of zero is received from a station,
NONE is displayed. This indicates that the station
has not defined its program contents.
#If the signal is too weak for this unit to pick up
the PTY code, NO PTY is displayed.
Recei ing PTY alarm
broadcasts
PTY alarm is a special PTY code for announce-
ments regarding emergencies such as natural
disasters. When the tuner receives the radio
alarm code, ALARM appears on the display
and the volume adjusts to the TA volume.
When the station stops broadcasting the
emergency announcement, the system re-
turns to the previous source.
!An emergency announcement can be can-
celled by pressing TA.
RDS
En 11
English
Section
05

!You can also cancel an emergency an-
nouncement by pressing SOURCE,BAND,
a,b,cor d.
Selecting alternati e
frequencies
If you are listening to a broadcast and the re-
ception becomes weak or there are other pro-
blems, the unit will automatically search for a
different station in the same network which is
broadcasting a stronger signal.
!AF is on as a default.
1 Press FUNCTION to select AF.
Press FUNCTION until AF appears in the dis-
play.
2 Press ato turn AF on.
Press aand AF :ON is displayed.
3 Press bto turn AF off.
Press band AF :OFF is displayed.
Notes
!Only RDS stations are tuned in during seek
tuning or BSM when AF is on.
!When you recall a preset station, the tuner
may update the preset station with a new fre-
quency from the stations AF list. (This is only
available when using presets on the F1 or F2
bands.) No preset number appears on the dis-
play if the RDS data for the station received
differs from that for the originally stored sta-
tion.
!Sound may be temporarily interrupted by an-
other program during a AF frequency search.
!AF can be turned on or off independently for
each FM band.
Using PI Seek
If the unit fails to find a suitable alternative fre-
quency, or if you are listening to a broadcast
and the reception becomes weak, the unit will
automatically search for a different station
with the same programming. During the
search, PI SEEK is displayed and the output is
muted. The muting is discontinued after com-
pletion of the PI Seek, whether or not a differ-
ent station is found.
Using Auto PI Seek for preset
stations
When preset stations cannot be recalled, as
when travelling long distances, the unit can
be set to perform PI Seek during preset recall.
!The default setting for Auto PI Seek is off.
See Switching Auto PI Seek on page 35.
Limiting stations to regional
programming
When AF is used to automatically retune fre-
quencies, the regional function limits the se-
lection to stations broadcasting regional
programs.
1 Press FUNCTION to select REG.
Press FUNCTION until REG appears in the dis-
play.
2 Press ato turn the regional function
on.
Press aand REG :ON is displayed.
3 Press bto turn the regional function
off.
Press band REG :OFF is displayed.
RDS
En
1
Section
05

Notes
!Regional programming and regional networks
are organized differently depending on the
country (i.e., they may change according to
the hour, state or broadcast area).
!The preset number may disappear on the dis-
play if the tuner tunes in a regional station
which differs from the originally set station.
!The regional function can be turned on or off
independently for each FM band.
Recei ing traffic
announcements
TA (traffic announcement standby) lets you re-
ceive traffic announcements automatically, no
matter what source you are listening to. TA
can be activated for both a TP station (a sta-
tion that broadcasts traffic information) or an
enhanced other networks TP station (a station
carrying information which cross-references
TP stations).
1 Tune in a TP or enhanced other net-
works TP station.
When you are tuned into a TP or enhanced
other networks TP station the TP ( ) indica-
tor will light.
2 Press TA to turn traffic announcement
standb on.
Press TA and TA ON appears in the display.
The tuner will standby for traffic announce-
ments.
#To turn traffic announcements standby off,
press TA again.
3 Use VOLUME to adjust the TA volume
when a traffic announcement begins.
Press to increase or decrease the volume.
The newly set volume is stored in memory and
recalled for subsequent traffic announce-
ments.
4 Press TA while a traffic announcement
is being received to cancel the announce-
ment.
The tuner returns to the original source but re-
mains in the standby mode until TA is pressed
again.
#You can also cancel the announcement by
pressing SOURCE,BAND,a,b,cor dwhile a
traffic announcement is being received.
Notes
!You can also turn on or off TA function in the
menu that appears with the pressing of
FUNCTION.
!The system switches back to the original
source following traffic announcement recep-
tion.
!Only TP and enhanced other networks TP sta-
tions are tuned in during seek tuning or BSM
when TA is on.
Responding to the TP alarm
When a TP or enhanced other networksTP
station is lost due to a weak signal the TP ( )
indicator is extinguished and a series of short
beeps, about five seconds long, sound to re-
mind you to select another TP or enhanced
other networks TP station.
%When listening to the tuner, tune in an-
other TP or enhanced other networksTP
station.
RDS
En 13
English
Section
05

