Pioneer PDP-S34-LR User manual

ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2005
RRV3143
T-ZZK APR. 2005 Printed in Japan
PDP-S34-LR
SPEAKER SYSTEM
XIN/UC
65S
This service manual is intended for qualified service technicians; it is not meant for the
casual do-it-yourselfer. Qualified technicians have the necessary test equipment and
tools, and have been trained to properly and safely repair complex products such as
those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability
of the product and may void the warranty. If you are not qualified to perform the repair
of this product properly and safely, you should not risk trying to do so and refer the
repair to a qualified service technician.
WARNING
This product contains lead in solder and certain electrical parts contain chemicals
which are known to the state of California to cause cancer, birth defects or other
reproductive harm.
Health & Safety Code Section 25249.6 – Proposition 65
PDP-S34-LR

2
1234
1234
C
D
F
A
B
E
PDP-S34-LR
FOR PRECAUTION OF REASSEMBLY AND DISASSEMBLY
The grille is attached to the baffle using double-sided self-adhe-
sive tape. To avoid damaging the grille, work with the speaker
on top of a blanket or similar, face up.
There are two slots in the lower part of the speaker. Insert a
screwdriver(-) into each slot and push down detach the lower
part.
Turn the speaker over and insert a screwdriver(-) between the
grille and the baffle. Taking care not to damage the baffle, push
down on the screwdriver(-) to prize the baffle and grille apart.
When reattaching the grille, use double-sided self-adhesive
tape in the locations shown in the diagram and press the grille
assy into place.
The grille is fixed using boss and double-sided self-adhesive
tape(The tape is in the locations indicated in the diagram be-
low). Do not use a dryer to heat the self-adhesive tape when
removing the grille.
The woofer is attached to the baffle by external screws. To de-
tach it, unfasten those screws. When attaching it, face its termi-
nal downward.
The tweeter is attached to the baffle by external screws. To de-
tach it, unfasten those screws.
Slot
GRILLE
Screwdriver(-)
Grille
Baffle
Down
LOCATIONS TO FIX DOUBLE-SIDED
SELF-ADHESIVE TAPE
Tape
(SEH1075 x2)
Tape
(SEH1063)
Tape
(SEH1075 x2)
Tape
(SEH1063)
(11)
(11)

