Gripper & Experimenter’s Module
1
1. Introduction
ongratulations on your purchase and welcome to the rapidly
growing community of researchers, developers, and
enthusiasts of the Pioneer 1 Mobile Robot.
This Pioneer 1 Gripper & Experimenter’s Module Manual
provides the general and technical details you will need to install
and operate your new Gripper and to develop your own
attachments and enhancements for the Pioneer 1 Mobile Robot with the integrated
Experimenter’s Module.
We also encourage you to use these companion resources that come with your
Pioneer:
9 Pioneer Operation Manual
9 Saphira Software Manual
9 Pioneer Registration & Account Sheet
9 Personal account for the http://css.activmedia.com Internet server
9 Pioneer- and [email protected] support newsgroups
2.1 Gripper and Experimenter’s Package
Our experienced robotics manufacturing staff put your Pioneer 1 Gripper and
Experimenter’s Module through a “burn-in” period and carefully tested them before we
shipped the hardware and software to you. Our care extends beyond: Besides the
companion resources listed above that bring the whole community of Pioneer to you, we
warranty the Gripper and Experimenter’s Module against mechanical and electronic parts
and labor defects for 90 days. All of these precautions ensure that you have many years
to enjoy your new accessories for the Pioneer 1 Mobile Robot.
Even though we’ve made every effort to make your package complete, please check
the components once again after you unpack it from the shipping crate.
2.1.1 Package Components
9 Pioneer 1 Gripper & Experimenter’s Module Assembly
9 32K EPROM containing latest PSOS
9 Gripper & Experimenter’s Module Manual
2.1.2 User Supplied Components
9 Pioneer 1 Mobile Robot
9 Set of hex wrenches that accompanied original robot
9 Small, flat-bladed screwdriver
9 Optional “chip-puller” tool
C

Overview
2
2.2 Basic Pioneer Platform
Pioneer 1 is a small, mobile robot developed by Kurt Konolige of SRI International
and Grinnell More of Real World Interface, Inc., and is available exclusively through
ActivMedia, Inc.
The basic Pioneer 1 Mobile platform contains all of the components for sensing and
navigation in a real-world environment, including battery power, drive motors and
wheels, position encoders, and ultrasonic sonar transducers—all managed via an
MC68HC11-based microcontroller board (Figure 1-1).
Figure 1-1. Basic components of the Pioneer 1.
The Pioneer 1 also comes with the Pioneer Server Operating System (PSOS) software
on EPROM for easy access and control of the robot’s systems, an RS232 serial port for
communication between the robot and other computers, as well as a variety of expansion
I/O ports for optional and custom attachments.
2.3 The Gripper & Experimenter’s Module
The Pioneer 1 Experimenter’s Module essentially is a circuit board and accessory
electronics that extend the capabilities of the Pioneer 1 microcontroller’s standard I/O
ports, including electrical support for the Pioneer Gripper. The Experimenter’s Module is
part of the Pioneer Gripper assembly, which together replace the nose the of basic robot
(see Figures 1-1 and 1-2 and Chapter 2, Installation).
2.3.1 Gripper Description
The Pioneer Gripper is a simple, yet powerful 2-DOF robotic manipulator and sensor
(Figure 1-2 and Figure 1-3). Driven by a single, reversible-DC servo-motor under control
of the Pioneer microcontroller, it operates between two states: down/open and up/closed.

Gripper & Experimenter’s Module
3
Figure 1-2 Pioneer Gripper side view.
Figure 1-3. Pioneer Gripper top view
In its fully down/open state, the two 2.5 inch (5cm) tall by 3.5 inch (9.5cm) deep
Gripper paddles (each with 0.5cm foam pads on the inside) are 8.5 inches (21.5cm) apart
and ride 1 inch (2.3cm) off the floor. The paddles extend out from the front robot’s main
body 3 inches (10cm) beyond the console edge.

