Pioneering Technologies RangeMinder Guide

Printed in Canada PTI-STT69-A
Intelligent Cooking System
A Pioneering Technology Product
www.pioneeringtech.com
www.preventcookingfires.com
Care and Use Manual
Limited Warranty
IMPORTANT!
READ ALL INSTRUCTIONS BEFORE INSTALLATION
KEEP THIS MANUAL FOR FUTURE REFERENCE
NEVER LEAVE COOKING UNATTENDED

2
CONTENTS
CONTENTS...................................................................................................................................................2
IMPORTANT SAFETY PRECAUTIONS....................................................................................................3
FACTS AND FIGURES................................................................................................................................3
Introduction....................................................................................................................................................4
Features..........................................................................................................................................................4
How the RangeMinder™ works ....................................................................................................................5
Cooking with the RangeMinder™ .................................................................................................................6
Efficient Cooking...........................................................................................................................................7
What this product will not do?...................................................................................................................7
Care and use...................................................................................................................................................8
Cleaning .....................................................................................................................................................8
Replacing the Battery.................................................................................................................................8
Troubleshooting .............................................................................................................................................9
Specifications...............................................................................................................................................11
Dial...........................................................................................................................................................11
Base Unit..................................................................................................................................................11
FCC Class B Notice.................................................................................................................................12
Limited Warranty.........................................................................................................................................13

3
IMPORTANT SAFETY PRECAUTIONS
Safety Tips from the National Fire Protection Association (NFPA)
Never leave food cooking on the stovetop unattended.
Keep cooking area clean and clear of combustibles (e.g. potholders, towels,
rags, drapes and food packaging).
Keep children and pets away from cooking areas by creating a three-foot (one-
meter) ‘kid-free zone’ around the stove/range.
Wear short, close fitting or tightly rolled sleeves when cooking. Loose clothing
can dangle onto the stove/range burners and catch fire.
Turn pot handles inward so they can’t be bumped and children can’t grab
them.
Never use a wet oven mitt, as it presents a scald danger if the moisture in the
mitt is heated.
FACTS AND FIGURES
1
In 2011, cooking was involved in an estimated 156,300 home structure fires
that were reported to U.S. fire departments. These fires caused:
•470 deaths,
•5,390 injuries, and
•$1.0 billion in direct property damage.
Cooking caused almost half (44%) of reported home fires, one of every five
(19%) home fire deaths, two of every five (39%) home fire injuries, and 15% of
the direct property damage from home fires in 2011.
Unattended cooking was by far the leading cause of cooking fires.
1
From the National Fire Protection Association (NFPA)

4
INTRODUCTION
Congratulations on your purchase of the RangeMinder™. The patented and
patent pending RangeMinder™ Intelligent Cooking System is the latest tool in the
fight against unattended stovetop cooking fires. This product is an easy to install
upgrade for stoves/ranges, engineered to help prevent cooking fires before they
start while also helping to reduce the amount of energy used to cook. Best of all it
is fully automatic.
The system includes touch sensing intelligent dials which know when you have
turned the burner on or off. They allow you to cook normally while the
RangeMinder™ does the rest. You will have the comfort of knowing that the
RangeMinder™ will draw your attention back to the stove/range if you get
distracted while cooking or forget the stove/range is on.
FEATURES
Easy to install. The dials are designed to directly replace existing dials on
most North American stoves/ranges.
Easy to setup. With a few simple steps the RangeMinder™can be set up to
work on either gas or electric stoves/ranges.
The intelligent dials with touch sensing technology know when you have
turned the burner on and to which setting, allowing it to adapt to your cooking.
To avoid unnecessarily loud noises the reminder alert starts at a low volume
and increases until you return to the stove/range.
The touch intelligent dials communicate wirelessly with the base so the base
unit can be placed centrally in your home (within 15-25 ft. of the stove/range)
to ensure you hear it wherever you are.
Additional base units can be added to the system and placed around the home
(within 15-25 ft. of the stove/range) for those with a hearing impairment or
times when you have been distracted and moved away from the kitchen.
Special low-pitch buzzer operates at a frequency (850-1000 Hz) suited for
those with impaired hearing.
Additional dials can be added for stoves/ranges with more than 4 burners
(IMPORTANT: Some features not compatible with multi-coil elements).