3
1234
1234
C
D
F
A
B
E
PDP-S34-LR
For Packing
Mark No. Description Part No.
NSP Accessories Set (Flush & Screw,Cord) SME3630
Protector SHB1159
NSP Accessories Set (Flush) SME3626
Spacer SHD1067
Accessory Case SHF1086
Bracket A ASSY (R) SNX1175
NSP Polyethylene Bag S1 KHL1079
NSP Label (R) SAK1014
Gasket SEC1861
Gasket A SEC1935
NSP Bracket A SNA1447
NSP Clear Tape 12mm ZTA-400-12
Bracket A ASSY (L) SNX1176
NSP Polyethylene Bag S1 KHL1079
NSP Label (L) SAK1015
Gasket SEC1861
Gasket A SEC1935
NSP Bracket A SNA1447
NSP Clear Tape 12mm ZTA-400-12
Bracket B ASSY (R) SNX1177
NSP Polyethylene Bag S1 KHL1079
NSP Label (R) SAK1014
Gasket SEC1861
Gasket B SEC1936
NSP Bracket B SNA1448
NSP Clear Tape 12mm ZTA-400-12
Bracket B ASSY (L) SNX1178
NSP Polyethylene Bag S1 KHL1079
NSP Label (L) SAK1015
Gasket SEC1861
Gasket B SEC1936
NSP Bracket B SNA1448
NSP Clear Tape 12mm ZTA-400-12
NSP Danpron Tape
ZTA-DANPRON-50CL
NSP Accessory Set (Screw & Cord) SME3527
NSP Polyethylene Bag S1 KHL1079
NSP Screws Set SME3510
Screw BMZ50P100FTB
NSP Polyethylene Bag S0 KHL1081
NSP MAX No.10-1M ZMX-MAX10-1M
Speaker Wire Set SME3528
Speaker Wire SDS1167
NSP Polyethylene Bag S1 SHL1359
NSP MAX No.10-1M ZMX-MAX10-1M
NSP MAX No.10-1M ZMX-MAX10-1M
NSP Danpron Tape ZTA-DANPRON-50CL
NSP Clear Tape 12mm ZTA-400-12
Mark No. Description Part No.
NSP Baffle L SNK2862
NSP Baffle R SNK2863
NSP Cabinet L SNK2866
NSP Cabinet R SNK2867
Grille ASSY SMG1848
NSP Grille Cloth SAS1575
NSP Grille Frame SMH1106
Network ASSY SWN1736
Capacitor 2.7 SCE1029
NSP Packing SEB1232
NSP Gasket SEC1855
NSP Gasket SEC1856
NSP Gasket SEC1857
NSP Gasket SEC1860
NSP Terminal SFK1034
NSP Terminal SFK1035
Choke Coil 1.1 STH1260
NSP Rosin Core Solderpbf ZSA-5020-1R6
NSP Red-Black Wire ZWWAC3318-20
NSP Red-White Wire ZWWAC3318-29
NSP Blue-White Wire ZWWAC3318-69
Input Terminal KKX1015
NSP Model Label (L) SAN3663
NSP Model Label (R) SAN3664
NSP Insert Nut M5 SBN1056
NSP Gasket (BF: WF-TW) SEB1250
NSP Gasket (Input-Side) SEB1255
NSP Gasket (WF: Input) SEB1256
NSP Gasket (TW: Input) SEB1271
NSP Gasket (BF: C) SEB1272
NSP Gasket (CAB: Input) SEB1273
Gasket (Input Terminal Back) SEC1724
NSP Gasket (WF: Gasket) SEC1754
NSP Gasket (BF-CAB: Short) SEC1859
NSP Gasket (BF-CAB: Long) SEC1868
NSP Gasket (BF: Side) SEC1869
NSP Gasket (CAB: Short U UN) SEC1932
NSP Gasket (CAB: Long Inside) SEC1933
NSP Gasket (BF: WF-Side) SEC1934
NSP Felt (CB: Input C UN) SED1113
NSP Felt (Duct: Inside) SED1122
Tape (Grille: Short) SEH1063
Tape (Grille: Long) SEH1075
NSP Paper Tube 26 SMR1380
NSP Port Tube Ring 26 SMR1382
NSP Acoustic Absorbent (Roll : Small) SMT1240
NSP Acoustic Absorbent (TW: Back) SMT1245
NSP Acoustic Absorbent (CAB: Roll) SMT1246
NSP Acoustic Absorbent (CAB: U UN) SMT1248
NSP Acoustic Absorbent (CAB: UN) SMT1249
NSP Acoustic Absorbent (DUCT: Outside) SMT1250
NSP Label Serial (Model Label L,R) SRW1083
Speaker A101EC65-54F
Speaker FADD55-52F
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
N
OTES:
PARTS LIST

4
1234
1234
C
D
F
A
B
E
PDP-S34-LR
Mark No. Description Part No.
NSP Accessories Set (R) (Set Back (R) Set) SME3627
Accessory Case SHF1092
Bracket A ASSY (R) SNX1179
NSP Polyethylene Bag S1 KHL1079
NSP Label (R) SAK1014
Gasket SEC1861
Gasket A SEC1935
NSP Bracket A SNA1449
NSP Clear Tape 12mm ZTA-400-12
Bracket B ASSY (R) SNX1181
NSP Polyethylene Bag S1 KHL1079
NSP Label (R) SAK1014
Gasket SEC1861
Gasket B SEC1936
NSP Bracket B SNA1450
NSP Clear Tape 12mm ZTA-400-12
NSP Danpron Tape ZTA-DANPRON-50CL
NSP Accessories Set (L) (Set Back (L) Set) SME3628
Accessory Case SHF1092
Bracket A ASSY (L) SNX1180
NSP Polyethylene Bag S1 KHL1079
NSP Label (L) SAK1015
Gasket SEC1861
Gasket A SEC1935
NSP Bracket A SNA1449
NSP Clear Tape 12mm ZTA-400-12
Bracket B ASSY (L) SNX1182
NSP Polyethylene Bag S1 KHL1079
NSP Label (L) SAK1015
Gasket SEC1861
Gasket B SEC1936
NSP Bracket B SNA1450
NSP Clear Tape 12mm ZTA-400-12
NSP Danpron Tape ZTA-DANPRON-50BR
NSP Danpron Tape ZTA-DANPRON-50CL
NSP Inst. Manual Set SME3625
NSP Poly Bag S2 SHL1309
Owner’s Manual SRD1282
(English, Spanish, French)
NSP Clear Tape 12mm ZTA-400-12
Mark No. Description Part No.
Foam Pad SHA2484
Protector SHB1156
Protector SHB1157
Protector SHB1165
Packing Case SHG2647
Polyethylene Bag S2 SHL1406
NSP Label Serial SRW1087
Screw (TW) BPZ35P080FTB
Screw (Terminal) BPZ35P140FTB
Screw (BF-CAB, WF) BPZ40P100FTB
Screw (NW:L) BPZ40P300FTB
SCHEMATIC DIAGRAM
Network ASSY (SWN1736)
I N
Red
Red
Black
Blue
White
White
2.7µF/100V
C
L
1.1mH
Woofer
Tweeter

