Pioneer SX-319V-K User manual

ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION
2009
2009 Printed in Japan
BAND
PHONES
INPUT
SELECTOR
STANDBY/ON
PHASE
CONTROL
AUTOSURROUND/
STREAMDIRECT
STEREO/
A.L.C.
ADVANCED
SURROUND
STANDARD
SURROUND
MASTER
VOLUME
SPEAKERS CONTROL
MULTI-ZONE
ON/OFF
PORTABLE
TUNEREDIT ENTER
AUDIO/VIDEO MULTI-CHANNEL RECEIVER SX-319V
TENU + TENU PRESET + PRESET
SX-319V-K
RRV3943
AUDIO/VIDEO MULTI-CHANNEL RECEIVER
SX-319V-K
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model Type Power Requirement Remarks
SX-319V-K UCXCN AC 120 V
For details, refer to "Important Check Points for good servicing".
T- Z Z K M AY

2SX-319V-K
12 3 4
A
B
C
D
E
F
12 3 4
SAFETY INFORMATION
NOTICE
(FOR CANADIANMODEL ONLY)
Fuse symbols (fast operating fuse) and/or (slow operating fuse) on PCB indicate that replacement parts must
be of identical designation.
REMARQUE
(POUR MODÈLE CANADIENSEULEMENT)
Les symboles de fusible (fusible de type rapide) et/ou (fusible de type lent) sur CCI indiquent que les pièces
de remplacement doivent avoir la même désignation.
This service manual is intended for qualified service technicians; it is not meant for the casual
do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
trained to properly and safely repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may
void the warranty. If you are not qualified to perform the repair of this product properly and safely,
you should not risk trying to do so and refer the repair to a qualified service technician.
WARNING
This product may contain a chemical known to the State of California to cause cancer, or birth defects or other reproductive
harm.
Health & Safety Code Section 25249.6 - Proposition 65
ANY MEASUREMENTS NOT WITHIN THE
LIMITS OUTLINED ABOVE ARE INDICATIVE
OF A POTENTIAL SHOCK HAZARD AND
MUST BE CORRECTED BEFORE RETURN-
ING THE APPLIANCE TO THE CUSTOMER.
2. PRODUCT SAFETY NOTICE
Many electrical and mechanical parts in the appliance
have special safety related characteristics. These are
often not evident from visual inspection nor the
protection afforded by them necessarily can be obtained
by using replacement components rated for voltage,
wattage, etc. Replacement parts which have these
special safety characteristics are identified in this
Service Manual.
Electrical components having such features are
identified by marking with a on the schematics and
on the parts list in this Service Manual.
The use of a substitute replacement component which
does not have the same safety characteristics as the
PIONEER recommended replacement one, shown in the
parts list in this Service Manual, may create shock, fire,
or other hazards.
Product Safety is continuously under review and new
instructions are issued from time to time. For the latest
information, always consult the current PIONEER
Service Manual. A subscription to, or additional copies
of, PIONEER Service Manual may be obtained at a
nominal charge from PIONEER.
(FOR USA MODEL ONLY)
1. SAFETY PRECAUTIONS
The following check should be performed for the
continued protection of the customer and service
technician.
LEAKAGE CURRENT CHECK
Measure leakage current to a known earth ground
(water pipe, conduit, etc.) by connecting a leakage
current tester such as Simpson Model 229-2 or
equivalent between the earth ground and all exposed
metal parts of the appliance (input/output terminals,
screwheads, metal overlays, control shaft, etc.). Plug
the AC line cord of the appliance directly into a 120V
AC 60 Hz outlet and turn the AC power switch on. Any
current measured must not exceed 0.5 mA.
Device
under
test
Leakage
current
tester
Earth
ground
Reading should
not be above
0.5 mA
Also test with
plug reversed
(Using AC adapter
plug as required)
Test a ll
exposed metal
surfaces
AC Leakage Test

