Pioneer GEX-2850DVB2 User manual

Dual Diversity DVB-T2 TV Receiver
GEX-2850DVB2
Operation Manual

2
Contents
Important Safety Instructions and Caution........................................... 3
Precaution............................................................................................ 3
Unit Description.................................................................................... 4
Front View............................................................................................ 4
Rear View............................................................................................. 4
Power Input/Output Port...................................................................... 5
Accessories.......................................................................................... 5
Remote Control Operations................................................................. 5
Remote Control Battery Installation..................................................... 5
Connection with Accessories............................................................... 6
Connection with Pioneer Multimedia Receiver ............................. 6
Antenna Installation ............................................................................. 7
Quick Guide for First-time User..............................................8-9
Operating GEX-2850DVB2.................................................................. 9
TV Mode............................................................................................. 10
Menu Selection under TV Mode........................................................ 10
Channel List.................................................................................. 10-11
Channel Setting ............................................................................ 11-12
Scan................................................................................................... 12
Channel Information........................................................................... 13
Audio.................................................................................................. 13
Subtitle............................................................................................... 13
Display ............................................................................................... 14
Teletext............................................................................................... 14
TV Recording Function...................................................................... 14
Movie Mode ....................................................................................... 15
Movie Mode Menu ............................................................................. 16
Audio Selection.................................................................................. 16
Subtitle............................................................................................... 16
Music Mode........................................................................................ 17
Music Mode Menu.............................................................................. 17
System Settings................................................................................. 18
Country/Language ............................................................................. 18
Display Setting................................................................................... 18
HDMI Setting...................................................................................... 18
Version Upgrade................................................................................ 19
Reset to Default................................................................................. 19
Troubleshooting ................................................................................. 20
Copyright and trademark ................................................................... 21
Specification..................................................................................21-22
The screens shown in the samples may differ from actual screens, which may be
changed without notice for performance and function improvements.
Precaution
01
Thank you for buying this Pioneer product.
Please read through these instructions so you will know how to operate your model
properly. After you have finished reading the instructions, keep this document in a
safe place for future reference.
Important
Basic Operation
02
Configuration for GEX-2850DVB2
03
Configuration for GEX-2850DVB2
03

3
Please Read all of these instructions regarding your unit, and retain
them for future reference.
Keep this user manual handy as a reference for operating
procedures and safety information.
Do not insert irrelevant objects of any kind into this device
through openings as they may touch dangerous voltage
points or short-out parts that could result in a fire or electric
shock.
Do not place this unit near the liquids as electrical shock
could result. Damages resulting from splashing liquids on the
device may cause smoke and overheat.
On Safety
Do not attempt to install or service your Digital TV receiver on
your own. Installation or servicing by people without proper
training, or experience in electronic equipment and automotive
accessories may be dangerous and could expose you to the risk
of electric shock or other hazards.
If the receiver does not work properly, please disconnect the
power plug for safety. Contact your local dealer immediately for
further technical support.
If any solid object or liquid fall into the cabinet, disconnect the unit
and have it checked by qualified person before operating it any
further.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK –DO NOT REMOVE COVER (OR BACK)NO
USER-SERVICEABLE PARTS INSIDE REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL
The lighting flash with arrowhead symbol within an
equilateral triangle is intended to alert the user to the
presence of uninsulated dangerous voltage within the
product’s enclosure that may be of sufficient magnitude
to constitute a risk at electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance
Important Safety Instructions and Caution
Precaution

