Pioneer XR-VS200 User manual

PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2001
ORDER NO.
T – ZZK SEPT. 2001 Printed in Japan
Model No. Order No. Remarks
XR-VS70SW/DBDXJ RRV2364
¶This service manual should be used together with the following manual(s):
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
STEREO CD/VCD CASSETTE DECK RECEIVER
XR-VS200
RRV2532
Type Model Power Requirement The voltage can be converted by
XR-VS200 the following method.
DXJN/NC AC110-127V/220-230V/240V With the voltage selector

XR-VS200
2
2. CONTRAST OF MISCELLANEOUS PARTS
CONTRASTTABLE
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
Reference Nos. indicate the pages and Nos. in the service manual for the base model.
NOTES:
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
561
473
R50
1R0
5621
560
47k
0.5
1
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x10
3
R50
1R0
561
473
5.62k RN1/4PC F562 x 10
1
5621
XR-VS200/DXJN/NC and XR-VS70SW/DBDXJ are constructed the same except for the following :
Part No.
Ref. No. Mark Symbol and Description XR-VS70SW XR-VS200 Remarks
/DBDXJ /DXJN/NC
PCB ASSEMBLIES
COMPLEX ASSY XWM3160 AWM7611
P5- 3 PRIMARY ASSY XWZ3291 AWU7965
P7- 1 DISPLAY ASSY XWZ3302 AWU7795
P5- 4 FM/AM TUNER Module AXQ7062 AXQ7065 *1
PACKING SECTION
P3- 1 Power Cord ADG1158 ADG1154
P3- 8 Front Pad XHA3018 XHA3028
P3- 9 Rear Pad XHA3019 XHA3029
P3-10 Packing Case XHD3124 XHD3270
P3-12 Operating Instructions XRE3034 Not used
(English/Chinese/Spanish)
P3-12 Operating Instructions (Thai) Not used XRC3047
P3-14 SW Wire Antenna ADH7006 Not used
Caution Sheet XRH3003 Not used
EXTERIOR SECTION
P5-11 Tray Cap XAK3156 XAK3236
Tray Panel CD Not used XAK3269 For Tray Cap
P5-15 Rear Panel XNC3057 XNC3133
P5-26 NSP Tray Cap Assy XXG3046 Not used
P5-31 Caution Label Not used PRW1018
P5-36 NSP Getter XAX3168 XAX3264
P5-44 Barrier XEC3013 XEC3027
Rear Sheet AED7037 Not used
NSP Name Label XAL3045 XAL3097
FRONT PANEL SECTION
P7-18 Volume Knob XAA3013 XAA3022
P7-21 FUNC Button L XAD3078 XAD3116 No.8
FUNC Cap L Not used XAK3247 No.7
P7-22 FUNC Button R XAD3079 XAD3117 No.10
FUNC Cap R Not used XAK3248 No.9
P7-23 FUNC Frame L XAD3052 Not used
P7-24 FUNC Frame R XAD3053 Not used
P7-25 CD ENT Button XAD3055 XAD3109 No.12
P7-26 Display Panel XAK3129 XAK3317
P7-27 EQ Panel XAK3149 Not used

