Pioneer AVIC-900DVD User manual

ENG/MASTER COVER 98
2
PIONEER CORPORATION
4-1, MEGURO 1-CHOME, MEGURO-KU, TOKYO 153-8654, JAPAN
PIONEER ELECTRONICS (USA) INC.
P.O. Box 1540, Long Beach, California 90801-1540, U.S.A.
TEL: [phone]
PIONEER EUROPE NV
Haven 1087, Keetberglaan 1, B-9120 Melsele, Belgium
TEL: [phone]
PIONEER ELECTRONICS ASIACENTRE PTE. LTD.
253 Alexandra Road, #04-01, Singapore 159936
TEL: [phone]
PIONEER ELECTRONICS AUSTRALIA PTY. LTD.
178-184 Boundary Road, Braeside, Victoria 3195, Australia
TEL: [phone]
PIONEER ELECTRONICS OF CANADA, INC.
300 Allstate Parkway, Markham, Ontario L3R OP2, Canada
TEL: [phone]
PIONEER ELECTRONICS DE MEXICO, S.A. de C.V.
Blvd.Manuel Avila Camacho 138 10 piso
Col.Lomas de Chapultepec, Mexico, D.F. 11000
TEL:[phone]
Published by Pioneer Corporation.
Copyright © 2003 by Pioneer Corporation.
All rights reserved.
Publication de Pioneer Corporation.
Copyright © 2003 Pioneer Corporation.
Tous droits de reproduction et de traduction
réservés.
Printed in Japan
Imprimé au Japon
<CRD3803-A> EW<KKYHF/03D00001>
ENG/MASTER COVER 98 INST
MANUEL D’INSTALLATION
INSTALLATION MANUAL
ENGLISH ESPAÑOL DEUTSCH FRANÇAIS ITALIANO NEDERLANDS
This product conforms to new cord colours.
Los colores de los cables de este producto se confor-
man con un nuevo código de colores.
Dieses Produkt entspricht den neuen kabelfarben.
Le code de couleur des câbles utilisé pour ce produit est
nouveau.
Questo prodotto è conforme ai nuovi codici colori.
De kleuren van de snoeren van dit toestel zijn gewijzigd.
3
Technische Hotline der
Pioneer Electronics Deutshland GmbH
TEL: [phone]
AVIC-900DVD
AVIC-800DVD
CRD3803A_inst_cover 3/10/03 1:31 PM Page 2

1
IMPORTANT INFORMATION
ABOUT YOUR NEW DVD NAVIGATION UNIT AND THIS MANUAL
• The Pioneer DVD Navigation Unit is intended solely as an aid to you in the oper-
ation of your vehicle. It is not a substitute for your attentiveness, judgement and
care while driving.
• Do not use your navigation system to route you to emergency services such as
hospitals or police stations. Not all emergency service facilities are contained in
the map data.
•Do not operate the DVD Navigation Unit if doing so will divert your attention
from the safe operation of your vehicle. Always observe safe driving rules and
follow all existing traffic regulations.
• This manual explains how to install this DVD Navigation Unit in your vehicle.
Operation of this DVD Navigation Unit is explained in the separate “Operation
Manual” or “Hardware Manual” that also came with this unit.
ENG/MASTER 96 2
CRD3803A_inst_001_029_UK 4/1/03 2:22 PM Page 2

3
IMPORTANT SAFEGUARDS .................... 3
PLEASE READ ALL OF THESE
INSTRUCTIONS REGARDING
YOUR DVD NAVIGATION
UNIT AND RETAIN THEM
FOR FUTURE REFERENCE .................... 3
Connecting the System ............................ 4
CAUTION ........................................................ 4
-Before installing the unit
-To prevent damage
-Parts supplied
Connecting the system ...................................... 7
-Connecting to the display with 26-pin
input
(AVH-P7500DVD, AVH-P6500DVD, etc.)
-Connecting to the display with 20-pin input
Connecting the power cord (1) .......................... 9
Connecting the power cord (2) ........................ 11
Installation ................................................ 12
CAUTION ...................................................... 12
To guard against electromagnetic
interference ................................................13
Before installing and fixing ............................ 13
Before using the adhesive tape ........................ 13
Installing the main unit .................................... 14
-Installation notes
-Parts supplied
-CAUTION
-If you install with the left and right sides of
the DVD Navigation Unit parallel to your
vehicle’s forward / backward direction
DIN Front/Rear-mount .................................... 17
DIN Front-mount ............................................ 17
-Installation with the rubber bush
-Removing the Unit
DIN Rear-mount .............................................. 18
-Installation using the screw holes on the
side of the unit
Installing the GPS aerial .................................. 19
-CAUTION
-Installation notes
-Parts supplied
-When installing the aerial inside the
vehicle (on the dashboard or rear shelf)
-When installing the aerial outside the
vehicle (on the body)
Installing the steering remote control .............. 22
-Parts supplied
-Loading the battery
-Remote control handling notes
-Installing the holders and the steering remote
control
Installing the microphone ................................ 25
-Installation notes
-Parts supplied
-When installing the microphone on the
sun visor
-When installing the microphone on the
steering column
-CAUTION
After installing the unit .......................... 28
2
ENGLISH ESPAÑOL DEUTSCH FRANÇAIS ITALIANO NEDERLANDS
ENG/MASTER 96
Contents
CRD3803A_inst_001_029_UK 4/1/03 2:22 PM Page 3