4
Unit Description
Front View
(1) Power/IR In: A harness for connection with IR sensor and
+12V vehicle power supply.
(2) RGB Port: This is a 26-pin connector port for exclusive
connection with Pioneer AV head units (MULTIMEDIA
RECEIVER)
(3) HDMI Out: The TV audio and video output (digital) via a
mini HDMI port
(4) AV Out: The TV audio and video output (analog) via a
3.5mm earphone jack
(5) Antenna In: Antenna input connector. Note that +5V DC
output for powering active antenna is also provided via this
port.
Rear View
(6) Video Out: The DVB-T2 TV video output via a RCA
connector
(7) USB Port: USB memory stick (or HDD) for multimedia
playback and TV recording.
(8) Operating LED: “ON” indicates the system is working.
*Please see next chapter for more information
Note: Connect antennas to the unit BEFORE turning on engine.
Please connect the antennas first and then turn on the unit. If users turn
on the main unit and then connect the antennas later, the connected
antenna will NOT be detected nor activated for receiving DVB-T signal
as it should.
Warning: Make sure the power supply wire is correctly connected.
If this unit intends to use +12 power supply provided by vehicle via ACC wiring,
please make sure that the red wire is correctly connected with the ACC ignition
for proper system operations.
Basic Operation
(5) Antenna In
(4) AV Out
(3) HDMI Out
(2) RGB Port
(1) Power/IR In
(8) Operating LED
(7) USB Port
(6) Video Out

5
Power Input/Output Port
1
Power GND (Black wire). To vehicle (metal) body.
2
Reserved
3
+12V Input (Yellow wire). To terminal supplied with power
regardless of ignition switch position.
4
Reserved
5
ACC In (Red wire). To electric terminal controlled by ignition
switch On/Off.
6
IR LED. Power for the LED of the IR receiver.
7
Reserved
8
IR data In. Infrared data input of the IR receiver.
9
IR Power Out. Power for IR LED.
10
IR GND. Ground for IR LED.
Accessories
The table below lists all accessories supplied in the package.
No.
Part Name
No.
Part Name
1
Power with IR Cord
4
Pioneer RGB Cable
2
IR Extension Cable
5
2 Active Rod Antennas
3
Remote Controller
Remote Control Operations
Remote Control Battery Installation
Before attempting to operate your remote control, install the battery as
described below:
1. Open the battery cover at the back side of the remote control.
2. Take out the battery and put another battery in.
3. Put the cover back.
Button name
Function
1
POWER
Select power-on or stand-by
2
MUTE
Mute control
3
Home
Go to home screen
4
EXIT
Exit the current setup
5
EPG
Electronic Program Guide
6
MENU
Enter the setup menu
7
Cursor
Move the cursor right
8
Cursor
Move the cursor left
9
OK
Select the highlighted item
10
CH▲
Select channel up or move the cursor up
11
CH▼
Select channel down or move the cursor down
12
PLAY/PAUSE
Select play or pause
13
FF
Fast Forward
14
REC●
Start record TV/Radio program or exit recording
15
FR
Fast Rewind
16
Digital keys
Digit buttons to select channels
17
INFO
Display digital TV system information
18
AUTO SCAN
To scan channels automatically
NULL
NULL
NULL
+12V In
(1)
(5)
(8)
(6)
––
)
(9)
(14)
(15)
(18)
(10)
(2)
(3)
(7)
(11)
(4)
(12)
(13)
(16)
(17)
NULL

6
Connection with Accessories
The accessories included within the package are to be connected to
GEX-2850DVB2 as shown in the diagram below:
Connection with Pioneer Multimedia Receiver
(1) Connecting GEX-2850DVB2 to Multimedia Receiver with
RGB connector
Compatible Pioneer Multimedia Receivers models available in market
are equipped with a 26-pin RGB connector as an interface for external
accessories. Compatible accessories connected by the RGB connector
can enjoy the benefits of easy installation and touch-control operations.
(2) Connecting GEX-2850DVB2 to Multimedia Receiver via
Mini HDMI Connector
IMPORTANT NOTE: Please be sure to set GEX-2850DVB2 HDMI
output resolution to 480P for interoperability. Please refer to “Display
Setting” for HDMI output resolution selection.
(3) Connecting GEX-2850DVB2 to Multimedia Receiver
AUX Output
RGB Cable
Basic Operation
Antenna
Antenna
RGB Interconnection
Cable
Power / IR Cord
IR Extension Cable
GEX-2850DVB2
GEX-2850DVB2
Pioneer Multimedia Receiver
HDMI Cable
Aux Cable

