Pioneer NDBC4 User manual

UNIVERSAL REAR-VIEW CAMERA
CAMERA DE RECUL UNIVERSELLE
Owner's Manual
Mode d'emploi
ND-BC4
PIONEER CORPORATION
4-1, MEGURO 1-CHOME, MEGURO-KU, TOKYO 153-8654, JAPAN
PIONEER ELECTRONICS (USA) INC.
P.O. Box 1540, Long Beach, California 90801-1540, U.S.A.
TEL: [phone]
PIONEER EUROPE NV
Haven 1087, Keetberglaan 1, B-9120 Melsele, Belgium
TEL: [phone]
PIONEER ELECTRONICS ASIACENTRE PTE. LTD.
253 Alexandra Road, #04-01, Singapore 159936
TEL: [phone]
PIONEER ELECTRONICS AUSTRALIA PTY. LTD.
178-184 Boundary Road, Braeside, Victoria 3195, Australia
TEL: [phone]
PIONEER ELECTRONICS OF CANADA, INC.
300 Allstate Parkway, Markham, Ontario L3R OP2, Canada
TEL: [phone]
TEL: [phone]
PIONEER ELECTRONICS DE MEXICO, S.A. de C.V.
Blvd. Manuel Avila Camacho 138 10 piso
Col. Lomas de Chapultepec, Mexico,
D.F. 11000
TEL: [phone]
;t~~~f91j~R1} m
*!0PJ: Er~t$tpLlJ~t~=¥~445~13~
~~li: [phone]
;t~m::r (:g~ft) 1j~R1}m
w~fLft~~i9>OJlm~~t!tW-fflij~tp'L\9~901-6~
~~li: [phone]
<KNKNN> <09HOOOOO>
Published by Pioneer Corporation.
Copyright ©2009 by Pioneer Corporation.
All rights reserved.
Publication de Pioneer Corporation.
Copyright ©2009 Pioneer Corporation.
Tous droits de reproduction et de traduction
reserves.
Printed
in Japan
Imprime
au Japon
<CZR5182-A> EL

WARNING:
Handling the cord on this product or cords associated
with accessories sold with the product may expose
you to chemicals listed on proposition 65 known to
the State
of California and other governmental enti-
ties to cause cancer and birth defects or other repro-
ductive harm. Wash hands after handling.
Private households in the 25 member states of the
EU, in Switzerland and Norway may return their
used electronic products free
of charge to designated
collection facilities
or to aretailer (if you purchase a
similar new one).
For countries not mentioned above, please contact
your local authorities for the correct method
of dis-
posal.
By doing so you will ensure that your disposed prod-
uct undergoes the necessary treatment, recovery and
recycling and thus prevent potential negative effects
on the environment and human health.
This device complies with Part
15 of the FCC
Rules.
Operation
is subject to the followinotwo condi-
. b
tlOns:
(I) This device may not cause harmful interference
and (2) this device must accept any interference '
received, including interference that may cause
undesired operation.
Information to User
Alteration or modifications carried out without
appropriate authorization may invalidate the user's
right to operate the equipment.
-
If you want to dispose this product, do not
mix it with general household waste. There
is aseparate collection system for used elec-
tronic products in accordance with leoisla-
. b
Hon that requires proper treatment, recovery
and recycling.
IMPORTANT
SAFEGUARDS
• l~st~llati?n and wiring of this product require spe-
cialist skIll and experience. To assure your safety,
please request aspecialist technician to install the
unit.
•Do not attempt to heat the surface
of the camera
lens
or camera lens itself with alighter and so on
when they have become frozen. This can cause a
malfunction.
•This product is arear view
camera for checking
the view at the rear
of acar.
Arear view camera is acamera that provides sym-
metrical images in the same way as rear and side
view mirrors.
•Connection to a
TV with an RCA video input is
possible, but confirm whether the TV you use has
areverse gear connection function.
•Direct sunlight or strong light (sunlight reflected
from abumper etc) on the camera may result in
smear above and below the location where the
light strikes, but this is not amalfunction.
•This product
is designed to supplement the driver'
srear view, but the camera images do not show all
dangers and obstacles. Be sure to look behind you
when reversing to confirm the view.
•This product features awide-angle lens, so the
near view
is wide and the far view is narrow
which may create afalse sense
of distance. Be
sure to look behind you when reversing to confirm
the view.