Overview
4
In transition from the fully down/open position to their up/closed state, the Gripper
paddles close together horizontally until they pinch an object or close on themselves. At
that point, the entire Bar and Gripper Assembly rises up vertically—with or without an
object in its grasp. Under software control, the Gripper then rises to a special “carry”
position or all the way to the top of the Gripper case 4 inches (10.5 cm) off the floor to its
closed/up position. It is not normally possible to open the Gripper at this state.
The reverse cycle lowers the Gripper Bar and paddles to the bottom of the assembly,
whereupon the paddles separate, dropping any contents, and open to their fully
down/open position.
Two “bump” switches—one on each paddle tip—sense contact with objects. IR-based
“break beams” embedded at the front and back of each paddle sense objects between and
within the Gripper’s grasp.
Three other switches sense the Gripper’s paddle positions. One switch inside the Bar is
on when the Gripper paddles are in their fully open position. Another at the top of the
Bar toggles on when the Gripper reaches its fully up position. A third “carry” switch,
located behind the Bar, indicates when the Gripper is between 1.5 and 2 inches (4-5cm)
off the floor.
2.3.2 Experimenter’s Module Description
The Experimenter’s Module includes several additional features that users may enable
through the Pioneer I/O controls: There are green “directional” LEDs embedded in the
tip of each paddle and at the top of each side, facing front on the Gripper’s back plate.
On the left side of the Gripper, there is a speaker, an SPST on-off slide switch, a
momentary push-button switch, and another LED (amber).
Figure 1-4. Pioneer 1 Experimenter’s Module
Inside and on the Experimenter’s Module is a bank of eight RC-servo controller ports.
Layout/solder pads with DC power and I/O port connections supplied by the Pioneer
microcontroller also are on the Module card, as well as eight multiplexed analog-to-

Gripper & Experimenter’s Module
5
digital ports. There also is circuitry and a connector for an as-yet-implemented remote-
controller IR.
A complete list of available I/O ports and connections can be found in Chapter 4,
Experiment’s Module.
2.4 Additional Resources
Every Pioneer 1 customer gets three additional and valuable resources: a private
account on ActivMedia’s Internet server for downloading Pioneer software, updates, and
manuals, access to RWI’s private robotics newsgroups, and E-mail access to the Pioneer
1 support team.
2.4.1 Pioneer Web Software Archive
We have a World Wide Web server connected continuously to the Internet where
customers may obtain Pioneer 1 software and support materials. Point your favorite Web
browser to:
http://css.activmedia.com
Some access areas are restricted to licensed customers, including Pioneer owners. To
gain restricted access, use the username and password that are written on the Pioneer 1
Registration & Account Sheet that accompanied your robot.
2.4.2 Pioneer and Saphira Newsgroups
RWI also maintains a special E-mail-based newsgroup for Pioneer 1 owners and
Saphira programmers to share ideas, software, and questions. We strongly encourage you
to sign up. For details, send E-mail:
To: [email protected]
From: <your return E-mail address goes here>
Subject: help (Subject: always ignored)
(body of message—choose one or more commands:)
help (returns instructions)
lists (returns list of newsgroups)
subscribe <list name here> (waddayatink?)
unsubscribe <list name here> (ditto)
end

Overview
6
2.4.3 Support
Have a problem? Can’t find the answer in this or any of the accompanying manuals?
Know a way that we might improve Pioneer 1? Share your thoughts and questions
directly with us:
[email protected]
Your message goes to our team of Pioneer developers who will help you directly or
point you to where you may find help. Because this is a support option, not a general-
interest newsgroup like Pioneer-users described above, we must reserve the option to
reply only to questions about bugs or problems with Pioneer 1 and its accessories.

