Pioneer FH-P4100XN User manual

PIONEER CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A.
PIONEER EUROPE NV Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 253 Alexandra Road, #04-01, Singapore 159936
C PIONEER CORPORATION 2002 K-ZZU. MAR. 2002 Printed in Japan
ORDER NO.
CRT2825
MULTI-CD CONTROL DSP HIGH POWER CD CASSETTE PLAYER WITH FM/AM TUNER
FH-P4100 XN/UC,XN/ES
Service
Manual
-This service manual should be used together with the manual(s) listed below.
For the parts numbers, adjustments, etc. which are not shown in this manual, refer to the following
manual(s).
Model No. Order No. Mech. Module Remarks
FH-P4000/X1N/UC CRT2674
CX-977 CRT2624 S9 CD Mech. Module:Circuit Description, Mech.Description, Disassembly
CX-1011 CRT2406 3L Cassette Mech. Module:Mech.Description, Disassembly, Adjustment
FH-P4100R XN/EW
MULTI-CD CONTROL DSP HIGH POWER CD CASSETTE PLAYER WITH RDS TUNER

2
FH-P4100,P4100R
EXPLODED VIEWS AND PARTS LIST
PACKING (Page 4)
-PACKING SECTION PARTS LIST
Part No.
Mark No. Description FH-P4000/X1N/UC FH-P4100/XN/UC
9 Carton CHG4348 CHG4698
10 Contain Box CHL4348 CHL4698
14-3 Owner's Manual CRD3403 CRD3580
14-4 Installation Manual CRD3404 CRD3581
-PACKING SECTION PARTS LIST
Part No.
Mark No. Description FH-P4000R/X1N/EW FH-P4100R/XN/EW
9 Carton CHG4347 CHG4697
10 Contain Box CHL4347 CHL4697
14-3 Owner's Manual CRD3397 CRD3576
14-4 Installation Manual CRD3398 CRD3577
14-6 Owner's Manual CRD3399 CRD3578
14-7 Installation Manual CRD3400 CRD3579
-PACKING SECTION PARTS LIST
Part No.
Mark No. Description FH-P4000/X1N/ES FH-P4100/XN/ES
9 Carton CHG4346 CHG4699
10 Contain Box CHL4346 CHL4699
14-3 Owner's Manual CRD3401 CRD3582
14-4 Installation Manual CRD3402 CRD3583

3
FH-P4100,P4100R
EXTERIOR (Page 6-8)
-EXTERIOR SECTION PARTS LIST
Part No.
Mark No. Description FH-P4000/X1N/UC FH-P4100/XN/UC
16 Audio Amp Unit CWM7526 CWM8203
42 Panel Unit CXB7289 CXB8347
43 Button CAC6904 CAC7677
44 Door CAT2223 CAT2336
76 Remote Control Unit CXB6796 CXB8744
77 Cover CNS6439 CNS7068
78 CD Mechanism Module CXK5500(S9) CXK5501(S9ANA)
-EXTERIOR SECTION PARTS LIST
Part No.
Mark No. Description FH-P4000R/X1N/EW FH-P4100R/XN/EW
16 Audio Amp Unit CWM7523 CWM8202
33 Chassis Unit CXB6786 CXB8722
42 Panel Unit CXB7289 CXB8347
43 Button CAC6904 CAC7677
44 Door CAT2223 CAT2336
78 CD Mechanism Module CXK5500(S9) CXK5501(S9ANA)
-EXTERIOR SECTION PARTS LIST
Part No.
Mark No. Description FH-P4000/X1N/ES FH-P4100/XN/ES
14 Audio Amp Unit CWM7529 CWM8204
58 CD Mechanism Module CXK5500(S9) CXK5501(S9ANA)
65 Remote Control Unit CXB6796 CXB8744
66 Cover CNS6439 CNS7068

