Pioneer PDP-R03U Setup guide

Product Training Guide
Media Receiver
PDP-R03U
Multimedia & Web Training Department
545 Nolan Drive Suite 100
Southlake, Texas 76092

Contents
Overview…………………………21
PCB Layout……………………………22
PC I/F Unit………………………….....23
Power Supply……………………......24
Extension Cables………………..…..25
AV Unit (Basic Signal Path)………..26-27
CC & V-Chip (Basic Signal Path)….28-29
PC I/F (Basic Signal Path)……….…30-31
Basic Audio Signal Path…………...32-33
Power On Procedure………………..34-35
DC to DC Converter (Startup)……..36-37
AV System Block (Overall)………...38-39
PC I/F Block (Overall)………………40-41
Disassembly…………………………42-43
Adjustments………………………….44-49
Trouble Shooting (Charts)………...50-56
IC Descriptions……………………...57-57
Specifications………………………..60
Preface ……………………….…….....3
Basic Operation ………………,4-20
Connecting the System.……………4
Controls & Connectors………..……5
Remote………………………..……….6
Power On………………………………7
Auto Installation…………………..….8
Basic Adjustment Settings……..…..9-10
Connections…………………………..11
V-Chip Settings………………………12-16
Multiscreen Functions………………17
Consumer Troubleshooting……….18
PC Compatibility Chart……………..19
Factory Preset………………………..20

3.
Lead in the solder used in this product
is a known reproductive toxicant which
may cause birth defects or other reproductive
harm. (California Health and Safety Code
Section 25249.5).
When servicing this or handling circuit
boards and other components which
contain solder, avoid unprotected skin
contact with the solder. Also, when
soldering do not inhale any smoke or
fumes produced.
This technical training guide will address
the disassembly and adjustments of the
Pioneer PDP-R03U Media receiver
This guide was designed as a servicing aid
and is not intended to replace the service
manual. The student should have the
appropriate service manual on hand when
when using this guide. Data in the service
manual for this unit contains specific
information on safety, parts and adjustments.
Safety information
Important safety data for this Pioneer model
is contained in the service manual. Before
returning the unit to the customer, complete
all product safety obligations and tests.
Technicians who bypass safety features or
fail to carry out safety checks may expose
themselves and others to possible injury,
and may be liable for any resulting damages.
Preface
For more information on electronic
circuits and block diagrams refer
to Service manual ARP3113.

4.
System cable
Media Receiver (rear view)
Power cord
Plasma Display (rear view)
Power cord
System cable
(bottom view)
For details on optional
PIONEER speaker
installation refer to the
speaker instruction
manual provided.
(GRAY)(WHITE)
(GRAY) (WHITE)
Connecting the system
1. Connecting the system cable and the power cord to the Plasma Display
2. Connecting the system cable and the power cord to the Media Receiver
L
•THESE SPEAKER TERMINALS CAN BE UNDER HAZARDOUS VOLTAGE WHEN YOU CONNECT OR DISCONNECT
THE SPEAKER CABLES. TO PREVENT THE RISK OF ELECTRIC SHOCK, DO NOT TOUCH UNINSULATED PARTS
BEFORE DISCONNECTING THE POWER CORD.
(GRAY)
RS-232C
IN OUT
CONTROL
AC INLET
SYSTEM
CABLE (WHITE)
YP B P R
S-VIDEO VIDEO R-AUDIO-L
YP
B P R
S-VIDEO
ANT/CABLE 75ΩOUT
COMPONENT VIDEO COMPONENT VIDEO
VIDEO R-AUDIO-L
AB INPUT 1
INPUT 2
RGB INPUT
INPUT 3
MONITOR OUTPUT