7
Antenna Installation
In-car digital TV reception varies from vehicle to vehicle and the
installer may need to try several mounting positions to determine
the best one which provides strong and stable signal reception in
your vehicle.
Important Notes on Antenna Installation: For a better reception,
please place the rod antenna horizontally, and keep the rod
antenna away from metals.
Antenna Position
To extend the reception area, we recommend that one antenna is
mounted at the front and one at the rear of the vehicle. Please
refer to the diagram below for some recommended locations.
(1) Behind the Front Bumper, provided that it is not metal
(2) Top of Front Windscreen, but at least 5cm away from metal
body (in car)
(3) Top of Rear Windscreen, but at least 5cm away from metal body
(in car)
(4) Bottom of Rear Windscreen, but at least 5cm away from metal
body (in car)
(5) Behind the Rear Bumper, provided that it is not metal
*Noted: The DTV signal of position (2) ~ (4) is generally better than
position (1) and (5). However, because the windshields of many cars
are usually equipped with film coating (that contains metal), the actual
signal reception may be degraded, depending on the extent of metal
embedded within film.
Antenna Cable Routing
Once a suitable position is found, carefully route the antenna
cables to the receiver unit and then connect to the Antenna Inputs
on the DTV receiver.
1
2
4
3
5

8
Quick Guide for First-time User.
GEX-2850DVB2 can be connected with a compatible Multimedia
Receiver via its RGB Connector. With such a system configuration,
the AV shall, after powering on, immediately detect the existence of
GEX-2850DVB2 device and a “TV” icon will appear in the Multimedia
Receiver main menu for user selection.
Note: For models without TV icon, press Mode Button to activate TV
Function.
Step 1: Turn on the Pioneer Multimedia Receiver & Access GEX-
2850DVB2
1. Turn on the Pioneer head unit
2. Select the “TV” source from Pioneer head unit main menu
3. “Home Menu” screen of GEX-2850DVB2 TV receiver shows up
Pioneer AVH Main Menu GEX-2850DVB2 Main Menu
Note: if HDMI interconnection is used between GEX-2850DVB2 and
Multimedia Receiver, the TV icon will not appear in the Multimedia
Receiver main menu. Instead, one can select the HDMI source from
Multimedia Receiver main menu to access GEX-2850DVB2 TV
receiver.
Step 2: Enter the TV mode (at GEX-2850DVB2 Main Menu) to start
“Setup Wizard”
Touch Panel:
Press [TV] icon in GEX-2850DVB2 Home Menu to enter the TV
mode. The setup wizard screen shall show up after this operation.
Remote control:
Press [VOL] / [VOL] buttons to select “TV” options and press
[OK] button to enter the TV mode. After that, the setup wizard
screen shows up.
Step 3: Configure “Setup Wizard” to select preferred OSD
Language, region of operation, etc.
Touch panel:
1. Press [UP]/[DOWN] icons to highlight the item.
2. And press [LEFT] /[RIGHT] icons to set the highlight item.
3. Then, press [UP]/[DOWN] to scroll up and down the
options.
4. After that, press [ ] icon or exit the setting by pressing
[ ] icon.
Remote control:
1. Use [CH]/[CH] buttons to highlight the item.
2. Use [VOL] button to set the highlight item.
3. Press [CH]/[CH] buttons to scroll up and down the options.
4. Select one by pressing the [OK] button or exit the setting by
pressing the [MENU] button.
Operation Guide

9
Step 4: Press “Start” to perform channel search for available TV
channels.
Touch panel:
Press [UP]/[DOWN] icons to highlight the Start item. Then,
press [ ] icon to start.
Remote control:
Use [CH]/[CH] buttons to highlight the Start item. Then,
Press [OK] button to start.
Step 5: You can now sit back and enjoy your mobile TV.
NOTE: Keep [OK] button pressed to change the aspect ratio of current TV
program.
Operating GEX-2850DVB2
Home Menu of GEX-2850DVB2 TV
receiver allows a user to enter one of its
four different mode of operations:
TV Mode
To enter TV mode.
Movie Playback Mode
To enter playback mode and watch movie files.
Music Playback Mode
To enter audio playback mode and listen to music.
System Settings
To configure the device settings.
Note: Press the [HOME] key to go back to the home
screen anytime.

