Pioneer Elite VSX-41 User manual

ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2002
RRV2614
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
T – ZZK MAY. 2002 Printed in Japan
Model No. Order No. Remarks
VSX-D811S/KUXJI RRV2583
¶This service manual should be used together with the following manual(s):
AUDIO/VIDEO MULTI-CHANNEL RECEIVER
VSX-41
Type Model Power Requirement Remarks
VSX-41
KUXJI/CA AC120V

VSX-41
2
jpfy
For the applying amount of lubricants or glue, follow the instructions in this manual.
(In the case of no amount instructions, apply as you think it appropriate.)
1. CONTRAST OF MISCELLANEOUS PARTS
CONTRAST TABLE
VSX-41/KUXJI/CA and VSX-D811S/KUXJI are constructed the same except for the following :
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
Reference Nos. indicate the pages and Nos. in the service manual for the base model.
NOTES:
Notes : For PCB ASSEMBLIES, Refer to “CONTRAST OF PCB ASSEMBLIES” and “2. SCHEMATIC DIAGRAM”.
Part No.
Ref. No. Mark Symbol and Description VSX-D811S VSX-41 Remarks
/KUXJI /KUXJI/CA
PCB ASSEMBLIES
P9 - 1 DD & INPUT ASSY XWX3049 XWX3052
NSP AMP&PS ASSY XWK3059 XWK3063
P9 - 2 AMP&PRIMARY ASSY XWZ3539 XWZ3543
NSP COMPLEX ASSY XWK3046 XWK3051
P9 - 8 6CH IN ASSY XWZ3508 XWZ3509
P9 - 9 DIGITAL IN ASSY XWZ3519 XWZ3520
P9 - 10 S. VIDEO ASSY XWZ3522 XWZ3523
P9 - 11 COMPORNENT ASSY XWZ3524 XWZ3525
P9 - 14 PRE-OUT ASSY XWZ3530 XWZ3531
P9 - 15 VIDEO ASSY XWZ3583 XWZ3491
P11 - 1 FRONT ASSY XWZ3501 XWZ3506
P11 - 6 R. ENCODER ASSY XWZ3582 XWZ3512
PACKING SECTION
P7 - 4 NSP Dry Cell Batteries (AA/R6P) VEM-013 Not used
P7 - 4 NSP Dry Cell Batteries (AA/LR6) Not used VEM1021
P7 - 5 Operating Instructions (English) XRB3013 XRB3018
P7 - 7 Remote Control Unit XXD3043 XXD3046
P7 - 13 Packing Case XHD3202 XHD3310
EXTERIOR SECTION
P9 - 40 Rear Panel XNC3141 XNC3175
FRONT PANEL SECTION
P11 - 18 D Panel R5 W XAK3274 XAK3345
P11 - 19 BN Cover XAK3294 XAK3319
P11 - 21 Pioneer Badge XAM3006 VAM1109
P11 - 24 Front Panel XMB3063 XMB3090
P11 - 30 Door Assy XXG3091 XXG3132
P11 - 31 NSP Door XAK3275 XAK3344
•When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
560 Ω→56 × 101→561 ........................................................ RD1/4PU 56
1
J
47k Ω→47 × 103→473 ........................................................ RD1/4PU 47
3
J
0.5 Ω→R50 ..................................................................................... RN2H
R 5
0K
1 Ω→1R0 ..................................................................................... RS1P 1
R 0
K
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
5.62k Ω→ 562 × 101→5621 ...................................................... RN1/4PC
5 6
2
1
F

VSX-41
3
XWX3052 and XWX3049 are constructed the same except for the following :
DD & INPUT ASSY
Mark Symbol and Description Part No. Remarks
XWX3049 XWX3052
JA101–JA104 (4P PIN JACK) AKB7048 AKB7108
F
A
CONTRAST OF PCB ASSEMBLIES
XWZ3520 and XWZ3519 are constructed the same except for the following :
DIGITAL IN ASSY
Mark Symbol and Description Part No. Remarks
XWZ3519 XWZ3520
C1927 Not used CKSRYB104K25
R1915 Not used RS1/16S101J
JA1901, JA1907 (1P PIN JACK) VKB1077 VKB1074
JA1906 (OPT. LINK OUT 12MB/S) Not used JFJ3000-010020
F
J
XWZ3543 and XWZ3539 are constructed the same except for the following :
AMP&PS ASSY
F
B
Mark Symbol and Description Part No. Remarks
XWZ3539 XWZ3543
C701, C702 (4700µF/71V) ACH7137 Not used
C701, C702 (5600µF/71V) Not used XCH3005
XWZ3523 and XWZ3522 are constructed the same except for the following :
S. VIDEO ASSY
Mark Symbol and Description Part No. Remarks
XWZ3522 XWZ3523
CN352 (3-4P MIN DIN SOCKET) AKP7043 Not used
CN353 (2-4P MIN DIN SOCKET) AKP7020 AKP7023
JA352 (3-4P MIN DIN SOCKET) Not used AKP7049 For CN352
F
N
XWZ3491 and XWZ3583 are constructed the same except for the following :
VIDEO ASSY
Mark Symbol and Description Part No. Remarks
XWZ3583 XWZ3491
CN305 (6P PIN JACK) AKB7123 XKB3018
F
L
XWZ3509 and XWZ3508 are constructed the same except for the following :
6CH IN ASSY
Mark Symbol and Description Part No. Remarks
XWZ3508 XWZ3509
308 (6P PIN JACK) AKB7089 AKB7088
F
M

VSX-41
4
XWZ3506 and XWZ3501 are constructed the same except for the following :
FRONT ASSY
Mark Symbol and Description Part No. Remarks
XWZ3501 XWZ3506
R428 Not used RS1/16S472J
R429 RS1/16S0R0J RS1/16S622J
F
O
XWZ3525 and XWZ3524 are constructed the same except for the following :
COMPORNENT ASSY
F
V
Mark Symbol and Description Part No. Remarks
XWZ3524 XWZ3525
JA551 (6P PIN JACK) AKB7128 AKB7127
JA553 (3P PIN JACK) AKB7124 XKB3022
XWZ3512 and XWZ3582 are constructed the same except for the following :
R. ENCODER ASSY
Mark Symbol and Description Part No. Remarks
XWZ3582 XWZ3512
D512 SLI-343DCW(STU) E1L4E-7B1A(2345)
F
P
XWZ3531 and XWZ3530 are constructed the same except for the following :
PRE-OUT ASSY
Mark Symbol and Description Part No. Remarks
XWZ3530 XWZ3531
1575 (6P PIN JACK) AKB7089 AKB7088
F
W

VSX-41
5
1234
1234
C
D
F
A
B
E
VSX-41
VSX-41
NO USE
NO USE
NO USE
DIGITAL IN ASSY
(XWZ3520)
CN9101
CN951
T
A2/4
J F
2. SCHEMATIC DIAGRAM
2.1 DIGITAL IN ASSY
Note : When ordering service parts, be sure to refer to "EXPLODED VIEWS and PARTS LIST" or "PCB PARTS LIST"
F
J

VSX-41
6
1234
1234
C
D
F
A
B
E
2.2 FRONT ASSY
F
O
VSX-41
/KUXJI/CA
FRONT ASSY
(XWZ3506)
O F