5.
(GRAY)
RS-232C
IN OUT
CONTROL
AC INLET
SYSTEM
CABLE (WHITE)
YP B P R
S-VIDEO VIDEO R-AUDIO-L
YP
B P R
S-VIDEO
ANT/CABLE 75ΩOUT
COMPONENT VIDEO COMPONENT VIDEO
VIDEO R-AUDIO-L
AB INPUT 1
INPUT 2
RGB INPUT
INPUT 3
MONITOR OUTPUT
POWER
STANDBY/ON
MEDIA RECEIVER PDP-R03U
Front view
CLEAR*
POWER button INPUT 4 terminal (S-VIDEO)
INPUT 4 terminal (VIDEO)
PC INPUT terminal (AUDIO) INPUT 4 terminals (AUDIO)
PC INPUT terminal (ANALOG RGB)
Media Receiver
*If you’re having problems operating the Media Receiver and want to return to normal screen, even when it
stays on (the indicator lights green), press CLEAR on the Media Receiver. Pressing CLEAR resets the System
as shown below.
•AV SELECTION resets to STANDARD
•TV channel returns to initial channel setting(Air:2ch, Cable:1 or 2ch)
•Multiscreen resets to normal
•Audio setting initializes
•SRS resets to Off.
•Image position initializes
A
•Pressing CLEAR will not work if the System is in standby mode but the indicator lights red.
•Pressing CLEAR will not delete channel preset or secret number.
Rear view
INPUT 1 COMPONENT VIDEO
terminals (Y, PB, PR)
INPUT 3 COMPONENT
VIDEO terminals (Y, PB, PR)
MONITOR OUTPUT
terminal (S-VIDEO)
SYSTEM CABLE terminal
(GRAY)
SYSTEM CABLE
terminal (WHITE)
AC INLET terminal
RS-232C terminal
(used in the factory setup)
MONITOR OUTPUT
terminal (VIDEO)
MONITOR OUTPUT
terminals (AUDIO)
CONTROL terminals
(IN/OUT)
Antenna input
terminal (A)
Antenna input
terminal (B)
Antenna output
terminal
INPUT 3
RGB INPUT
terminal
INPUT 3 terminal
(S-VIDEO)
INPUT 3 terminal
(VIDEO)
INPUT 3 terminals
(AUDIO)
INPUT 1 terminal
(S-VIDEO)
INPUT 1 terminal
(VIDEO)
INPUT 1 terminals
(AUDIO)
INPUT 2 terminal
(S-VIDEO)
INPUT 2 terminal
(VIDEO)
INPUT 2 terminals
(AUDIO)
Push CLEAR lightly with the tip
of a pointed object like a
ballpoint pen.

6.
Remote control unit
A
•When using the remote control unit, point it at the Plasma
Display.
1TVa:Switch the Plasma Display power on or off.
2 FRONT SURR: Set SRS and FOCUS Sound System.
3 AV SELECTION: Select an audio or video setting.
(AV mode: STANDARD, DYNAMIC,
MOVIE, GAME, USER.
PC mode: STANDARD, USER.)
4 SCREEN MODE: Select the screen size.
5 DISPLAY: Display the channel information.
6 SLEEP: Set the SLEEP timer.
7 CH RETURN: Return to the previous channel.
8CHk/l: Select the channel.
9 MENU: Display the menu screen.
10 MENU RETURN: Return to the previous menu screen.
11 a/b/c/d: Select a desired item on the setting screen.
12ANT:Select the antenna. (A, B)
13 INPUT: Select an input source of the Plasma Display.
(TV, INPUT 1, INPUT 2, INPUT 3, INPUT 4, PC)
14 :When pressed all buttons on the remote control unit
will light. The lighting will turn off if no operations
are performed within about 5 seconds. This button
is used for performing operations in dark places.
15 MTS: Select the MTS/SAP.
16 CC: Display captions during closed-caption source.
17 Dual picture mode select buttons
SPLIT: Set the dual picture mode. Press again to return
to normal screen.
FREEZE: Set the still image. Press again to return to
normal screen.
SELECT: Select the active screen.
SUB INPUT: Select an input source of sub screen.
SUB CH k/l:Select the channel of sub screen.
18 0 –9: Set the channel.
19 CH ENTER: Execute a channel number.
20 VOL k/l: Set the volume.
21 eMUTING: Mute the sound.
22 SET/ENTER: Execute a command.
23 FAVORITE CH
A, B, C, D: Select any of four preset channels.
While watching you can toggle the set channels by
pressing A, B, C and D.
24 LED for transmission confirmation
TV
ANT INPUT
SURR
FRONT
AV
SELECTION
MTS CC
SPLIT
SELECT
SUB SUB CH
ⴐ
ⴐ
ⴑ
ⴐ
ⴑ
FREEZE MODE
CH VOL
RETURN
CH
MUTING
MENU TV/SAT/DVD
FAVORITE CH
RECEIVER
DTV/DVD TOP
SOURCE DTV/SAT
DTV/SAT
VCR REC
ABCD
RETURN MENU
PLASMA DISPLAY
SET/
ENTER
MENU
GUIDE
INPUT VOL
ⴑ VOL ⴐ
INFO
SCREEN
SLEEP LEARNEDIT/ DISPLAY
INPUT ⴑ
TV VCRCBL
/SAT
/DTV
DVD
/LD
123
456
789
0
CH
ENTER
11224 13
15
16
14
17
18
19
4
3
2
5
6
7
20
21
22
23
8
9
10
11
Mode switch