4
ENG/MASTER 96
IMPORTANT SAFEGUARDS
3
PLEASE READ ALL OF THESE INSTRUCTIONS REGARDING YOUR DVD
NAVIGATION UNIT AND RETAIN THEM FOR FUTURE REFERENCE
1. Read this manual fully and carefully before installing your DVD Navigation Unit.
2. Keep this manual handy for future reference.
3. Pay close attention to all warnings in this manual and follow the instructions care-
fully.
4. This unit is intended solely as an aid to you in the operation of your vehicle. It is
not a substitute for your attentiveness, judgement and care while driving. Do not
operate your DVD Navigation Unit if doing so will divert your attention from the
safe operation of your vehicle. Always observe safe driving rules and follow all
existing traffic regulations.
5. This DVD Navigation Unit may in certain circumstances display erroneous infor-
mation regarding the position of your vehicle, the distance of objects shown on
the screen, and compass directions. In addition, the system has certain limitations,
including the inability to identify one-way streets, temporary traffic restrictions
and potentially unsafe driving areas. Please exercise your own judgement in light
of actual driving conditions.
6. As with any accessory in your vehicle’s interior, the DVD Navigation Unit
should not divert your attention from the safe operation of your vehicle. If you
experience difficulty in operating the system or reading the display, please make
adjustments while safely parked.
7. Do not attempt to install or service your DVD Navigation Unit by yourself.
Installation or servicing of the DVD Navigation Unit by persons without training
and experience in electronic equipment and automotive accessories may be dan-
gerous and could expose you to the risk of electric shock or other hazards.
8. Please remember to wear your seat belt at all times while operating your vehicle.
If you are ever in an accident, your injuries can be considerably more severe if
your seat belt is not properly fastened.
CRD3803A_inst_001_029_UK 4/1/03 2:22 PM Page 4

5
4
ENGLISH ESPAÑOL DEUTSCH FRANÇAIS ITALIANO NEDERLANDS
ENG/MASTER 96
Connecting the System
CAUTION
• Pioneer does not recommend that you install or service your DVD navigation
unit yourself. Installing or servicing of the product may expose you to risk of
electric shock or other hazards. Refer all installation and servicing of your
navigation unit to authorised Pioneer service personnel.
• Secure all wiring with cable clamps or electrical tape. Do not allow any bare
wiring to remain exposed.
• Do not drill a hole into the engine compartment to connect the yellow lead of
the unit to the vehicle battery. Engine vibration may eventually cause the
insulation to fail at the point where the wire passes from the passenger com-
partment into the engine compartment. Take extra care in securing the wire
at this point.
• It is extremely dangerous to allow the GPS aerial cable or microphone cable
to become wound around the steering column or gearstick. Be sure to install
the unit in such a way that it will not obstruct driving.
• Make sure that wires will not interfere with moving parts of the vehicle, such
as the gearstick, handbrake or seat sliding mechanism.
• Do not route wires where they will be exposed to high temperatures. If the
insulation heats up, wires may become damaged, resulting in a short circuit
or malfunction.
• Do not cut the GPS aerial cable to shorten it or use an extension to make it
longer. Altering the aerial cable could result in a short circuit or malfunc-
tion.
• Do not shorten any leads. If you do, the protection circuit may fail to work
properly.
• Never feed power to other electronic products by cutting the insulation of the
power supply lead of the DVD navigation unit and tapping into the lead. The
current capacity of the lead will be exceeded, causing overheating.
CRD3803A_inst_001_029_UK 4/1/03 2:22 PM Page 5