4
FH-P4100,P4100R
Mark No. Description Part No. Mark No. Description Part No.
101 Screw BPZ20P080FZK
102 Keyboard Unit(UC) CWM8417
Keyboard Unit(EW) CWM8416
103 Holder CNC9168
104 Connector(CN1000) CKS3580
105 IC(IC1401) TS04840SB1
106 Spacer CNM7603
107 Sheet CNM7084
108 Connector CNV6586
109 LCD CAW1664
110 Lighting Conductor CNV6582
111 Grille Unit(UC) CXB9548
Grille Unit(EW) CXB9547
112 Button(TAPE EJ) CAC7438
113 Button(CD EJ) CAC7433
114 Button(SEL) CAC7441
115 Button(VOLUME) CAC7434
116 Button(1-6)(UC) CAC7443
Button(1-6)(EW) CAC7440
117 Button(DISP,AUDIO) CAC7442
118 Lighting Conductor CNV7021
119 Button(DETACH) CAC7439
120 Spring CBH2210
121 Cover CNS6926
-DETACH GRILLE ASSY SECTION PARTS LIST
(UC , EW model)
BF
DETACH GRILLE ASSY(UC,EW model)
NOTE:
-Parts marked by “*” are generally unavailable because they are not in our Master Spare Parts List.
-Screws adjacent to ∇mark on the product are used for disassembly.

5
FH-P4100,P4100R
Mark No. Description Part No. Mark No. Description Part No.
101 Screw BPZ20P080FZK
102 Keyboard Unit CWM8418
103 Holder CNC9168
104 Connector(CN1000) CKS3580
105 Cover CNS6926
106 Guide CNV6580
107 Sheet CNM7084
108 Connector CNV6586
109 LCD CAW1664
110 Lighting Conductor CNV6582
111 Grille Unit CXB9549
112 Door CAT2336
113 Spring CBH1838
114 Button(TAPE EJ) CAC7438
115 Button(CD EJ) CAC7433
116 Button(SEL) CAC7435
117 Button(VOLUME) CAC7434
118 Button(1-6) CAC7443
119 Button(DISP,AUDIO) CAC7442
120 Lighting Conductor CNV7021
121 IC(IC1401) TS04840SB1
122 Spacer CNM7603
-DETACH GRILLE ASSY SECTION PARTS LIST
(ES model)
BF
DETACH GRILLE ASSY(ES model)

6
FH-P4100,P4100R
CD MECHANISM MODULE
GEM1035
GEM1035
UD321BR
CF

7
FH-P4100,P4100R
Mark No. Description Part No. Mark No. Description Part No.
1 Control Unit CWX2481
2 Connector(CN701) CKS1959
3 Connector(CN101) CKS3486
4 Screw BMZ20P025FMC
5 Screw BSZ20P040FMC
6 Screw(M2x4) CBA1362
7 Screw(M2x3) CBA1527
8 Screw CBA1545
9 Washer CBF1037
10 Washer CBF1038
11 Washer CBF1039
12 Washer CBF1060
13 Spring CBH2378
14 Spring CBH2379
15 Spring CBH2514
16 Spring CBH2533
17 Spring CBH2382
18 Spring CBH2383
19 Spring CBH2384
20 Spring CBH2527
21 Spring CBH2386
22 Spring CBH2537
23 Spring CBH2390
24 Spring CBH2391
25 Spring CBH2523
26 Spring CBH2426
27 Spring CBH2444
28 Spring CBL1561
29 Spring CBL1553
30 Shaft CLA3845
31 Roller CLA3910
32 Frame CNC9654
33 Lever CNC9664
34 Lever CNC8949
35 Arm CNC9661
36 Arm CNC9016
37 Arm CNC9017
38 Bracket CNC9123
39 Frame CNC9656
40 Belt CNT1086
41 Gear CNV6886
42 Gear CNV6316
43 Gear CNV6317
44 Gear CNV6318
45 Gear CNV6319
46 Gear CNV6320
47 Arm CNV6322
48 Arm CNV6323
49 Arm CNV6324
50 Arm CNV6888
51 Arm CNV6889
52 Guide CNV6327
53 Arm CNV6924
54 Guide CNV6921
55 Rack CNV6923
56 Clamper CNV6331
57 Arm CNV6332
58 Guide CNV6333
59 Cover CNV6334
60 Arm CNV6335
61 Guide CNV6336
62 Roller CNV6338
63 Damper CNV6339
64 Damper CNV6340
65 Guide CNV6925
66 Chassis Unit CXB7980
* 67 Arm Unit CXB7983
68 Arm Unit CXB7984
69 Arm Unit CXB7985
70 Motor Unit(M2) CXB5903
71 Screw Unit CXB5904
72 Gear Unit CXB8076
73 Bracket Unit CXB7982
74 Motor Unit(M1) CXB6007
75 Arm Unit CXB8504
76 Screw(M2x5) EBA1028
77 Screw JFZ20P020FMC
78 Screw JGZ17P020FZK
79 Washer YE15FUC
80 Washer YE20FUC
81 Pickup Unit(Service)(P9) CXX1480
82 Screw IMS26P030FMC
83 Guide CNV6922
84 Roller CNV6887
85 Spring CBH2509
86 Spring CBH2512
87 Spring CBH2536
88 Collar CNV6906
-CD MECHANISM MODULE SECTION PARTS LIST

