AMPLIFICATION AND BUILD
››110›Watts›x›7›Advanced›Direct›Energy›Amplification›
(20Hz›–›20kHz,›8›ohms,›0.08%›THD›–›FTC)
››Rigid›Trans›Stabilizer›Construction
››Advanced›Direct›Construction
››Glossy Aluminum Front Panel
››Energy›Saver›Power›Supply
AUDIO FEATURES
››Freescale™›Digital›Core›Engine
››THX®›Select2›Plus›Processing›and›Certification
››Dolby®›TrueHD,›Dolby›Digital›Plus,›Dolby›ProLogic›IIz,›
DTS-HD®›Master›Audio›/›High›Resolution›Audio
››Advanced›MCACC›(Auto›Room›Calibration)
›– Symmetric›9-Band›EQ
›– Standing›Wave›Control
›– Auto›Crossover
››192›kHz›/›24-Bit›DAC›(111›db›S/N)
››192›kHz›/›24-Bit›ADC›(112›db›S/N)
››Jitter Reduction Plus
››Phase›Control
››WMA9›Pro›Decoder
››DTS›Neural›Surround
››PQLS›Multi-Channel›Surround›(Precision›Quartz›Lock›System)
››Advanced›Surround›Sound›(13+1›Modes)
››Wide›Surround
››Front›Stage›Surround›Advance›(Focus,›Wide)
››Headphone›Surround
››Virtual›Surround›Back›and›Height
››XM-HD Surround
››Multi-Channel›Auto›Level›Control
››Dialogue›Enhancement
››Multi-Channel›Advanced›Sound›Retriever
››Sound›Retriever›AIR›for›Enhanced›2-Channel›Playback›via›Bluetooth®
››Digital›Noise›Reduction
››Midnight›Listening›Mode
››Sound›Delay›(Lip-Sync)
››Multi-Channel›Tone›Control
VIDEO FEATURES
››HDMI®›(V.1.4a›with›3D)
››Audio›Return›Channel
››Marvell®›1080p›/›24fps›Video›Processor
››Supports›36-bit›Deep›Color›and›x.v.›Color
››Pure›Cinema›I/P›Conversion
››3D›Noise›Reduction›(for›Analog›and›HDMI›HD)
››Advanced›Video›Adjustments›with›Black›Level
CONNECTIVITY
››Made›for›iPod›&›iPhone›Certified›with›Front›USB›Featuring›iPhone,››
iPod›Touch,›and›iPod®››Player›Album›Art›and›Full›Color›GUI››
(USB›+›Composite›Cable›Included)
››Ethernet›Input›for›Internet›Radio›(24›Presets)
››Front›Panel›USB›Memory›Audio›and›Photo›Playback
››Bluetooth›Ready1
››HDMI (6 Inputs Including 1 Front Input / 2 Outputs)
››Digital›Coaxial›(2›Inputs)
››Digital›Optical›(3›Inputs›/›1›Output)
››Audio›In›/›Out›(2›Inputs›/›1›Output)
››A/V›Composite›(4›Inputs›/›1›Output)›Including›1›Front›Input
››Component›Video›(2›Inputs›–›Assignable›/›1›Output)
››SIRIUS›Satellite›Radio›Ready2
››XM Satellite Radio Ready2
››7.1›Pre-Amp›Output
››Large›Speaker›Terminals›–›All›Channels
CUSTOM CONTROL
››PC›Web›Browser›Control
››iControlAV›App›for›control›of›receiver›with›iPhone/iPod›Touch›
(available›for›download›in›the›Apple›App›Store)3
››On-Screen Display (Independent On-Screen Display for Zone 2)
››3-Zone Multi-Zone and Source (3rd Zone Audio)
››Second›Zone›iPod›USB›/›Internet›Radio›/›SIRIUS›/›XM
››Internet›Radio›Station›Input›via›USB-connected›Keyboard
››Versatile›Speaker›Configuration
››Main Room / Multi-zone Illuminated Preset Remote
››RS-232C›Interface
››12›Volt›Trigger›(x2›–›Assignable)
››I/R (2 In / 1 Out)
››Detachable›Power›Cord
››Pioneer›RF›Remote›Ready
VSX-33
7.1-Channel Elite A/V Receiver Featuring Dolby®TrueHD, dts-HD®Master
Audio, THX Select2 Plus and Marvell™Video Processing
Bold denotes›step-up›features›from›VSX-32

Specifications and design subject to modification without notice.
PIONEER, ELITE, and the Pioneer and Elite logos are registered trademarks of Pioneer Corporation.
DOLBY, Dolby TrueHD, Pro Logic IIz, Dolby Digital EX Dolby Digital Plus, and the double-D symbol are
registered trademarks of Dolby Laboratories.
DTS and the Symbol are registered trademarks and the DTS logos are trademarks of DTS, Inc.
THX, the THX Logo and THX Select 2 Plus are trademarks of THX Ltd., which may be registered in
some jurisdictions. All rights reserved.
Marvell and the Marvell logo are registered trademarks of Marvell.
Bluetooth is a registered trademark of Bluetooth SIG, Inc. Bluetooth functionality requires a compat-
ible A2DP profile Bluetooth-enabled device. Certain Bluetooth features may not be supported by all
compatible Bluetooth-enabled devices, and/or the functionality of such features may be limited in
certain devices.
HDMI, the HDMI logo, and High-Definition Multimedia Interface are trademarks or registered trade-
marks of HDMI Licensing LLC in the United States and other countries.
HDMI connection may not allow transmission of copyright-protected material, depending on the
capability of the display device.
Microsoft, Windows Media, and the Windows logo are trademarks or registered trademarks of
Microsoft Corporation.
SIRIUS and related marks are trademarks of Sirius Satellite Radio Inc.
iPhone, iPod, and iPod Touch are registered trademarks of Apple Computer, Inc., registered in the U.S.
and other countries.
Freescale is a trademark of Freescale Semiconductor Inc.
XM is a registered trademark of XM Satellite Radio Inc.
HDMI connection may not allow transmission of copyright-protected material, depending on the
capability of the signal source.
1Optional AS-BT100 Bluetooth Adapter required and sold separately.
2SIRIUS and XM antennas and subscription services each sold separately and required to receive
SIRIUS or XM radio.
3Home network required.
©›2010›Pioneer›Electronics›(USA)›Inc.
VSX-33
7.1-Channel Elite A/V Receiver Featuring Dolby®TrueHD, dts-HD®Master
Audio, THX Select2 Plus and Marvell™Video Processing
CONNECTIONS
Rear›Panel
INTEGRATED TECHNOLOGIES
PRODUCT SPECIFICATIONS
››W›x›H›X›D:›16.54”›x›6.81”›x›17.05”
››Weight:›29›lbs.›9›oz.›
UPC
››884938109048
CARTON SPECIFICATIONS
››W›x›H›x›D:›20.43”›x›12”›x›21.10”
››Weight:›37›lbs.›8›oz.
