Pioneer DEH-P7100R User manual

Multi-CD/DAB control High power CD player with
RDS tuner
Manual
DEH-P7100R
DEH-P6100R


&RQWHQWV
Installation .............................................4
Installation with the Rubber Bush ...................... 4
Removing the Unit .............................................. 5
Installing the Steering Remote
Control Unit ........................................6
Installing the Unit on a Left-Hand-Drive Car .... 7
Connecting the Units ............................8
Connection Diagram ...........................10
Key Finder ...........................................14
•HeadUnit
• Steering Remote Controller
Before Using This Product .................15
About This Product ........................................... 15
About This Manual ........................................... 15
About the Demo Mode ..................................... 15
• Reverse Demo
• Feature Demo
Precaution ......................................................... 16
In Case of Trouble ............................................ 16
When using the 50-Disc Type
Multi-CD Player ............................................ 16
Remote Controller and Care ..............17
Using the Steering Remote Controller .............. 17
• Battery
Basic Operation ..................................19
To Listen to Music ............................................ 19
Basic Operation of Tuner ................................. 21
• Manual and Seek Tuning
• Preset Tuning
•Band
Basic Operation of Built-in CD Player ............. 22
• Switching the Display
•Open
• Track Search and Fast Forward/Reverse
• Track Number Indicator
• Disc Loading Slot
• Eject
Basic Operation of Multi-CD Player ................ 24
• Disc Search
• Track Search and Fast Forward/Reverse
• Disc Number Search
(for 6-Disc, 12-Disc types)
Corresponding Display Indications
and Buttons..................................................... 25
Entering the Function Menu ............................. 26
Function Menu Functions ................................. 27
Entering the Detailed Setting Menu ................. 29
Detailed Setting Menu Functions ..................... 30
Tuner Operation .................................. 31
• Local Seek Tuning (LOCAL)
• Best Stations Memory (BSM)
Using RDS Functions ......................... 32
What is RDS? ................................................... 32
Program Service Name Display ....................... 32
AF Function (AF) ............................................. 33
• Activating/Deactivating the AF Function
PI Seek Function .............................................. 34
• PI Seek
• Auto PI Seek (for preset station)
Regional Function (REG) ................................ 34
• Activating/Deactivating the REG Function
TA Function (TA) ............................................ 35
• Activating/Deactivating the TA Function
• Canceling Traffic Announcements
• Adjusting the TA Volume
• TP Alarm Function
PTY Function ................................................... 37
• Searching the PTY
• News Program Interruption Setting (NEWS)
•PTYAlarm
• Canceling Announcements
• PTY List
Radio Text ........................................................ 40
• Radio Text Display
• Storing Radio Text in Memory
• Recalling Preset Radio Text
Using the Built-in CD Player .............. 42
• Repeat Play (RPT)
• Random Play (RDM)
• Scan Play (T.SCAN)
• Pause (PAUSE)
• Disc Title Input (TITLE IN)