•
Do not wash your car with an automatic car wash
or high-pressure water as it may result in water
entering the camera
or the camera falling off.
•Check camera stand installation before driving.
Are the screws loose?
Is the camera stand firmly secured?
If the rear view camera comes loose while you
are driving it may cause an accident. .

®Rear view camera X I
@Hexagon wrench X I
@Clamp X 6
®RCA power supply cable X I
®Hook and loop fastener
(sofltype) X I
®Waterproof
pad X 1
©Power supply unit X I
®Hook and loop fastener
(hard type) X I
CD Double-sided
tape X I

Installation <ENGLISH>
Parts supplied
®Rear view camera X I
®RCA power supply cable X
©Power supply unit X I
@Hexagon wrench X I
®Hook and loop fastener (soft type) X I
®Hook and loop fastener (hard type) X
® Clamp X 6
®Waterproof pad X I
CD Double-sided tape X
Installation example (Fig. 1)
CD Glass surface
@Make sure it doesn't touch the wiper
@Install on the center part
Installation Procedure
Note:
Before making afinal installation of the unit,
temporarily connect the wiring to confirm that
the connections
are correct and the system works
properly.
Use only the parts included with the unit to ensure
proper installation.
The use of unauthorized parts
can
cause malfunctions.
Consult with
your nearest dealer if installation
requires the drilling
of holes or other modifications
of the vehicle.
Install the unit where it does not get in the driver"
sway and cannot injure the passenger if there
is a
sudden stop, like an emergency stop.
When mounting this unit, make sure none of the
leads are trapped between this unit and the sur-
rounding metalwork
or fillings.
To prevent electric shock,
do not install the power
supply unit in places where
it might come in con-
tact with liquids.
Do not mount this unit near the heater outlet,
where it would be affected by heat,
or near the
doors, where rainwater might splash
OnlO it. (Never
install
in locations such as the above because of
the danger of malfunction due to high tempera-
tures.)
Before drilling any mounling holes always check
behind where you want to drill the holes. Do not
drill into the
gas line, brake line, electrical wiring
or other important parts.
If this unit
is installed in the passenger compartment,
anchor
it securely so it does not break free while the
car
is moving, and cause injury or an accident.
If this unit
is installed under afront seat, make
sure
il does nOI obslruct seat movement. Route
all leads and cords carefully around the sliding
mechanism so they
do not get caught or pinched in
the mechanism and cause ashort circuit.
oLocate in the position you want to install thl' rear
view camera, Adjust the angle
of the rear \lew
camera, and install so that the camera doe,n't
touch the car.
oWhen sticking to aglass surface, stick it on in a
position that assures the camera
doesn't touch the
rear window.
oInstall so that it does not obstruct the rear field of
view.
oInstall so that it does not protrude from the side of
the car.
o Do not perform installation in rain or fog.
oWhen humidity is high, dry the surface to which
the unit
is to be attached before installing, Moisture
on the attachment surface reduces adhesive strength
which may lead to the unit coming off.
o If the temperature of the attachment surface is
low, warm with ahair dryer
of other means before
installing to improve adhesive strength.
oDo not attach the camera stand to areas on the car
body treated with fluorocarbon resin, or glass. This
may result
in the rear view camera falling off.
oDuring the 24-hour period after installing:
-Do not apply water to the unit.
-Do not expose the unit to rain.
-Do not subject the camera to unnecessary force,
Thoroughly clean where tape is used for sticking
on the unit.
1. Clean the surface to which the rear
view camera is to be installed.
(Fig.
2)
Use acloth or other item to wipe oil, wax,
dust and any other dirt from the installation
surface.
2. Peel off the sheet on the back of the
camera stand and stick it on. (Fig. 3,
Fig. 4, Fig.
5)
Press the camera stand with your fingers to
stick it to the installation surface, Touching
the adhesive surface or sticking the unit
on asecond time reduces adhesive power
which may result
in the unit coming off.
CD Camera stand
®Top
®Mark
®Bottom
®Make sure to install the rear view camera so
that the mark
is located on top of the camera.
®Be sure not to hide any part of the characters
on the license plate when auaching the cam-
era.
3. Adjust the angle so that the bumper
or rear edge of the car is displayed
at the bottom of the TV screen.
(Fig. 6, Fig. 7, Fig. 8)
CD Hexagon wrench
® Bumper or rear edge of car
4. Attach the power supply unit.
(Fig.