3
SX-319V-K
56 7 8
56 7 8
A
B
C
D
E
F
[Important Check Points for Good Servicing]
In this manual, procedures that must be performed during repairs are marked with the below symbol.
Please be sure to confirm and follow these procedures.
1. Product safety
Please conform to product regulations (such as safety and radiation regulations), and maintain a safe servicing environment by
following the safety instructions described in this manual.
1 Use specified parts for repair.
Use genuine parts. Be sure to use important parts for safety.
2 Do not perform modifications without proper instructions.
Please follow the specified safety methods when modification(addition/change of parts) is required due to interferences such as
radio/TV interference and foreign noise.
3 Make sure the soldering of repaired locations is properly performed.
When you solder while repairing, please be sure that there are no cold solder and other debris.
Soldering should be finished with the proper quantity. (Refer to the example)
4 Make sure the screws are tightly fastened.
Please be sure that all screws are fastened, and that there are no loose screws.
5 Make sure each connectors are correctly inserted.
Please be sure that all connectors are inserted, and that there are no imperfect insertion.
6 Make sure the wiring cables are set to their original state.
Please replace the wiring and cables to the original state after repairs.
In addition, be sure that there are no pinched wires, etc.
7 Make sure screws and soldering scraps do not remain inside the product.
Please check that neither solder debris nor screws remain inside the product.
8 There should be no semi-broken wires, scratches, melting, etc. on the coating of the power cord.
Damaged power cords may lead to fire accidents, so please be sure that there are no damages.
If you find a damaged power cord, please exchange it with a suitable one.
9 There should be no spark traces or similar marks on the power plug.
When spark traces or similar marks are found on the power supply plug, please check the connection and advise on secure
connections and suitable usage. Please exchange the power cord if necessary.
aSafe environment should be secured during servicing.
When you perform repairs, please pay attention to static electricity, furniture, household articles, etc. in order to prevent injuries.
Please pay attention to your surroundings and repair safely.
2. Adjustments
To keep the original performance of the products, optimum adjustments and confirmation of characteristics within specification.
Adjustments should be performed in accordance with the procedures/instructions described in this manual.
4. Cleaning
For parts that require cleaning, such as optical pickups, tape deck heads, lenses and mirrors used in projection monitors, proper
cleaning should be performed to restore their performances.
3. Lubricants, Glues, and Replacement parts
Use grease and adhesives that are equal to the specified substance.
Make sure the proper amount is applied.
5. Shipping mode and Shipping screws
To protect products from damages or failures during transit, the shipping mode should be set or the shipping screws should be
installed before shipment. Please be sure to follow this method especially if it is specified in this manual.

4SX-319V-K
12 3 4
A
B
C
D
E
F
12 3 4
CONTENTS
SAFETY INFORMATION..........................................................................................................................................................2
1. SERVICE PRECAUTIONS ....................................................................................................................................................5
1.1 NOTES ON SOLDERING ...............................................................................................................................................5
1.2 CAUTION ........................................................................................................................................................................5
2. SPECIFICATIONS .................................................................................................................................................................6
2.1 SPECIFICATIONS...........................................................................................................................................................6
2.2 PANEL FACILITIES .........................................................................................................................................................7
3. BASIC ITEMS FOR SERVICE.............................................................................................................................................11
3.1 CHECK POINTS AFTER SERVICING..........................................................................................................................11
3.2 PCB LOCATIONS .........................................................................................................................................................12
3.3 JIGS LIST......................................................................................................................................................................13
4. BLOCK DIAGRAM...............................................................................................................................................................14
4.1 OVERALL WIRING DIAGRAM......................................................................................................................................14
4.2 AUDIO BLOCK DIAGRAM ............................................................................................................................................16
4.3 U-COM BLOCK DIAGRAM ...........................................................................................................................................18
4.4 POWER SUPPLY BLOCK DIAGRAM ...........................................................................................................................19
5. DIAGNOSIS.........................................................................................................................................................................20
5.1 DIAGNOSIS FLOWCHART...........................................................................................................................................20
5.2 DETECTION CIRCUIT..................................................................................................................................................29
6. SERVICE MODE .................................................................................................................................................................32
6.1 SERVICE MODE...........................................................................................................................................................32
7. DISASSEMBLY....................................................................................................................................................................35
7.1 DISASSEMBLY .............................................................................................................................................................35
8. EACH SETTING AND ADJUSTMENT ................................................................................................................................43
8.1 IDLE CURRENT ADJUSTMENT ..................................................................................................................................43
9. EXPLODED VIEWS AND PARTS LIST...............................................................................................................................44
9.1 PACKING SECTION......................................................................................................................................................44
9.2 EXTERIOR SECTION...................................................................................................................................................46
10. SCHEMATIC DIAGRAM ....................................................................................................................................................50
10.1 P.C.B SUB ASSY (MAIN) and P.C.B SUB ASSY (P/T)................................................................................................50
10.2 P.C.B SUB ASSYS (FRONT), (VOLUME), (FUNCTION), (HEADPHONE) and (PORTABLE)....................................52
10.3 P.C.B SUB ASSY (AMP) .............................................................................................................................................54
10.4 P.C.B SUB ASSY (INPUT) ..........................................................................................................................................56
10.5 P.C.B SUB ASSY (VIDEO)..........................................................................................................................................58
10.6 P.C.B SUB ASSY (SPEAKER) and P.C.B SUB ASSY (CNT)......................................................................................59
10.7 P.C.B SUB ASSY (DSP) (1/2) .....................................................................................................................................60
10.8 P.C.B SUB ASSY (DSP) (1/2) and P.C.B SUB ASSY (REG).......................................................................................62
11. PCB CONNECTION DIAGRAM ........................................................................................................................................64
11.1 P.C.B SUB ASSY (MAIN) and P.C.B SUB ASSY (P/T)................................................................................................64
11.2 P.C.B SUB ASSY (FRONT).........................................................................................................................................68
11.3 P.C.B SUB ASSYS (VOLUME), (FUNCTION), (HEADPHONE) and (PORTABLE).....................................................70
11.4 P.C.B SUB ASSY (AMP) .............................................................................................................................................72
11.5 P.C.B SUB ASSY (INPUT) ..........................................................................................................................................74
11.6 P.C.B SUB ASSY (VIDEO)..........................................................................................................................................76
11.7 P.C.B SUB ASSY (SPEAKER) ....................................................................................................................................80
11.8 P.C.B SUB ASSYS (DSP), (CNT) and (REG) .............................................................................................................82
11.9 P.C.B SUB ASSY (HDMI) ............................................................................................................................................86
12. PCB PARTS LIST ..............................................................................................................................................................88