Using Multi-CD Players .......................44
• Repeat Play (PMODE)
• Random Play (RDM)
• Scan Play (SCAN)
• Pause (PAUSE)
ITS (Instant Track Selection) ........................... 46
• ITS Programming (ITS)
• ITS Play (ITS-P)
• Erase a Track Program
• Erase a Disc Program
Disc Title .......................................................... 48
• Disc Title Input (TITLE)
• Selecting Discs by Disc Title List (T.LIST)
• Displaying Disc Title
Compression and DBE (COMP) ...................... 50
• COMP/DBE ON/OFF Switching
CD TEXT Function (for CD TEXT
compatible type) ............................................ 51
• Title Display Switching
• Title Scroll1
Audio Adjustment ...............................52
Selecting the Equalizer Curve .......................... 52
Entering the Audio Menu ................................. 52
Audio Menu Functions ..................................... 53
• Balance Adjustment (Fad)
• Equalizer Curve Adjustment
(EQ-LOW/MID/HIGH)
• Equalizer Curve Fine Adjustment
• Loudness Adjustment (Loud)
• Subwoofer Output (Sub.W1)
• Subwoofer Setting Adjustment (Sub.W2)
• Non Fading Output (NonFad)
• Non Fading Output Level
Adjustment (NonFad)
• High Pass Filter (HPF)
• Front Image Enhancer Function (FIE)
• Source Level Adjustment (SLA)
• Automatic Sound Levelizer (ASL) Function
(for DEH-P7100R)
Detaching and Replacing the
Front Panel .......................................61
Theft Protection ............................................... 61
• Detaching the Front Panel
• Replacing the Front Panel
• Warning Tone
Initial Setting .......................................62
Entering the Initial Setting Menu ..................... 62
Initial Setting Menu Functions ......................... 63
• Changing the FM Tuning Step (FM)
• Setting the DAB Priority Function (DAB)
• Switching the Auto PI Seek (A-PI)
• Setting the Warning Tone (WARN)
• Switching the AUX Mode (AUX)
• Setting the Dimmer (DIM)
• Selecting the Brightness (BRIGHT)
• Selecting the Illumination Color (ILL)
• Setting the Rear Speaker Lead and
Subwoofer Controller (SW)
• Switching the Muting or Handsfree
Telephoning (TEL 1)
• Switching the Telephone Standby (TEL 2)
• Switching the Motion Screen (DISP)
Other Functions ..................................68
Switching the Entertainment Display .............. 68
Using the AUX Source .................................... 68
• Selecting the AUX Source
• AUX Title Input (TITLE)
Using the Telephone Muting and Handsfree
Telephoning Function ................................... 69
• Telephone Muting Function
• Handsfree Telephoning Function
When using the DAB (Digital Audio
Broadcasting) Tuner ...................................... 70
• About This Product’s Indications
• Operation
CD Player and Care .............................72
Precaution ........................................................ 72
Built-in CD Player's Error Message ................. 73
Specifications ......................................74


1RWH
• Before finally installing the unit, connect the wiring temporarily, making sure it is all connected up
properly, and the unit and the system work properly.
• Use only the parts included with the unit to ensure proper installation. The use of unauthorized parts
can cause malfunctions.
• Consult with your nearest dealer if installation requires the drilling of holes or other modifications of
the vehicle.
• Install the unit where it does not get in the driver’s way and cannot injure the passenger if there is a
sudden stop, like an emergency stop.
• The semiconductor laser will be damaged if it overheats, so don’t install the unit anywhere hot — for
instance, near a heater outlet.
• If installation angle exceeds 60° from horizontal, the unit might not give its optimum performance.
Installation with the Rubber Bush
Holder
After inserting the holder into the dashboard, then select the
appropriate tabs according to the thickness of the dashboard
material and bend them. (Install as firmly possible using the
top and bottom tabs. To secure, bend the tabs 90 degrees.)
Screw
Rubber bush
Dashboard
,QVWDOODWLRQ


Removing the Unit
Pull out to remove the frame.
(When reattaching the frame, point the side
with a groove downwards and attach it.)
Frame
Insert the supplied extraction keys into the unit,
as shown in the figure, until they click into
place. Keeping the keys pressed against the
sides of the unit, pull the unit out.


,QVWDOOLQJWKH6WHHULQJ5HPRWH&RQWURO8QLW
 WARNING
• Avoid installing this unit in such a location where the operation of safety devices such as airbags is
prevented by this unit. Otherwise, there is a danger of a fatal accident.
• Avoid installing this unit in such a location where the operation of the steering wheel and the gearshift
lever may be prevented. Otherwise, it may result in a traffic accident.
 CAUTION
• Installation of this unit requires specialized skills and experience. Installation of this unit should be
entrusted to a dealer from whom you purchased this unit.
• Install this unit using only the parts supplied with this unit. If other parts are used, this unit may be
damaged or could dismount itself, which leads to an accident or trouble.
• Install this unit as required by this manual. Failure to do so may cause an accident.
• Do not install this unit near the doors where rainwater is likely to be spilled on the unit. Incursion of
water into the unit may cause smoke or fire.
 WARNING
• Fix this unit securely to the steering wheel with the belt attached to the unit. If this unit is loose, it
disturbs driving stability, which may result in a traffic accident.
• Do not attach this unit to the outer circumference of the steering wheel. Otherwise, it disturbs driving
stability, causing a traffic accident. Always attach this unit to the inner circumference of the steering
wheel as shown.
1RWH
• Do not install this unit in such a place as may obstruct the driver's view.
• Since interior layout differs depending on the type of vehicle, the ideal installation location for the
unit also differs. When installing the unit, select a location that assures optimum transmission of
signals from the unit to the car stereo.


