Pioneer Dvr-xd11t User manual

DVR-XD11T

Thank you for buying this Pioneer product. Before using the drive, read all warnings, cautions, notices and other

important safety information contained in these Operating Instructions. Please read the entire manual before using

this drive as it contains important information, such as regulatory data, software license agreement(s), product

registration details, service instructions and guidelines.

WARNING

This equipment is not waterproof. To prevent a fire

or shock hazard, do not place any container filled

with liquid near this equipment (such as a vase or

flower pot) or expose it to dripping, splashing, rain

or moisture.

D3-4-2-1-3_B_En

Precautions Regarding Use

•

DANGER – VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN. AVOID DIRECT EXPOSURE TO BEAM.

Pioneer may not be held liable for the loss of any data or any other direct or indirect damage suffered as the

result of the use or breakdown of this product. It is strongly recommended to regularly back up all critical data.

Care must be taken not to infringe copyright restrictions under the laws of each country. If this device is used

to record copyrighted materials, approval must be obtained from the respective copyright holders. The

recording of copyrighted materials without the express approval of the respective copyright holders may result

in legal penalties. Pioneer disclaims any and all responsibility for any legal damages resulting from the use of

this device in the unauthorized copying of copyrighted materials.

All names of corporations, products, and systems listed herein, even when the (™) or (®) symbols are omitted,

are considered the registered trademarks of the respective owners.

The exclamation point within an equilateral

triangle is intended to alert the user to the

presence of important operating and

maintenance (servicing) instructions in the

literature accompanying the appliance.

The lightning flash with arrowhead symbol,

within an equilateral triangle, is intended to

alert the user to the presence of uninsulated

“dangerous voltage” within the product’s

enclosure that may be of sufficient

magnitude to constitute a risk of electric

shock to persons.

CAUTION:

TO PREVENT THE RISK OF ELECTRIC

SHOCK, DO NOT REMOVE COVER (OR

BACK). NO USER-SERVICEABLE PARTS

INSIDE. REFER SERVICING TO QUALIFIED

SERVICE PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

IMPORTANT

D3-4-2-1-1_A1_En

Operating Environment

Operating environment temperature and humidity:

+5 °C to +35 °C (+41 °F to +95 °F); less than 85

%RH (cooling vents not blocked)

Do not install this unit in a poorly ventilated area, or

in locations exposed to high humidity or direct

sunlight (or strong artificial light)

D3-4-2-1-7c*_A1_En

For PLUGGABLE EQUIPMENT, the socket-outlet shall be installed near the equipment and shall be

easily accessible.

IMPORTANT NOTICE

RECORD THE MODEL NUMBER AND SERIAL NUMBERS OF THIS EQUIPMENT BELOW.

THE NUMBERS ARE ON THE BOTTOM.

MODEL NO.

SERIAL NO.

KEEP THESE NUMBERS FOR FUTURE USE.

D1-4-2-6-2*_A1_En

DVR-XD11T

CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE

SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

CAUTION: THE USE OF OPTICAL INSTRUMENTS WITH THIS PRODUCT WILL INCREASE EYE HAZARD.

D58-5-1-2a_A1_En

CAUTION

This product is a class 1 laser product classified

under the Safety of laser products, IEC

60825-1:2007, but this product contains a laser

diode higher than Class 1. To ensure continued

safety, do not remove any covers or attempt to

gain access to the inside of the product.

Refer all servicing to qualified personnel.

The following caution label appears on your unit.

Location: bottom of the unit

D58-5-2-2b*_A1_En

CLASS 1 LASER PRODUCT

Machine Noise Information Regulation 3.

GPSGV: The highest sound-pressure level is 70 dB(A) or less in accordance EN ISO 7779.

Information to User

Alterations or modifications carried out without appropriate authorization may invalidate the user’s right to operate

the equipment. D8-10-2_A1_En

is a trademark of DVD Format/Logo Licensing Corporation.

