Multi-CD control high power DVD/Video CD/CD/MP3
player with FM/AM tuner
Syntoniseur AM/FM et lecteur de DVD/CD Vidéo/CD/
MP3, Puissance élevée, avec contr leur pour lec-
teur de CD à chargeur
DVH-P5000MP
English Français

Thank you for buying this Pioneer product.
Please read through these operating instructions so you will know how to operate
your model properly. After you have finished reading the instructions, put them away
in a safe place for future reference.
Be sure to read this
!Playable discs 7
!DVD video disc region numbers 7
!When an operation is prohibited 10
Precautions
To ensure safe driving 6
Before You Start
Information to User 7
For Canadian model 7
About this unit 7
About this manual 8
After-sales service for Pioneer products 8
Product registration 8
Precautions 9
Features 9
Condition memory 10
hat the marks on DVDs indicate 10
About the XM READY mark 10
Use and care of the remote control 11
Whats What
Head unit 12
Remote control 13
Basic Operations
Switching the remote control operation mode
switch 16
Turning the unit on 16
Selecting a source 16
Loading a disc 17
Adjusting the volume 17
Turning the unit off 17
Protecting your unit from theft 18
Tuner
Listening to the radio 19
Introduction of advanced tuner
operation 20
Storing and recalling broadcast
frequencies 20
Tuning in strong signals 20
Storing the strongest broadcast
frequencies 21
Playin DVD video discs
atching a DVD video 22
Basic operation of DVD video 22
Specifying title 23
Specifying chapter 23
Frame-by-frame playback 23
Pausing DVD video playback 23
Slow motion playback 24
Changing audio language during playback
(Multi-audio) 24
Changing the subtitle language during
playback (Multi-subtitle) 24
Changing the viewing angle during playback
(Multi-angle) 25
Operating from the information displays 26
Operating from the function display 28
Playin Video CDs
atching a Video CD 30
Basic operation of Video CD 30
Specifying track 31
Pausing Video CD playback 31
Slow motion playback 31
Operating from the information display 32
Operating from the function display 33
Playin CDs
Listening a CD 35
Basic operation of CD 35
Contents
En
2

Operating from the information display 36
Operating from the function display 38
Playin MP3
Listening MP3 41
Basic operation of MP3 41
Operating from the information display 43
Operating from the function display 45
Multi-CD Player
Playing a CD 48
50-disc multi-CD player 48
Introduction of advanced multi-CD player
operation 49
Repeating play 49
Playing tracks in a random order 49
Scanning CDs and tracks 50
Pausing CD playback 50
Using ITS playlists 50
Using disc title functions 52
Using CD TEXT functions 53
Using compression and bass emphasis 53
Audio Adjustments
Introduction of audio adjustments 54
Compensating for equalizer curves (EQ-
EX) 55
Setting the sound focus equalizer
(SFEQ) 55
Using balance adjustment 55
Using the equalizer 56
Adjusting bass and treble 57
Adjusting loudness 58
Using subwoofer output 58
Using non fading output 59
Using the high pass filter 59
Adjusting source levels 60
Di ital Si nal Processor
Introduction of DSP adjustments 61
Using the sound field control 62
Using the position selector 62
Using balance adjustment 63
Adjusting source levels 63
Using the dynamic range control 63
Using the dual mono mode 64
Using the direct control 64
Using the Dolby Pro Logic 64
Setting the speaker setting 65
Selecting a cut-off frequency 66
Adjusting the speaker output levels 66
Adjusting the speaker output levels using a
test tone 66
Adjusting the time alignment 67
Using the equalizer 68
Settin up the DVD player
Introduction of DVD setup adjustments 70
Returning to the previous display 70
Setting the subtitle language 70
Setting the audio language 71
Setting the menu language 71
Setting assist subtitles on or off 72
Setting angle icon display 72
Setting the aspect ratio 72
Setting the parental lock 73
Setting remote control code type 74
Initial Settin s
Adjusting initial settings 75
Setting the clock 75
Switching the warning tone 75
Switching the auxiliary setting 76
Switching the dimmer setting 76
Setting the rear output and subwoofer
controller 76
En 3
English
Contents