8
FH-P4100,P4100R
BF
TAPE
CN80
A
A
1234
B
C
D
1234
SCHEMATIC DIAGRAM
KEYBOARD UNIT

9
FH-P4100,P4100R
BF
CN801
A
Decimal points for resistor
and capacitor fixed values
are expressed as :
2.2 2R2
0.022 R022
←
←
For resistors and capacitors in the circuit diagrams, their resistance values or
capacitance values are expressed in codes:
Ex. *Resistors
Code Practical value
123 12k ohms
103 10k ohms
*Capacitors
Code Practical value
103 0.01uF
101/10 100uF/10V
Symbol indicates a resistor.
No differentiation is made between chip resistors and
discrete resistors.
NOTE :
Symbol indicates a capacitor.
No differentiation is made between chip capacitors and
discrete capacitors.
BF
KEYBOARD UNIT
330K(B)
5678
A
B
C
D
5678

10
FH-P4100,P4100R
LOUND
BF
KEYBOARD UNIT
A
1234
B
C
D
1234
PCB CONNECTION DIAGRAM
KEYBOARD UNIT
NOTE FOR PCB DIAGRAMS
1. The parts mounted on this PCB
include all necessary parts for
several destination.
For further information for
respective destinations, be sure
to check with the schematic dia-
gram.
2. Viewpoint of PCB diagrams
Capacitor
Connector
P.C.Board Chip Part
SIDE A
SIDE B
BF