XR-VS200
3
DISPLAY ASSY
F
I
CONTRAST OF PCB ASSEMBLIES
AWU7795 and XWZ3302 are constructed the same except for the following :
Mark Symbol and Description Part No. Remarks
XWZ3302 AWU7795
D5594 1SS133 Not used
D5610, D5611, D5615, D5616, D5904 SLP3118C51H SLR-343MC(NPQ)
D5612, D5614 SLP6118C51H SLR-343DC(NPQ)
D5619, D5620, D5903 SLP9118C51H SLR-343VC(NPQ)
D5902 SLP7118C51H SLR-343PC(KLM)
S5911, S5913, S5915–S5921, S5923–S5929 XSG3001 ASG1051
S5931–S5940 XSG3001 ASG1051
Notes : For PCB ASSEMBLIES, Refer to “CONTRAST OF PCBASSEMBLIES”.
The numbers in the remarks column correspond to the numbers on the “ FRONT PANEL ASSY ”.
*1 Refer to XR-VS70/DLXJ/NC.
Part No.
Ref. No. Mark Symbol and Description XR-VS70SW XR-VS200 Remarks
/DBDXJ /DXJN/NC
SC Panel Not used XAK3268 No.26
SC Panel Assy Not used XXG3090 No.13
P7-28 JOG Lens XAK3152 XAK3243 No.23
P7-29 V Lens XAK3153 XAK3313
P7-33 FL Cover XAK3163 XAK3239
P7-34 Cover Sheet L XAK3184 Not used
P7-35 Cover Sheet R XAK3185 Not used
LED Barrier Not used XEC3022 No.24
P7-36 Power Button XAD3043 XAD3102 No.17
P7-37 CD Button XAD3045 XAD3104 No.19
P7-38 SC Button XAD3060 Not used
SC Button L Not used XAD3105 No.29
SC Cap L Not used XAK3241 No.27
SC Button R Not used XAD3106 No.30
SC Cap R Not used XAK3267 No.28
ASES Button Not used XAD3114 No.20
Timer Button Not used XAD3115 No.21
P7-39 SC Button L XAD3047 Not used
Audio Button Not used XAD3107 No.14
P7-40 SC Button R XAD3049 Not used
Visual Button Not used XAD3108 No.15
P7-41 DOLBY Button XAD3054 XAD3119 No.11
P7-42 Sub Panel XAK3198 XAK3256 No.6
P7-43 Standby Lens XAK3151 XAK3240 No.18
P7-44 Deck Lens L XAK3159 XAK3249 No.3
P7-45 Deck Lens R XAK3160 XAK3250 No.5
P7-46 JOG Conductor XAK3165 XAK3244 No.22
P7-47 Deck Door_L XAN3021 XAN3041 No.2
P7-48 Deck Door_R XAN3025 XAN3042 No.4
P7-49 Front Panel XMB3026 XMB3056 No.1
O/C Button Not used XAD3103 No.16
P7-50 NSP Front Panel Assy XXG3062 XXG3115
P7-52 Spacer XEB3012 Not used
P7-53 Spacer XEB3013 Not used
P7-59 Cushion Spacer XEB3015 Not used
P7-60 Cushion Spacer XEB3016 Not used
P7-61 Cushion Spacer XEB3017 Not used
Spacer XEC3014 Not used
Spacer XEC3019 Not used

XR-VS200
4
12
1
13
15
18
17
19
16
24
22
25
21
96
10
11
5
4
25
23
14
20
7
8
3
2
27, 29 26 28, 30
13
FRONT PANEL ASSY
• FRONT PANEL ASSY PARTS LIST
Mark No. Description Part No. Mark No. Description Part No.
1 Front Panel XMB3056
2 Deck Door_L XAN3041
3 Deck Lens L XAK3249
4 Deck Door_R XAN3042
5 Deck Lens R XAK3250
6 Sub Panel XAK3256
7 FUNC Cap L XAK3247
8 FUNC Button L XAD3116
9 FUNC Cap R XAK3248
10 FUNC Button R XAD3117
11 DOLBY Button XAD3119
12 CD ENT Button XAD3109
13 SC Panel Assy XXG3090
14 Audio Button XAD3107
15 Visual Button XAD3108
16 O/C Button XAD3103
17 Power Button XAD3102
18 Standby Lens XAK3240
19 CD Button XAD3104
20 ASES Button XAD3114
21 Timer Button XAD3115
22 JOG Conductor XAK3244
23 JOG Lens XAK3243
24 LED Barrier XEC3022
25 Screw BPZ30P080FMC
26 SC Panel XAK3268
27 SC Cap L XAK3241
28 SC Cap R XAK3267
29 SC Button L XAD3105
30 SC Button R XAD3106
PRIMARY ASSY
F
H
AWU7965 and XWZ3291 are constructed the same except for the following :
Mark Symbol and Description Part No. Remarks
XWZ3291 AWU7965
L1 LINE FILTER ATF7018 Not used