Gripper & Experimenter’s Module
7
3. Installation
lease read through this chapter carefully before you attempt to attach the Gripper
& Experimenter’s Module to your Pioneer 1 Mobile Robot. If for any reason you
do not wish to perform the work yourself, contact RWI and make arrangements to
have the assembly installed at the factory.
On the other hand, skip this chapter altogether if your Pioneer 1 Mobile Robot came
with the Gripper & Experimenter’s Module Assembly already attached.
Turn OFF the Pioneer robot’s Main Power before installing the
Gripper & Experimenter’s Module.
3.1.1 Step 1: Remove the Console
The Gripper & Experimenter’s Module Assembly’s various ports and accessories
connect to the Pioneer microcontroller’s power and expansion I/O. Also, software
support is provided through a special Pioneer Server Operating System (PSOS), which is
stored on a 32K EPROM mounted on the microcontroller. Accordingly, to install the
Gripper/Experimenter’s Module and new PSOS, you must first disassemble the Pioneer
Console.
With one of the hex wrenches that came with your robot, remove the six outermost
screws that secure the top plate to the Console—two on the front (including camera, if
attached) and two on each side.
If one is attached, carefully unplug and remove the Pioneer camera from the Console
and back panel. Also unscrew and remove the radio modem antenna, if attached.
Twist counter-clockwise to remove, and
twist clockwise to insert the various screws.
Gently lift the Console top plate to expose the microcontroller board, which is
mounted to its underside, and the various wire harnesses attached to it. Being careful to
not handle the attached microcontroller card, remove the wire connectors on both sides of
the card from their sockets, freeing the Console top plate with the microcontroller card
attached.
3.1.2 Step 2: Remove Microcontroller from Console
Lay the Console top plate face up, with the Pioneer 1 microcontroller card down, onto
a clean, soft surface (first section of the Sunday Times is a great pad). Locate and remove
the six hex screws—one in each side and two in the middle—which secure the
microcontroller board to the Console top plate. Separate the parts. The microcontroller
board should be exposed now, face-up on the table (Figure 2-1).
P

Installation
8
Figure 2-1. Pioneer 1 microcontroller card
3.1.3 Step 3: Replace the
PSOS EPROM
Locate the EPROM/SRAM socket
(Figure 2-2) on the microcontroller
card and note that the Pin 1 locator
notch on its case is towards the outer
edge of the board—you’ll want to
similarly position the new PSOS
EPROM.
Pry or pull out the socketed
EPROM chip. We’d prefer that you
use a special “chip-puller” tool, but
if one isn’t handy, use a thin, flat-
bladed screwdriver and gently pry
up each end of the chip until it lifts
out of the socket freely.
EPROM chips are sensitive to static electricity. Be careful to handle
them by their case and store them on conductive foam. Don’t touch
the pins with your fingers, and be particularly careful not to bend
any of their 28 delicate connector pins.
Now carefully remove the new PSOS EPROM that came with the Gripper/
Experimenter’s Module from its protective foam and insert it into the EPROM socket. Be
sure to line up the Pin 1 notch and insert the pins in their respective socket holes. Then
Figure 2-2. Location of the EPROM socket

Gripper & Experimenter’s Module
9
press carefully, but firmly down on the chip with your thumb or forefinger to seat it
tightly in the socket.
3.1.4 Step 4 Reattach Microcontroller to Console
By reversing the procedures you took in Step 2 and using the same tools and screws,
reattach the Pioneer microcontroller to the Console top plate. Set the entire assembly
aside for the moment in a safe place.
3.1.5 Step 5 Remove Nose
The Gripper/Experimenter’s Module replaces the Pioneer’s nose. Use the hex
wrenches that came with your robot to remove the six screws that secure the Nose to the
Pioneer Deck and Body: four on top of the Deck and one on each side at the bottom.
Store the Nose away.
3.1.6 Step 6 Connect Cables
Place the Gripper/Experimenter’s assembly on top of a table close to and in front of
the Pioneer, with the Module card and attached flat ribbon cables facing the robot’s
Nose. Push those three cables’ free connector ends through the opening in the nose and
up into the Console. Similarly, push the Pioneer’s power cable through and out the Nose.
Plug the power cable attached to the Pioneer robot into its new 12-pin socket on the
Experimenter’s Module just below the accessory’s power cable and socket. The cable’s
yellow wires should point towards the center of the Module.
CAUTION: HOT POWER CABLE!
The Pioneer power cable is connected, unswitched, directly to the
battery. Be careful to align the connector with its socket.
Misalignment may cause damage to the Pioneer microcontroller or
to the Experimenter’s Module.
You may find that first unplugging the new power cable connector from its socket on
the Module will expose the lower socket for easier attachment of the robot’s power
connector. Do re-insert the new power cable from the Module back into its socket before
proceeding with the installation. Do not switch the connectors, plugging the robot’s
power cable into the upper socket—otherwise, no damage will occur, but the Gripper will
activate without provocation.
3.1.7 Step 7 Attach Gripper/Experimenter’s Module to Pioneer
Use the hex wrenches that came with your robot and the screws you removed from the
robot’s Nose to attach the Gripper/Experimenter’s Module to the Deck (4 screws; no
screws attach to the Pioneer Body, as they do for the Nose).