Installing the Unit on a Left-Hand-Drive Car
1RWH
• When the unit is installed on a right-hand-drive car, the horizontal positions are inverted.
Inner holder
Belt
 6HFXUHLQQHUKROGHUWRWKHLQQHU
FLUFXPIHUHQFHRIWKHVWHHULQJZKHHO
ZLWKEHOW
•Fit the inner holder to the steering wheel
so that the arrow-marked side faces the
driver as shown below.
 &XWWKHH[WUDSRUWLRQRIWKHEHOWDW
WKHFHQWHURIWKHLQQHUKROGHU
•Keep the cut-off portion of the belt as a
spare.
Outer holder
Screw
 ,QVWDOORXWHUKROGHURQWKHLQQHU
KROGHUDQGVHFXUHZLWKVFUHZV
•Tighten the screws with the supplied
hexagonal wrench.
Release Section
 ,QVWDOOWKHUHPRWHFRQWUROXQLWLQWKH
KROGHU
•When removing the remote control unit
from the holder, move the corrugated
release section toward the steering
wheel and slide the remote control unit
toward you.


&RQQHFWLQJWKH8QLWV
1RWH
• This unit is for vehicles with a 12-volt battery and negative grounding. Before installing it in a
recreational vehicle, truck, or bus, check the battery voltage.
• To avoid shorts in the electrical system, be sure to disconnect the
 battery cable before beginning
installation.
• Refer to the owner's manual for details on connecting the power amp and other units, then make
connections correctly.
• Secure the wiring with cable clamps or adhesive tape. To protect the wiring, wrap adhesive tape
around them where they lie against metal parts.
• Route and secure all wiring so it cannot touch any moving parts, such as the gear shift, handbrake,
and seat rails. Do not route wiring in places that get hot, such as near the heater outlet. If the insulation
of the wiring melts or gets torn, there is a danger of the wiring short-circuiting to the vehicle body.
• Don't pass the yellow lead through a hole into the engine compartment to connect to the battery. This
will damage the lead insulation and cause a very dangerous short.
• Do not shorten any leads. If you do, the protection circuit may fail to work when it should.
• Never feed power to other equipment by cutting the insulation of the power supply lead of the unit
and tapping into the lead. The current capacity of the lead will be exceeded, causing overheating.
• When replacing fuse, be sure to use only fuse of the rating prescribed on the fuse holder.
• Since a unique BPTL circuit is employed, never wire so the speaker leads are directly grounded or
the left and right
 speaker leads are common.
• DEH-P7100R: If the RCA pin jack on the unit will not be used, do not remove the caps attached to
the end of the connector.
• Speakers connected to this unit must be high-power types with minimum rating of 45 W and
impedance of 4 to 8 ohms. Connecting speakers with output and/or impedance values other than those
noted here may result in the speakers catching fire, emitting smoke, or becoming damaged.
• When this product's source is switched ON, a control signal is output through the blue/white lead.
Connect to an external power amp's system remote control or the car's Auto-antenna relay control
terminal (max. 300 mA 12 V DC). If the car features a glass antenna, connect to the antenna booster
power supply terminal.


• When an external power amp is being used with this system, be sure not to connect the blue/white
lead to the amp's power terminal. Likewise, do “not” connect the blue/white lead to the power
terminal of the auto-antenna. Such connection could cause excessive current drain and malfunction.
• To avoid short-circuiting, cover the disconnected lead with insulating tape. Especially, insulate the
unused speaker leads without fail. There is a possibility of short-circuiting if the leads are not
insulated.
• To prevent incorrect connection, the input side of the IP-BUS connector is blue, and the output side
is black. Connect the connectors of the same colors correctly.
• If this unit is installed in a vehicle that does not have an ACC (accessory) position on the ignition
switch, the red lead of the unit should be connected to a terminal coupled with ignition switch ON/
OFF operations. If this is not done, the vehicle battery may be drained when you are away from the
vehicle for several hours.
• The black lead is ground. Please ground this lead separately from the ground of high-current products
such as power amps.
If you ground the products together and the ground becomes detached, there is a risk of damage to the
products or fire.
ACC position No ACC position
• Cords for this product and those for other products may be different colors even if they have
the same function. When connecting this product to another product, refer to the supplied
Installation manuals of both products and connect cords that have the same function.