Using news program
interruption
When a news program is broadcast from a
PTY code news station the unit can switch
from any station to the news broadcast sta-
tion. When the news program ends, reception
of the previous program resumes.
%Press TA and hold to turn on news pro-
gram interruption.
Press TA until NEWS ON appears in the dis-
play.
#To turn off news program interruption, press
TA and hold until NEWS OFF appears in the dis-
play.
#A news program can be cancelled by pressing
TA.
#You can also cancel the news program by
pressing SOURCE,BAND,a,b,cor dwhile a
news program is being received.
Note
You can also turn on or off news program in the
menu that appears with the pressing of
FUNCTION.
PTY list
Specific Type of program
NEWS News
AFFAIRS Current affairs
INFO General information and advice
SPORT Sports
WEATHER Weather reports/meteorological infor-
mation
FINANCE Stock market reports, commerce,
trading, etc.
POP MUS Popular music
ROCK MUS Contemporary modern music
Specific Type of program
EASY MUS Easy listening music
OTH MUS Non categorized music
JAZZ Jazz
COUNTRY Country music
NAT MUS National music
OLDIES Oldies music, golden oldies
FOLK MUS Folk music
L. CLASS ight classical music
CLASSIC Serious classical music
EDUCATE Educational programs
DRAMA All radio plays and serials
CULTURE National or regional culture
SCIENCE Nature, science and technology
VARIED ight entertainment
CHILDREN Childrens
SOCIAL Social affairs
RELIGION Religion affairs or services
PHONE IN Phone In
TOURING Travel programs, not for announce-
ments about traffic problems
LEISURE Hobbies and recreational activities
DOCUMENT Documentaries
RDS
En
14
Section
05

Playing a CD
1 32
These are the basic steps necessary to play a
CD with your built-in CD player. More ad-
vanced CD operation is explained starting on
the next page.
1Pla time indicator
Shows the elapsed playing time of the cur-
rent track.
2TXT indicator
Shows when a CD TEXT is inserted.
3Track number indicator
Shows the track currently playing.
1 Press OPEN to open the front panel.
CD loading slot appears.
#After a CD has been inserted, press SOURCE
to select the built-in CD player.
2 Insert a CD into the CD loading slot.
Playback will automatically start.
CD loading slot
EJECT button
#You can eject a CD by pressing EJECT.
#To avoid a malfunction, make sure that no
metal object comes into contact with the term-
inals when the front panel is open.
3 Close the front panel.
4 Use VOLUME to adjust the sound level.
Press to increase or decrease the volume.
5 To perform fast forward or reverse,
press and hold cor d.
#If you select the search method to ROUGH,
pressing and holding cor denables you to
search every ten track in the current disc. (Refer
to Selecting the search method on page 17.)
6 To skip back or forward to another
track, press cor d.
Pressing dskips to the start of the next track.
Pressing conce skips to the start of the cur-
rent track. Pressing again will skip to the pre-
vious track.
Notes
!The built-in CD player plays one, standard, 12-
cm or 8-cm (single) CD at a time. Do not use
an adapter when playing 8-cm CDs.
!Do not insert anything other than a CD into
the CD loading slot.
!If you cannot insert a disc completely or if
after you insert a disc the disc does not play,
check that the label side of the disc is up.
Press EJECT to eject the disc, and check the
disc for damage before inserting the disc
again.
!If the built-in CD player does not operate prop-
erly, an error message such as ERROR-11
may be displayed. Refer to Understanding
built-in C player error messages on page
38.
Built-in CD Player
En 15
English
Section
06