CAUTION

This product satisfies EMC regulations when shielded cables and connectors are used to

connect the unit to other equipment. To prevent electromagnetic interference with electric

appliances such as radios and televisions, use shielded cables and connectors for

connections.

If you want to dispose this product, do not mix it with general household waste. There is a separate collection system for used

electronic products in accordance with legislation that requires proper treatment, recovery and recycling.

Private households in the member states of the EU, in Switzerland and Norway may return their used electronic products free of charge to

designated collection facilities or to a retailer (if you purchase a similar new one).

For countries not mentioned above, please contact your local authorities for the correct method of disposal.

By doing so you will ensure that your disposed product undergoes the necessary treatment, recovery and recycling and thus prevent potential

negative effects on the environment and human health.

K058b_A1_En

AFTER-SALES SERVICE FOR PIONEER PRODUCTS

Please contact the dealer or distributor from where you purchased

the product for its after-sales service (including warranty conditions)

or any other information. In case the necessary information is not

available, please contact the Pioneer’s subsidiaries (regional service

headquarters) listed below:

PLEASE DO NOT SHIP YOUR PRODUCT TO THE COMPANIES at the

addresses listed below for repair without advance contact, for these

companies are not repair locations.

PIONEER HIGH FIDELITY TAIWAN CO., LTD.

8F., No.407, Ruiguang Rd., Neihu Dist., Taipei City 114, Taiwan

(R.O.C)

S022_A_En

English

Safety instructions

To ensure your personal safety and to maximize the full operating potential of your unit, read and follow

these safety instructions.

Read & Retain Instructions – Read all operating and user information provided with this drive.

Cleaning – Use a damp cloth to clean the exterior housing. Avoid using any fluids including liquid,

aerosol or alcohol-based cleaning products.

Water or Moisture – Avoid operating or locating this drive near water or other sources of fluid.

Installation – Do not place this product on an unstable cart, stand, or table. The product may fall and

be seriously damaged.

Ventilation – Slots and openings in the chassis are for cooling and proper operation of the unit. Do NOT

block or cover the openings. Do NOT place this unit on a bed, rug, etc. as this can block the openings.

This unit should not be placed in a built-in installation unless properly ventilated.

Operation – Avoid moving, lifting or reorienting this drive while a disc is rotating inside.

Environment – Avoid installing this drive in a location with exposure to large quantities of dust, high

temperatures, high humidity, or subject to excessive vibrations or shocks.

Power Sources – Operate this drive only from the recommended power sources. If you are unsure of the

power source, consult an authorized Pioneer representative.

Power-Cord Protection – When unplugging the unit, pull on the plug – not on the cord. Do not handle

the cord or plug with wet hands; doing so could cause an electric short or shock. Do not allow anything

to pinch or rest on the power cord and do not place in a walkway.

Power – Turn OFF the system before installing this or any other hardware device.

Overloading – Avoid connecting too many devices to a single wall socket or power source as this can

cause fires or short circuits.

Object & Liquid Entry – Never push inappropriate objects in to the device. Avoid spilling any liquids in

to or on the outside of the drive.

Condensation – Moisture can form in the operating section of the product if the drive is taken from cool

surroundings to a room with a warmer temperature. Let the drive stand for one to two hours in the new

location before turning it ON.

Servicing – Opening or removing the cover exposes you to possible electrical shock or other danger.

Contact a Pioneer authorized service representative for repairing this drive (refer to the enclosed Service

& Support Card).

Damage Requiring Service – Unplug the unit and refer servicing to qualified service personnel in the

following situations:

• When the power cord, plug, or chassis is damaged.

• If liquid has been spilled, or objects have fallen into the video product.

• If the product has been exposed to rain or water.

• If the product does not operate normally when the operating instructions are followed. Adjust only

those controls that are covered by the operating instructions. Improper adjustment of other

controls may result in damage and can require extensive work by a qualified technician to restore

the unit to its normal operation.

• When the product exhibits a distinct change in performance – this indicates a need for service.