&RQQHFWLRQ'LDJUDP'(+35
1RWH
Depending on the kind of vehicle, the function of
3* and 5* may be different. If this is the case, be
sure to connect 2* to 5* and 4* to 3*.
Multi-CD player
(sold separately)
Antenna jack
This product
Subwoofer output or
Non Fading Output
IP-Bus input (Blue)
Connect leads of the same
color to each other.
Cap (1*)
Whennotusingthis terminal,
do not remove the cap.
Yellow (3*)
Back-up
(or accessory)
Yellow (2*)
To terminal always supplied with
power regardless of ignition switch
position.
Red (5*)
Accessory
(or back-up)
Red (4*)
To electric terminal controlled by
ignition switch (12 V DC)
ON/OFF.
Orange
To lighting switch terminal.
Black (ground)
To vehicle (metal) body.
Fuse holder
ISO connector
1RWH
In some vehicles, the ISO connector may
be divided into two. In this case, be sure to
connect to both connectors.
Speaker leads
White : Front left

White/black : Front left

Gray : Front right

Gray/black : Front right

Green : Rear left

or Not used
Green/black : Rear left

or Not used
Violet : Rear right

or Subwoofer

Violet/black : Rear right

or Subwoofer

IP-BUS cable


Blue/white
Tosystemcontrolterminalof thepower amp
(max. 300 mA 12 V DC).
Yellow/black
If you use a cellular telephone, connect it via the Audio Mute lead on the cellular
telephone. If not, keep the Audio Mute lead free of any connections.
ASL unit
Refer to a Handsfree Telephone unit’s
manual (sold separately).
Connecting cords
with RCA pin plugs
(sold separately)
Front output
Blue/white (6*) Blue/white (7*)
To Auto-antenna relay control
terminal (max. 300 mA 12 V DC).
The pin position of the ISO connector will differ
depending on the type ofvehicle. Connect 6* and7*
when Pin 5 is an antenna control type. In another
type of vehicle, never connect 6* and 7*.
System remote control
Power amp
(sold separately)
1RWH
When a subwoofer is connected to this unit instead of a rear right speaker,
do not connect the rear left speaker lead to anything. For details, refer to
the Initial Setting Menu in the Operation Manual.
Subwoofer Subwoofer
Front speaker Front speaker
/HIW 5LJKW
Use this forconnections when
you have the separately
available amplifier.
Power amp
(sold separately)
This product conforms to new cord colors.


&RQQHFWLRQ'LDJUDP'(+35
1RWH
Depending on the kind of vehicle, the
function of 3* and 5* may be different. If
this is the case, be sure to connect 2* to 5*
and 4* to 3*.
Multi-CD player
(sold separately)
Antenna jack
This product
Subwoofer output or
Non Fading Output
IP-Bus input (Blue)
Connect leads of the same
color to each other.
Cap (1*)
Whennot usingthis terminal,
do not remove the cap.
Yellow (3*)
Back-up
(or accessory)
Yellow (2*)
To terminal always supplied with
power regardless of ignition switch
position.
Red (5*)
Accessory
(or back-up)
Red (4*)
To electric terminal controlled by
ignition switch (12 V DC)
ON/OFF.
Orange
To lighting switch terminal.
Black (ground)
To vehicle (metal) body.
Fuse holder
ISO connector
1RWH
In some vehicles, the ISO connector may
be divided into two. In this case, be sure to
connect to both connectors.
Speaker leads
White : Front left