Installation
10
3.1.8 Step 8 Re-Attach the Console Cables
Carefully handling the Console top plate with attached microcontroller by its edges,
reattach the various cables, front and back. Although the order is not critical, for
convenience we recommend attaching the front cables firstthe sonar and drive (left and
right) cables.
Then, to the sockets on the rear of the microcontroller, attach the 4-pin serial
connector, the new 16-pin Nose I/O and 26-pin General I/O connectors, and finally the
new power connector to their respective sockets.
3.1.9 Step 9 Re-Attach the Console
Align the Console top-plate with microcontroller on top the Console, and using the
tools and the screws from Step 2, reattach it to the robot body. Reattach the camera to the
front of the Console as well, if it is with your robot. Then plug the camera power and
signal cables back into their respective sockets on the Console back plate, and screw in
the antenna through the hole in the Console top plate and into the radio modem beneath.
3.1.10 Step 10 Test the Assembly
Time to switch on the Pioneer’s Main Power and sniff for blue smoke. If sparks don’t
fly and smoke is absent, the Pioneer will automatically exercise it’s new Gripper and
finish with three loud and firm beeps through the newly attached speaker—not that weak,
sniveling old “beep, beep” of the Gripper-less Pioneer, mind you, so keep sensitive
babies and weaklings clear.
You’ve completed assembly and now are ready to run your Pioneer’s brand new
gadgets. And for your troubles, you get two loose screws left over (they are the two
round headed ones that came out of the bottom of the Nose).

Gripper & Experimenter’s Module
11
4. Gripper Operation and Programming
he Pioneer Gripper comes fully integrated with the robot’s systems and software.
The latest versions of PSOS (4.2+) contains support for direct control of the
Pioneer’s onboard I/O that run the Gripper functions, as well as state-based
software control routines that manage the Gripper functions for you. In turn, these PSOS
functions are supported in Saphira (version 5.3+), the Pioneer Application Interface
(PAI), and Pioneer-LOGO. Consult the various Pioneer-related Operation and Software
Manuals for more details about PSOS, Saphira, PAI, and P-LOGO.
4.1 Gripper Self Test
Gripper-enabled versions of PSOS come with test routines for all the main functions
of the robot. This section describes the Gripper’s self-test. Consult the Pioneer 1
Operations and Software Manual for a detailed description of the location and operation
of the various Console function buttons and switches and for how to test the drive and
I/O systems, sonars, and processor.
Make sure the Pioneer motors are disengaged,
if you perform the Gripper self-test on a table top.
The Gripper self-test happens whenever you turn the Main Power on or press the Reset
button. The exercise first drives the Gripper Bar and paddles to their fully down and open
state, and then back up to their fully up and closed state.
Always place Pioneer 1 on the floor and have everyone step back
before engaging the motors.
You may also test the Gripper’s open, up, and carry state switches. See the
Experimenter’s Module, Digin I/O test mode section in Chapter 4 for details.
4.2 PSOS Server Information Packet
PSOS regularly sends Pioneer server information to a connected client over the serial
communication line. Included in that Server Information Packet are the various states and
readings from the Gripper and the Experimenter’s Module I/O. A summary of the PSOS
Server Information Packet is in the Appendix B. These various readings may be captured
and individually read by the client, or you may use the various Saphira, PAI, or P-LOGO
functions to manage the packet and read the values for you.
T