7.
Plasma Display
Media Receiver
Off
Flashing red
Red
Green
Plasma Display status indicators
Power off
Media Receiver does not turn on or its power cord is disconnected.
The Plasma Display System is in standby mode.
The Plasma Display System turns the power on.
Media Receiver status indicators
Power off
Only the Media Receiver is in standby mode or the Plasma Display System is in standby mode.
The Plasma Display System turns the power on.
STANDBY/ON
MAIN POWER
STANDBY/ON
INPUTSTANDBY/ON VOLUMECHANNEL
Power indicator
POWER
STANDBY/ON
MEDIA RECEIVER PDP-R03U
PUSH
PLASMA DISPLAY SYSTEM
POWER
Power indicator
TV
ANT INPUT
SURR
FRONT
AV
SELECTION
MTS CC
SPLIT
SELECT
SUB SUB CH
ⴐ
FREEZE MODE
SCREEN
SLEEP LEARNEDIT/ DISPLAY
INPUT ⴑ
TV VCRCBL
/SAT
/DTV
DVD
/LD
123
456
789
0
CH
ENTER
Turning on the power
1Press MAIN POWER on the Plasma Display.
•The power indicator on the Plasma Display flashes red.
2Press POWER on the Media Receiver.
•The System turns the power on.
•The power indicators on the Plasma Display and Media
Receiver lights up green.
•If the power indicators still light up red, press TV aon
the remote control unit or STANDBY/ON on the Plasma
Display to turn the System on.
First time turning on Media Receiver
1Press POWER on the Media Receiver.
•The power indicator on the Media Receiver lights up
red.
2Press MAIN POWER on the Plasma Display.
•The System turns the power on.
•The power indicators on the Plasma Display and Media
Receiver lights up green.
•If the power indicators still light up red, press TV aon
the remote control unit or STANDBY/ON on the Plasma
Display to turn the System on.
A
•In this manual, “System”mean the Plasma Display Panel and
Media Receiver.
Turning off the power
1Press TV aon the remote control unit or STANDBY/
ON on the Plasma Display.
•The System enters standby mode and the image on
the screen disappears.
•Both power indicators change from green to red.
2Press POWER on the Media Receiver.
•The power indicator on the Media Receiver turns off
and the one on the Plasma Display flashes red.
3Press MAIN POWER on the Plasma Display.
•The power indicator on the Plasma Display turns off
after approximately 5 seconds.
A
•If you are not going to use this System for a long time, be sure to
remove the Power cord from the power outlet.
Off
Red
Green

8.
Language menu
Antenna menu
1. Setting a language
1Press a/bto select the desired language listed
on the screen.
2Press SET/ENTER to enter the setting.
2. Setting the antenna mode
1Press a/bto select “Air”or “Cable”on the screen.
2Press SET/ENTER to enter the setting.
Searching TV channels
CH Search
Air 2
Initial auto installation
When you turn on the Plasma Display System for the first time, it will automatically memorize the broadcasting
channels where you live. Perform the following steps before you press TV a.
1. Insert the batteries into the remote control unit.
2. Connect the antenna cable to the Media Receiver.
3. Plug in the power cord to the wall outlet.
3. Automatic channel searching
Channel auto search makes the Plasma Display System
look for all channels viewable in the set area.
A
•If no channel is found, “No program found. Is antenna
connected properly?”displays. And the auto channel
search finishes.
•Channel search function is available for ANT-A only.
•ANT-B cannot perform channel search.
•You may need to manually add the CABLE Converter
output channel setting (fixed), when connecting the CABLE
Converter output signal to the B terminal (ANT/CABLE
75q) on the Media Receiver (Rear).
Language
English
Français
Español
Air/Cable
Air
Cable

9.
MENU
Contrast
Bright
Color
Tint
Sharp
Advanced
Reset
Basic adjustment settings
MENU
Energy Save
No Signal off
No Operation off
Description
Save power by decreasing picture
brightness.
System automatically shuts down if
no signal inputs for 15 minutes.
System automatically shuts down if
you do not operate the System for 3
hours.
Description
Adjusts the picture between light and
shade.
Adjusts picture brightness.
Adjusts color intensity.
Adjusts skin color to a more natural
tone.
Adjusts picture sharpness.
Adjusts color temperature, black,
3D-Y/C and black & white and
PureCinema.
All image adjustment settings return
to the factory preset values.
MENU
Treble
Bass
Balance
Reset
Description
Adjusts the treble weaker or stronger.
Adjusts the bass weaker or stronger.
Adjusts audio output between left
and right speakers.
All audio adjustment settings return
to the factory preset values.
MENU
Auto Installation
CH Setup
Parental CTRL
Description
Automatically memorizes the
broadcasting channels where you
live.
Sets the channel preset.
Sets a secret number to restrict
operations.
MENU
Input Select
Position
Audio Out
Demo
Language
Description
Select the kind of input signal of each
input source.
Adjusts the horizontal/vertical
position of the image displayed.
Select the type of monitor output. You
can adjust volume for the main
speaker or monitor output.
Demonstration setting for storefront
displays.
Select the on screen display
language.
First MENU
MENU
Power Control
Audio
Setup
Option
Power Control
Energy Save [Standard]
No Signal off [Disable]
No Operation off
RETURN
[Disable]
USER
Contrast
Bright
Color
Tint
Sharp
Advanced
Reset
RETURN
[+30]
[0]
[0]
[0]
[0]
0
–30
–30
–30
–7
+40
+30
+30
+30
+7
Audio
USER
Treble
Bass
Balance
Reset
RETURN
[0]
[0]
[0]
–15
–15
Left
+15
+15
Right
AV mode menu items
List of AV menu items to help you with operations.
Setup
Auto Installation
CH Setup
Parental CTRL
RETURN
Option
Position
Audio Out
Demo
[Fixed]
[Off]
Input Select
Language
RETURN
[English]

