Pioneer 2 / PeopleBot User manual

Pioneer 2 / PeopleBot
Operations Manual
for P2OS-based ActivMedia Robots
TM
PIONEER 2-DXEPIONEER 2-AT PEOPLEBOT
TM

Copyright © 2002, ActivMedia Robotics, LLC. All rights reserved.
Under international copyright laws, this manual or any portion of it may not be copied or
in any way duplicated without the expressed written consent of ActivMedia Robotics.
The software on disk and on the microcontroller ROM, which accompany the robot, and
are available for network download by ActivMedia Robotics customers, are solely
owned and copyrighted or are licensed products distributed by ActivMedia Robotics.
Developers and users are authorized by revocable license to develop and operate
custom software for personal research and educational use only. Duplication,
distribution, reverse-engineering, or commercial application of the ActivMedia Robotics
software and hardware without the expressed written consent of ActivMedia Robotics,
LLC, is explicitly forbidden.
The various names and logos for products used in this manual are often registered
trademarks or trademarks of their respective companies. Mention of any third-party
hardware or software constitutes neither an endorsement nor a recommendation.
ActivMedia Robotics Pioneer 2/PeopleBot Operations Manual v10, July 2002
ii

ActivMedia Robotics
Important Safety Instructions
! Read the installation and operations instructions before using the equipment.
! Avoid using power extension cords.
! To prevent fire or shock hazard, do not expose the equipment to rain or moisture.
! Refrain from opening the unit or any of its accessories.
! Keep wheels away from long hair or fur.
Inappropriate Operation
Inappropriate operation voids your warranty! Inappropriate operation includes, but is
not limited to:
! Dropping the robot, running it off a ledge, or otherwise operating it in an
irresponsible manner
! Overloading the robot above its payload capacity
! Getting the robot wet
! Continuing to run the robot after hair, yarn, string, or any other items have
become wound around the robot’s axles or wheels
! All other forms of inappropriate operation or care
iii