Switching the telephone muting/
attenuation 77
Switching the automatic disc playback 77
Correcting distorted sound 77
Other Functions
Turning the clock display on or off 78
Setting the level indicator 78
Using the AUX source 78
Introduction of XM operation 79
Introduction of DVD operation 79
Additional Information
Troubleshooting 81
Error messages 83
DVD player and care 84
DVD discs 84
CD-R/CD-R discs 84
MP3 files 85
About folders and MP3 files 86
Language code chart for DVD 87
Terms 88
Specifications 91
Contents
En
4

Selecting fine audio equipment such as the unit you’ve just purchased is only the start of your
musical enjoyment. Now it’s time to consider how you can maximize the fun and excitement your
equipment offers. This manufacturer and the Electronic Industries Association’s Consumer
Electronics Group want you to get the most out of your equipment by playing it at a safe level. One
that lets the sound come through loud and clear without annoying blaring or distortion—and, most
importantly, without affecting your sensitive hearing.
Sound can be deceiving. Over time your hearing “comfort level” adapts to higher volumes of
sound. So what sounds “normal” can actually be loud and harmful to your hearing. Guard against
this by setting your equipment at a safe level BEFORE your hearing adapts.
To establish a safe level:
•Start your volume control at a low setting.
•Slowly increase the sound until you can hear it comfortably and clearly, and without distortion.
Once you have established a comfortable sound level:
•Set the dial and leave it there.
Taking a minute to do this now will help to prevent hearing damage or loss in the future. After
all, we want you listening for a lifetime.
We Want You Listening For A Lifetime
Used wisely, your new sound equipment will provide a lifetime of fun and enjoyment. Since
hearing damage from loud noise is often undetectable until it is too late, this manufacturer and the
Electronic Industries Association’s Consumer Electronics Group recommend you avoid prolonged
ex
p
osure to excessive noise. This
l
ist of sound
l
eve
l
s is inc
l
uded for
y
our
p
rotection
.
D
ec
i
bel
Leve
l Exampl
e
30
Quiet
l
i
b
rar
y
, soft whis
p
er
s
4
0
L
ivin
g
room, refri
g
erator,
b
edroom awa
y
from traffi
c
50
L
i
g
ht traffic, norma
l
conversation,
q
uiet office
60 Air conditioner at 20 feet, sewing machine
70 Vacuum cleaner, hair dryer, noisy restaurant
80 Average city traffic, garbage disposals, alarm clock at two feet
THE FOLLOWING NOISES CAN BE DANGEROUS UNDER CONSTANT EXPOSURE
90 Subway, motorcycle, truck traffic, lawn mower
100 Garbage truck, chain saw, pneumatic drill
120 Rock band concert in front of speakers, thunderclap
140 Gunshot blast, jet plane
180 Rocket launching pad
Information courtesy of the Deafness Research Foundation.
En 5
English

To ensure safe driving
WARNING
!To avoid the risk of accident and the potential
violation of applicable laws, this unit is not for
use with a video screen that is visible to the
driver.
!In some countries or states the viewing of
images on a display inside a vehicle even by
persons other than the driver may be illegal.
here such regulations apply, they must be
obeyed.
This unit detects whether your cars parking
brake is engaged or not, and prevents you
from watching a DVD or Video CD on the dis-
play connected to FRONT VIDEO OUTPUT
while driving. hen you attempt to watch a
DVD/Video CD, the screen will turn black.
hen you park your car in a safe place and
apply the parking brake, the picture appears
on the screen.
When using a display connected
to DVD REAR MONITOR OUTPUT
This unitsDVD REAR MONITOR OUTPUT is
for connection of a display to enable passen-
gers in the rear seats to watch the DVD or
Video CD.
WARNING
NEVER install the display in a location that en-
ables the driver to watch the DVD or Video CD
while driving.
Precautions
En
6
Section
01

Information to User
Alteration or modifications carried out without
appropriate authorization may invalidate the
users right to operate the equipment.
For Canadian model
This Class B digital apparatus complies with
Canadian ICES-003.
About this unit
The tuner frequencies on this unit are allo-
cated for use in North America. Use in other
areas may result in improper reception.
Important (Serial number)
The serial number is located on the bottom of
this unit. For your own security and convenience,
be sure to record this number on the enclosed
warranty card.
Playable discs
DVD, Video CD and CD discs that display the
logos shown below can be played back on this
player.
DVD video
Video CD
CD
Note
It is not possible to play back DVD audio disc.
This player can only playback discs bearing the
marks shown above.
DVD video disc region numbers
DVD video discs that have incompatible region
numbers cannot be played on this player. The
region number of the player can be found on
the bottom of this unit.
The illustration below shows the regions and
corresponding region numbers.
Before ou Start
En 7
English
Section
02