5
HOW THE RANGEMINDER™WORKS
There are many factors affecting how quickly food heats such as weight, type of
pan, contact surface, etc. In general, the higher you set the dial, the faster the
cooking ingredients will heat and the faster they will reach the point of ignition
which means that cooking on HI requires more attention. This is the basis for the
design of the RangeMinder™. The RangeMinder™sensor technology detects
how much the dial has been turned and it uses this to set the timer. This enables
the dial to grab your attention quickly when cooking on HI and avoid unnecessary
interruptions when on LO.
In addition, the RangeMinder uses a patent-pending technology to track all the
burners you are using and set the timer based on which burner will need attention
first. This minimizes unnecessary interruptions while keeping you safe.
What is a safe time? There are a lot of factors affecting time to ignition including
the type of stove/range, quality of cooking utensils and more. Below is a timing
guide we recommend which is based on more than a decade of experience
designing, building and testing products to help prevent cooking fires. While no
system can guarantee that a fire will not start, our experience has been that this
system can significantly reduce the chances of injury or property damage.

6
COOKING WITH THE RANGEMINDER™
The patented and patent pending RangeMinder™was engineered to help prevent
the number one cause of household fire –stovetop cooking –and more
specifically to help prevent unattended cooking, the leading cause of these fires.
NEVER LEAVE COOKING UNATTENDED.
1. Always hold the dials from the grip. Do not hold from the edges.
2. Turn your range top on just as you normally would.
3. The dial is designed to know at what temperature setting you are cooking at
and to set the timer appropriately. For example, if you are cooking on HI the
base unit will alert you after approximately 5 minutes. If you are cooking on LO
the base unit will alert you after approximately 60 minutes. During installation
RangeMinder™ dial is calibrated to identify all temperature settings and set the
timer for the appropriate level between 5 and 60 minutes.
4. If the base unit begins beeping check your cooking to determine if the element
needs to be turned down. If it does, simply turn the dial to the new lower setting
and the dial timer will reset based on the new setting. If your cooking
temperature does not need to be adjusted simply touch any one of the 4 dials
and the timer will be automatically reset and the timing will begin again.
5. A short beep from the base unit will let you know that timer has been set.

7
EFFICIENT COOKING
The RangeMinder can help you save energy as well by helping to avoid these
scenarios:
Forgetting a pot of water on HI long after it has started boiling.
Forgetting to turn the burner OFF after cooking is complete.
What this product will not do?
It will not prevent all cooking fires.
It will not shut off the stove.
It is not a replacement for safe cooking behavior.

8
CARE AND USE
Cleaning
Use a damp cloth to clean the RangeMinder™dials. For stubborn stains use a
household spray cleaner by applying the cleaner to a clean cloth and wiping the
dial.When cleaning under the dial it is recommended that the dials be removed
one at a time and reinstalled before moving on to the next one.
If the dial is removed from the stove/range, be sure to return it to the same
location. Since each dial is calibrated for that location placing it in a different
location may affect the accuracy and result in improper operation. If unsure which
location the dial was in simply remove the battery and repeat the calibration
procedure in the new location.
IMPORTANT!
Although RangeMinder dials resist steam/vapor and occasional splashes of water
they are not waterproof. Never immerse dials in water or soak with liquids as any
liquid entering the dial may cause it to fail.
Replacing the Battery
When the battery reaches a critically low level the base unit will emit a single low-
pitched beep. The dial will then cease to transmit and will flash slowly. The
battery should be replaced immediately. Battery life will be approximately 1 year
for typical use. To replace the battery on a dial follow the instructions in the
Installation Manual.
If you are replacing one of the dials or the base unit you will need to set-up the
dial/base unit as if you are setting it up for the first time. Please follow the
instructions in the Installation Manual.

9
TROUBLESHOOTING
1.The light on the base unit is on but I never get an alert when I am cooking.
a) Base is not responding
A power outage or fluctuation has caused the base unit to lock up. Unplug
the base. Wait 10 seconds and plug it in again.
The stove may be too far from the base unit. Move the base to an outlet
closer to the stove/range.
b) Dial is not transmitting
The battery in the dial may be dead. Replace battery.
c) The learn procedure has not been performed or the memory in the dial has
been erased.
Perform installation again.
2.Every time I perform a calibration the base unit beeps 5 times.
The RangeMinder does not recognize the stove type.
Location of HI and LO are not where expected. Repeat calibration being
careful to stop at the exact locations of HI and LO.
Stove/range type not in memory. The stove/range is not one of the common
types held in memory or it has a dual-ring type burner.
NOTE: Dial will default to 5 minutes in this case.
3.The base unit does not beep after I insert a new battery and place it on the
stove/range.
Dial is not responding to your touch or the magnets on the stove/range.
After a new battery is installed in the dial the touch sensor will perform a
self-calibration. It you are touching the touch-sensitive area during this
process the calibration will fail and the dial will be unable to detect your
touch. When installing a battery do not touch the grip portion for a couple
seconds to allow the calibration to complete.
Ensure sensor ring is installed on the stove and the arrow is pointing toward
the OFF position (usually up).