5
SX-319V-K
56 7 8
56 7 8
A
B
C
D
E
F
1. SERVICE PRECAUTIONS
1.1 NOTES ON SOLDERING
1.2 CAUTION
• For environmental protection, lead-free solder is used on the printed circuit boards mounted in this unit.
Be sure to use lead-free solder and a soldering iron that can meet specifications for use with lead-free solders for repairs
accompanied by reworking of soldering.
• Compared with conventional eutectic solders, lead-free solders have higher melting points, by approximately 40 ºC.
Therefore, for lead-free soldering, the tip temperature of a soldering iron must be set to around 373 ºC in general, although
the temperature depends on the heat capacity of the PC board on which reworking is required and the weight of the tip of
the soldering iron.
Do NOT use a soldering iron whose tip temperature cannot be controlled.
Compared with eutectic solders, lead-free solders have higher bond strengths but slower wetting times and higher melting
temperatures (hard to melt/easy to harden).
The following lead-free solders are available as service parts:
• Parts numbers of lead-free solder:
GYP1006 1.0 in dia.
GYP1007 0.6 in dia.
GYP1008 0.3 in dia.
• Discharging
For more detail, please refer to “7. DISASSEMBLY - 1. Discharging”.
• Notes on Ground Points Connection
For more detail, please refer to “7. DISASSEMBLY - 2. Notes on Ground Points Connection”.

6SX-319V-K
12 3 4
A
B
C
D
E
F
12 3 4
2. SPECIFICATIONS
2.1 SPECIFICATIONS
Accessories
AM loop antenna
(E601016000010-IL) FM wire antenna
(E605010070001-IL)
AAA size IEC R03
Dry cell batteries (x2)
Remote control
(8300753500010-IL)
Amplifier section
Continuous average power output of 80
watts* per channel, min., at 8 ohms, from
20 Hz to 20 000 Hz with no more than
0.2 %** total harmonic distortion.
Front (stereo) . . . . . . . . . . . . . . . .80 W+ 80 W
Power output (1 kHz, 8Ω, 0.05 %)
. . . . . . . . . . . . . . . . . . . . . . . . .110 Wper channel
Guaranteed speaker impedance
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Ω to 16 Ω
* Measured pursuant to the Federal Trade Commission’s
Trade Regulation rule on Power Output Claims for
Amplifiers
** Measured by Audio Spectrum Analyzer
Audio Section
Input (Sensitivity/Impedance)
LINE . . . . . . . . . . . . . . . . . . . . . . 200 mV/47 kΩ
Output (Level/Impedance)
REC. . . . . . . . . . . . . . . . . . . . . . .200 mV/330 Ω
ZONE 2 . . . . . . . . . . . . . . . . . . . . . 200 mV/1 kΩ
Signal-to-Noise Ratio
(IHF, short circuited, A network)
LINE . . . . . . . . . . . . . . . . . . . . . . . . . . . . .98dB
Signal-to-Noise Ratio [EIA, at 1 W(1 kHz)]
LINE . . . . . . . . . . . . . . . . . . . . . . . . . . . . .79 dB
Tuner Section
Frequency Range (FM) . . .87.5 MHz to 108MHz
Antenna Input (FM). . . . . . . . . 75 Ωunbalanced
Frequency Range (AM). . . .530 kHz to 1700 kHz
Antenna (AM). . . . . . . . . . . . . . . . . Loop antenna
Digital I/O
HDMI terminal. . . . . . . . . . . . . . 19-pin (Not DVI)
HDMI output type . . . . . . . . . . . . . . .5 V, 100 mA
Integrated control section
Control (IR) terminal. . .∅3.5 Mini-jack (MONO)
IR signal . . . . . . .High Active (High Level : 2.0 V)
Miscellaneous
Power Requirements. . . . . . . . . .AC 120 V, 60 Hz
Power Consumption . . . . . . . . . . . . . . . . . .310 W
In standby. . . . . . . . . . . . . . . . . . . . . . . . . . . 0.5 W
Dimensions
. . . . . 420 mm (W) x 158mm (H) x 347.7 mm (D)
169/16 in. (W) x 61/4in. (H) x 133/4in. (D)
Weight (without package). . . . 8.8kg (19 lb 7 oz)
Furnished Parts
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Dry cell batteries (AAA size IEC R03). . . . . . . 2
AM loop antenna . . . . . . . . . . . . . . . . . . . . . . . . . 1
FM wire antenna . . . . . . . . . . . . . . . . . . . . . . . . . 1
Operating instructions
Note
• Specifications and the design are subject
to possible modifications without notice,
due to improvements.
Manufactured under license from Dolby
Laboratories. Dolby, Pro Logic and
the double-D symbol are trademarks
of Dolby Laboratories.
Manufactured under license under U.S.
Patent #’s: 5,451,942; 5,956,674;
5,974,380; 5,978,762; 6,226,616;
6,487,535 & other U.S. and worldwide
patents issued & pending.
DTS and DTS Digital Surround are
registered trademarks and the DTS
logos, Symbol and DTS 96/24 are
trademarks of DTS, Inc. © 1996-2008
DTS, Inc. All Rights Reserved.
BD TV
INPUT SELECT SOURCE
DVR
INPUT
1 4 7
TEST TONE
HDD
CH
TV CONTROL
RECEIVER
RECEIVER
ZONE 2
ON/OFF
CD CD-R TUNER
PORTABLE MULTIIN SIGNAL SEL
MIDNIGHT PHASE S.RETRIEVER
BD MENU
ENTER
STANDARD ADV SURR
STEREO/
A.L.C.
AUTO/
DIRECT
VOL
2 5 8
SPEAKERS
DISPLAY
SLEEP
DIMMER
DVD
3 6 9
0ENTERCLR
CH CH
CH SELECT
VCR
SHIFT
MUTE
RETURNSETUP
AUDIO
PARAMETER
TUNEREDIT
TOOLS
MASTER
VOLUME
BAND
MENU
HOME
MENU
ANT
TRE
BASS
TOP MENU
RECEIVER
T
U
N
E
T
U
N
E
P
R
E
S
E
T
P
R
E
S
E
T