5
Connecting the System
Before installing the unit
• This unit is for vehicles with a 12-volt battery and negative grounding. Before installing
it in a recreational vehicle, lorry, or bus, check the battery voltage.
To prevent damage
No ACC positionACC position
O
N
S
T
A
R
T
O
F
F
A
C
C
O
N
S
T
A
R
T
O
F
F
• When disconnecting a connector, pull
the connector itself. Do not pull the
lead, as you may pull it out of the con-
nector.
• If this unit is installed in a vehicle that
does not have an ACC (accessory)
position on the ignition switch, the red
lead of the unit should be connected to
a terminal coupled with ignition switch
ON/OFF operations. If this is not done,
the vehicle battery may be drained
when you are away from the vehicle
for several hours.
• To avoid short-circuiting, cover the
disconnected lead with insulating tape.
• To avoid shorts in the electrical sys-
tem, be sure to disconnect the (-) bat-
tery cable before beginning installa-
tion.
ENG/MASTER 96 6
CRD3803A_inst_001_029_UK 4/1/03 2:22 PM Page 6

7
6
ENGLISH ESPAÑOL DEUTSCH FRANÇAIS ITALIANO NEDERLANDS
ENG/MASTER 96
Parts supplied
26-pin cableConnectorPower cord
CRD3803A_inst_001_029_UK 4/1/03 2:22 PM Page 7

8
7
Connecting the System
ENG/MASTER 96
Microphone
Connecting the system
Connecting to the display with 26-pin input (AVH-P7500DVD, AVH-P6500DVD, etc.)
Power cord
This product
☞ See pages 9-11.
Antenna jack Black
Display unit
Yellow
15 cm
Note:
If you use equipment other than this unit
that require the connection of FM aerial,
use an adequate aerial distributor available
in the shops.
GPS aerial
☞ See page 19.
☞ See page 25.
(Ex. AVH-P7500DVD, AVH-P6500DVD
AVD-W6210, AVH-P6400CD, AVH-P6400R)
26-pin cable (supplied)
When resetting AV Head Unit
When pressing the reset button of AV Head
Unit while Navigation System and AV Head
Unit (AVH-P7500DVD, AVH-P6500DVD,
AVH-P6400CD, AVH-P6400R) are com-
bined, make sure that ACC is tuned OFF. If
the reset button is pressed while ACC is
ON, it may not work properly.
There may be no voice guidance depending on a
combined display unit. In that case, an external
speaker (commercially available) must be con-
nected to the SP-OUT jack (3.5 ø MINI JACK,
1 W max [8 Ω]) on this unit’s back.
Not used.
CRD3803A_inst_001_029_UK 4/1/03 2:22 PM Page 8

Connecting to the display with 20-pin input
8
ENGLISH ESPAÑOL DEUTSCH FRANÇAIS ITALIANO NEDERLANDS
ENG/MASTER 96
9
Please make sure to complete this
connection. Otherwise you cannot
see the image of the DVD-Video.
Audio output
Video output
Microphone
☞ See page 25.
GPS aerial
☞ See page 19.
RCA cable
(sold separately)
CD-RGB26P
(sold separately)
RGB output (Green)
Use this jack when
connecting the
Pioneer display.
Green
Power cord
This product
☞ See pages 9-11.
Level Control
This is used for adjusting output from Audio
Output. If you turn it to the right, the volume
increases, while turning it to the left reduces the
volume. (Normally, turn it fully to the right, and
instead use the external equipment outputting
sound, such as a display, for adjusting the vol-
ume.)
Antenna jack
15 cm
Note:
If you use equipment other than this
unit that require the connection of FM
aerial, use an adequate aerial distributor
available in the shops.
To RGB input of the
display.
(Ex. AVX-7300)
To Audio inputs.
To VTR input of
the display.
Not used.
*1: If AVIC-800DVD is
combined, this connec-
tion is not required.
CRD3803A_inst_001_029_UK 4/1/03 2:22 PM Page 9