10
TV Mode
1. On the home menu screen, press or
select [TV] icon to enter the TV
mode operation.
Touch panel:
Press [TV] icon to select it.
Remote control:
Use [VOL] and [VOL] buttons
to highlight the [TV] icon and press [OK] button to select it.
2. If there are TV channels stored in GEX-2850DVB2 already, one can
then select your preferred TV channel. Otherwise, one should
configure the SET-UP wizard and then perform a channel scan to
find possible TV channels. To tune TV programs (if any), one can:
Touch panel:
Press [UP]/[DOWN] icons to
select TV channel.
Remote control:
Press [CH]/[CH]buttons to
select TV channel.
Digital keyboard on touch panel:
-Press icons to display
the digital keyboard
-Press numerical keys, 0
~9, to select TV channel.
-Press numerical keys, 0-9, to
select TV Channel
-Press icons to hide the
digital keyboard
\
Menu Selections under TV Mode
After entering the TV service,
press [ ] icon / [MENU] button
to open TV menu. By navigating
the different options, you can have
access to channel list, channel
setting, channel scan function,
channel Information, TV audio
settings, subtitle function, Display
function and teletext services.
Channel List
This is to display channel
information, preview the
program, and to access the
Electronic Program Guide (EPG)
info.
a. Channel List
Touch Panel:
1. Select “Channel List” in the TV menu and press [ ] icon.
The “Channel List” will appear on screen.
2. Press [UP]/[DOWN] icons to scroll up/down the channel
list to preview the program.
3. Press [RIGHT] icon to show the details of the channel.

11
4. Press [ ] icon to exit.
Remote Control:
1. Select “Channel List” in the TV menu and press [OK] button.
The “Channel List” will appear on screen.
NOTE: you can also press [EPG] button on the remote control to
enter “Channel List” while enjoying TV.
2. Press [CH]/[CH] buttons to scroll up/down the channel list to
preview the program.
3. Press [VOL] button to show the details of the channel.
4. Press [EXIT]/[MENU] button or to exit.
b. EPG Schedule
Touch Panel:
1. Press [RIGHT] icons to scroll
the date list to see the program
schedule of the corresponding date.
2. Press [RIGHT] icons to activate
program schedule.
3. Press [UP]/[DOWN] icons to
scroll up/down the program schedule
to see previous/next program on the
selected date.
4. To return back to date list, press [LEFT] icon.
5. Press [ ] icon to return to “Channel List”.
Remote Control:
1. Press [VOL] buttons to scroll the date list to see the program
schedule of the corresponding date.
2. Press [VOL] button to activate program schedule.
3. Press [CH]/[CH] buttons to scroll up/down the program
schedule to see previous/next program on the selected date.
4. To return back to date list, press [VOL] button.
5. Press [EXIT]/[MENU] button to return to “Channel List”.
c. Program Information
Touch Panel:
1. While in program schedule list,
press [ ] icon to see more
information of the selected program.
2. Press [ ] icon to return to
“Schedule”.
Remote Control:
1. While in program schedule list, press [OK] button to see more
information of the selected program.
2. Press [EXIT]/[MENU] to return to “Schedule”.
Channel Setting
This is to reset and to edit
the TV channel listing by
using skip, move, and
delete functions
Touch Panel:
1. Select “Channel Setting” in the TV Menu and press [ ] icon.
The setting screen will appear as on the right picture.
2. Press [ ]/[ ] icons to scroll up/down the channel list.
Press desired channel to enter the editing menu for a chosen channel.
3. Press [ ] icon to exit anytime.
Remote Control:
1. Select “Channel Setting” in the TV Menu and press [OK] button.
The setting screen will appear as on the right picture.
2. Press [CH]/[CH] buttons to scroll up/down the channel list.
Press [OK] button to enter the editing menu for a chosen channel.
3. Press [EXIT]/[MENU] button to exit anytime.