10.
Basic adjustment settings
First MENU
MENU
Energy Save
Power
Management
Description
Save power by decreasing picture
brightness.
System automatically shuts down if
you set the time. Select Mode1 or
Mode2.
MENU
Contrast
Bright
Red
Green
Blue
Reset
Description
Adjusts the picture between light and
shade.
Adjusts picture brightness.
Adjusts red color intensity.
Adjusts green color intensity.
Adjusts blue color intensity.
All image adjustment settings return
to the factory preset values.
MENU
Treble
Bass
Balance
Reset
Description
Adjusts the treble weaker or
stronger.
Adjusts the bass weaker or stronger.
Adjusts audio output between left
and right speakers.
All audio adjustment settings return
to the factory preset values.
MENU
Auto Sync.
Fine Sync.
Audio Out
Description
Provides a clear input image.
Adjusts image H-Pos, V-Pos, clock
and phase.
After selecting type of monitor output,
adjusts the volume of the main
speaker or monitor output.
MENU
Power Control
Audio
Option
Power Control
Energy Save [Standard]
Power Management
RETURN
[Off]
USER
Contrast
Bright
Red
Green
Blue
Reset
RETURN
[+30]
[0]
[0]
[0]
[0]
0
–30
–30
–30
–30
+40
+30
+30
+30
+30
Audio
USER
Treble
Bass
Balance
Reset
RETURN
[0]
[0]
[0]
–15
–15
Left
+15
+15
Right
Option
Fine Sync.
Audio Out
RETURN
[Fixed]
Auto Sync.
PC mode menu items
List of PC menu items to help you with operations.

11.
Using external equipment
(GRAY)
RS-232C
IN OUT
CONTROL
AC INLET
SYSTEM
CABLE (WHITE)
YP B P R
S-VIDEO VIDEO R-AUDIO-L
YP
B P R
S-VIDEO
ANT/CABLE 75ΩOUT
COMPONENT VIDEO COMPONENT VIDEO
VIDEO R-AUDIO-L
AB INPUT 1
INPUT 2
RGB INPUT
INPUT 3
MONITOR OUTPUT
POWER
STANDBY/ON
MEDIA RECEIVER PDP-R03U
DVD player
Media Receiver
(rear view)
Media Receiver
(front view)
AV Receiver
(Built-in Tuner Amp) VCR
Digital tuner
Game console/
Camcorder
Computer
You can connect many types of external equipment to your Plasma Display System, like a DVD player, VCR,
Digital tuner, computer, game console and camcorder. To view external source images, select the input source
from INPUT on the remote control unit or on the Plasma Display.
L
• To protect all equipment, always turn off the Media Receiver before connecting to a DVD player, VCR, Digital tuner,
computer, game console, camcorder or other external equipment.
A
• Please refer to the relevant operation manual (DVD player, computer, etc.) carefully before making connections.
RGB
S-VIDEO
AV
S-VIDEO
Y/PB/PR
AV
Y/PB/PR
AV
S-VIDEO
AV
S-VIDEO
PC-AUDIO
ANALOG RGB
AV
S-VIDEO

12.
Useful adjustment settings
Parental control (setting V-CHIP level)
V-CHIP is an electronic filtering device built into your System. This tool gives parents a great degree of control
over broadcasts accessed by their children. It allows parents to select programs judged suitable for child
viewing while blocking ones judged not suitable. It does so automatically once you activate the V-CHIP feature
in your Plasma Display.
V-CHIP and Status will not be selectable from the menu if you do not first configure your secret number.(See
page 52 for Secret number setting for parental control.)
•The U.S. has two rating systems for viewing content: TV Parental Guidelines and movie ratings.
•The TV Parental Guidelines work in conjunction with the V-CHIP to help parents screen out inappropriate
television shows from their children.
•Movie ratings are used for original movies rated by the Motion Picture Association of America (MPAA) as
watched on cable TV and not edited for television. The V-CHIP can also be set to block MPAA-rated movies
Voluntary movie rating system (MPAA)
Rating
Age
G
PG
PG-13
R
NC-17
X
General audiences. All ages admitted.
Parental guidance suggested. Some material may not be suitable for children.
Parents strongly cautioned. Some material may be inappropriate for children under 13.
Restricted. Under 17 requires accompanying parent or adult guardian (age varies in some
jurisdictions).
No one 17 and under admitted.
A rating that has now been superseded by NC-17.
Description
X: Content rating can be set.
TV Parental Guidelines
TV-Y (All children)
TV-Y7 (Directed to older children)
TV-G (General audience)
TV-PG (Parental guidance suggested)
TV-14 (Parents strongly cautioned)
TV-MA (Mature audience only)
Rating
Suggested
age
Content
FV
(Fantasy
violence)
V
(Violence)
S
(Sexual
situation)
L
(Adult
language)
D
(Sexually
suggestive
dialog)
X
X
X
X
X
X
X
X
X
X
X
X
Setup
MPAA
MENU
Parental CTRL
V-Chip
G
PG
PG-13
R
NC-17
X
RETURN
[———]
[———]
[———]
[———]
[———]
[———]
a
•If you select “PG-13”, this will automatically block the higher ratings “R”, “NC-17”and “X”.
A
•Voluntary movie rating system only uses an age-based rating.