About this manual
This unit features a number of sophisticated
functions ensuring superior reception and op-
eration. All the functions have been designed
for the easiest possible use, but many are not
self-explanatory. This operation manual will
help you benefit fully from this productspo-
tential and to maximize your listening enjoy-
ment.
e recommend that you familiarize yourself
with the functions and their operation by read-
ing through the manual before you begin
using this unit. It is especially important that
you read and observe precautions on the next
page and in other sections.
This manual mainly explains remote control
operation. However, in addition to those func-
tions related with DVD/Video CD/CD/MP3 op-
eration that can only be operated by the
remote control, there are also functions that
can be operated similarly by the head unit and
functions that can only be operated by the but-
tons provided for the head unit.
After-sales service for
Pioneer products
Please contact the dealer or distributor from
where you purchased this unit for after-sales
service (including warranty conditions) or any
other information. In case the necessary infor-
mation is not available, please contact the
companies listed below:
Please do not ship your unit to the companies
at the addresses listed below for repair without
advance contact.
U.S.A.
Pioneer Electronics (USA) Inc.
CUSTOMER SUPPORT DIVISION
P.O. Box 1760
Long Beach, CA 90801-1760
800-421-1404
CANADA
Pioneer Electronics of Canada, Inc.
CUSTOMER SATISFACTION DEPARTMENT
300 Allstate Parkway
Markham, Ontario L3R OP2
[phone]
1-877-283-5901
For warranty information please see the Lim-
ited arranty sheet included with this unit.
Product registration
Visit us at the following site:
1 Register your product. e will keep the details
of your purchase on file to help you refer to
this information in the event of an insurance
claim such as loss or theft.
2 Receive updates on the latest products and
technologies.
3 Download owners manuals, order product
catalogues, research new products, and
much more.
Before ou Start
En
8
Section
02

Precautions
CA TION:
SE OF CONTROL OR ADJ STMENT OR
PERFORMANCE OF PROCED RES
OTHER THAN THOSE SPECIFIED HEREIN
MAY RES LT IN HAZARDO S RADIATION
EXPOS RE.
CA TION:
THE SE OF OPTICAL INSTR MENTS
WITH THIS PROD CT WILL INCREASE
EYE HAZARD.
!Keep this manual handy as a reference for
operating procedures and precautions.
!Always keep the volume low enough so you
can hear sounds outside of the car.
!Protect this product from moisture.
!If the battery is disconnected or dis-
charged, the preset memory will be erased
and must be reprogrammed.
Features
DVD video playback
It is possible to play back DVD video, DVD-R
(video mode) and DVD-R (video mode).
Video CDs featuring PBC compatibility
It is possible to play back Video CDs featuring
PBC (playback control).
CD playback
Music CD/CD-R/CD-R playback is possible.
MP3 file playback
It is possible to play back MP3 files recorded
on CD-ROM/CD-R/CD-R (ISO9660 Level 1/
Level 2 standard recordings).
!Supply of this product only conveys a li-
cense for private, non-commercial use and
does not convey a license nor imply any
right to use this product in any commercial
(i.e. revenue-generating) real time broad-
casting (terrestrial, satellite, cable and/or
any other media), broadcasting/streaming
via internet, intranets and/or other net-
works or in other electronic content distri-
bution systems, such as pay-audio or
audio-on-demand applications. An inde-
pendent license for such use is required.
For details, please visit
http://www.mp3licensing.com.
NTSC compatibility
This unit is NTSC system compatible. hen
connecting other components to this unit, be
sure components are compatible with the
same video system or else images will not be
correctly reproduced.
Dolby Digital/DTS compatibility
hen using this unit with a Pioneer multi-
channel processor, you can enjoy the atmo-
sphere and excitement provided by DVD movie
and music software featuring 5.1channel re-
cordings.
!Manufactured under license from Dolby La-
boratories. Dolbyand the double-D sym-
bol are trademarks of Dolby Laboratories.
!DTSis a registered trademark of Digital
Theater Systems, Inc.
Multi-aspect
Switching between wide screen, letter box and
panscan display is possible.
Multi-audio
You can switch between multiple audio sys-
tems recorded on a DVD as desired.
Before ou Start
En 9
English
Section
02