12
Channel Movement
After entering the Channel Movement menu.
Touch Panel:
Press [ ]/[ ] icon to entry move mode and move the
channel up or down in the list. Then, channel movement
automatic saves the new listing.
Remote Control:
Select the [ ]/[ ] visual-icon on screen by pressing
[VOL]/[VOL] buttons. And use [CH]/[CH] buttons to
move the channel up or down in the list. Then, press [OK]
button to save the new listing.
Channel Delete
After entering the channel delete menu.
Touch Panel:
Press [ ] icon to entry delete mode. And press
[ ]/[ ] icons to select the channel in the list. Then,
press [ ] icon to delete the channel.
Remote Control:
Select the “DELETE” visual-button on the screen by using
[VOL]/[VOL] buttons. Then, press [OK] button to delete the
channel.
NOTE: this function will permanently delete the channel from
the current program list. Users restore the channels only by
performing auto search.
Skip a Channel
After entering the Skip a Channel menu.
Touch Panel:
Press [ ] icon to entry skip mode. And press
[ ]/[ ] icons to move the channel up or down in the
list. Then, press [ ] icon to activate or deactivate it.
Remote Control:
Select the [ ] visual-icon on screen by pressing
[VOL]/[VOL] buttons. Then, press [OK] button to activate or
deactivate it.
NOTE: this function temporarily removes the channel from the
program list. Users can restore the channels by deactivating the
function.
Scan To search the available
channels automatically:
Touch Panel:
Press [ ] icon to enter the
scan option.
Remote Control:
1.Browse the TV menu screen using [VOL]/[VOL] buttons to
highlight the “Scan” option.
NOTE: you can also press [SCAN] button to enter “Automatic
Channel Scan” while enjoying TV.
2.Press [OK] button to start the channel search.

13
Channel Information
Provide the information of current service’s system
parameters and signal information
Touch Panel:
1. Press [ ] icon to display the
channel information.
2. Press [ ] icon to exit.
Remote Control:
1. Browse the TV menu screen using [VOL]/[VOL] buttons to
highlight the channel information option.
NOTE: you can also press [INFO] button to enter “Channel
Information” while enjoying TV.
2. Press [OK] button to display the channel information.
3. Press [EXIT]/[MENU] button to exit
Audio
To select either master or secondary language as well as
the audio channel of current service
Touch Panel:
1. Press [ ] icon to display the
Audio information.
2. Use [RIGHT]/[LEFT] icons
to select stereo/up/down audio
channel. Scroll the available
language using [UP▲]/[DOWN▼] icons.
3. Press [ ] icon to exit.
Remote Control:
1. Browse the TV menu screen using [VOL]/[VOL] buttons to
highlight the “Audio” option. Press [OK] button to enter the “Audio”
menu.
2. Use [VOL]/[VOL] buttons to select stereo/up/down audio
channel. Scroll the available language using [CH▲]/[CH▼]
buttons.
3. Press [OK] button to select the language.Press [EXIT]/[MENU]
key to exit.
Subtitle
To activate or deactivate the subtitle function
Touch Panel:
1. Press [ ] icon to display
the Subtitle information.
2. Scroll the available
language using
[UP▲]/[DOWN▼] icons.
3. Press [ ] icon to exit.
Remote Control:
1. Browse the TV menu screen using [CH]/[CH] buttons
to highlight the “Subtitle” option. Press [OK] button to enter
the “Subtitle” menu.
2. Scroll the available language using [CH▲]/[CH▼] buttons.
3. Press [OK] button to activate the subtitle.Press
[EXIT]/[MENU] key to exit.
NOTE: you can also press [RED]button to enter “Subtitle”
while enjoying TV.