White/black : Front left

Gray : Front right

Gray/black : Front right

Green : Rear left

or Not used
Green/black : Rear left

or Not used
Violet : Rear right

or Subwoofer

Violet/black : Rear right

or Subwoofer

IP-BUS cable


Blue/white
Tosystem control terminalof thepoweramp
(max. 300 mA 12 V DC).
Yellow/black
If you use a cellular telephone, connect it via the Audio Mute lead
on the cellular telephone. If not, keep the Audio Mute lead free of
any connections.
Connecting cords with RCA pin plugs
(sold separately)
Front output
Blue/white (6*) Blue/white (7*)
To Auto-antenna relay control terminal
(max. 300 mA 12 V DC).
The pin position of the ISO connector will differ
depending on the typeof vehicle. Connect 6* and7*
when Pin 5 is an antenna control type. In another
type of vehicle, never connect 6* and 7*.
System remote control
Power amp
(sold separately)
1RWH
When a subwoofer is connected to this unit instead of a rear right
speaker, do not connect the rear left speaker lead to anything. For
details, refer to the Initial Setting Menu in the Operation Manual.
Subwoofer Subwoofer
/HIW 5LJKW
Use this forconnections when
you have the separately
available amplifier.
This product conforms to new cord colors.


Head Unit
Steering Remote Controller
A steering remote controller that enables remote operation of the head unit is supplied.*
Operation is the same as when using buttons on the head unit.
* A steering remote controller (CD-SR77) is an option for DEH-P6100R.
SOURCE/OFF button
VOLUME
PTY button
 buttons
Buttons 1–6 AUDIO button
FUNCTION button
EQ selector
DISPLAY button
TA button
OPEN button
BAND button
TEXT button
ENTERTAINMENT button
SOURCE/OFF button
 buttons
AUDIO button
FUNCTION
button
BAND button
+/– button
Raise or
lower the
volume.
ATT button
This lets you quickly lower
volume level (by about 90%).
Press once more to return to the
original volume level.
 buttons
.H\)LQGHU


%HIRUH8VLQJ7KLV3URGXFW
About This Product
The tuner frequencies on this product are allocated for use in WesternEurope, Asia, the Middle
East, Africa and Oceania. Use in other areas may result in improper reception. The RDS
function operates only in areas with FM stations broadcasting RDS signals.
About This Manual
This product features a number of sophisticated functions ensuring superior reception and
operation. All are designed for the easiest possible use, but many are not self-explanatory. This
operation manual is intended to help you benefit fully from their potential and to maximize
your listening enjoyment.
We recommend that you familiarize yourself with the functions and their operation by reading
through the manual before you begin using this product. It is especially important that you read
and observe the “Precaution” ” on the next page and in other sections.
This manual explains head unit operation. You can perform the same operations with the
steering remote controller. The steering remote controller offers the convenience of ATT, a
function not provided on the head unit.
About the Demo Mode
This product features two demonstration modes. One is the Reverse Demo mode, the other is
the Feature Demo mode.
Reverse Demo
If you do not perform an operation within about 30 seconds, screen indications startto reverse,
and then continue reversing every 10 seconds. Pressing button 5 when power to this product is
switched OFF while the ignition switch is set to ACC or ON cancels the Reverse Demo mode.
Pressing button 5 again to start the Reverse Mode.
Feature Demo
The Feature Demo automatically starts when power to this product is switched OFF while the
ignition switch is set to ACC or ON. Pressing button 6 during Feature Demo operation cancels
the Feature Demo mode. Pressing button 6 again to start the Feature Mode. Remember that if
the Feature Demo continues operating when the car engine is switched OFF, it may drain
battery power.
1RWH
• You cannot cancel a Demo mode when the front panel is open.
• The red lead (ACC) of this product should be connected to a terminal coupled with ignition switch
ON/OFF operations. If this is not done, the vehicle battery may be drained.
• This product complies with the EMC Directives (89/336/EEC, 92/31/EEC) and CE Marking
Directive (93/68/EEC).


%HIRUH8VLQJ7KLV3URGXFW
Precaution
•A “CLASS 1 LASER PRODUCT” label is affixed to the bottom of the player.
•The Pioneer CarStereo-Pass is for use only in Germany.
•Keep this manual handy as a reference for operating procedures and precautions.
•Always keep the volume low enough for outside sounds to be audible.
•Protect the product from moisture.
•If the battery is disconnected, the preset memory will be erased and must be reprogrammed.
In Case of Trouble
Should this product fail to operate properly, contact your dealer or nearest authorized Pioneer
Service Station.
When using the 50-Disc Type Multi-CD Player
The available functions of the 50-Disc Type Multi-CD Player are described in this Operation
Manual. Note that other 50-Disc Type Multi-CD Player functions cannot be used with this
product.