Multi-subtitle
You can switch between multiple subtitle lan-
guages recorded on a DVD as desired.
Multi-angle
You can switch between multiple viewing an-
gles of a scene recorded on a DVD as desired.
Note
This product incorporates copyright protection
technology that is protected by method claims of
certain U.S. patents and other intellectual prop-
erty rights owned by Macrovision Corporation
and other rights owners. Use of this copyright
protection technology must be authorized by
Macrovision Corporation, and is intended for
home and other limited viewing uses only unless
otherwise authorized by Macrovision Corporation.
Reverse engineering or disassembly is
prohibited.
Condition memory
This function memorizes audio language, sub-
title language, angle number, audio output (L,
R) and aspect ratio made during disc playback
for up to 30 discs. ithout any special opera-
tions, the final setting details during playback
of a disc are memorized. The next time a disc
is played, the previous settings are automati-
cally applied.
!ith some discs, audio language and sub-
title language are automatically specified,
in which case condition memory does not
function.
!hen the number of discs exceeds 30, set-
tings for the latest disc replace those for
the least recent disc.
What the marks on DVDs
indicate
The marks below may be found on DVD disc
labels and packages. They indicate the type of
images and audio recorded on the disc, and
the functions you can use.
Mark Meanin
2Indicates the number of audio sys-
tems.
2Indicates the number of subtitle lan-
guages.
3Indicates the number of viewing an-
gles.
16 : 9 LB
Indicates the picture size (aspect
ratio: screen width-to-height ratio)
type.
1
ALL
Indicates the number of the region
where playback is possible.
When an operation is prohibited
hen you are watching a DVD and attempt to
perform an operation, it may not be performed
by the programming on the disc. hen this
happens, this unit indicates the icon on the
screen.
!The icon may not appear in certain dis-
cs.
About the XM READ mark
The XM READY mark printed on the front
panel indicates that the Pioneer XM tuner
(sold separately) can be controlled by this unit.
Please inquire to your dealer or nearest
authorized Pioneer service station regarding
Before ou Start
En
10
Section
02

the XM tuner that can be connected to this
unit. For XM tuner operation, please refer to
the XM tuner owners manual.
Notes
!XM Satellite Radio is developing a new band
of radio in the U.S.A.
The system will use direct satellite-to-receiver
broadcasting technology to provide listeners
in their cars and at home with crystal-clear
sound seamlessly from coast to coast. XM will
create and package up to 100 channels of di-
gital-quality music, news, sports, talk and chil-
drens programming.
!The XM name and related logos are trade-
marks of XM Satellite Radio Inc.
Use and care of the remote
control
Installing the battery
Slide the tray out on the back of the remote
control and insert the battery with the plus (+)
and minus () poles pointing in the proper di-
rection.
!hen using for the first time, pull out the
film protruding from the tray.
WARNING
Keep the battery out of the reach of children.
Should the battery be swallowed, immediately
consult a doctor.
CAUTION
!Use only one CR2025 (3 V) lithium battery.
!Remove the battery if the remote control is not
used for a month or longer.
!Do not recharge, disassemble, heat or dispose
of the battery in fire.
!Do not handle the battery with metallic tools.
!Do not store the battery with metallic materi-
als.
!In the event of battery leakage, wipe the re-
mote control completely clean and install a
new battery.
!hen disposing of used batteries, please
comply with governmental regulations or en-
vironmental public institutions rules that
apply in your country/area.
!Always check carefully that you are loading
the battery with its plus (+) and minus ()
poles facing in the proper directions.
Using the remote control
Point the remote control in the direction of the
front panel to operate.
!The remote control may not function prop-
erly in direct sunlight.
Important
!Do not store the remote control in high tem-
peratures or direct sunlight.
!Do not let the remote control fall onto the
floor, where it may become jammed under the
brake or accelerator pedal.
Before ou Start
En 11
English
Section
02