10
9
Connecting the System
ENG/MASTER 96
Connecting the power cord (1)
Speed detection circuit lead
Vehicle injection computer
Connection method
Connector
Pass the extension cord and
the lead for the speed detec-
tion circuit through this hole.
Clamp firmly with
needle-nosed pliers.
Close the cover.
Note: The position of the speed
detection circuit depends on the
vehicle model. For details, consult
the relevant documents from
Pioneer. When making connec-
tions for a model not listed in
those documents or for which con-
nection to the speed detection cir-
cuit is too difficult, connect the
separately sold ND-PG1 speed
pulse generator to the pink lead.
Note: The position of the hand-
brake switch depends on the vehi-
cle model. For details, consult the
vehicle owner’s manual or dealer.
Pink (CAR SPEED SIGNAL INPUT)
The mobile navigation system is connected here to detect the distance
the vehicle travels. Always connect the vehicle’s speed detection cir-
cuit or the ND-PG1 speed pulse generator, sold separately. Failure to
make this connection will increase errors in the location display.
WARNING: IMPROPER CONNECTION MAY RESULT IN
SERIOUS DAMAGE OR INJURY INCLUDING ELECRICAL
SHOCK, AND INTERFERENCE WITH THE OPERATION OF
THE VEHICLE’S ANTILOCK BRAKING SYSTEM, AUTO-
MATIC TRANSMISSION AND SPEEDMETER INDICATION.
Lightgreen
Used to detect the ON/OFF status of the handbrake. This lead must
be connected to the power supply side of the handbrake switch. If
this connection is made incorrectly or omitted, certain functions
of your navigation system will be unusable.
Connection method
Clamp the handbrake switch
power supply side lead.
Clamp firmly with
needle-nosed pliers.
Power supply side
Ground side
Handbrake switch
CRD3803A_inst_001_029_UK 4/1/03 2:22 PM Page 10

11
10
ENGLISH ESPAÑOL DEUTSCH FRANÇAIS ITALIANO NEDERLANDS
ENG/MASTER 96
Note:
Cords for this product and those for other
products may be different colours even if
they have the same function. When con-
necting this product to another product,
refer to the supplied Installation manuals of
both products and connect cords that have
the same function.
This product
Power cord
Black, Orange/white, Red, Yellow
☞ See Page 11.
Yellow/black
When combining this navigation unit with a Pioneer car stereo,
if the car stereo has yellow/black leads, connect them to those
leads. In this way, when the guidance audio is output and
when you operate the system by voice, the vehicle stereo is
automatically muted to reduce the vehicle stereo volume.
Purple/white (REVERSEGEAR SIGNAL INPUT)
This is connected so that the navigation system can
detect whether the vehicle is moving forwards or
backwards. Connect the purple/white lead to the
lead whose voltage changes when the reverse gear
is engaged. Unless connected, the sensor may not
detect your vehicle travelling forward/backward
properly, and thus the position of your vehicle
detected by the sensor may be misaligned from the
actual position.
Note: When you use the ND-PG1 speed pulse
generator (sold separately), please make sure
to connect it.
Connection method
Clamp the reversing lamp
lead.
Clamp firmly with
needle-nosed pliers.
Reversing lamp lead.
Fuse resistor
Check the position of your vehicle’s
reversing lamp (the one that lights up
when the gearstick is in reverse [R]) and
find the reversing lamp lead in the boot.
CRD3803A_inst_001_029_UK 4/1/03 2:22 PM Page 11

12
11
Connecting the System
ENG/MASTER 96
Connecting the power cord (2)
This product
Yellow
To the terminal always supplied with power regardless of
ignition switch position.
Fuse holder (7.5 A)
Red
To the electric terminal controlled by the ignition switch
(12 V DC) ON/OFF.
Do not connect this lead to power source terminals to
which power is continuously supplied. If the lead is
connected to such terminals, the battery may be drained.
Orange/white
To lighting switch terminal.
Black
To vehicle (metal) body. To keep electromagnetic noise
from the vehicle body out of the mobile navigation system,
attach this lead near the main unit.
Fuse resistor
Fuse resistor
Yellow/black, Purple/white, Pink, Lightgreen
Note: When replacing the fuse, be
sure to use only a fuse of the rating
prescribed on the fuse holder.
Power cord
See pages 9-11.
Note: The yellow, red, and orange/white leads should
be connected to the opposite side of the fusebox
terminals from the battery.
☞
Note:
Cords for this product and those for other products
may be different colours even if they have the same
function. When connecting this product to another
product, refer to the supplied Installation manuals
of both products and connect cords that have the
same function.
CRD3803A_inst_001_029_UK 4/1/03 2:22 PM Page 12