14
Display
To set the mode of display
Touch Panel:
1. Press [ ] icon to entry
display mode.
2. Press [UP]/[DOWN] icons
to scroll up/down the display item.
3. Press [ ] icon to enter the editing menu for a chosen display.
Remote Control:
1. Using [VOL]/[VOL] buttons, browse TV menu to highlight
the “Display” option. Press [OK] button to enter “Display” menu.
2. Press [CH]/[CH] buttons scroll up/down the display item.
3. Press [OK] button to enter the editing menu for a chosen display.
Teletext
To enter the teletext menu
Touch Panel:
1. Press [ ] icon to entry
Teletext mode.
2. Press desired page of icon to
view the previous and next page.
3. Press [ ] icon to exit.
Remote Control:
1. Using [VOL]/[VOL] buttons to highlight the “Teletext” option.
2. Press [OK] button to enter “Teletext” menu.
3. Press [CH] button to view next page or [CH] to view
previous page. Press numerical key button to jump to the specific
teletext page.
4. Press [MENU]/[EXIT] to leave.
TV Recording Function
1. In TV mode, press [REC] to start recording TV programs. When
unit is started recording, icon will appear on the upper
left screen & the timer menu (disappear in 10 sec without control)
will appear on the lower left screen simultaneously.
2. Recorded TV programs can be played back in Movie mode.
NOTE:
a. Please ensure that a USB Storage device is connected to the
unit before recording.
b. While turn off the ACC/IGN, the unit will continue recording if
recording time has not endedt. The unit will automatically turn off
when the recording is finished.
Important notes:
i. A recorded program will be stored in a default folder named as
“Recorded_TV”. The file types will be “.tsv” file for TV program.
ii. Maximum file size of FAT/FAT32 is 4 GB, files will be split
automatically.
iii. 1 GB storage can record approximately 45 minutes.
iv. Storage system supports FAT/FAT32/NTFS format.
v. Generally, all USB 2.0 can be used as recorded file storage. It’s
recommended to format the USB storage device before it’s
inserted into the in-car TV receiver unit.
WARNING! Please do not edit the “*.PLT” & “RECORD.TMP” files.
Modifying/deleting this file will cause error on recorded file.

15
Movie Mode
The section below will explain you how to quickly play a video file
stored on USB device.
1. After selecting movie playback
mode on the home screen, the file
browser screen will appear.
Touch Panel:
Press [Movie] icon to start.
Remote control:
Press [OK] button to select the
root folder.
2. The available video files will
appear on screen.
Touch Panel:
Press [LAST PAGE] / [NEXT
PAGE] to scroll up and down
the files to start the movie.
Press [ ] button to return.
Remote control:
Use [CH] and [CH] buttons to scroll up and down the files,
then select the desired file by pressing [OK] button. Press [EXIT]
button to return.
NOTE: Users can only choose video files under this mode. The system will
not support music files under this mode.
3. The video file will instantly start playing.
Touch Panel:
/ Increase or decrease
the speed of track.
/ Go the previous or
next video file.
Pause the video file.
View the video information
Setting desired mode from the
Movie menu
Remote Control:
FR / FF Increase or decrease the speed of track.
[PLAY/PAUSE] Pause or resume music playing.
[RED] Delete highlighted file/folder.