Head unit
1CLOCK button
This button is only available on the head
unit.
Press to change to the clock display.
2VOLUME
hen you press VOLUME, it extends out-
ward so that it becomes easier to turn. To re-
tract VOLUME, press it again. Rotate to
increase or decrease the volume.
3A (audio) button
Press to select various sound quality con-
trols.
4a/b/c/dbuttons
hen controlling sources
!These buttons can perform the same op-
eration as m/n/o/p/r/qbut-
tons on the remote control. Press to do
manual seek tuning, fast forward, re-
verse, track search and folder select con-
trols.
hen controlling functions
!These buttons can perform the same op-
eration as r/q/m/nbuttons on
the remote control.
5OPEN button
This button is only available on the head
unit.
Press to open the front panel.
6BAND button
Press to select among three FM and one
AM bands and cancel the control mode of
functions.
7E -EX button
This button is only available on the head
unit.
Press and hold to switch between EQ-EX
and SFEQ functions. Press to operate each
function.
8F (function) button
Press to select functions.
916 buttons
These buttons can perform the same opera-
tion as NUMBER (16) buttons on the re-
mote control. Press for preset tuning and
disc number search when using a multi-CD/
DVD player.
aDISPLAY button
This button is only available on the head
unit.
4
6
123
9
5
78ac b
Whats What
En
12
Section
03

Press to select different displays.
bE button
This button is only available on the head
unit.
Press to select various equalizer curves.
cSOURCE button
This unit is turned on by selecting a source.
Press to cycle through all of the available
sources.
Remote control
1Remote control selection switch
Switch to change the setting of the remote
control. For details, refer to Setting remote
control code type on page 74.
2VOLUME button
Press to increase or decrease the volume.
3TOP MENU button
Press to return to the top menu during DVD
playback.
4MENU button
Press to display the DVD menu during DVD
playback.
1
2
f
g
h
i
j
k
l
m
n
d
c
b
a
9
8
7
6
5
4
3
o
p
e
Whats What
En 13
English
Section
03

5RETURN button
Press to return to the previous display when
the SET-UP MENU is displayed.
6AUDIO button
Press to change the audio language during
DVD playback.
7DISP button
Press to change the information display
while the DVD player is playing as the
source.
8SUBTITLE button
Press to change the subtitle language dur-
ing DVD playback.
9ANGLE button
Press to change the viewing angle during
DVD playback.
aPLAY/PAUSE (f) button
Press to switch sequentially between play-
back and pause play.
bREVERSE (m) button
Press to perform fast reverse playback or
seek tuning while the tuner is playing as the
source.
cPREVIOUS (o)/F (function) button
hen the remote control is set to DVD
mode, press to return to the previous track
(chapter). If the remote control is set to
DVH mode, the function menu appears on
the head unit display.
dNUMBER buttons
Press to directly select the desired track,
chapter, preset tuning and disc. 16buttons
can operate the preset tuning for the tuner
or disc number search for the multi-CD
player.
eDIRECT button
Press to do direct channel select when
using an XM tuner.
fSOURCE button
This unit is turned on by selecting a source.
Press to cycle through all of the available
sources.
gJoystick
Move to select the setting. Click to set the
setting or select on or off.
hRemote control operation mode switch
Switch the operation mode between DVD
mode (only the DVD player can be operated
by the remote control) or DVH mode (all
sources of this unit can be operated by the
remote control). (Refer to page 16.)
iBAND button
Press to select among three FM and one
AM bands and cancel the control mode of
functions.
jREAR.S button
Press to watch a DVD/Video CD on a rear
display if DVD (built-in DVD player) is not
selected as the source.
kSTEP (r/q) button
Press to move ahead one frame at a time
during DVD/VideoCD playback. Press and
hold for one second to activate slow play-
back.
lATT button
Press to quickly lower the volume level, by
about 90%. Press once more to return to the
original volume level.
mFORWARD (n) button
Press to perform fast forward playback or
seek tuning while the tuner is playing as the
source.
Whats What
En
14
Section
03

nSTOP (g) button
Press to stop playback.
oNEXT (p)/A (audio) button
hen the remote control is set to DVD
mode, press to return to the previous track
(chapter). If the remote control is set to
DVH mode, the audio menu appears on the
head unit display.
pCLEAR button
Press to cancel the input number while
NUMBER are used.
Whats What
En 15
English
Section
03