7
SX-319V-K
56 7 8
56 7 8
A
B
C
D
E
F
2.2 PANEL FACILITIES
Front panel
Rear panel
1uSTANDBY/ON
2INPUT SELECTOR dial
Selects an input source.
3 Tuner control buttons
BAND
Switches between AM, FM ST (stereo) and
FM MONO radio bands.
TUNE +/–
Used to find radio frequencies.
TUNER EDIT
Use with TUNE +/–,PRESET +/– and
ENTER to memorize and name stations for
recall.
PRESET +/–
Use to select presetradio stations.
4 Character display
See Display.
5MASTER VOLUME dial
6PHONES jack
Use to connect headphones.
7 Listening mode buttons
AUTO SURROUND/STREAM DIRECT
Switches between Auto surround mode
(Auto playback) and Stream
Directplayback. Stream Directplayback
bypasses the tone controls for the most
accuratereproduction of a source.
STEREO/A.L.C.
Switches between stereo playback, Auto
level control stereo mode and
Front Stage Surround Advance modes.
BAND
PHONES
INPUT
SELECTOR
STANDBY/ON
PHASE
CONTROL
AUTO SURROUND/
STREAM DIRECT
STEREO/
A.L.C.
ADVANCED
SURROUND
STANDARD
SURROUND
MASTER
VOLUME
SPEAKERS CONTROL
MULTI-ZONE
ON/OFF
PORTABLE
TUNER EDIT ENTER
AUDIO/VIDEO MULTI-CHANNEL RECEIVER SX-319V
TENU + TENU PRESET + PRESET
123 54
6 107 98
ADVANCED SURROUND
Switches between the various surround
modes.
STANDARD SURROUND
Press for Standard decoding and to switch
between the various ∂Pro Logic II options.
8 SPEAKERS
Use to change the speaker system on or off.
9 MULTI ZONE controls
If you’ve made MULTI-ZONE connections (see
MULTI-ZONE listening) use these
conrols to control the sub zone from the main
zone (see Using the MULTI-ZONE controls).
10 PORTABLE audio input jack
Connect an auxiliary component using a stereo
mini-jack cable.
AUDIO AUDIO
DIGITAL
BD/DVD MULTI CH IN
BD/DVD IN
HDMI
ANTENNA
FM
UNBAL
75 Ω
AM
LOOP
FRONT
L
R
L
R
CENTERSURROUND
COAXIAL
(CD)
IN 1
(CD-R/TAPE)
IN 1
1 - 2
(DVR/VCR)
IN 2
OPTICAL
ASSIGNABLE
IR
ASSIGNABLE
OUT IN
ZONE2 OUT
LR
DVR/VCR TV/SAT
L
R
OUT
TV/SAT
IN
OUT
IN IN
IN
CD-R/TAPE CD
SUBWOOFER
IN
L
R
HDMI
BD/DVD
IN
(CD-R/TAPE)
IN 1
TV/SAT IN
Class 2 Wiring
SPEAKERS A
SURROUND CENTER SUBWOOFER
RL
FRONT
RL