13
Installation
12
ENGLISH ESPAÑOL DEUTSCH FRANÇAIS ITALIANO NEDERLANDS
ENG/MASTER 96
CAUTION
•Pioneer does not recommend that you install or service your DVD navigation
unit yourself. Installing or servicing the product may expose you to risk of
electric shock or other hazards. Refer all installation and servicing of your
navigation unit to authorised Pioneer service personnel.
•Never install the unit in places where:
* It could injure the driver or passengers if the vehicle stops suddenly.
* It may interfere with the driver’s operation of the vehicle, such as on the
floor in front of the driver’s seat.
•Make sure there is nothing behind the dashboard or panelling when drilling
holes in them. Be careful not to damage fuel lines, brake lines or power
cables.
•When using screws, do not allow them to come into contact with any electri-
cal lead. Vibration may damage wires, leading to a short circuit or other
damage to the vehicle.
•To ensure proper installation, use the supplied parts in the manner specified.
If any parts other than the supplied ones are used, they may damage internal
parts of the unit or they may work loose and the unit may become detached.
•It is extremely dangerous to allow the GPS aerial lead or microphone lead to
become wound around the steering column or gearstick. Be sure to install
the unit in such a way that it will not obstruct driving.
•Make sure that leads cannot get caught in a door or the sliding mechanism of
a seat, resulting in a short circuit.
•Please confirm the proper function of your vehicle’s other equipment follow-
ing installation of the DVD navigation unit.
CRD3803A_inst_001_029_UK 4/1/03 2:22 PM Page 13

14
To guard against electromagnetic interference
•In order to prevent interference, set the following items as far as possible from the main
unit of this Navigation System, other cables or leads:
- TV aerial and aerial lead
- FM, MW/LW aerial and its lead
- GPS aerial and its lead
In addition you should lay each aerial lead as far as possible from other aerial leads.
Do not bind them together, lay them together, or cross them.
Such electromagnetic noise would increase the error for the location display.
Before installing and fixing
•Consult with your nearest dealer if installation requires the drilling of holes or other mod-
ifications of the vehicle.
•Before finally installing the unit, connect the wiring temporarily, making sure it is all
connected up properly, and the unit and the system work properly.
Before using the adhesive tape
•Make sure the surface is free of moisture, dust, grime, oil, etc. before affixing the tape.
13
Installation
ENG/MASTER 96
CRD3803A_inst_001_029_UK 4/1/03 2:22 PM Page 14

15
14
ENGLISH ESPAÑOL DEUTSCH FRANÇAIS ITALIANO NEDERLANDS
ENG/MASTER 96
Installing the main unit
Installation notes
•Do not install the main unit in places where it may become subject to high temperatures
or humidity, such as:
* Places close to a heater outlet.
* Places exposed to direct sunlight, such as on top of the dashboard or the rear shelf.
* Places that may be splashed by rain, for example close to the door.
•The installation strength will depend on the vehicle model and the installation position.
Choose a position where the main unit can be firmly installed, and install it securely.
If the main unit is not securely fastened, the errors in location display will be greater.
•Do not install the main unit on the board covering the spare tyre or other places which
are subject to vibration.
•When the main unit is installed under a front seat, ensure that it does not obstruct the
sliding action of the seat.
•Do not install the main unit where it will be under luggage. Strong mechanical shock to
the main unit would increase the errors in location display.
•Avoid installing the main unit in places where it will interfere with loading and unload-
ing of the spare tyre, jack, tools, etc.
•Check that a disc or a PC card can be ejected with the main unit installed.
•Install the main unit on a surface within +30 degrees to -15 degrees tolerance (within
five degrees to the left or right of your vehicle’s direction of travel). A surface tilted
more than this would increase the errors in location display.
•Do not install the main unit vertically. Installing it this way can cause it to function
improperly.
5°
5°
30°
15°
CRD3803A_inst_001_029_UK 4/1/03 2:22 PM Page 15

16
15
Installation
ENG/MASTER 96
Parts supplied
Holder
Extraction Key (2 pcs.)
Screw
Main unit
Rubber bush Binding screw
(5 ×6 mm)
(4 pcs.)
Flush surface screw
(5 ×6 mm)
(4 pcs.)
Frame
CRD3803A_inst_001_029_UK 4/1/03 2:22 PM Page 16