16
Movie Mode Menu
On entering Movie mode service, user can manipulate aspect ratio,
sound effect, set up the equalizer, set the play mode, change audio,
and subtitle. To access the menu options under Movie mode,
Touch Panel:
1. Press [ ] to enter “Menu”.
2. Press [UP]/[DOWN] icons to highlight the item you want to
adjust.
3. Press [RIGHT] icons and use [UP]/[DOWN] to scroll up
and down the options.
4. Select options by pressing the
[ ] icon or exit the setting by
pressing the [ ] icon.
5. After adjusting, press [ ]
icon to exit the “Movie Menu”.
Remote Control:
1. Press [MENU] to enter “Menu”.
2. Press [CH]/[CH] buttons to highlight the item you want to
adjust.
3. Press [VOL] button and use [CH]/[CH] to scroll up and
down the options.
4. Select one by pressing the [OK] button or exit the setting by
pressing the [EXIT]/[MENU] button.
5. After adjusting, press [EXIT]/[MENU] button to exit the “Movie
Menu”.
Audio Selection
Touch Panel:
1. Select [AUDIO] option to enter “Audio Selection” while enjoying
Movie playback.
2. Use [LEFT]/[RIGHT] icons
to select stereo/left/ right audio
channel. Scroll the available
language by using
[UP▲]/[DOWN▼] icons. Press
[ ] icon to select the language.
3. Press [ ] icon to exit.
Remote Control:
1.Press [AUDIO] button to enter “Audio Selection” while enjoying
Movie playback.
2. Use [VOL]/[VOL] buttons to select stereo/left/right audio
channel. Scroll the available language using [CH▲]/[CH▼]
buttons. Press [OK] button to select the language.
3. Press [EXIT]/[MENU] key to exit.
Subtitle
Touch Panel:
Press [UP▲]/[DOWN▼] icons to select [Subtitle] option. And press
[ ] icon to enter “Subtitle Selection” while enjoying Movie
playback.
Remote Control:
1. Press [RED] button to enter “Subtitle” menu while enjoying
Movie playback.
2. Press [RED] button to change switch subtitle or off.

17
Music Mode
The GEX-2850DVB2 Music Mode allow users to play music files
stored on USB device.
1. After selecting music playback mode on the home screen, the file
browser screen will appear.
Touch Panel:
Press [ ] icon to select the root
folder.
Remote Control:
Press [OK] button to select the
root folder.
2. The available audio files will appear on screen.
Touch Panel:
Press [LAST PAGE] /[NEXT
PAGE] to scroll up and
down the files and press the
file to start the music.
Return to the home menu.
/ Next / Previous
/ Play or pause the video file.
/ / Music repeat, Music single repeat or Music Folder
repeat
Music random
Remote Control:
Use [CH] and [CH] buttons to scroll up and down the files,
select the desired file by pressing the [OK] button.
[FR] / [FF] Increase or decrease the speed of track
[PLAY/PAUSE] Pause or resume music playing.
[RED] Delete highlighted file/folder.
Music Mode Menu
Press [MENU] button to select the music menu.
Touch Panel:
Adjust the mode by pressing the
[ / / / / / /
/////]
icons.
: Return to parent directory
: Scroll to previous/next page
/ : Play previous/next file
/ : Play/Pause
: Play randomly
: Repeatly play whole directory
: Repeatly play selected file
: Repeatly play off
: Go to HOME menu
Remote Control:
1. Press [CH]/[CH] buttons to browse the files in the file
directory; press [OK] button to play the selected file.
2. Press [VOL]/[VOL] button to play previous/next file.
3. Press [MENU] button to enter Music MENU to set the play
mode(shuffle or sequence) and set the repeat mode(repeat off,
repeat file, or repeat directory)
4. After adjusting, press [EXIT]/[MENU] button to exit.

18
System Settings
The system settings mode allows users to select the country /
language setting, display setting, HDMI Setting, Version upgrade,
and Reset to default.
Touch Panel:
Press selected icons to entry
the desired setting item.
Remote Control:
Use [VOL]/[VOL] buttons
to highlight the desired item
and press [OK] button to select
one.
Country / Language
To set up the OSD language and TV regional settings
Touch Panel:
1. Press [UP]/[DOWN] icons
to highlight the item you want to
adjust.
2. Press [VOL] icon and use
[UP]/[DOWN] icons to scroll
up and down the options.
3. Select one by pressing the
[ ] icon or exit the setting by
pressing the [ ] icon.
4. After adjusting, press [ ] icon to exit the “Country /
Language” menu.
Remote Control:
1. Press [CH]/[CH] buttons to highlight the item you want to
adjust.
2. Press [OK] button and use [CH]/[CH] buttons to scroll up
and down the options.
3. Select one by pressing [OK] button or exit the setting by
pressing [EXIT ]/ [MENU] button.
4. After adjusting, press [EXIT] / [MENU] button to exit the
“Country/Language” menu.
Display Setting
To set up and adjust the display settings
Touch Panel:
1. Press [UP] / [DOWN] icons to highlight the item you want to
adjust.
2. Press [VOL] icon and use
[UP] / [DOWN] icons to scroll
up and down the options.
3. Select one by pressing the
[ ] icon or exit the setting by
pressing the [ ] icon.
4. After adjusting, press [ ]
icon to exit the “Display” menu.
Remote Control:
1. Press [CH]/[CH] buttons to highlight the item you want to
adjust.
2. Press [OK] button and use [CH]/[CH] buttons to scroll up and
down the options.
3. Select one by pressing the [OK] button or exit the setting by
pressing [EXIT]/[MENU] button.
4. After adjusting, press [EXIT]/[MENU] button to exit the “Display”
menu.

