Pioneer VSX-D488 Use and maintenance manual

ORDER NO.
PIONEER ELECTRONIC CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER ELECTRONIC (EUROPE) N.V. Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER ELECTRONIC CORPORATION 1999
RRV2098
T – ZZK JAN. 1999 Printed in Japan
¶Refer to the service manual RRV1911 for VSX-D507S/KUXJI.
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model
VSX-D488
Type Power Requirement Remarks
KUXJI
KCXJI
AUDIO/VIDEO MULTI-CHANNEL RECEIVER
VSX-D488
‡AC120V
‡AC120V

VSX-D488
2
1. CONTRAST OF MISCELLANEOUS PARTS
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
Reference Nos. indicate the pages and Nos. in the service manual for the base model.
NOTES:
CONTRAST TABLE
VSX-D488/KUXJI and VSX-D507S/KUXJI are constructed the same except for the following :
PACKING
P3- 3 Operating Instructions (English) ARB7134 ARB7179
P3- 4 NSP Warranty Card ARY1051 ARY7023
P3- 5 Remote Control Unit (CU-VSX127) AXD7158 Not used
P3- 5 Remote Control Unit (CU-VSX154) Not used AXD7211 *1
P3-11 Packing Case AHD7554 AHD7731
P3-13 Sub Instructions (English) ARH7033 Not used
EXTERIOR SECTION
P5-14 AC Power Cord PDG1063 PDG1064
P5-19 Rear Panel ANC7624 ANC7797
FRONT PANEL SECTION
P6-17 Front Panel AMB7486 AMB7607
P6-19 PIONEER Badge PAM1755 PAM1776
Part No.
VSX-D507S
/KUXJI
Ref. No. Symbol and Description Remarks
Mark VSX-D488
/KUXJI
VSX-D488/KCXJI and VSX-D507S/KCXJI are constructed the same except for the following :
PACKING
P3- 3 Operating Instructions (English/French) ARE7165 ARE7203
P3- 4 NSP Warranty Card ARY1075 ARY7024
P3- 5 Remote Control Unit (CU-VSX127) AXD7158 Not used
P3- 5 Remote Control Unit (CU-VSX154) Not used AXD7211 *1
P3-11 Packing Case AHD7601 AHD7731
P3-13 Sub Instructions (English) ARH7033 Not used
EXTERIOR SECTION
P5-14 AC Power Cord PDG1063 PDG1064
P5-19 Rear Panel ANC7670 ANC7798
FRONT PANEL SECTION
P6-17 Front Panel AMB7486 AMB7607
P6-19 PIONEER Badge PAM1755 PAM1776
Part No.
VSX-D507S
/KCXJI
Ref. No. Symbol and Description Remarks
Mark VSX-D488
/KCXJI
*1 : refer to “2. REMOTE CONTROL UNIT [CU-VSX154 (AXD7211)]”.
*1 : refer to “2. REMOTE CONTROL UNIT [CU-VSX154 (AXD7211)]”.

VSX-D488
3
2. REMOTE CONTROL UNIT [CU-VSX154 (AXD7211)]
2.1 EXPLODED VIEWS AND PARTS LIST
•Parts List
Mark No. Description Part No.
1 Filter AZA7152
2 Name Plate AZA7323
3 Rubber Sheet (A) AZA7324
4 Rubber Sheet (B) AZA7322
5 Spring (+) AZB7049
6 Spring (–) AZB7050
7 Spring AZB7051
8 Screw AZB7052
9 Remo-con Case (A) AZN7766
10 Remo-con Case (B) AZN7326
11 Battery Cover AZN7327
12 Main Key (FF) AZN7666
13 Main Key (STOP) AZN7767
14 Main Key (REV) AZN7665
15 Main Key (PAUSE) AZN7768
16 Main Key (PLAY) AZN7765
NSP 17 PCB AZW7248
2
9
13
12
16
15
14
3
17
1
10
8
11
7
6
5
4
NOTES: •Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
•The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
•Screws adjacent to mark on the product are used for disassembly.