Introduction of ad anced
built-in CD player operation
2
1
1RPT indicator
Shows when repeat play is turned on.
2Function displa
Shows the function status.
%Press FUNCTION to displa the function
names.
Press FUNCTION repeatedly to switch be-
tween the following functions:
RPT (repeat play)RDM (random play)
SCAN (scan play)PAUSE (pause)
FF/REV (search method)TAG (ID3 tag dis-
play)
#To return to the playback display, press BAND.
Notes
!When playing audio data (CD-DA), it is not ef-
fective even if you turn TAG (ID3 tag display)
on. (Refer to page 23.)
!If you do not operate the function within about
30 seconds, the display is automatically re-
turned to the playback display.
Repeating play
Repeat play lets you hear the same track over
again.
1 Press FUNCTION to select RPT.
Press FUNCTION until RPT appears in the dis-
play.
2 Press ato turn repeat pla on.
RPT:ON appears in the display. The track cur-
rently playing will play and then repeat.
3 Press bto turn repeat pla off.
RPT:OFF appears in the display. The track cur-
rently playing will continue to play and then
play the next track.
Note
If you perform track search or fast forward/re-
verse, repeat play is automatically cancelled.
Playing tracks in a random
order
Random play lets you play back tracks on the
CD in a random order.
1 Press FUNCTION to select RDM.
Press FUNCTION until RDM appears in the
display.
2 Press ato turn random pla on.
RDM :ON appears in the display. Tracks will
play in a random order.
3 Press bto turn random pla off.
RDM :OFF appears in the display. Tracks will
continue to play in order.
Scanning tracks of a CD
Scan play lets you hear the first 10 seconds of
each track on the CD.
1 Press FUNCTION to select SCAN.
Press FUNCTION until SCAN appears in the
display.
Built-in CD Player
En
16
Section
06

2 Press ato turn scan pla on.
SCAN:ON appears in the display. The first 10
seconds of each track is played.
3 When ou find the desired track press
bto turn scan pla off.
SCAN:OFF appears in the display. The track
will continue to play.
#If the display has automatically returned to
the playback display, select SCAN again by press-
ing FUNCTION.
Note
After scanning of a CD is finished, normal play-
back of the tracks will begin again.
Pausing CD playback
Pause lets you temporarily stop playback of
the CD.
1 Press FUNCTION to select PAUSE.
Press FUNCTION until PAUSE appears in the
display.
2 Press ato turn pause on.
PAUSE:ON appears in the display. Play of the
current track pauses.
3 Press bto turn pause off.
PAUSE:OFF appears in the display. Play will re-
sume at the same point that you turned pause
on.
Note
You can also turn pause on or off by pressing
PAUSE.
Selecting the search method
You can switch the search method between
fast forward/reverse and searching every 10
track.
1 Press FUNCTION to select FF/REV.
Press FUNCTION until FF/REV appears in the
display.
#If the search method ROUGH has been pre-
viously selected, ROUGH will be displayed.
2 Press cor dto select the search meth-
od.
Press cor duntil the desired search method
appears in the display.
!FF/REV Fast forward and reverse
!ROUGH Searching every 10 track
Searching e ery 10 track in
the current disc
If a disc contains over 10 tracks, you can
search every 10 track. When a disc contains a
lot of tracks, you can roughly search the track
you want to play.
1 Select the search method ROUGH.
Refer to Selecting the search method on this
page.
2 Press and hold cor dto search ever
10 track in a disc.
#If a disc contains less than 10 tracks, pressing
and holding drecalls the last track of a disc.
Also, if the remaining number of tracks after
searching every 10 tracks are less than 10, press-
ing and holding drecalls the last track of a disc.
Built-in CD Player
En 17
English
Section
06