5
1234
1234
C
D
F
A
B
E
PDP-S34-LR
PACKING
9
10
12
11
3
2
2
1
4
7
4
5
8
12 13
11
12
10
6
A Side B Side
*Top side and bottom side of the packing case are " I " taped.
NOTE
*This specification shows imaginary,so the form disagrees with actual parts.
Gasket
PIONEER LOGO
PACKING CASE 1
SHG2647
SEREAL BARCORD LABEL
2
2
SRW1087
ACCESSORIES SET
PROTECTOR
PROTECTOR
1
1
SME3630
SHB1157
SHB1165
1
ACCESSORIES SET (R) SME3527
SPEAKER SYSTEM L,R
1set
2
PACKING BAG S2 SHL1406
ACCESSORIES SET (L) 1
SME3528
2
FOAM PAD SHA2484
SHB1156
PROTECTOR 1
INST.MANUAL SET 1
SME3625
CLEAR TAPE 12mm 12cm
ZTA-400-12
DANPRON-TAPE CLEARNESS 50mm
180cm
ZTA-DANPRON-50CL
No. Num. RemarksPart No.Part Name
1
2
3
4
5
6
7
8
9
10
11
12
13
14
Set Back R
Flush & Screw, Cord
Set Back L
Top
14

6
1234
1234
C
D
F
A
B
E
PDP-S34-LR
ACCESSORIES SET
SMD3627: Set Back (R)
SME3628: Set Back (L)
10 cm
20 cm
20 cm
HOLE (2)
HOLE (1)
HOLE (3)
HOLE (4)
1
2
4
3
5
5
ACCESSORY SET(for Set Back)
SHF1092-
BRACKET A ASSY(R) 1SNX1179
1
BRACKET B ASSY(R)
SNX1181
SHF1092 ACCESSORY CASE 1
BRACKET A ASSY(L) 1SNX1180
1
BRACKET B ASSY(L)
SNX1182
10cm
40cm
DANPRON TAPE
DANPRON TAPE
ZTA-DANPPRON-50BR
ZTA-DANPPRON-50CL
SHF1092 ACCESSORY CASE 1
No. Num.Part NamePart Num.
1
2
3
4
5
No. Num.Part NamePart Num.
1
2
3
4
5
ACCESSORIES SET (L) SME3628
10cm
40cm
DANPRON TAPE
DANPRON TAPE
ZTA-DANPPRON-50CL
ZTA-DANPPRON-50CL
ACCESSORIES SET (R) SME3627

7
1234
1234
C
D
F
A
B
E
PDP-S34-LR
ACCESSORIES SET
SME3630: Flush & Screw, Cord
No. Num.Part NamePart Num.
1
2
3
4
5
1
1
1
10 cm
7 cm
Protector
Accessories Set
Accessory Set
Danpron Tape
Tape
SHB1159
SME3626
SME3527
ZTA-DANPRON-50CL
ZTA-400-12
4
1
2
3
5
SHB1159-