8SX-319V-K
12 3 4
A
B
C
D
E
F
12 3 4
6 Speaker indicator
Shows if the speaker system is on or not.
SPdAmeans the speakers are switched on.
SPd means the speakers are switched off and
sound is output from the headphone jack.
7 Sleep timer indicator
Lights when the receiver is in sleep mode.
8 Tuner preset indicators
PRESET
Shows when a preset radio station is
registered or called.
MEM
Blinks when a radio station is registered.
9 PRESET information or input signal
indicator
Shows the preset number of the tuner or the
input signal type etc.
10 DTS indicators
DTS
Lights when a source with DTS encoded
audio signals is detected.
96/24
Lights when a source with DTS 96/24
encoded audio signals is detected.
11 Character display
Displays various system information.
12 Dolby Digital indicators
∂D
Lights when a Dolby Digital encoded signal
is detected.
∂PLll
Lights to indicate Pro Logic II decoding
(see Listening in surround sound
for more on this).
13 ADV.S.
Lights when one of the Advanced Surround
modes has been selected (See Using the
Advanced surround effects for
more on this).
14 SIGNAL SELECT indicators
DIGITAL
Lights when a digital audio signal is
selected.
Blinks when a digital audio signal is not
selected.
HDMI
Lights when an HDMI signal is selected.
Blinks when an HDMI signal is not
selected.
15 DIMMER indicator
Shows when the display isset to turn off as the
DIMMER setting.
16 DIR.
Lights when the DIRECT or PURE DIRECT
mode is switched on.
Display
1 PHASE
Lights when the Phase Control is switched on.
2 AUTO
Lights when the Auto Surround feature is
switched on (See Auto playback).
3 ST
Lights when a stereo FM broadcast is being
received in auto stereo mode.
4 TUNE
Lights when a broadcast is being received.
5 ZONE
Lights when the MULTI-ZONE feature is active.
1 2 3 4 5 6 7 89
10 1211 13 14 14 1615

9
SX-319V-K
56 7 8
56 7 8
A
B
C
D
E
F
Remote control
As for operating other devices, the remote
control codes for the Pioneerproducts are
preset. The settings cannot be changed.
1 INPUT SELECT
Use to select the input source.
2uRECEIVER
Switches the receiver between standby and on.
3 RECEIVER
Switches the remote to control the receiver
(used to select the white commands above the
number buttons (TEST TONE, etc)). Also use
this button to set up surround sound
or Audio parameters.
4 ZONE 2 ON/OFF
Switches zone 2 of the multi-zone function
between on and off.
5MULTI CONTROL buttons
Press to select control of other components.
6Receiver control buttons
SIGNAL SEL
Use to select an input signal.
MIDNIGHT
Switches to Midnight or Loudness
listening.
PHASE
Press to switch on/off Phase Control.
S.RETRIEVER
Press to restore CD quality sound to
compressed audio sources.
PressBD first to access:
BD MENU
Displays the disc menu of Blu-ray Discs.
7Listening mode buttons
AUTO/DIRECT
Switches between Auto surround mode
(Auto playback) and Stream
Directplayback. Stream Directplayback
bypasses the tone controls for the most
accurate reproduction of a source.
BD TV
INPUT SELECT SOURCE
DVR
INPUT
1
4
7
TEST TONE
HDD
CH
TV CONTROL
RECEIVER
RECEIVER
ZONE 2
ON/OFF
CD CD-R TUNER
PORTABLE MULTI IN SIGNAL SEL
MIDNIGHT PHASE S.RETRIEVER
BD MENU
ENTER
STANDARD ADV SURR
STEREO/
A.L.C.
AUTO/
DIRECT
VOL
2
5
8
SPEAKERS
DISPLAY
SLEEP
DIMMER
DVD
3
6
9
0ENTERCLR
CH
CH
CH SELECT
VCR
SHIFT
MUTE
RETURN
SETUP
AUDIO
PARAMETER
TUNER EDIT
TOOLS
MASTER
VOLUME
BAND
MENU
HOME
MENU
ANT
TRE
BASS
TOP
MENU
RECEIVER
T
U
N
E
T
U
N
E
P
R
E
S
E
T
P
R
E
S
E
T
1
122
13
14
15
16
3
4
5
6
7
8
9
10
11
17
STEREO/A.L.C.
Switches between stereoplayback, Auto
level control stereo mode and
Front Stage Surround Advance modes.
STANDARD
Press for Standard decoding and to switch
between ∂Pro Logic II options.
ADV SURR
Switches between the various surround
modes.
8 System Setup and Component control
buttons
The following button controls can be accessed
after you have selected the corresponding
MULTI CONTROL button (BD,TV, etc.).
Press RECEIVER first to access:
AUDIO PARAMETER
Use to access the Audio options.