CAUTION
•Install with the left and right sides of the DVD Navigation Unit perpendicular
or parallel to your vehicle’s direction of travel. Do not install diagonally to your
vehicle’s direction of travel or the current location will be displayed incorrectly.
•If you install the left and right sides of the DVD Navigation Unit parallel to
your vehicle’s direction of travel, switch the installation direction lever, and
attach the locking screw to the “↔”side, or else the G sensor mounted in the
DVD Navigation Unit will not operate correctly.
If you install with the left and right sides of the DVD Navigation Unit parallel to
your vehicle’s forward / backward direction
If you install with the left and right sides of the DVD Navigation Unit parallel to your
vehicle’s forward / backward direction, remove the mounting screw underneath the DVD
Navigation Unit, and switch the installation direction lever. Then change the screw mount-
ing position from “↔”side to “↕”side. If the screw is attached to the “↔”side, the G sen-
sor mounted in the DVD Navigation Unit will not operate correctly.
1. Remove the locking screw attached to the installation direction lever.
2. Switch the lever, and attach the mounting screw to the “↔”side.
Locking screw
Installation direction lever
Underneath the DVD Navigation Unit Locking screw
Installation direction lever
Front
Front Front
Front
Front
(Perpendicular)
Attachment
position of the
locking screw ↕
(Parallel)
Attachment
position of the
locking screw ↔
Forward / Backward
direction of vehicle
Forward / Backward
direction of vehicle
Forward / Backward
direction of vehicle
16
ENGLISH ESPAÑOL DEUTSCH FRANÇAIS ITALIANO NEDERLANDS
ENG/MASTER 96
17
CRD3803A_inst_001_029_UK 4/1/03 2:22 PM Page 17

18
17
Installation
ENG/MASTER 96
DIN Front/Rear-mount
This unit can be properly installed either from “Front”(conventional DIN Front-mount) or
“Rear”(DIN Rear-mount installation, utilising threaded screw holes at the sides of unit
chassis). For details, refer to the following illustrated installation methods.
DIN Front-mount
Installation with the rubber bush
Removing the Unit
After inserting the holder into the dash-
board, then select the appropriate tabs
according to the thickness of the dash-
board material and bend them.
(Install as firmly as possible using the
top and bottom tabs. To secure, bend
the tabs 90 degrees.)
182
53 Rubber bush
Screw
Dashboard
Holder
Pull out to remove the frame.
(When reattaching the frame, point the
side with a groove downwards and
attach it.)
Frame
Insert the supplied extrac-
tion keys into the unit, as
shown in the figure, until
they click into place.
Keeping the keys pressed
against the sides of the unit,
pull the unit out.
CRD3803A_inst_001_029_UK 4/1/03 2:22 PM Page 18

DIN Rear-mount
Installation using the screw holes on the side of the unit
•Fastening the unit to the factory radio mounting bracket.
Select a position where the screw holes of the bracket and
the screw holes of the head unit become aligned (are fit-
ted), and tighten the screws at 2 places on each side.
Use either binding screws (5 ×6 mm) or flush surface
screws (5 ×6 mm), depending on the shape of the screw
holes in the bracket.
18
ENGLISH ESPAÑOL DEUTSCH FRANÇAIS ITALIANO NEDERLANDS
ENG/MASTER 96
19
Screw
Dashboard or Console
Mounting bracket
CRD3803A_inst_001_029_UK 4/1/03 2:22 PM Page 19

19
Installation
Installing the GPS aerial
CAUTION
•Do not cut the GPS aerial lead to shorten it or use an extension to make it
longer. Altering the aerial cable could result in a short circuit.
Installation notes
•When installing the GPS aerial inside the vehicle, be sure to use the metal sheet provid-
ed with your system. If this is not used, the reception sensitivity will be poor.
•Do not cut the accessory metal sheet. This would reduce the sensitivity of the GPS aeri-
al.
•Take care not to pull the aerial lead when removing the GPS aerial. The magnet attached
to the aerial is very powerful, and the lead may become detached.
•The GPS aerial is installed with a magnet. When installing the GPS aerial, be careful
not to scratch the vehicle body.
•When installing the GPS aerial on the outside of the vehicle, always put it in the vehicle
when going through an automatic vehicle wash. If it is left on the outside it may be
knocked off and scratch the vehicle body.
•Do not paint the GPS aerial, as this may affect its performance.
Dashboard
Roof Rear shelf
Boot lid
•The aerial should be installed on a
level surface where radio waves will
be blocked as little as possible. Radio
waves cannot be received by the aerial
if reception from the satellite is
blocked.
Installation on the vehicle roof or boot
lid is recommended to enable best
reception.
ENG/MASTER 96 20
CRD3803A_inst_001_029_UK 4/1/03 2:22 PM Page 20