#If a disc contains less than 10 tracks, pressing
and holding crecalls the first track of a disc.
Also, if the remaining number of tracks after
searching every 10 tracks are less than 10, press-
ing and holding crecalls the first track of a
disc.
Using disc title functions
You can input CD titles and display the title.
The next time you insert a CD for which you
have entered a title, the title of that CD will be
displayed.
Entering disc titles
Disc title input lets you input CD titles up to 8
letters long and up to 48 disc titles into this
unit.
1 Pla a CD that ou want to enter the
title.
2 Press FUNCTION and hold until TITLE IN
appears in the displa .
#When playing a CD TEXT disc, you cannot
switch to TITLE IN. The disc title will have already
been recorded on a CD TEXT disc.
3 Press aor bto select a letter of the al-
phabet.
Each press of awill display a letter of the al-
phabet in A B C ... X Y Z, numbers and sym-
bols in 1 2 3 ... > [ ] order. Each press of bwill
display a letter in the reverse order, such as Z
Y X ... C B A order.
4 Press dto move the cursor to the next
character position.
When the letter you want is displayed, press d
to move the cursor to the next position and
then select the next letter. Press cto move
backwards in the display.
5 Move the cursor to the last position b
pressing dafter entering the title.
When you press done more time, the entered
title is stored in memory.
6 Press BAND to return to the pla back
displa .
Notes
!Titles remain in memory, even after the disc
has been removed from this unit, and are re-
called when the disc is reinserted.
!After data for 48 discs has been stored in
memory, data for a new disc will overwrite the
oldest one.
!If you connect a multi-CD player, you can
input disc titles for up to 100 discs.
Displaying disc titles
You can display the title of any disc that has
had a disc title entered.
%Press DISPLAY.
Press DISPLAY repeatedly to switch between
the following settings:
Play timeDISC TTL (disc title)
When you select DISC TTL, the title of the cur-
rently playing disc is shown in the display.
#If no title has been entered for the currently
playing disc, NO TITLE is displayed.
Built-in CD Player
En
18
Section
06

Using CD TEXT functions
Some discs have certain information encoded
on the disc during manufacture. These discs
may contain such information as the CD title,
track title, artists name and playback time
and are called CD TEXT discs. Only these spe-
cially encoded CD TEXT discs support the
functions listed below.
Displaying titles on CD TEXT discs
%Press DISPLAY.
Press DISPLAY repeatedly to switch between
the following settings:
Play timeDISC TTL (disc title)ART NAME
(disc artist name)TRK TTL (track title)
ART NAME (track artist name)
#If specific information has not been recorded
on a CD TEXT disc, NO XXXX will be displayed
(e.g., NO T-TTL).
Scrolling titles in the display
This unit can display the first 8 letters only of
DISC TTL,ART NAME,TRK TTL and
ART NAME. When the recorded information is
longer than 8 letters, you can scroll the text to
the left so that the rest of the title can be seen.
%Press DISPLAY and hold until the title
begins to scroll to the left.
The rest of the title will appear in the dis-
play.
Built-in CD Player
En 19
English
Section
06

Playing a MP3
1 32 4
These are the basic steps necessary to play an
MP3 with your built-in CD player. More ad-
vanced MP3 operation is explained starting on
the next page.
1Folder number indicator
Shows the folder number currently playing.
2MP3 indicator
Shows when the MP3 file is playing.
3Pla time indicator
Shows the elapsed playing time of the cur-
rent track (file).
4Track number indicator
Shows the track (file) currently playing.
!If a track number 100 to 199 is selected,
don the left of the track number indica-
tor will light.
!If a track number 200 or more is selected,
don the left of the track number indica-
tor will blink.
1 Press OPEN to open the front panel.
CD loading slot appears.
#After a CD-ROM has been inserted, press
SOURCE to select the built-in CD player.
2 Insert a CD-ROM into the CD loading
slot.
Playback will automatically start.
CD loading slot
EJECT button
#You can eject a CD-ROM by pressing EJECT.
#To avoid a malfunction, make sure that no
metal object comes into contact with the term-
inals when the front panel is open.
3 Close the front panel.
4 Use VOLUME to adjust the sound level.
Press to increase or decrease the volume.
5 Press aor bto select a folder.
#You cannot select a folder that does not have
an MP3 file recorded in it.
#To return to folder 01 (ROOT), press and hold
BAND. However, if folder 01 (ROOT) contains no
files, playback commences with folder 02.
6 To perform fast forward or reverse,
press and hold cor d.
#This is fast forward and reverse operation only
for the file being played. This operation is can-
celed when the previous or next file is reached.
#If you select the search method to ROUGH,
pressing and holding cor denables you to
search every ten track in the current folder. (Refer
to Selecting the search method on page 23.)
7 To skip back or forward to another
track, press cor d.
Pressing dskips to the start of the next track.
Pressing conce skips to the start of the cur-
rent track. Pressing again will skip to the pre-
vious track.
MP3 Player
En
0
Section
07