5HPRWH&RQWUROOHUDQG&DUH
Using the Steering Remote Controller
3UHFDXWLRQ
• Do not operate this unit while manipulating the steering wheel as it might result in a traffic accident.
• If you have to operate this unit unavoidably when driving, look ahead carefully to avoid the risk of
being involved in a traffic accident.
• If any of the following troubles occur, immediately stop using this unit and consult with the dealer
from whom you purchased it:
– the unit is smoking.
– the unit is emitting abnormal odor.
– a foreign object has entered the unit.
– liquid has been spilled on or into the unit.
If you continue to use this unit without finding a remedy, the unit may be damaged badly, resulting
in a serious accident or fire.
• Do not leave this unit free (unattached) inside the car. When the car stops or turns a curve, the unit
might drop on the floor. If the unit rolls under the brake pedal, it might prevent the driver from braking
well, causing serious trouble. Be sure to fix this unit to the steering wheel.
• Do not disassemble or modify this unit. To do so may cause a fault.
Battery
Install the Lithium Battery
•5HPRYHWKHFRYHURQWKHEDFNRIWKHVWHHULQJUHPRWHFRQWUROOHUDQGLQVHUWWKHEDWWHU\
ZLWKWKHDQG±SROHVSRLQWLQJLQWKHSURSHUGLUHFWLRQ


5HPRWH&RQWUROOHUDQG&DUH
Replacing the Lithium Battery
•5HPRYHWKHOLWKLXPEDWWHU\
3UHFDXWLRQ
• Replace the battery with a CR2032 lithium battery.
• Replace the battery in the unit using a non metallic tapered instrument.
 WARNING:
•Keep the lithium battery out of reach of children. Should the battery be swallowed,
immediately consult a doctor.
 CAUTION:
•Do not recharge, disassemble, heat or dispose of battery in a fire.
•Use a CR2032 (3 V) lithium battery only. Never use other types of battery with this
unit.
•Do not handle the battery with metallic tools.
•Do not store the lithium battery with metallic materials.
•Dispose of the used lithium battery, in compliance with applicable laws and
regulations.
•Always check carefully that you are loading the battery with its (+) and (-) poles
facing in the proper directions.


%DVLF2SHUDWLRQ
To Listen to Music
The following explains the initial operations required before you can listen to music.
1RWH
• Loading a disc in this product. (Refer to page 22.)
 6HOHFWWKHGHVLUHGVRXUFHHJ7XQHU
Each press of the SOURCE/OFF button selects the desired source in the following order:
Built-in CD player 3TV 3Tuner 3DAB (Digital Audio Broadcasting) Tuner 3Multi-CD
player 3External Unit 1 3External Unit 2 3AUX 3Telephone standby (for DEH-P7100R)
1RWH
• External Unit refers to a Pioneer product (such as one available in the future) that, although
incompatible as a source, enables control of basic functions by this product. Two External Units can
be controlled by this product, although “External” is displayed whether you select External Unit 1 or
External Unit 2. When two External Units are connected, the allocation of them to External Unit 1 or
External Unit 2 is automatically set by this product.
• In the following cases, the sound source will not change:
* When a product corresponding to each source is not connected to this product.
* When no disc is set in this product.
* When no magazine is set in the Multi-CD player.
* When the AUX (external input) is set to OFF. (Refer to page 64.)
* When the Telephone standby is set to OFF. (Refer to page 67.)
• When this product's blue/white lead is connected to the car's Auto-antenna relay control terminal, the
car's Auto-antenna extends when this product's source is switched ON. To retract the antenna, switch
the source OFF.
 ([WHQGWKH92/80(IRUZDUG
When you press the VOLUME, it extends forward so that it becomes easier to roll. To retract
the VOLUME, press it again.
Each press changes the Source ...


%DVLF2SHUDWLRQ
 5DLVHRUORZHUWKHYROXPH
Rolling the VOLUME changes the volume level.
1RWH
• Roll clockwise to raise the volume level.
• Roll counterclockwise to lower the volume level.
 7XUQWKHVRXUFH2))
Hold for 1 second