9)
Affix the Hook and loop fastener (hard
type) to the bottom
of the power supply
unit, and affix the Hook and loop fastener
(soft type) to the mounting location,
CD Power supply unit
®Hook and loop fastener (hard type)
@Hook and loop fastener (soft type)
• You can use Hook and loop fastener (hard
type) to attach directly to acarpet, but do not
use the soft type,
•Install the power supply unit close enough
for the rear view camera cable to reach,
Installation <ENGLISH>
Parts supplied
@Rear view camera X I
®RCA power supply cable X
©Power supply unit X I
@Hexagon wrench X I
®Hook and loop fastener (soft type) X I
®Hook and loop fastener (hard type) X
® Clamp X 6
®Waterproof pad X I
<D Double-sided tape X
Installation example (Fig. 1)
CD Glass surface
®Make sure it doesn't touch the wiper
@Install on the center part
Installation Procedure
Note:
•Before making afinal installation of the unit,
temporarily connect the wiring to confirm that
the connections
are correct and the system works
properly.
•Use only the parts included with the unit to ensure
proper installation.
The use of unauthorized parts
can cause malfunctions.
•Consult with
your nearest dealer if installation
requires the drilling
of holes or other modifications
of the vehicle.
•Install the unit
where it does not get in the driver"
sway and cannot injure the passenger if there
is a
sudden stop, like an emergency stop.
•
When mounting this unit, make sure none of the
leads are trapped between this unit and the sur-
rounding metalwork
or fiHings.
To prevent electric shock,
do not install the power
supply unit in places where it might
come in con-
tact with liquids.
•Do not mount this unit near the heater outlet,
where
it would be affected by heat, or near the
doors, where rainwater might splash onto it. (Never
install in locations such as the above because
of
the danger of malfunction due to high tempera-
tures.)
Before drilling any mounting holes always check
behind where you want to drill the holes. Do not
drill into the
gas line, brake line, electrical wiring
or other important parts.
•If this unit
is installed in the passenger compartment,
anchor
it securely so it does not break free while the
car
is moving, and cause injury or an accident.
If this unit
is installed under afront seat, make
sure
it does not obstruct seat movement. Route
all leads and cords carefully around the sliding
mechanism so they
do not get caught or pinched in
the mechanism and cause ashort circuit.
Locate
in the position you want to install the rear
view camera. Adjust the angle
of the rear \lew
camera, and install so that the camera doe,n't
touch the car.
•
When sticking to aglass surface. stick it on in a
position that assures the camera
doesn't touch the
rear window.
•Install so that
it does not obstruct the rear field of
view.
•Install so that it does not protrude from the side
of
the car.
•
Do not perform installation in rain or fog.
•When humidity
is high. dry the surface to which
the unit
is to be attached before installing. Moisture
on the attachment surface reduces adhesive strength
which may lead to the unit coming off.
•
If the temperature of the aHachment surface is
low, warm with ahair dryer
of other means before
installing to improve adhesive strength.
•Do not attach the camera stand to areas on the
car
body treated with fluorocarbon resin, or glass. This
may result
in the rear view camera tid ling off.
•During the 24-hour period after installing:
-Do not apply water to the unit.
-Do not expose the unit to rain.
-Do not subject the camera to unnecessary force.
•
Thoroughly clean where tape is used for sticking
on the unit.
1. Clean the surface to which the rear
view camera is to be installed.
(Fig.
2)
Use acloth or other item to wipe oil, wax,
dust and any other dirt from the installation
surface.
2. Peel off the sheet on the back of the
camera stand and stick it on. (Fig. 3,
Fig. 4, Fig.
5)
Press the camera stand with your fingers to
stick it to the installation surface. Touching
the adhesive surface or sticking the unit
on a
second time reduces adhesive power
which may result in the unit coming off.
CD Camera stand
®Top
®Mark
®Bottom
®Make sure to install the rear view camera so
that the mark
is located on top of the camera.
®Be sure not to hide any part of the characters
on the license plate when attaching the cam-
era.
3. Adjust the angle so that the bumper
or rear edge of the car is displayed
at the bottom of the TV screen.
(Fig. 6, Fig. 7, Fig. 8)
CD Hexagon wrench
(3) Bumper or rear edge of car
4. Attach the power supply unit.
(Fig.