Gripper Operation and Programming
12
4.3 Gripper I/O
The Gripper’s single drive motor is controlled through two digital output lines and
under control of the microcontroller CPU: Output port OD0 controls the direction of
rotation and OD1 enables/disables the motor.
The act of gripping and raising objects is mechanical and dependent on the Gripper’s
position—you cannot independently operate the gripper paddles. Rather, you drive the
motor in one direction or the other. The paddles automatically open when the Gripper is
being lowered and reaches the bottom of the assembly. In reverse, the paddles
automatically close upon themselves or an object and then rise.
Switches on top (“up”), inside at one end of the Bar (“open”), and behind the Bar
(“carry”) indicate the various Gripper (G) positions (Table 3-1). In addition, bump
switches on the tips of each paddle indicate collisions, and break beams (b-b) inside the
paddles indicate the position of an object within the grasp. We identify the various I/O
ports and connections by name in Table 3-1. Consult the Tables in Chapter 5 for their pin
locations on the General and Nose I/O connectors.
Table 3-1. Gripper motor controls and state switches
Name I/O port Meanings
G.motor OD0 rotate 1=down; 0=up
G.motor OD1 1=enable
top ID0 0= G at top
carry ID1 0=paddles closed, G 4-5cm above floor
open ID2 0=paddles fully open
inner b-b ID3 1=object inside
outer b-b ID4 1=object inside
bumps ID5 0=paddle tip touching object
4.4 Gripper Programming
You can directly control the Gripper motor through the PSOS sfCOMDIGOUT
command and byte parameters. PSOS also will accept a new state command,
sfCOMGRIPPER, to achieve a gripper state, and sets the gripper motor bits
appropriately. There also are some Saphira convenience functions defined for getting
and setting the gripper state. For details on programming PSOS directly and through
Saphira, consult the Saphira Software and Pioneer Operations and Software Manuals.
sfCOMDIGOUT control of Pioneer digital output ports has been
changed in PSOS version 4.2 and later.
4.4.1 Direct Control via Digital Ports

Gripper & Experimenter’s Module
13
The revised PSOS 4.2 (and later) sfCOMDIGOUT command has a two-byte
argument: The high byte is a mask of those output bits you want to change, and the low
byte is the bit pattern for the bits to change. This way, you don’t need to know the state
of the port(s) you want to change; just the state in which you want them to be, and you
won’t change the state of any of the other ports.
The Saphira function, sfRobotCom2Bytes, packages the sfCOMDIGOUT command
and values for you. For example:
sfRobotCom2Bytes(sfCOMDIGOUT, 0x20, 0x00)
resets bit 5 (OD0=0), and leaves everything else alone.
Accordingly, make the Gripper go up:
sfRobotCom2Bytes(sfCOMDIGOUT, 0x3, 0x3)
Go down:
sfRobotCom2Bytes(sfCOMDIGOUT, 0x3, 0x2)
And stop:
sfRobotCom2Bytes(sfCOMDIGOUT, 0x2, 0x00)
You have to monitor the various Gripper state switches to determine if and when it
achieves a particular state—fully down with paddles open, for instance—when setting the
Gripper’s control I/O ports directly (see below).
4.4.2 State Commands
A more intelligent means of controlling the Gripper is through PSOS
sfCOMGRIPPER command and state parameters. These automatically manage the
Gripper so to achieve some pre-defined state. PSOS also monitors and reports the
Gripper’s progress towards that state, saving you some coding time and effort. And the
state commands use a timeout feature to protect against unfortunate stalls or hang-ups.
To operate the Gripper this way, you simply issue a state command to the robot. You
don’t need to, but you may monitor the Gripper’s progress towards the state via bits 0
and 2 of the digout part of the server information packet (“sfROBOT.digoutput”). During
transitions, the state returned by the robot is set to sfGRIPMOVING. After successfully
achieving a state, the state returned is that state. If there is a time-out (6 seconds) without
achieving the state, the return state is set to sfGRIPOFF.
The various states and values are included in the script at the end of this chapter and
that you may including in your own C programs.
There also are several Saphira convenience functions defined for gripper states:
int sfGripperGetState (void)
Returns the robot gripper state setpoint
void sfGripperSetState (int state)
Sets the robot gripper state setpoint