11
FH-P4100,P4100R
BF
BF
KEYBOARD UNIT
5678
A
B
C
D
5678

ELECTRICAL PARTS LIST(Page 50)
Audio Amp Unit
Part No.
FH-P4000/X1N/UC FH-P4100/XN/UC
Symbol and Description FH-P4000/X1N/ES FH-P4100/XN/ES
IC101 IC CA0008AM HA12187FP
IC301 IC PAL006A PAL007A
IC601 IC PE5211A PE5323A
IC602 IC S-80735ANDZI S-80835ANUP-EDZ
D852 Diode HZU8R2(B1) UDZS8R2(B)
TH601 Thermistor CCX1037 Not used
R642 RN1/16SE2202D RS1/16S473J
C131 CEJA220M16 CEJQ220M16
C133,216,217,821 CEJA100M16 CEJQ100M16
C203 CEJA470M10 CEJQ470M10
C220,221 CEJA1R0M50 CEJQ1R0M50
C222,223,224,225 CEJA4R7M35 CEJQ4R7M35
C267,268,269,272,273,278 CEJA220M6R3 CEJQ220M6R3
C326 CEJA330M10 CEHAR330M10
C327 4700µF/16V CCH1302 CCH1367
C329 CEJA100M16 CEHAR100M16
C406 CEJA220M10 CEJQ220M10
C411 CEJA101M10 CEJQ101M10
Audio Amp Unit
Part No.
Symbol and Description FH-P4000R/X1N/EW FH-P4100R/XN/EW
IC101 IC CA0008AM HA12187FP
IC301 IC PAL006A PAL007A
IC602 IC S-80735ANDZI S-80835ANUP-EDZ
D852 Diode HZU8R2(B1) UDZS8R2(B)
TH601 Thermistor CCX1037 Not used
R642 RN1/16SE2202D RS1/16S473J
C131 CEJA220M16 CEJQ220M16
C133,216,217,821 CEJA100M16 CEJQ100M16
C203 CEJA470M10 CEJQ470M10
C220,221 CEJA1R0M50 CEJQ1R0M50
C222,223,224,225 CEJA4R7M35 CEJQ4R7M35
C267,268,269,272,273,278 CEJA220M6R3 CEJQ220M6R3
C326 CEJA330M10 CEHAR330M10
C327 4700µF/16V CCH1302 CCH1367
C329 CEJA100M16 CEHAR100M16
C406,501,505 CEJA220M10 CEJQ220M10
C411 CEJA101M10 CEJQ101M10
12
FH-P4100,P4100R