9)
Affix the Hook and loop fastener (hard
type) to the bottom
of the power supply
unit, and affix the
Hook and loop fastener
(soft type) to the mounting location.
CD Power supply unit
®Hook and loop fastener (hard type)
@Hook and loop fastener (soft type)
• You can use Hook and loop fastener (hard
type) to attach directly to acarpet, but do not
use the soft type.
•Install the
power supply unit close enough
for the rear view camera cable to reach.

\
-J -'----------,
A~__a_;
O~~
®Install on the center part
,~
l
CD Glass s~L-------"f
oMake sure it doesn't touch the wiper
Fig. 1
Abb.1
Fig. 2
Abb.2
Fig. 3
Abb.3
o
/~
CD Camera
stand

a
a
® Be sure not to hide any part of the char-
acters
on the license plate when attaching
the camera. I
@Bottom
® Make sure to install the rear view camera so
that the mark is located on top of the camera.
Fig. 4
Abb.4
Fig.5
Abb.5
CD Hexagon wrench
Q[f'i/
Fig. 6
Abb.6
Fig. 7
Abb.7
7
oBumper or rear edge of car
Fig.8
Abb.8
Fig. 9
Abb.9

Connection <ENGLISH>
Connection sample (Fig. 10)
CD Clamps
oRear view camera
CD RCA power supply cable
@Product with avideo input jack
(Hideaway unit etc.)
®Power supply unit
®Made with arasp etc.
(j) Scuff plate
®Clamp
®Waterproof pad
Attach the waterproof pad using double-
sided tape.
~()rdi(1~tilUilti()n.poiflts7 (fig· .. l~)
•Open and close the hatch door slowly
to confirm that the cord is not rubbing
against the rim
of the door.
•When the rear view camera cord cannot
be pulled out from the lower side due to
the type
of car.
As shown
in the figure 13, bend the cord
into a U shape
in front of the waterproof
pad, making sure that rain water cannot
enter the car by running down the cord.
CD Clamps
oWaterproof pad
CD Rubber packing
@Make aV-shaped loop in the lead outside
the rubber packing to prevent rainwater from
flowing along the lead into the interior
of the
vehicle.
Attach the waterproof pad using double-
sided tape.
Accessory power supply
To electric terminal controlled by ignition
switch (12 VDC) ON/OFF.
®Red
(j) Fuse (I A)
Ground
To vehicle (metal) body.
®Black
Cord instaUation(Fig.11)
•When pulling the cord out of the car,
pull from the outer side
of the hatch har-
ness cover and hinge.
CD Pull out from here
oHinge
CD Harness cover
@Rear view camera
®Hatch
~f!~f;~()r~·iin;:;!ilU@ti()(1i·(Jig ... l~)
No ACC position
ACC position
Note:
•This unit is for vehicles with a12-volt battery and nega-
tive grounding. Before installing it
in arecreational vehi-
cle, truck,
or bus, check the battery voltage.
•To avoid shorts in the electrical system, be sure to discon-
nect the 8battery cable before beginning installation.
•Refer to the
owner's manual for details on connecting the
other units, then make connections correctly.
•Secure the wiring with cable clamps or adhesive tape. To
protect the wiring, wrap adhesive tape around them where
they lie against metal parts.
•Route and secure all wiring so it cannot touch any mov-
ing parts, such as the gear shift, handbrake and seat rails.
Do not route wiring in places that get hot, such as near
the heater outlet.
If the insulation of the wiring melts or
gets tom, there is adanger
of the wiring short-circuiting
to the vehicle body.
•Do not shorten any leads.
•Never feed power to other equipment by cutting the insu-
lation
of the power supply lead of the unit and tapping
into the lead. The current capacity
of the lead will be
exceeded, causing over heating.
•When replacing the fuse, be sure to only use afuse
of the
rating prescribed on the fuse holder.
•To minimize noise locate the TV antenna cable, radio
antenna cable and RCA power supply cable as far away
from each other as possible.
•Connection to a TV with an RCA video input is possible,
but confirm whether the TV you use has areverse gear
connection function.
•If this unit
is installed in avehicle that does not have an
ACC (accessory) position on the ignition switch, the red
lead of the unit should be connected to aterminal coupled
with ignition switch ON/OFF operations. If this is not
done, the vehicle battery may be drained when you are
away from the vehicle for several hours.