Gripper Operation and Programming
14
Table 3-2. Gripper functions
/*************************************************************
* Gripper functions --- For setting and retrieving gripper states
* States are sfGRIPUP, sfGRIPDOWN, sfGRIPMIDDLE, sfGRIPOFF,
* and sfGRIPMOVING
* sfGRIPMOVING occurs only during transitions between states
* sfGRIPOFF can be set by the user, which means no state control
* sfGRIPOFF is set by the robot to indicate a timeout (6
* seconds) if a state is not achieved
*
**************************************************************/
/* states */
#define sfGRIPOFF 0
#define sfGRIPUP 1
#define sfGRIPMOVING 2
#define sfGRIPMIDDLE 4
#define sfGRIPDOWN 5
#define sfCOMGRIPPER 33
/* gripper control bits (DIGOUTPUT) */
#define sfGRIPSTATEMASK 0x05 /* picks out state bits in DIGOUTPUT */
#define sfGRIPMOTORBIT 0x02 /* motor bit, 0 is off, 1 is on */
#define sfGRIPDIRBIT 0x01 /* direction bit, 0 is down, 1 is up */
#define sfSPEAKERBIT 0x04
#define sfRIGHTLEDBIT 0x08 /* 0 is off, 1 is on */
#define sfLEFTLEDBIT 0x10
/* gripper sense bits (DIGINPUT) */
#define sfGRIPTOPBIT 0x01 /* top limit switch, 0 if hit */
#define sfGRIPMIDBIT 0x02 /* carry switch, 0 if hit */
#define sfGRIPBOTBIT 0x04 /*open limit switch, 0 if hit */
#define sfGRIPINIRBIT 0x08 /* inner break beam, 1 is beam break */
#define sfGRIPOUTIRBIT 0x10 /* outer break beam, 1 is beam break */
#define sfGRIPBUMPBIT 0x20 /* gripper bumpers, 0 is bump */
#define sfGRIPMOMBIT 0x40 /* momentary switch, 0 is pressed */
#define sfGRIPSPSTBIT 0x80 /* SPST switch, 0 is up */

Gripper & Experimenter’s Module
15
5. Experimenter’s Module
esides hosting the Gripper, the Experimenter’s Module brings several new
features to the Pioneer 1 Mobile Robot, and provides you with a platform for
adding your own robotics options and features (Figure 4-1):
9
Easy access to Pioneer digital I/O, A/D, and timer functions
9
Speaker with new PSOS “say” command
9
User-controlled LEDs and switches
9
8 RC-servo ports (RC0-7)
9
8 Analog-to-Digital Input Ports (AN0-7)
9
Range-finding IR connector
Figure 4-1. Experimenter’s Module.
5.1 I/O Ports
By cables connected to the Pioneer microcontroller, the Experimenter’s Module brings
both the Nose and General I/O expansion ports onto a single, open platform. All of ports
now appear as solderable connections alongside a components pad, complete with power
connections (Figure 4-1).
The I/O ports and their uses are summarized in Table 4-1. The Vcc ports supply logic
power, so use them for that purpose only. The Pioneer microcontroller has a single A/D
port that appears on both the General I/O connector and Nose I/O connector. This port is
multiplexed into eight A/D ports on the Experimenter’s platform. And special circuitry
on the Experimenter’s board lets you control up to eight separate RC servos.
B

Experimenter’s Module
16
Note also that the Nose (N) 16-pin and the General (G) 26-pin I/O connectors are
numbered odd pins on top and even pins on the bottom; not top, left to right, then bottom
left to right. The pinouts for the Nose connector, for example, are:
1 3 5 7 9 11 13 15
246810121416
Table 4-1. Pioneer I/O ports and connections
Label Connector/Pin Use
Digital Inputs
ID0 G7 Gripper top switch
ID1 G9 Gripper carry switch
ID2 G11 Gripper open switch
ID3 G13 Paddle inner break beam
ID4 G15 Paddle outer break beam
ID5 N5 Paddle bump switches
ID6 N3 User push-button switch
ID7 N1 User slide switch
Digital Outputs
OD0 G17 Gripper motor rotation direction
OD1 G19 Gripper motor enable
OD2 G21 User LED (amber)
OD3 G23 Right paddle and front LEDs
OD4 G25 Left paddle and front LEDs
OD5 N13 Speaker
OD6 N11 User servo motor logic
OD7 N9 User servo motor logic
Miscellaneous
A/D N7,G1 Analog-to-digital input
IDT G3 Timer input
ODT N15 Timer output
Logic Power
Ground N2,4,6,8,14,16; G2,4,10,12,14,16,18,20,22,24,26
+5 VDC N10,12; G6,8