13.
Useful adjustment settings
Voluntary movie rating system (MPAA)
1Press MENU.
2Press a/bto select “Setup”, and then press SET/
ENTER.
•Secret number setting menu displays only when
“Secret No.”is set. (See page 52.)
•V-CHIP and Status will not be selectable from the menu
if you do not first configure your secret number.
(See page 52.)
3Enter your 4-digit secret number with 0–9to cancel
the “Secret No.”when you set it.
4Press a/bto select “Parental CTRL”, and then
press SET/ENTER.
5Press a/bto select “V-Chip”, and then press SET/
ENTER.
6Press a/bto select “MPAA”, and then press SET/
ENTER.
7Press a/b to select the desired item, and then
press SET/ENTER to select “BLOCK”.
•The setting automatically enters “BLOCK”for any
ratings below your selection.
•If Status is not set to “On”the configuration settings
will not work. (See page 53.)
8Press MENU to exit the menu.
A
•Return to the previous menu by pressing MENU RETURN.
TV Parental Guidelines (TV Guidelines)
1Press MENU.
2Press a/bto select “Setup”, and then press SET/
ENTER.
•Secret number setting menu displays only when
“Secret No.”is set. (See page 52.)
•V-CHIP and Status will not be selectable from the menu
if you do not first configure your secret number.
(See page 52.)
3Enter your 4-digit secret number with 0–9to cancel
the “Secret No.”when you set it.
4Press a/bto select “Parental CTRL”, and then
press SET/ENTER.
5Press a/bto select “V-Chip”, and then press SET/
ENTER.
6Press a/bto select “TV Guidelines”, and then
press SET/ENTER.
7Press a/bto select the desired item, and then
press SET/ENTER to select “BLOCK”.
•The setting automatically enters “BLOCK”for any
ratings below your selection.
•When “Block Content”is selected, its menu displays
as shown left.
•If Status is not set to “On”the configuration settings
will not work. (See page 53.)
8Press MENU to exit the menu.
A
•Return to the previous menu by pressing MENU RETURN.
Setup
TV Guidelines
MENU
Parental CTRL
V-Chip
TV-Y
TV-Y7
TV-G
TV-PG
TV-14
TV-MA
Block Content
RETURN
[———]
[———]
[———]
[BLOCK]
[BLOCK]
[BLOCK]
TV
ANT INPUT
SURR
FRONT
AV
SELECTION
MTS CC
SPLIT
SELECT
SUB SUB CH
ⴐ
ⴐ
ⴑ
ⴐ
ⴑ
FREEZE MODE
CH VOL
RETURN
CH
MUTING
MENU TV/SAT/DVD
FAVORITE CH
RECEIVER
DTV/DVD TOP
SOURCE DTV/SAT
DTV/SAT
VCR REC
ABCD
RETURN MENU
PLASMA DISPLAY
SET/
ENTER
MENU
GUIDE
INPUT VOL
ⴑ VOL ⴐ
INFO
SCREEN
SLEEP LEARNEDIT/ DISPLAY
INPUT ⴑ
TV VCRCBL
/SAT
/DTV
DVD
/LD
123
456
789
0CH
ENTER
Setup
TV Guidelines [TV-PG]
MENU
Parental CTRL
V-Chip
Block Content
D
L
S
V
FV
RETURN
[BLOCK]
[———]
[———]
[———]
[———]
Setup
MENU
Secret No. –––
–
Setup
MPAA
MENU
Parental CTRL
V-Chip
G
PG
PG-13
R
NC-17
X
RETURN
[———]
[———]
[———]
[———]
[———]
[———]