CD Power supply unit
oRear view camera connector
CD RCA power supply cable connector
@Rear view camera
Video input jack
Connect to video input jack.
®RCA pin
Connection <ENGLISH>
Connection sample (Fig. 10)
CD Clamps
oRear view camera
CD RCA power supply cable
@Product with avideo input jack
(Hideaway unit etc.)
®Power supply unit
®Made with arasp etc.
(j) Scuff plate
®Clamp
®Waterproof pad
Attach the waterproof pad using double-
sided tape.
~()rdi(1~tilUilti()n.poiflts7 (fig· .. l~)
•Open and close the hatch door slowly
to confirm that the cord is not rubbing
against the rim
of the door.
•When the rear view camera cord cannot
be pulled out from the lower side due to
the type
of car.
As shown
in the figure 13, bend the cord
into a U shape
in front of the waterproof
pad, making sure that rain water cannot
enter the car by running down the cord.
CD Clamps
oWaterproof pad
CD Rubber packing
@Make aV-shaped loop in the lead outside
the rubber packing to prevent rainwater from
flowing along the lead into the interior
of the
vehicle.
Attach the waterproof pad using double-
sided tape.
Accessory power supply
To electric terminal controlled by ignition
switch (12 VDC) ON/OFF.
®Red
(j) Fuse (I A)
Ground
To vehicle (metal) body.
®Black
Cord instaUation(Fig.11)
•When pulling the cord out of the car,
pull from the outer side
of the hatch har-
ness cover and hinge.
CD Pull out from here
oHinge
CD Harness cover
@Rear view camera
®Hatch
~f!~f;~()r~·iin;:;!ilU@ti()(1i·(Jig ... l~)
No ACC position
ACC position
Note:
•This unit is for vehicles with a12-volt battery and nega-
tive grounding. Before installing it
in arecreational vehi-
cle, truck,
or bus, check the battery voltage.
•To avoid shorts in the electrical system, be sure to discon-
nect the 8battery cable before beginning installation.
•Refer to the
owner's manual for details on connecting the
other units, then make connections correctly.
•Secure the wiring with cable clamps or adhesive tape. To
protect the wiring, wrap adhesive tape around them where
they lie against metal parts.
•Route and secure all wiring so it cannot touch any mov-
ing parts, such as the gear shift, handbrake and seat rails.
Do not route wiring in places that get hot, such as near
the heater outlet.
If the insulation of the wiring melts or
gets tom, there is adanger
of the wiring short-circuiting
to the vehicle body.
•Do not shorten any leads.
•Never feed power to other equipment by cutting the insu-
lation
of the power supply lead of the unit and tapping
into the lead. The current capacity
of the lead will be
exceeded, causing over heating.
•When replacing the fuse, be sure to only use afuse
of the
rating prescribed on the fuse holder.
•To minimize noise locate the TV antenna cable, radio
antenna cable and RCA power supply cable as far away
from each other as possible.
•Connection to a TV with an RCA video input is possible,
but confirm whether the TV you use has areverse gear
connection function.
•If this unit
is installed in avehicle that does not have an
ACC (accessory) position on the ignition switch, the red
lead of the unit should be connected to aterminal coupled
with ignition switch ON/OFF operations. If this is not
done, the vehicle battery may be drained when you are
away from the vehicle for several hours.
CD Power supply unit
oRear view camera connector
CD RCA power supply cable connector
@Rear view camera
Video input jack
Connect to video input jack.
®RCA pin

CD Clamps
®RCA power supply cable
connector
3m(9ft.IOin.)
L
+® RCA pin
3
111 (9 fl. lOin.)
~+®Red
7
7 m (23 ft. 4in.)
®Rear view camera
connector
ape. 0
<®Waterproof pad
Attach the waterproof pad usinG
double-sided t
®Mad '
i I- ewith arasp elc.
1_ <Z? (j) Scuff plate
~ ---~ I-
~ 1---
~-"
-/
Fig. 10
Abb.10
+®Black
1.5111 (4 fl. II in.)
L
Fig. 11
Abb.11
3mifl.IOin.)
@Rear .
.vIew camera
connector
oRear view ca
~ mera
7
7m(23 ft 4·
. 111.)
(1) RCA power sup I
connector pycable
. +® RCA pin
3m(9ft 10·
_-diC--
H
--- / . 111.)