About DualDisc Playback – DualDisc is a two-sided disc with one side containing DVD video/audio/etc.

content and the opposite side containing non-DVD content such as digital audio material. The non-DVD

audio side is not compliant with the CD Audio Specification; therefore, may not play. The DVD side of

DualDisc media plays in this unit. For more details about the DualDisc specification, please refer to the

disc manufacturer or your retailer.

Note

Some discs may not be playable due to different recording formats or the physical condition of the

disc at the time of recording or playback.

• Avoid touching or scratching the signal surface (shiny side) of the

disc.

• Hold the disc by the edges or by the center hold and one edge.

• Do not affix paper or labels to the disc.

• Discard warped or cracked discs as they may cause damage to

the drive.

• Avoid specially shaped discs such as hearts or polygons.

• Remove dust or lint from the disc with a soft cloth by wiping from

the inside to the outside edge rather than in a circular motion.

• Do not use record-cleaning or anti-static agents as the solutions

may cause damage to a disc.

Always be sure to store your discs in proper disc storage cases

when not in use, and always be sure to check for dirt or dust

on discs (especially on the recording side) before use.

English

Features

Write Speed (ZCLV, CAV, PCAV)

DVD-R

DVD-R DL

DVD-RW

DVD+R

DVD+R DL

DVD+RW

DVD-RAM

CD-R

CD-RW

2X, 4X, 6X, 8X

2X, 4X, 6X

2X, 4X, 6X

2.4X, 4X, 6X, 8X

2.4X, 4X, 6X

2.4X, 4X, 6X, 8X

2X, 3X, 5X

10X, 16X, 20X, 24X

4X, 10X, 16X, 20X, 24X

Maximum Read Speed (ZCLV, CAV)

DVD-ROM (single)

DVD-R, DVD+R

DVD-RW, DVD+RW

CD-ROM, CD-R

8X

24X

DVD-ROM (dual)

DVD-R DL, DVD+R DL

DVD-RAM

CD-RW

8X

5X

24X

Buffer Memory Size

Interface 1 Mbyte (Read/Write)

USB 2.0

Disc Format

•CD-DA

• Mixed-CD

• CD-ROM Mode 1

• CD-ROM XA Mode 2 [form 1, form 2]

• KODAK Photo CD Single and Multi-session

• CD Extra [CD PLUS]

•VideoCD

•CDtext(Read/Write)

• CD-R (Read/Write)

• CD-RW [HS/US/US+] (Read/Write)

• DVD-ROM [Single/Dual]

• DVD-Video [Single/Dual]

• DVD-R Ver.2.0 & 2.1 for General (Read/Write)

• DVD-R DL Ver.3.0 (Read/Write)

• DVD-RW Ver.1.0 & 1.1 & 1.2 (Read/Write)

• DVD+R Ver.1.3 (Read/Write)

• DVD+R DL Ver.1.0 & 1.1 (Read/Write)

• DVD+RW Ver.1.3 (Read/Write)

• DVD+RW high speed Ver.1.0 (Read/Write)

• DVD-RAM Ver.2.0 & 2.1 & 2.2 [Non-cartridge] (Read/Write)

media is supported only reading.

Note

•A specific application software is necessary to write the formats listed above.

•Supported media required for specific DVD and CD writing speeds.

•Average writing speed may decrease when multiple discs are written during the same session.

Interface

Front/Top view

1 Power/Busy Indicator

Operation status is indicated as follows:

During Power ON: Lights dimly

During reading/writing: Lights

During disc cover open: Lights

2 OPEN Button

Press to open the disc cover.

3 Disc Cover

Press the OPEN button to open the disc cover

then place a CD or DVD disc onto the tray with

the label facing up. Close the disc cover gently.

Do not manually force open the disc cover.

Use the Forced Open Lever to open the disc cover during POWER OFF.