13
FH-P4100,P4100R
NOTES:
- Parts whose parts numbers are omitted are subject to being not supplied.
- The part numbers shown below indicate chip components.
Chip Resistor
RS1/_S___J,RS1/__S___J
Chip Capacitor (except for CQS.....)
CKS....., CCS....., CSZS.....
=====Circuit Symbol and No.===Part Name Part No.
--- ------ ------------------------------------------ -------------------------
=====Circuit Symbol and No.===Part Name Part No.
--- ------ ------------------------------------------ -------------------------
Unit Number : CWM8417(UC model)
: CWM8416(EW model)
Unit Name : Keyboard Unit
MISCELLANEOUS
IC 1000 IC PE5234B
IC 1002 IC S-80834ANUP-EDY
IC 1050 IC SED1526F0A
IC 1101 IC TSOP4840SB1
D 1000 Diode Network DA204U
D 1001 Diode Network DA204U
D 1002 Diode MA111
D 1104 LED NSSW440-9159
D 1105 LED NSSW440-9159
D 1106 LED NSSW440-9159
D 1107 LED NSSW440-9159
D 1108 LED(UC model) CL195FGCD
D 1108 LED(EW model) CL195SRCD
D 1109 LED(UC model) CL195FGCD
D 1109 LED(EW model) CL195SRCD
D 1113 LED(UC model) CL195FGCD
D 1113 LED(EW model) CL195SRCD
D 1114 LED(UC model) CL195FGCD
D 1114 LED(EW model) CL195SRCD
L 1000 Inductor CTF1379
L 1001 Inductor CTF1379
L 1002 Inductor-Array CTF1421
L 1003 Inductor-Array CTF1421
L 1004 Inductor LCTB2R2K2125
L 1005 Inductor LCTB2R2K2125
L 1006 Inductor CTF1379
L 1007 Inductor CTF1379
L 1008 Inductor CTF1379
L 1050 Inductor LCYC150K2125
X 1000 Ceramic Resonator 4.72MHz CSS1582
S 1100 Push Switch(UC model) CSG1127
S 1100 Push Switch(EW model) CSG1133
S 1101 Push Switch(UC model) CSG1127
S 1101 Push Switch(EW model) CSG1133
S 1102 Push Switch(UC model) CSG1127
S 1102 Push Switch(EW model) CSG1133
S 1103 Push Switch(UC model) CSG1127
S 1103 Push Switch(EW model) CSG1133
S 1104 Push Switch(UC model) CSG1127
S 1104 Push Switch(EW model) CSG1133
S 1105 Push Switch(UC model) CSG1127
S 1105 Push Switch(EW model) CSG1133
S 1106 Push Switch(UC model) CSG1127
S 1106 Push Switch(EW model) CSG1133
S 1107 Push Switch(UC model) CSG1127
S 1107 Push Switch(EW model) CSG1133
S 1108 Push Switch(UC model) CSG1127
S 1108 Push Switch(EW model) CSG1133
S 1109 Push Switch(UC model) CSG1127
S 1109 Push Switch(EW model) CSG1133
S 1110 Push Switch(UC model) CSG1127
S 1110 Push Switch(EW model) CSG1133
S 1111 Push Switch(UC model) CSG1127
S 1111 Push Switch(EW model) CSG1133
S 1112 Push Switch(UC model) CSG1127
S 1112 Push Switch(EW model) CSG1133
S 1113 Push Switch(UC model) CSG1127
S 1113 Push Switch(EW model) CSG1133
S 1114 Push Switch(UC model) CSG1127
S 1114 Push Switch(EW model) CSG1133
S 1115 Push Switch(UC model) CSG1127
S 1115 Push Switch(EW model) CSG1133
S 1116 Push Switch(UC model) CSG1127
S 1116 Push Switch(EW model) CSG1133
S 1117 Push Switch(UC model) CSG1127
S 1117 Push Switch(EW model) CSG1133
S 1118 Push Switch(UC model) CSG1127
S 1118 Push Switch(EW model) CSG1133
S 1119 Push Switch(UC model) CSG1127
S 1119 Push Switch(EW model) CSG1133
S 1120 Push Switch(UC model) CSG1127
S 1120 Push Switch(EW model) CSG1133
S 1121 Push Switch(UC model) CSG1127
S 1121 Push Switch(EW model) CSG1133
S 1122 Push Switch(UC model) CSG1127
S 1122 Push Switch(EWmodel) CSG1133
VR 1050 Semi-fixed 330kΩ(B) CCP1457
RESISTORS
R 1000 RS1/16S473J
R 1002 RS1/16S102J
R 1003 RS1/16S102J
R 1004 RAB4C102J
R 1005 RS1/16S102J
R 1006 RS1/16S474J
R 1007 RS1/16S102J
R 1008 RS1/16S103J
R 1009 RS1/16S102J
R 1010 RS1/16S224J
R 1011 RS1/16S102J
R 1012 RS1/16S473J
R 1013 RS1/16S473J
R 1015 RS1/16S0R0J
R 1019 RS1/16S0R0J
R 1020 RS1/16S101J
R 1021 RS1/16S103J
R 1050 RS1/16S564J
R 1051 RS1/16S684J
R 1052 RS1/16S393J
R 1056 RAB4C102J
R 1058 RAB4C102J
R 1060 RS1/16S102J
R 1061 RS1/16S102J
R 1062 RS1/16S102J
BF