14.
Setup
Secret No.
MENU
Parental CTRL
Secret No.
Clear Secret No.
RETURN
Useful adjustment settings
Secret number setting for parental
control (AV mode only)
Allows you to use a secret number to protect certain
settings from being accidentally changed.
Setting a secret number
1Press MENU.
2Press a/bto select “Setup”, and then press SET/
ENTER.
3Press a/bto select “Parental CTRL”, and then
press SET/ENTER.
4Press a/bto select “Secret No.”, and then press
SET/ENTER.
5Repeat step 4 again.
6Enter the 4-digit number as a secret number using
0–9.
7And enter the same 4-digit number on the
“Reconfirm”screen as in step 6 to confirm.
•“New Secret No. is registered.”displays.
8Press MENU to exit the menu.
A
•Return to the previous menu by pressing MENU RETURN.
TV
ANT INPUT
SURR
FRONT
AV
SELECTION
MTS CC
SPLIT
SELECT
SUB SUB CH
ⴐ
ⴐ
ⴑ
ⴐ
ⴑ
FREEZE MODE
CH VOL
RETURN
CH
MUTING
MENU TV/SAT/DVD
FAVORITE CH
RECEIVER
DTV/DVD TOP
SOURCE DTV/SAT
DTV/SAT
VCR REC
ABCD
RETURN MENU
PLASMA DISPLAY
SET/
ENTER
MENU
GUIDE
INPUT VOL
ⴑ VOL ⴐ
INFO
SCREEN
SLEEP LEARNEDIT/ DISPLAY
INPUT ⴑ
TV VCRCBL
/SAT
/DTV
DVD
/LD
123
456
789
0CH
ENTER
Setup
MENU
Parental CTRL
Secret No.
Secret No.
Input Secret No.
New Secret No.
Reconfirm
––––
–––
–
––––
Setup
MENU
Parental CTRL
Secret No.
Secret No.
Input Secret No.
New Secret No.
Reconfirm –––
––––
****
*
Secret number
setting menu
Setup
MENU
Secret No. –––
–
Setup
MENU
Parental CTRL
Secret No.
Secret No.
Input Secret No.
New Secret No.
Reconfirm –––
–––
*
*
***
*
Setup
MENU
Parental CTRL
Secret No.
Secret No.
Input Secret No.
New Secret No.
Reconfirm
–––
––––
****
*
Setup
MENU
Parental CTRL
Secret No.
Secret No.
Input Secret No.
New Secret No.
Reconfirm –––
****
****
*
Changing the secret number
Allows you to change your current secret number.
1Press MENU.
2Press a/bto select “Setup”, and then press SET/
ENTER.
•Secret number setting menu displays.
3Enter your 4-digit secret number with 0–9to cancel
the “Secret No.”when you set it.
4Press a/bto select “Parental CTRL”, and then
press SET/ENTER.
5Press a/bto select “Secret No.”, and then press
SET/ENTER.
6Repeat step 5 again.
7Enter the Old 4-digit number you have set using
0–9.
8Enter the New 4-digit number you have set using
0–9.
9And enter the same 4-digit number on the
“Reconfirm”screen as in step 8 to confirm.
•“New Secret No. is registered.”displays.
10 Press MENU to exit the menu.
A
•Return to the previous menu by pressing MENU RETURN.

15.
Useful adjustment settings
Clearing the secret number
Allows you to clear your secret number.
1Press MENU.
2Press a/bto select “Setup”, and then press SET/
ENTER.
•Secret number setting menu displays.
3Enter your 4-digit secret number with 0–9to cancel
the “Secret No.”when you set it.
•Setup menu displays.
4Press a/bto select “Parental CTRL”, and then
press SET/ENTER.
5Press a/bto select “Secret No.”, and then press
SET/ENTER.
6Press a/bto select “Secret No. Clear”, and the
press SET/ENTER.
7Press a/bto select “Yes”, and the press SET/
ENTER.
•Your secret number is cleared.
8Press MENU to exit the menu.
A
•Return to the previous menu by pressing MENU RETURN.
•As a precautionary measure, make a note of your
secret number and keep it in a familiar place. If you
lose or forget your secret number, initialize the Plasma
Display System to return all settings except for the TV
channel settings to factory preset values.
Setup
Off
MENU
Parental CTRL
Status [On]
On
TV
ANT INPUT
SURR
FRONT
AV
SELECTION
MTS CC
SPLIT
SELECT
SUB SUB CH
ⴐ
ⴐ
ⴑ
ⴐ
ⴑ
FREEZE MODE
CH VOL
RETURN
CH
MUTING
MENU TV/SAT/DVD
FAVORITE CH
RECEIVER
DTV/DVD TOP
SOURCE DTV/SAT
DTV/SAT
VCR REC
ABCD
RETURN MENU
PLASMA DISPLAY
SET/
ENTER
MENU
GUIDE
INPUT VOL
ⴑ VOL ⴐ
INFO
SCREEN
SLEEP LEARNEDIT/ DISPLAY
INPUT ⴑ
TV VCRCBL
/SAT
/DTV
DVD
/LD
123
456
789
0CH
ENTER
Setup
Secret No. Clear
MENU
Parental CTRL
Secret No.
No
Yes
Setting parental control status
Used to enable or disable the parental control function.
1Press MENU.
2Press a/bto select “Setup”, and then press SET/
ENTER.
•Secret number setting menu displays only when
“Secret No.”is set. (See page 52.)
•V-CHIP and Status will not be selectable from the menu
if you do not first configure your secret number.
3Enter your 4-digit secret number with 0–9to cancel
the “Secret No.”when you set it.
4Press a/bto select “Parental CTRL”, and then
press SET/ENTER.
5Press a/bto select “Status”, and then press SET/
ENTER.
6Press a/bto select “On”or “Off”, and then press
SET/ENTER.
•Select “On”to enable and “Off”to disable Parental
CTRL.
7Press MENU to exit the menu.
A
•If the secret number is cleared the Status setting
automatically sets to “Off”. V-CHIP and Status will not
be selectable from the menu.
•Return to the previous menu by pressing MENU RETURN.
Setup
Secret No.
MENU
Parental CTRL
Secret No.
Secret No. Clear
RETURN
Secret number
setting menu
Setup
MENU
Secret No. –––
–