10 SX-319V-K
12 3 4
A
B
C
D
E
F
12 3 4
SETUP
Press to access the System Setup menu.
RETURN
Confirm and exit the current menu screen.
Press BD orDVR first to access:
TOP MENU
Displays the disc ‘top’ menu of a BD/DVD.
HOME MENU
Displays the HOME MENU screen.
RETURN
Confirm and exit the current menu screen.
MENU
Displays the TOOLS menu of Blu-ray Disc
player.
Press TUNER first to access:
T.EDIT
Memorizes/names stations forrecall.
BAND
Switches between AM, FM ST (stereo) and
FM MONO radio bands(page34).
9ijkl (TUNE i/j,PRESET k/l),
ENTER
Use the arrow buttons when setting up your
surround sound system. Also used
to control BD/DVD menus/options.
Use the TUNE i/j buttons can be used to
find radio frequencies and the
PRESET k/l buttons can be used to select
preset radio stations.
10 Component control buttons
The main buttons (d,e, etc.) are used to
control a component after you have selected it
using the input source buttons.
The controls above these buttons can be
accessed after you have have selected the
corresponding input source button (for
exampleBD,DVR orTV). These buttons also
function as described below.
PressRECEIVER first to access:
BASS –/+
Use to adjust Bass1
TRE –/+
Use to adjust Treble1
PressTV first to access:
ANT
Use to select the VHF/UHF antennas or
Cable TV.
11 Number buttons and other component
controls
Use the number buttons to directly select the
tracks on a CD, DVD, etc. There are other
buttons that can be accessed after the
RECEIVER button is pressed. (For example
TEST TONE, etc.)
HDD*, DVD*, VCR*
These buttons switch between the hard
disk, DVD and VCR controls for HDD/DVD/
VCRrecorders.
Note
1The tone controls are disabled when the listening mode is set to DIRECT or PURE DIRECT.
TEST TONE
Outputs the test tones on each channel.
Use the i/jbuttons to select the channe
and use the k/lbuttons to adjust the
level on each channel. PressingTEST
TONE again exits the test tone mode.
CH SELECT
Press repeatedly to select a channel, then
use+/– to adjust the level.
CH SELECT +/–
Use to adjust the channel levels.
SPEAKERS
Use to change the speaker system on or o
SLEEP
Press to change the amount of time
beforethe receiver switches into standby
(30 min – 60min – 90 min – Off). You ca
check the remaining sleep time at any tim
by pressing SLEEP once.
DIMMER
Dims or brightens the display. The
brightness can be controlled in four steps.
12 u SOURCE
Turns on or off the power of the Pioneer DVD/
DVR units when BD orDVR is selected using
the MULTI CONTROL buttons.
13 TV CONTROL buttons
These buttons can control only be used with
Pioneer flat panel TVs.
u
Use to turn on/off the power of the TV.
INPUT
Use to select the TVinput signal.
CH +/–
Use to select channels.
VOL +/–
Use to adjust the volume on your TV.
14 MASTER VOLUME +/–
Use to set the listening volume.
15 MUTE
Mutes/unmutes the sound.
16 DISPLAY
Switches the display of this unit. The input
name, listening mode or sound volume can be
checked by selecting an input source.
17 SHIFT
Press to access the ‘boxed’ commands (abov
the buttons) on the remote. These buttons are
marked with an asterisk (*) in this section. Th
button is also used for operating ZONE 2.

11
SX-319V-K
56 7 8
56 7 8
A
B
C
D
E
F
3. BASIC ITEMS FOR SERVICE
3.1 CHECK POINTS AFTER SERVICING
Item to be checked regarding video Item to be checked regarding audio
Block noise Distortion
Horizontal noise Noise
Flicker Volume too low
Disturbed image (video jumpiness) Volume too high
Too dark Volume fluctuating
Too bright Sound interrupted
Mottled color
No. Procedures Check points
1
2
3
4
5
6
7
8
Confirm whether the customer complain has been solved.
If the customer complain occurs with the particular source,
such as Dolby Digital, DTS, AAC, DVD-A and HDMI, input it for
the operation check.
The customer complain must not be reappeared.
Video, Audio and operations must be normal.
Check the analog audio playback.
(Make the analog connections with a DVD player.)
Each channel audio and operations must be normal.
Check the digital audio playback.
(Make the digital connections with a DVD player.)
Each channel audio and operations must be normal.
Check surround playback.
(Select Surround mode and check the multichannel operations
via the DSP circuit.)
Each channel audio and operations must be normal.
Check the tuner (AM and FM) operations. Audio and operations must be normal.
Check the video outputs.
(Connect with a DVD player.)
Video and operations must be normal.
Check the sound from headphone output. Sound must be normal, without noise.
Check the appearance of the product. No scratches or dirt on its appearance after receiving it for
service.
Items to be checked after servicing / VSX, SC
To keep the product quality after servicing, confirm recommended check points shown below.
See the table below for the items to be checked regarding video and audio.