Switching the remote control
operation mode switch
There are two remote control operation modes
on the remote control. If you want to operate
this unit by remote control, turn the mode
switch to DVH mode. In this case, both the
head units buttons and remote control can
control this unit.
If you want to operate the DVD playback on
the rear display, turn the mode switch to DVD
mode. In this case, the remote control can
control the DVD playback of the rear display
independently. (If both the front and rear dis-
plays are playing DVD as the source at the
same time, operation is the same for the front
and rear displays.)
If the rear display is connected to this unit and
the remote control operation mode is set to
DVD mode, the rear display can playback DVD
even though the source which is selected by
the head unit is not DVD.
Note
If the remote control operation mode is set to
DVD mode, only the DVD player can be operated
by the remote control.
Turning the unit on
%Press SOURCE to turn the unit on.
hen you select a source the unit is turned
on.
When the DVD player is
operated from rear seats
%Press REAR.S to turn the DVD playback
on.
Notes
!Even if the source selected with this unit is
not DVD, if you switch power to this unit on
with REAR.S, you can watch the DVD picture
from this unit on the rear display.
!Regardless of whether this unit is switched on
or off, you can watch the DVD video on the
rear display.
Selecting a source
You can select a source you want to listen to. If
AUTO PLAY is turned on, load a disc in this
unit to switch to DVD (refer to Switching the
automatic disc playback on page 77).
%Press SOURCE to select a source.
Press SOURCE repeatedly to switch between
the following sources:
XM (XM tuner)TUNER (tuner)TV (televi-
sion)DVD (built-in DVD player)S-DVD
(DVD player/multi-DVD player)MULTI-CD
(multi-CD player)EXT (external unit 1)EXT
(external unit 2)AUX (AUX)
Notes
!In the following cases, the sound source will
not change:
hen a unit corresponding to each source
is not connected to this unit.
hen no disc is set in this unit.
hen no disc is set in the DVD player.
hen no magazine is set in the multi-CD
player.
hen no magazine is set in the multi-DVD
player.
hen the AUX (auxiliary input) is set to off
(refer to page 76).
!External unit refers to a Pioneer product (such
as one available in the future) that, although
incompatible as a source, enables control of
basic functions by this unit. Two external units
Basic Operations
En
16
Section
04

can be controlled by this unit. hen two exter-
nal units are connected, the allocation of
them to external unit 1 or external unit 2 is
automatically set by this unit.
!hen this units blue/white lead is connected
to the cars auto-antenna relay control term-
inal, the cars antenna extends when this
units source is turned on. To retract the an-
tenna, turn the source off. ( hen you con-
nected a Pioneer multi-channel processor
(DEQ-P7000) to this unit, auto-antenna cannot
be controled.)
Loading a disc
1 Press OPEN to open the front panel.
Disc loading slot appears.
#After a disc has been inserted, press SOURCE
to select the DVD player.
2 Insert a disc into the disc loading slot.
hen you set A-PLY: ON, playback will auto-
matically start. If you set A-PLY: OFF, press
SOURCE to select DVD (refer to the previous
page).
Disc loading slot
EJECT button
#To eject a disc, press EJECT.
#To avoid a malfunction, make sure that no
metal object comes into contact with the term-
inals when the front panel is open.
3 Close the front panel.
Notes
!The DVD player plays one, standard, 12-cm or
8-cm (single) disc at a time. Do not use an
adapter when playing 8-cm discs.
!Do not insert anything other than a disc into
the disc loading slot. Discs which can be
played back are listed on Playable discs on
page 7.
!If you cannot insert a disc completely or if
after you insert a disc the disc does not play,
check that the label side of the disc is up.
Press EJECT to eject the disc, and check the
disc for damage before inserting the disc
again.
!If the DVD player does not operate properly,
an error message such as ERROR-02 may be
displayed. Refer to Error messages on page
83.
Adjusting the volume
%Use VOLUME to adjust the sound level.
ith the head unit, rotate VOLUME to in-
crease or decrease the volume.
ith the remote control, press VOLUME to in-
crease or decrease the volume.
Turning the unit off
%Press SOURCE and hold until the unit
turns off.
When the DVD player is
operated from rear seats
%Press REAR.S to turn the DVD playback
off.
REAR will disappear from the head units dis-
play.
Basic Operations
En 17
English
Section
04