14
FH-P4100,P4100R
R 1063 RS1/16S102J
R 1111 RS1/16S101J
R 1112 RS1/16S101J
R 1113 RS1/16S181J
R 1114 RS1/16S181J
R 1115 RS1/16S181J
R 1116 RS1/16S181J
R 1117 RS1/16S181J
R 1118 RS1/16S181J
R 1119 RS1/16S181J
R 1124 RS1/16S560J
R 1125 RS1/16S560J
R 1126 RS1/16S181J
R 1127 RS1/16S181J
R 1128 RS1/16S181J
R 1129 RS1/16S181J
R 1130 RS1/16S181J
R 1131 RS1/16S181J
R 1132 RS1/16S181J
R 1152 RS1/16S472J
R 1153 RS1/16S821J
R 1154 RS1/16S122J
R 1155 RS1/16S182J
R 1156 RS1/16S302J
R 1160 RS1/16S472J
R 1161 RS1/16S821J
R 1162 RS1/16S122J
R 1163 RS1/16S182J
R 1164 RS1/16S302J
R 1165 RS1/16S622J
R 1167 RS1/16S472J
R 1168 RS1/16S821J
R 1169 RS1/16S122J
R 1170 RS1/16S182J
R 1171 RS1/16S302J
R 1172 RS1/16S622J
R 1173 RS1/16S223J
R 1175 RS1/16S472J
R 1176 RS1/16S821J
R 1177 RS1/16S122J
R 1178 RS1/16S182J
R 1179 RS1/16S302J
R 1180 RS1/16S622J
R 1181 RS1/16S223J
R 1182 RS1/16S181J
R 1183 RS1/16S181J
R 1184 RS1/16S181J
R 1185 RS1/16S181J
R 1186 RS1/16S181J
R 1187 RS1/16S181J
R 1188 RS1/16S181J
R 1189 RS1/16S181J
CAPACITORS
C 1001 CKSRYB102K50
C 1002 CSZS100M6R3
C 1005 CKSRYB104K16
C 1020 CSZS100M6R3
C 1050 CKSRYB104K16
C 1052 CKSRYB105K6R3
C 1053 CKSRYB105K6R3
C 1054 CKSRYB105K6R3
C 1056 CKSRYB105K6R3
C 1057 CKSRYB105K6R3
C 1058 CKSRYB105K6R3
C 1059 CKSRYB105K6R3
C 1060 CKSRYB105K6R3
C 1061 CKSRYB105K6R3
C 1062 CKSRYB102K50
C 1111 CKSRYB104K16
C 1112 CKSRYB104K16
C 1113 CKSRYB104K16
C 1114 CKSRYB104K16
C 1117 CKSRYB103K50
C 1119 CKSRYB103K50
C 1120 CKSRYB103K50
C 1121 CKSRYB103K50
Unit Number : CWM8418(ES model)
Unit Name : Keyboard Unit
MISCELLANEOUS
IC 1000 IC PE5234B
IC 1002 IC S-80834ANUP-EDY
IC 1050 IC SED1526F0A
IC 1101 IC TSOP4840SB1
D 1002 Diode MA111
D 1104 LED NSSW440-9159
D 1105 LED NSSW440-9159
D 1106 LED NSSW440-9159
D 1107 LED NSSW440-9159
D 1108 LED CL195FGCD
D 1109 LED CL195FGCD
D 1113 LED CL195FGCD
D 1114 LED CL195FGCD
L 1000 Inductor CTF1379
L 1001 Inductor CTF1379
L 1002 Inductor-Array CTF1421
L 1003 Inductor-Array CTF1421
L 1004 Inductor LCTB2R2K2125
L 1005 Inductor LCTB2R2K2125
L 1006 Inductor CTF1379
L 1007 Inductor CTF1379
L 1008 Inductor CTF1379
L 1050 Inductor LCYC150K2125
X 1000 Ceramic Resonator 4.72MHz CSS1582
S 1000 Switch CSG1110
S 1100 Push Switch CSG1127
S 1101 Push Switch CSG1127
S 1102 Push Switch CSG1127
S 1103 Push Switch CSG1127
S 1104 Push Switch CSG1127
S 1105 Push Switch CSG1127
S 1106 Push Switch CSG1127
S 1107 Push Switch CSG1127
S 1108 Push Switch CSG1127
S 1109 Push Switch CSG1127
S 1110 Push Switch CSG1127
S 1111 Push Switch CSG1127
S 1112 Push Switch CSG1127
S 1113 Push Switch CSG1127
S 1114 Push Switch CSG1127
S 1115 Push Switch CSG1127
S 1116 Push Switch CSG1127
S 1117 Push Switch CSG1127
S 1118 Push Switch CSG1127
S 1119 Push Switch CSG1127
=====Circuit Symbol and No.===Part Name Part No.
--- ------ ------------------------------------------ -------------------------
=====Circuit Symbol and No.===Part Name Part No.
--- ------ ------------------------------------------ -------------------------
BF