+®Red
CD Clamps
1.5 m(4 ft II·
L. 111.)
+®Black
Fig. 10
Abb.10
i® jade with arasp etc.
1;--3 (j) s,"IT p""
1--1
~,,,
-/
~
®Waterproof pad
Attach the
dwaterpro f
ouble-sided tape. 0pad using
Fig. 11
Abb.11

Fig. 12
Abb.12
~.
OJ R"bh"P"~ ~
oWaterproof pad
®Make aU-shaped loop in
the lead outside the rubber
packing to prevent rainwa-
ter from flowing along the
lead into the interior
of the
vehicle.
Attach the waterproof pad
using double-sided tape.
Fig. 13
Abb.13
Fig. 12
Abb.12
oWaterproof pad
®Make aU-shaped loop in
the lead outside the rubber
packing to prevent rainwa-
ter from flowing along the
lead into the interior
of the
vehicle.
Attach the waterproof pad
using double-sided tape.
Fig. 13
Abb.13

Specifications <.ENGLISH>
Power source 14.4 VDC
(10.8 Vto
15.1 Vallowable)
Grounding system Negative type
Max. current consumption 120 rnA
Output video Mirror image
(for rear view confirmation)
Sensor 1/4-inch color
CCD sensor
No.
of pixels 492 (vertical) X512 (horizontal)
(Total no.
of pixels: 270 000,
effective no.
of pixels roughly 250 000)
Lens Wide-angle,
focal length f=1.4 mm, Fvalue 2.3
Angle
of view Horizontal: approx. 135°
Vertical: approx. 105°
IR cutoff filter (special filter for vehicle mounting)
.................................................................. Provided
Iris system Electronic iris
Scanning system Interlace
Synchronizing system Internal synchronization
Signal-to-noise ratio
40 dB or more
(at the recommended intensity
of illumination)
Horizontal resolution Approx.
300 TV lines
Illumination range Approx. 0.9 lux to 100 000 lux
Image output IVp-p (75
0)
Operation temperature range -30°C to +70°C
_22°P to + I58°P
Storage temperature range
-40°C to +85°C
-40
0pto + I85°P
Dimensions
Camera unit ... 23 (W) X23 (H) X24 (D) mm
7/8 (W) X7/8 (H) XI(D) in.
Power supply unit
.................... 56 (W) X23 (H) X22 (D) mm
2-1/4 (W) X7/8 (H) X7/8 (D) in.
Weight
Camera unit 135 g(0.3 Ibs)
(including the cable)
Power supply unit 110 g(0.2 Ibs)
(including the power cord)
Note:
Specifications and the design are subject to possible
modification without prior notice due to improve-
ments.
Specifications <.ENGLISH>
Power source 14.4 VDC
(10.8 Vto
15.1 Vallowable)
Grounding system Negative type
Max. current consumption 120 rnA
Output video Mirror image
(for rear view confirmation)
Sensor 1/4-inch color
CCD sensor
No.
of pixels 492 (vertical) X512 (horizontal)
(Total no.
of pixels: 270 000,
effective no.
of pixels roughly 250 000)
Lens Wide-angle,
focal length f=1.4 mm, Fvalue 2.3
Angle
of view Horizontal: approx. 135°
Vertical: approx. 105°
IR cutoff filter (special filter for vehicle mounting)
.................................................................. Provided
Iris system Electronic iris
Scanning system Interlace
Synchronizing system Internal synchronization
Signal-to-noise ratio
40 dB or more
(at the recommended intensity
of illumination)
Horizontal resolution Approx.
300 TV lines
Illumination range Approx. 0.9 lux to 100 000 lux
Image output IVp-p (75
0)
Operation temperature range -30°C to +70°C
_22°P to + I58°P
Storage temperature range
-40°C to +85°C
-40
0pto + I85°P
Dimensions
Camera unit ... 23 (W) X23 (H) X24 (D) mm
7/8 (W) X7/8 (H) XI(D) in.
Power supply unit
.................... 56 (W) X23 (H) X22 (D) mm
2-1/4 (W) X7/8 (H) X7/8 (D) in.
Weight
Camera unit 135 g(0.3 Ibs)
(including the cable)
Power supply unit 110 g(0.2 Ibs)
(including the power cord)
Note:
Specifications and the design are subject to possible
modification without prior notice due to improve-
ments.