Rear/Bottom view

4 USB 2.0

USB 2.0 Mini-B Connector

5DCIN

AC Adapter Connector

6 Forced Open Lever

Use to open the disc cover when the drive is not

powered. If the disc cover fails to open when the

OPEN button is pressed, turn the power to the

drive OFF and wait approximately one minute until

the disc stops spinning before trying to open the

disc cover. During normal operation, the OPEN button should be used to open the disc cover.

Caution

About Region codes

• The region code can only be changed five (5) times, including the initial setting. Please be aware

that the fifth change becomes PERMANENT. Therefore, avoid changing the region code unless

absolutely necessary.

• Region codes are part of the DVD Standard. However, region codes on DVD discs are optional. DVD

discs with no specified region code can be played on all compliant players.

English

Connection

This is a hot-plug unit. Connect the unit to the supplied USB cable.

1 Confirm that your computer (PC) has two available USB ports.

2 With your Windows® operating system running, use the supplied USB cable to connect this unit

to the PC.

Caution

• Do not disconnect the USB cable during data transfers.

• Do not disconnect the USB cable during the PC start nor any operation with the unit.

Note

• This unit can operate with USB 1.1 but will not provide optimum performance.

• Connecting this unit through a USB HUB or using unspecified cables may not guarantee proper

operation.

• In some cases, the use of a single USB port may be insufficient for normal operation.

Use two USB ports for power enhancement.

Computer

(PC)

USB cable (supplied)

This unit

Operations

The unit writes to DVD-R/-RW media when the supplied software application is installed on your PC.

Writing fails if the PC or operating system does not support the software.

Begin writing to DVD-R/-RW

1 Connect the necessary USB cable.

2 Turn on the PC.

3 Press the OPEN button, and gently lift the disc cover by hand.

4 Place the disc in the tray with the label facing up.

5 Close the disc cover gently.

6 Start the disc-burning application.

End the writing session

1 Quit the disc burning application.

2 Press the OPEN button, and gently lift the disc cover by hand.

3 Remove the disc.

4 Close the disc cover gently.

5 Shut down the PC.

• For software installation directions, please refer to the manual available on the software disc included

with your drive. For assistance with writing or playing back discs, see the HELP function within the

software application.

• When the lock mechanism is released, the disc cover needs to be fully opened in order to close again.

Manual disc cover open

Use the Forced Open Lever to remove discs if the disc cover fails to

open and all other methods have been exhausted.

1 Shut down the PC.

2 Wait for the disc to stop spinning.

3 Slide the Forced Open Lever to open the disc cover.

4 Gently open the disc cover and remove the disc.

Warning

To prevent injury and damage to the unit, do NOT force the disc

cover to open while the disc is spinning.

English

Specifications

Position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . This drive is horizontal use.

Disc Size. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 cm/8 cm

(Drive does not support non-standard shapes such as business cards, diamond, etc.)

(Drive does not support 8 cm adapter.)

Disc Transfer Rate

* Media that is dirty or damaged can affect the transfer rate.

Data Read (sustained) DVD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Max. 10.8 MBytes/sec.

CD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Max. 3.6 MBytes/sec.

Data Write (sustained) DVD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Max. 10.8 MBytes/sec. (8X DVD-R)

CD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Max. 3.6 MBytes/sec. (24X CD-R)

Access Time/Seek Time

(Random Averages)

Access Time DVD-ROM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130 ms

CD-ROM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130 ms

Seek Time DVD-ROM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130 ms

CD-ROM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130 ms

Power

Standby . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.75 W

DC IN Connector

Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . DC +5 V, 1.0 A (AVE)

Physical Information

Dimensions (excluding foot pad) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133 mm (W) x 14.8 mm (H) x 133 mm (D)

Weight (Drive only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.22 kg (Typ.)

Operating Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +5 °C to +35 °C

Operating Humidity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 % to 85 % (no condensation)

Storage Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .– 40 °C to +60 °C

Storage Humidity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 % to 90 % (no condensation)

Accessories

Operating Instructions (This document)

USB Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Software disc. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Warranty card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Note