15
FH-P4100,P4100R
S 1120 Push Switch CSG1127
S 1121 Push Switch CSG1127
S 1122 Push Switch CSG1127
VR 1050 Semi-fixed 330kΩ(B) CCP1457
RESISTORS
R 1000 RS1/16S473J
R 1002 RS1/16S102J
R 1003 RS1/16S102J
R 1004 RAB4C102J
R 1005 RS1/16S102J
R 1006 RS1/16S474J
R 1007 RS1/16S102J
R 1008 RS1/16S103J
R 1009 RS1/16S102J
R 1010 RS1/16S224J
R 1011 RS1/16S102J
R 1012 RS1/16S473J
R 1013 RS1/16S473J
R 1014 RS1/16S102J
R 1019 RS1/16S0R0J
R 1020 RS1/16S101J
R 1021 RS1/16S103J
R 1050 RS1/16S564J
R 1051 RS1/16S684J
R 1052 RS1/16S393J
R 1056 RAB4C102J
R 1058 RAB4C102J
R 1060 RS1/16S102J
R 1061 RS1/16S102J
R 1062 RS1/16S102J
R 1063 RS1/16S102J
R 1111 RS1/16S101J
R 1112 RS1/16S101J
R 1113 RS1/16S181J
R 1114 RS1/16S181J
R 1115 RS1/16S181J
R 1116 RS1/16S181J
R 1117 RS1/16S181J
R 1118 RS1/16S181J
R 1119 RS1/16S181J
R 1124 RS1/16S560J
R 1125 RS1/16S560J
R 1126 RS1/16S181J
R 1127 RS1/16S181J
R 1128 RS1/16S181J
R 1129 RS1/16S181J
R 1130 RS1/16S181J
R 1131 RS1/16S181J
R 1132 RS1/16S181J
R 1152 RS1/16S472J
R 1153 RS1/16S821J
R 1154 RS1/16S122J
R 1155 RS1/16S182J
R 1156 RS1/16S302J
R 1160 RS1/16S472J
R 1161 RS1/16S821J
R 1162 RS1/16S122J
R 1163 RS1/16S182J
R 1164 RS1/16S302J
R 1165 RS1/16S622J
R 1167 RS1/16S472J
R 1168 RS1/16S821J
R 1169 RS1/16S122J
R 1170 RS1/16S182J
R 1171 RS1/16S302J
R 1172 RS1/16S622J
R 1173 RS1/16S223J
R 1175 RS1/16S472J
R 1176 RS1/16S821J
R 1177 RS1/16S122J
R 1178 RS1/16S182J
R 1179 RS1/16S302J
R 1180 RS1/16S622J
R 1181 RS1/16S223J
R 1182 RS1/16S181J
R 1183 RS1/16S181J
R 1184 RS1/16S181J
R 1185 RS1/16S181J
R 1186 RS1/16S181J
R 1187 RS1/16S181J
R 1188 RS1/16S181J
R 1189 RS1/16S181J
CAPACITORS
C 1001 CKSRYB102K50
C 1002 CSZS100M6R3
C 1005 CKSRYB104K16
C 1020 CSZS100M6R3
C 1050 CKSRYB104K16
C 1052 CKSRYB105K6R3
C 1053 CKSRYB105K6R3
C 1054 CKSRYB105K6R3
C 1056 CKSRYB105K6R3
C 1057 CKSRYB105K6R3
C 1058 CKSRYB105K6R3
C 1059 CKSRYB105K6R3
C 1060 CKSRYB105K6R3
C 1061 CKSRYB105K6R3
C 1062 CKSRYB102K50
C 1111 CKSRYB104K16
C 1112 CKSRYB104K16
C 1113 CKSRYB104K16
C 1114 CKSRYB104K16
C 1117 CKSRYB103K50
C 1119 CKSRYB103K50
C 1120 CKSRYB103K50
C 1121 CKSRYB103K50
=====Circuit Symbol and No.===Part Name Part No.
--- ------ ------------------------------------------ -------------------------
=====Circuit Symbol and No.===Part Name Part No.
--- ------ ------------------------------------------ -------------------------