VSX-D488
4
A
B
C
D
1234
1234
8 16 24 32 40 7 15 23 31 39 6 14 22 30 38 5 13 21 29 37
4 12 20 28 36 3 11 19 27 35 2 10 18 26 34 1 9 17 25 33
No.
128
27 26 25 24 23 22 21 20 19 18 17 16 15
3.0V
T5
T4T3
T1
X1
4.0MHz
T2
D2
RLS-73
KEY No.
R3
47Ω
R7
100kΩ
R6
100kΩ
R1
1.8ΩR2
220Ω
IC1
AZC7284
R18
0
Q4Q3Q2 R5
100kΩ
R10 R13
R16R15R14
R12R11
R9R8 D11
D14
D17
D1
SE303A-C
C3
1/50
C4
1/50
Q1
2SC3265
D16D15
D13D12
D10D9
Q2 - Q4 : RN4605 ×3
D9 - D17 : CL-230HR-CD ×9
R8 - R16 : 240Ω×9
P0D1 P0D0 P0C3 P0C2 P0C1 P0C0
P0B3 P0B2 P0B1 P0B0 P0A3 P0A2 P0A1 P0A0
2 3 4 5 6 7 8 9
10 11 12 13 14
P0D2 P0D3
P0D3 P0D2 P0D1
P0E3 P0E2 P0E0
INT P0E0 P0E1 P0E2 P0E3 REM VDD XOUT XIN GND RESET WDOUT
C1
220/6.3 C2
47/10
K01 : AMP (POWER) K02 : TV (POWER) K03 : MUTING K04 : POWER K05 : TV FUNC. K06 : VOL.- K07 : VOL.+ K08 : K09 : K10 : K11 : K12 : ENT. K13 : CH- K14 : CH+ K15 : DVD K16 : LD/SAT K17 : CD K18 : VCR1 K19 : TUNER K20 : TV CONTROL K21 : No key K22 : SURROUND K23 : No key K24 : 1 K25 : 2 K26 : 3 K27 : 4 K28 : 5 K29 : 6 K30 : 7 K31 : 8 K32 : 9 K33 : 10 (0) K34 : 11 (+10) K35 : 12 (DISC) K36 : No key K37 : FUNCTION K38 : MODE CHECK K39 : No key K40 : COMMANDER SET UP
SWITCHES
Note : When ordering service parts, be sure to refer to "EXPLODED VIEWS and PARTS LIST" or "PCB PARTS LIST"
2.2 SCHEMATIC DIAGRAM

VSX-D488
5
A
B
C
D
1234
1234
2.3 PCB DIAGRAM
K01
K04
K10
K12
K11
K09
K03
K07
K05
K06
K13
K15
K02
K08
K14
K16 K17
K18
K24
K20 K19
K21
K37 K36 K38
K39 K40
K22 K23
K25 K26 K27
K33
K28 K29 K30
K32 K34 K35
K31
SIDE A SIDE B

VSX-D488
6
2.4 PCB PARTS LIST
Mark No. Description Part No.
SEMICONDUCTORS
IC1 AZC7284
Q1 2SC3265
Q2-Q4 RN4605
D1 SE303A-C
D2 RLS-73
D9-D17 CL-230HR-CD
CAPACITORS
C2 CEAT470M10
C1 CEAT221M6R3
C3,C4 CEATR10M50
RESISTORS
R1 RS1/8S1R8J
Other Resistors RS1/10S J
OTHERS
X1 CERAMIC RESONATOR KBR-4.0M
(4MHz)
NOTES: •Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
•The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
•When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
560 Ω→56 × 101→561 ........................................................ RD1/4PU 56
1
J
47k Ω→47 × 103→473 ........................................................ RD1/4PU
4 7
3J
0.5 Ω→R50 ..................................................................................... RN2H R5
0
K
1 Ω→1R0 ..................................................................................... RS1P 1R
0
K
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
5.62k Ω→ 562 × 101→5621 ...................................................... RN1/4PC 56
2
1F