16.
Useful adjustment settings
How to temporarily release the V-CHIP
BLOCK
•The V-CHIP BLOCK is working and censors a
broadcast, “V-CHIP HAS BEEN ACTIVATED.”
displays.
1Press SET/ENTER while the V-CHIP is working and
then the secret number. setting menu displays.
2Enter your 4-digit secret number with 0–9and
then press SET/ENTER. At this time V-CHIP BLOCK
temporarily releases.
Reactivating the temporarily released V-CHIP
BLOCK
•You can reactivate the temporarily released V-CHIP
BLOCK as shown below.
Method 1:
Select Status setting (“On”or “Off”) from the
Parental CTRL menu to reactivate BLOCK.
Method 2:
Select V-CHIP setting (“MPAA”, “TV Guidelines”,
“Canadian English Ratings”or “Canadian French
Ratings”) from the Parental CTRL to reactivate
BLOCK.
Method 3:
Switch off the Media Receiver power.
A
•Performing any of the three above will activate the V-CHIP
BLOCK.
TV
ANT INPUT
SURR
FRONT
AV
SELECTION
MTS CC
SPLIT
SELECT
SUB SUB CH
ⴐ
ⴐ
ⴑ
ⴐ
ⴑ
FREEZE MODE
CH VOL
RETURN
CH
MUTING
MENU TV/SAT/DVD
FAVORITE CH
RECEIVER
DTV/DVD TOP
SOURCE DTV/SAT
DTV/SAT
VCR REC
ABCD
RETURN MENU
PLASMA DISPLAY
SET/
ENTER
MENU
GUIDE
INPUT VOL
ⴑ VOL ⴐ
INFO
SCREEN
SLEEP LEARNEDIT/ DISPLAY
INPUT ⴑ
TV VCRCBL
/SAT
/DTV
DVD
/LD
123
456
789
0CH
ENTER

17.
FREEZE
Picture and still image
You can display two same-sized pictures when
inputting from a AV source.
1Press FREEZE.
• A moving image displays on the left screen and a still
image displays on the right screen. The still image is
one frame captured from a moving image at the
moment you press FREEZE.
2Update the still image by pressing SET/ENTER.
• Each time you press SET/ENTER, the image on the
right screen updates.
3Press FREEZE to exit still image.
A
• This function does not work under the following input
conditions:
1PC INPUT mode,
2Images from a high frequency signal source.
• When this function is not available, “No still image display
available.” will display.
TV
ANT INPUT
SURR
FRONT
AV
SELECTION
MTS CC
SPLIT
SELECT
SUB SUB CH
ⴐ
FREEZE MODE
SCREEN
SLEEP LEARNEDIT/ DISPLAY
INPUT ⴑ
TV VCRCBL
/SAT
/DTV
DVD
/LD
FAVORITE CH
RECEIVER
SOURCE DTV/SAT
DTV/SAT
VCR REC
ABCD
PLASMA DISPLAY
SET/
ENTER
GUIDE
INPUT VOL
ⴑ VOL ⴐ
INFO
Useful features
Multiscreen functions
Allows you to display two pictures on the screen at one time.
Dual screen
You can display two same-sized pictures except when
inputting from a PC INPUT terminal.
1Press SPLIT.
• Dual screen displays and a selected input source
image displays.
2Press SELECT to set either screen to be active.
•“z” displays on the active screen, which has sound
output.
3Press SUB CHee
ee
e/ff
ff
f to select another channel on
the inactive screen.
4Press SUB INPUT to select another input source
on the inactive screen.
• A selected image displays.
5Press SPLIT to exit dual screen.
A
• This function does not work under the following input
conditions:
1PC INPUT mode,
2Two pictures from the same source (e.g. INPUT 1 and
INPUT 1),
3Images from a high frequency signal source.
• When this function is not available, “No dual screen display
available” will display.
TV
ANT INPUT
SURR
FRONT
AV
SELECTION
MTS CC
SPLIT
SELECT
SUB SUB CH
ⴐ
FREEZE MODE
SCREEN
SLEEP LEARNEDIT/ DISPLAY
INPUT ⴑ
TV VCRCBL
/SAT
/DTV
DVD
/LD