19
HDMI Setting
To choose AV output through HDMI and adjust output
color
Touch Panel:
1. Press [UP]/[DOWN] icons
to highlight the item you want to
adjust.
2. Press [VOL] icon and use
[UP] / [DOWN] icons to scroll
up and down the options.
3. Select one by pressing the
[ ] icon or exit the setting by pressing the [ ] icon.
4. After adjusting, press [ ] icon to exit the “HDMI Setting”.
Remote Control:
1. Press [CH]/[CH] buttons to highlight the item you want to
adjust.
2. Press [OK] button and use [CH]/[CH] buttons to scroll up
and down the options.
3. Select one by pressing the [OK] button or exit the setting by
pressing the [EXIT]/[MENU] button.
4. After adjusting, press [EXIT]/[MENU] button to exit the “HDMI
Setting”.
Version/Upgrade
To upgrade the user interface software version
1. Insert the USB device containing the software upgrade file into
the card slot.
2. After entering the Version/Upgrade menu,
Touch Panel:
Press [ ] icon to start the
upgrade.
Remote Control:
Press [OK] button to start the
upgrade.
Reset to Default
To reset all settings to factory default
Touch Panel:
1. Press [ ] icon to entry
“Reset Default” option.
2. Press [YES] to reset system’s
settings to factory default.
3. Press [ ] icon to exit.
Remote Control:
1. Press [VOL]/[VOL] buttons to highlight “Reset Default” option
and press [OK] to enter.
2. Press [OK] to reset system’s settings to factory default.
3. Press [EXIT] to exit.

20
Troubleshooting
The common cases and their respective solutions are listed in the table
below. If the problem persists, please contact the after sales service.
Symptom
Cause
Action Reference
No picture, no
audio.
The power cord is not
properly inserted into
the unit.
Check the power wire
connection.
The unit is not
switched on.
Press [POWER] button.
Unit is in stand-by
mode.
Press [POWER] button.
In TV mode,
the number of
TV channels is
not as much
as we
expected.
The number of
available channels is
limited due to the
local broadcasting
system. The available
channels can vary
depending on the
area.
Perform “Auto Search” or
“Manual Search” to rescan all
the channels.
The signal quality of
some TV channels is
too low.
Please use active antennas
instead of passive antennas
for better reception quality.
Some TV channels
are not available.
Only the locally free
broadcasted channels can be
viewed. They can differ
depending on the area.
Symptom
Cause
Action Reference
In TV mode, all
of the
channels show
“no signal or
random
mosaic tiles
appear on the
display.”
Some channels signal
quality is too low
Please use active antenna
(provided) instead of passive
antenna for better reception.
The antennas are not
properly connected
Please check the connection
of the antennas
No TV service is
provided in the area.
Check your country TV
coverage map. It is not
possible to watch digital
TV/listen to digital radio in
non-covered areas.
Incorrect Regional
Setting
Please check whether
“Regional Setting” is correct,
and perform “Auto Search” to
rescan all of the channels.
The video is
fine but there
is no sound.
The audio is muted.
Press [MUTE] button to
disable the mute function.
The remote
control does
not work
No power.
Check the remote control
battery. NOTE: the remote
control is supplied with a small
plastic insulator that must be
removed for the unit to
function. Check that the plastic
insulator has been removed.
No “line-of-sight”
between unit and
controller
Ensure there are no obstacle
between the controller and the
unit.