12 SX-319V-K
12 3 4
A
B
C
D
E
F
12 3 4
3.2 PCB LOCATIONS
C
P.C.B SUB ASSY
(FRONT) DP.C.B SUB ASSY
(VOLUME)
P.C.B SUB ASSY
(GUIDE PCB R)
AP.C.B SUB ASSY
(MAIN)
SP.C.B SUB ASSY
(REG)
BP.C.B SUB ASSY
(P/T)
P.C.B SUB ASSY
(FUNCTION)E
P.C.B SUB ASSY
(AMP) J
P.C.B SUB ASSY
(GUIDE PCB L)
PP.C.B SUB ASSY
(DSP)
KP.C.B SUB ASSY
(INPUT)
L
P.C.B SUB ASSY
(VIDEO)
M
P.C.B SUB ASSY
(SPEAKER)
Mark No. Description Part No. Mark No. Description Part No.
LIST OF ASSEMBLIES
NOTES:
-
Parts marked by “NSP” are generally unavailable because they are not in our Master Spare Parts List.
-
The >mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
P.C.B SUB ASSY
(HEADPHONE) F
NP.C.B SUB ASSY
(CNT)
NSP 1..P.C.B TOTAL ASSY (MAIN) 7025HK0812090-IL
2..P.C.B SUB ASSY (MAIN) 70280675010C0-IL
2..P.C.B SUB ASSY (GUIDE-L) 70280675020C0-IL
2..P.C.B SUB ASSY (GUIDE-R) 70280675030C0-IL
2..P.C.B SUB ASSY (CNT) 70280675040C0-IL
2..P.C.B SUB ASSY (P/T) 70280675050C0-IL
2..P.C.B SUB ASSY (HP GUIDE) 70280675060C0-IL
NSP 1..P.C.B TOTAL ASSY (FRONT) 7025HK0812091-IL
2..P.C.B SUB ASSY (FRONT) 7028067511030-IL
2..P.C.B SUB ASSY (HEADPHONE) 7028067512030-IL
2..P.C.B SUB ASSY (VOLUME) 7028067513030-IL
2..P.C.B SUB ASSY (FUNCTION) 7028067514030-IL
2..P.C.B SUB ASSY (PORTABLE) 7028067518030-IL
NSP 1..P.C.B TOTAL ASSY (AMP) 7025HK0812092-IL
2..P.C.B SUB ASSY (AMP) 7028068141010-IL
NSP 1..P.C.B TOTAL ASSY (INPUT) 7025HK0812093-IL
2..P.C.B SUB ASSY (INPUT) 7028067531040-IL
NSP 1..P.C.B TOTAL ASSY (VIDEO) 7025HK0812094-IL
2..P.C.B SUB ASSY (VIDEO) 7028067551030-IL
NSP 1..P.C.B TOTAL ASSY (DSP) 7025HK0812095-IL
2..P.C.B SUB ASSY (DSP) 7028067561040-IL
2..P.C.B SUB ASSY (REG) 7028067562010-IL
NSP 1..P.C.B TOTAL ASSY (HDMI) 7025HK0812096-IL
2..P.C.B SUB ASSY (HDMI) 7028067581040-IL
NSP 1..P.C.B TOTAL ASSY (SPEAKER) 7025HK0812097-IL
2..P.C.B SUB ASSY (SPEAKER) 7028068151010-IL
QP.C.B SUB ASSY
(HDMI-519)
IP.C.B SUB ASSY
(PORTABLE)
P.C.B SUB ASSY
(H/P GUIDE)

13
SX-319V-K
56 7 8
56 7 8
A
B
C
D
E
F
3.3 JIGS LIST
Silicon grease GEM1057
GYA1011 (KE40RTV-W)
Silicon adhesive
Name Lubricants and Glues No. Remarks
Refer to "9.2 EXTERIOR SECTION"
Refer to "9.2 EXTERIOR SECTION"
Lubricants and Glues list
Name Jig No. Remarks
10P extension jig cable GGD1628Diagnosis
8P extension jig cable GGD1629 Diagnosis
Board to board extension jig cable GGD1630 Diagnosis
Jigs list