8
1234
1234
C
D
F
A
B
E
PDP-S34-LR
ACCESSORIES SET
SME3626: Flush
No. Num.Part NamePart Num.
1
2
3
4
5
6
7
1
1
1
1
1
2
66mm
Bracket A ASSY (R)
Bracket A ASSY (L)
Bracket B ASSY (R)
Bracket B ASSY (L)
Accesary Case
Spacer
Danpron Tape
SNX1175
SNX1176
SNX1177
SNX1178
SHF1086
SHD1067
ZTA-DANPRON-50CL
MODEL MANE STAMP
2
5
6
6
7
1
4
3

9
1234
1234
C
D
F
A
B
E
PDP-S34-LR
PRODUCT APPEARANCE
BLUE
WF
TW
RED
WHITE
WHITE
LEAD WIRE (FOR TW)
LEAD WIRE (FOR WF)
RED
BLACK
LEAD WIRE (FOR INPUT)
L
RED(+)
WHITE(-)
< LOWFREQ. TRANS. >
WHITE(-)
BLUE(+)
RED(+)
BLACK(-)
<INPUT>
< HIGH FREQ. TRANS. >
C
2.7 µF/100V
end.
start.
1.1mH
SNK2862
No. Part No. Part Name
Num.
Remarks
1
1KKX10155
(6) SAN3564
1
MODEL LABEL(L)
1
SEB12508
9SEB1255
SEB1271
No.
SEB1273 SEC1724 SEC1754
SMT1240
SEC1859
No.
SMR1380
20 21 22 24 23 25
26 28 27
ACOUSTIC ABSORBENT
SAN3663
29
1
GASKET 1
INPUT TERMINAL
11
12 14 13 15 16 18 17
SED1113 SED1122
19
TAPESEH1063
BPZ40P300FTB
BPZ35P140FTB BPZ40P100FTB
SCREW
A101EC65-54F SRW1083 BPZ35P080FTB
LABEL SERIAL
TWEETER
WOOFER
Part No. Part Name
GASKET GASKET GASKET GASKET FELT FELT
Num.
Remarks
1
1 1 1 1 3 1
WOOFER
GRILLE ASS'Y DUCT INSIDE CABINET(SHORT)
TW INPUT
Part Name
Part No.
Num.
1 1
2
Remarks
1
Part No.
Num.
No. Part Name Remarks
37 38 36 35 34 33 32 39
SMR1382 SMT1245
ACOUSTIC ABSORBENT
SMT1246
ACOUSTIC ABSORBENT ACOUSTIC ABSORBENT ACOUSTIC ABSORBENT
1 1
FADD55-52F
TWEETER 1
MODEL LABEL L,R
2 2 4 1 3 1
1
INPUT TERMINAL BF~CAB,WF
NW COIL
40
SCREW SCREW SCREW
BAFFLE L INPUT TERMINAL MODEL LABEL(R) INSERT NUT M5
7SBN1056 4
GASKET BAFFLE
SEB1256
10 1GASKET
INPUT TERMINAL CABINET
PAPER TUBE 26 PORT TUBE RING 26
CABINET
CABINET CABINET BAFFLE CABINET CABINET
20
SEC1868 GASKET 1
6
TAPESEH1075 4
(1) SNK2863 BAFFLE R 1
SNK28662CABINET L 1
(2) SNK2867 CABINET R 1
3SMG1848
GRILLE ASS'Y
1
SWN1736
NETWORK ASS'Y
41
GRILLE ASS'Y
1
SMT1249 SMT124831
30
GASKET
SEC1932 GASKET
1BF SIDE
SEC1933 GASKET
2
CABINET(SHORT)
SEC1934 GASKET
1
CABINET(LONG)
SEC1869 GASKET
BF:WF SIDE
2
CABINET(LONG)
SEB1272 GASKET 2 BAFFLE
SMT1250
ACOUSTIC ABSORBENT
1
DUCT OUTSIDE
WF INPUT
2
5
27
7
30
34
7
6
35
15
37
36
10
29
20
11
13
23
25
14
16
17
16
30
22
39
22
4
3
26
28
30
31
40
39
38
1
9
22
24
8
29
18
21
19
19
38
40
33
33
31
32
30
12
12
*This product appearance shows Lch. Rch is symetrical from center line.
*2: Input terminal fixed with screw and adhesive. (Measure for air leak) *1: Chokecoil fixed with screw and adhesive. Top of screw fixed with adhesive.
*2: Adhesive
*1
*1