Notes
!hen you have turned the DVD playback on
by pressing REAR.S, you cannot turn this unit
off even if you press and hold SOURCE.(REAR
on the head units display lights.) In this case,
press REAR.S to turn REAR off. hen REAR
has disappeared from the head units display,
you can confirm that this unit is off.
!If the DVD playback is set to off, REAR will dis-
appear from the head units display.
Protecting your unit from
theft
The front panel can be detached from the
head unit and stored in the protective case
provided to discourage theft.
!If the front panel is not detached from the
head unit within five seconds of turning off
the ignition, a warning tone will sound.
!You can turn off the warning tone. See
Switching the warning tone on page 75.
Important
!Never use force or grip the display and the
buttons tightly when removing or attaching.
!Avoid subjecting the front panel to excessive
shocks.
!Keep the front panel out of direct sunlight and
high temperatures.
Removing the front panel
1 Press OPEN to open the front panel.
2 Grip the left side of the front panel and
pull it gently outward.
Take care not to grip it tightly or to drop it.
3 Put the front panel into the protective
case provided for safe keeping.
Attaching the front panel
%Replace the front panel by holding it
upright to this unit and clipping it securely
into the mounting hooks.
Basic Operations
En
18
Section
04

Listening to the radio
1 2 4
3
These are the basic steps necessary to operate
the radio. More advanced tuner operation is
explained starting on the next page.
1Band indicator
Shows which band the radio is tuned to, AM
or FM.
2Frequency indicator
Shows to which frequency the tuner is
tuned.
3Stereo (5) indicator
Shows that the frequency selected is being
broadcast in stereo.
4Preset number indicator
Shows what preset has been selected.
1 Press SOURCE to select the tuner.
Press SOURCE until you see TUNER dis-
played.
2 Press BAND to select a band.
Press BAND until the desired band is dis-
played, F1,F2,F3 for FM or AM.
3 To perform manual tuning, press mor
nwith quick presses.
The frequencies move up or down step by
step.
4 To perform seek tuning, press and hold
mor nfor about one second and re-
lease.
The tuner will scan the frequencies until a
broadcast strong enough for good reception is
found.
#You can cancel seek tuning by pressing either
mor nwith a quick press.
#If you press and hold mor nyou can skip
broadcasting stations. Seek tuning starts as soon
as you release the buttons.
Note
hen the frequency selected is being broadcast
in stereo the stereo (5) indicator will light.
Tuner
En 19
English
Section
05

Introduction of advanced
tuner operation
1
2
1Function display
Shows the function status.
2LOC indicator
Shows when local seek tuning is on.
%Press F to display the function names.
Press Frepeatedly to switch between the fol-
lowing functions:
BSM (best stations memory)LOCAL (local
seek tuning)
#To return to the frequency display, press
BAND.
Note
If you do not operate the function within about 30
seconds, the display is automatically returned to
the frequency display.
Storing and recalling
broadcast frequencies
If you press any of the NUMBER (16) you can
easily store up to six broadcast frequencies for
later recall with the touch of a button.
%When you find a frequency that you
want to store in memory press a NUMBER
(16) and hold until the preset number
stops flashing.
The number you have pressed will flash in the
preset number indicator and then remain lit.
The selected radio station frequency has been
stored in memory.
The next time you press the same NUMBER
(16) the radio station frequency is recalled
from memory.
Notes
!Up to 18 FM stations, 6 for each of the three
FM bands, and 6 AM stations can be stored in
memory.
!You can also use qand rto recall radio
station frequencies assigned to NUMBER
(16).
Tuning in strong signals
Local seek tuning lets you tune in only those
radio stations with sufficiently strong signals
for good reception.
1 Press F to select LOCAL.
Press Funtil LOCAL appears in the display.
2 Press rto turn local seek tuning on.
Local seek sensitivity (e.g., LOCAL 2) appears
in the display.
3 Press mor nto set the sensitivity.
There are four levels of sensitivity for FM and
two levels for AM:
FM: LOCAL 1LOCAL 2LOCAL 3
LOCAL 4
AM: LOCAL 1LOCAL 2
The LOCAL 4 setting allows reception of only
the strongest stations, while lower settings let
you receive progressively weaker stations.
Tuner
En
20
Section
05