14 SX-319V-K
12 3 4
A
B
C
D
E
F
12 3 4
4. BLOCK DIAGRAM
4.1 OVERALL WIRING DIAGRAM
P.C.B SUB ASSY
L
P.
(7
P.C.B SUB ASSY
(FUNCTION)
(7028067514030-IL)
E
E
P.C.B SUB
ASSY
(HEADPHONE)
(7028067512030-IL)
F
F
P.C.B SUB ASSY
(SPEAKER)
(7028068151010-IL)
M
P.C.B SUB ASSY
(70280675010C0-I
A
S
P.C.B SUB ASSY (AMP)
(7028068141010-IL)
J
P
A
(

15
SX-319V-K
56 7 8
56 7 8
A
B
C
D
E
F
C.B SUB ASSY (VIDEO)(7028067551030-IL)
P.C.B SUB ASSY (FRONT)
(7028067511030-IL)
CP.C.B SUB ASSY
(VOLUME)
(7028067513030-IL)
P.C.B SUB ASSY
(REG)
(7028067562010-IL)
D
P.C.B SUB ASSY
(CNT) (70280675040C0-IL)
N
P.C.B SUB ASSY
(INPUT)
(7028067531040-IL)
K
P.C.B SUB ASSY (HDMI)(7028067581040-IL)
Q
P1/2,2/2
P.C.B SUB ASSY (DSP)
(7028067561040-IL)
SUB ASSY (MAIN)
675010C0-IL)
S
P.C.B SUB
ASSY (P/T)
(70280675050C0-IL)
B
P.C.B SUB ASSY (PORTABLE)
(7028067518030-IL)
I

16 SX-319V-K
12 3 4
A
B
C
D
E
F
12 3 4
4.2 AUDIO BLOCK DIAGRAM
I
P.C.B SUB ASSY
(HDMI-519)
Q
P.C.B SUB ASSY
(DSP)
P.C.B SUB
ASSY (MAIN)
A
P
K
P.C.B SUB
(PORTABL
P.C.B SUB ASSY
(VIDEO)
L

17
SX-319V-K
56 7 8
56 7 8
A
B
C
D
E
F
P.C.B SUB ASSY
(HEADPHONE)
FI
P.C.B SUB ASSY (INPUT)
P.C.B SUB
ASSY (AMP)
J
P.C.B SUB
ASSY
(SPEAKER)
M
K
P.C.B SUB ASSY
(PORTABLE)

18 SX-319V-K
12 3 4
A
B
C
D
E
F
12 3 4
4.3 U-COM BLOCK DIAGRAM
P.C.B SUB ASSY
(FRONT)
C
P.C.B SUB ASSY (MAIN)
SX-319
A

19
SX-319V-K
56 7 8
56 7 8
A
B
C
D
E
F
4.4 POWER SUPPLY BLOCK DIAGRAM
S4(FLT)
S3(DSP, HDMI)
AC CORD
S2(+12V,-12V)
S1(AMP B+/B-)
S4(DIR/CODEC, HDMI, USB)
MAINTRANS
SUB TRANS

20 SX-319V-K
12 3 4
A
B
C
D
E
F
12 3 4
5. DIAGNOSIS
5.1 DIAGNOSIS FLOWCHART
Step 3: Regulator IC
REG101, REG102 (Pin 3)
Is the
voltage of 3.3 V
input?
Replace REG103.
Check the ZD200 2.4 VB
and IC106.
To Step 3
To Step 4
Step 0: Preliminary confirmation
Confirm the following items before checking
Tighten screws securely.
No
Yes
To Step 1
No
Troubleshooting
[1] DSP TROUBLESHOOTING
Step 2: Regulator IC
Check the REG101,
REG102 and MAINAssy
Check the REG103 and
MAINAssy.
REG103 (Pin 3)
Is the
voltage of around
5 Vinput?
No
Yes
(to chassis)
ZD200 kathode
Is the
voltage of 2.5 V
output?
No
*The I/O power of DSP Assy is OK
*The IC106 power of DSP Assy
*the DSP IC CORE power of DSP Assy
XMCK
Note: REG101, REG102 is made of
parallel connection.
REG103 (Pin 2)
Is the
voltage of 3.3 V
output?
No
Yes
Yes
Yes
Is the
voltage of 1.2 V
output? Replace REG101, 102.
Check the path to XTAL101.
No
Yes
(to chassis)
(to chassis)
REG101, REG102 (Pin 2) (to chassis)
Step 1: BtoB connector
CP200,CN206,CP105
Are the
connectors securely
inserted?
Turn the power off and
insert the connectors
securely.
No
Yes
To Step 2 *CN206,CP200 connectors
doesn't connection in case
of DSP JIG B'D use.
BtoB connector
Do screws of COAX
Jack securely tighten?
OR connect GND wire of
DSP JIG B'D to chassis.
Step 4: X'tal
To Step 5
Yes
IC109 (Pin 6, 7)
No
Is there
a 24.576 MHz
output?
Check the path to pin 6, 7 of IC109.
Replace XTAL101.
Yes
IC102 (Pin 17)
No
Is there
a 24.576 MHz
input?