18.
Appendix
• No power.
• Unit cannot be operated.
• Remote control unit does not
operate.
• Picture is cut off/with sidebar
screen.
• Strange color, light color, dark or
color misalignment.
• Power is suddenly turned off.
• No picture.
Problem Possible Solution
• Make sure the Plasma Display and the Media Receiver are connected correctly.
•Check if you pressed TV aon the remote control unit.
If the indicator on the Plasma Display lights up red, press TV a.
•Is the power cord disconnected?
•Has the main power been turned on?
• External influences such as lightning, static electricity, may cause improper
operation. In this case, operate the unit after first turning on the power of the
Plasma Display and the Media Receiver, or unplugging the power cord and
replugging it in after 1 or 2 minutes.
• Is the Mode switch set correctly? Slide it to the TV setting position.
•Are batteries inserted with polarity (e,f) aligned?
• Are batteries worn out? (Replace with new batteries.)
• Are you using it under strong or fluorescent lighting?
• Is a fluorescent light illuminated near the remote control sensor?
•Is the image position correct?
•Are screen mode adjustments such as picture size made correctly?
•Adjust the picture tone.
• Is the room too bright? The picture may look dark in a room that is too bright.
•Check the input signal setting.
•Is the sleep timer set?
•Check the power control setting.
• The unit’s internal temperature has increased.
Remove any objects blocking vent or clean.
•Is connection to other components correct?
•Has setup been done correctly after connection?
•Is the correct input selected?
•Is a non-compatible signal being input?
•Is picture adjustment correct?
Problem with Plasma Display System
Warning Possible Solution
• System cable connection
• Abnormal internal temperature
• Abnormal internal signaling or circuit
operation of the Plasma Display
• System cables are not properly connected. Check that
all system cables are connected properly.
• The internal temperature of the Plasma Display is
abnormally high. Check the location the System is
installed.
•Turn off the power once and turn it on again.
E01
E04
E06
Please check to see if a warning is displayed on the screen. If the problem still cannot be solved please consult the dealer
where this unit was purchased.
Troubleshooting

19.
640400
720400
640480
800600
832624
1024768
1280768
85 Hz
70 Hz
85 Hz
60 Hz
65 Hz
72 Hz
75 Hz
85 Hz
56 Hz
60 Hz
72 Hz
75 Hz
85 Hz
74.5 Hz
60 Hz
70 Hz
75 Hz
85 Hz
60 Hz
Computer compatibility chart
Apple and Macintosh are registered trademarks
of Apple Computer, Inc.
Microsoft is a registered trademark of Microsoft
Corporation.
DDC is a registered trademark of Video Electronics
Standards Association.
Power Management is a registered trademark of
Sun Microsystems, Inc.
VGA and XGA are registered trademarks of
International Business Machines Co., Inc.
Remarks
Macintosh 13 (67 Hz)
Macintosh 16
Macintosh 19
Resolution Frequency

20.
HOW TO SET THE FACTORY PRESETTINGS
Press and hold down CLEAR on the Media Receiver while it is in standby mode. Then press STANDBY/ON
on the Plasma Display or TV aon the remote control unit to turn the Plasma Display System on.
All setting items (except TV channel) return to the factory presetting.
A
•Running the factory presetting operation also clears the secret number.
You can run the Auto Installation again by using the following steps.
1Turn on the power of the Plasma Display and the Media Receiver.
2Press MENU. (Make sure the menu screen displays.)
3Press a/bto select “Setup”.
4Press SET/ENTER.
A
•If the secret number setting screen displays, you need to enter your secret number.
•If you forget your secret number, refer to HOW TO SET THE FACTORY PRESETTINGS above.
5Press a/bto select “Auto Installation”.
6Press SET/ENTER.
“Auto Installation completed”displays. After that, the screen changes to the TV mode.
*1SRS and the symbol are trademarks of SRS Labs, Inc.
SRS technology is incorporated under license from SRS Labs, Inc.
*1FOCUS and the symbol are trademarks of SRS Labs, Inc.
FOCUS technology is incorporated under license from SRS Labs, Inc.
A
•Products above are a trademark or registered trademark of corporation.
A
•As a precautionary measure, make a note of your secret number above, scissor it from this manual, and keep it in a
familiar place.
The secret number is .