10
4.When I insert a new battery in the dial I hear a low pitched tone from the
Base Unit.
Battery voltage low
A single low pitched beep signifies a low battery. This is accompanied by
slow flashing of the light on the dial. Replace battery with a new one.
5.After a blackout or after plugging in the Base Unit the alert begins to
sound immediately.
One of the burners was ON prior to the power being lost. To help provide
maximum protection, the base unit will remember if a burner was on prior to
losing power. If a burner was on then it will alert you immediately once power is
restored to remind you that something was cooking and the burner may still be
on.
The alarm can be stopped by touching each of the dials one at a time. This
will renew the link to the base unit.
If the alarm continues to sound then the base unit may need to be reset. To
reset touch and hold the learn button on the base unit until you hear 3
beeps. This will erase all settings in memory and disable the RangeMinder.
In this case you must put the base unit back into learning mode and touch
each dial to renew the link to the base. Ensure the base beeps once for
each dial. If this step is not performed the RangeMinder will remain
disabled.
6.After cleaning my stove/range the RangeMinder began to beep or did not
operate properly.
During the calibration process each dial is setup to work with the particular
sensor ring below it. Moving a dial to a different burner may cause the dial to
not operate properly.
Move the dial back to the position used during the calibration OR
Remove the battery and perform the calibration procedure again for the new
position.

11
SPECIFICATIONS
Dial
Power: 3V, battery operated
Battery Type: CR2450 coin cell
Expected Battery Life: 1 year for typical use
Transmitter Frequency: 434MHz
Range: up to 15-25ft (5-7.5m), dependant on environment such as electrical
interference, obstacles, walls, etc.
Base Unit
Power: 120VAC, 100mA, 60Hz
Buzzer frequency: 850-1000Hz
Maximum buzzer volume: 80dB typ. at 10 centimeters

12
FCC Class B Notice
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
1.This device may not cause harmful interference.
2.This device must accept any interference received, including interference that
may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
Consult the dealer or an experienced radio/television technician for help.
Industry Canada Compliance Statement
This Class B digital apparatus meets the requirements of the Canadian
Interference-Causing Equipment Regulations.
Avis de conformité à la réglementation d'Industrie Canada
Cet appareil numérique de la classe B respecte toutes les exigences du
Réglement sur le matériel brouilleur du Canada.

13
LIMITED WARRANTY
Pioneering Technology Corp. warrants that the product is free from defects in materials
and workmanship when operated and maintained according to the instructions provided
for a period of:
One (1) year from date of purchase for residential use
The limited warranty does not cover damage resulting from commercial use, misuse,
accident, modification or alteration to hardware or software, tampering, unsuitable
physical or operating environment beyond product specifications, or improper
maintenance. There is no warranty of uninterrupted or error-free operation.
For service under this warranty contact your RangeMinder™distributor or Pioneering
Technology Corp. at:
Pioneering Technology Corp. - Service Dept.
220 Britannia Rd. East
Mississauga, Ontario
Canada L4Z 1S6
Tel: [phone] or [phone] ext. 228
Email: [e-mail]
www.pioneeringtech.com
THERE ARE NO OTHER WARRANTIES. PIONEERING TECHNOLOGY CORP.
DISCLAIMS ALL OTHER WARRANTIES, EITHER EXPRESSED OR IMPLIED. THIS
WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY HAVE OTHERS
WHICH VARY FROM STATE TO STATE.
EXCEPT AS STATED HEREIN, IN NO EVENT SHALL PIONEERING TECHNOLOGY
CORP. BE LIABLE FOR ANY DAMAGES WHATSOEVER WHETHER BASED ON
CONTRACT, TORT, WARRANTY OR OTHER EQUITABLE GROUNDS, INCLUDING,
WITHOUT LIMITATION, OR OTHER PECUNIARY LOSS, ARISING OUT OF THE USE
OR INABILITY TO USE THIS PRODUCT, EVEN IF PIONEERING TECHNOLOGY HAS
BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. BECAUSE SOME
STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR
CONSEQUENTIAL OR INCIDENTAL DAMAGE, THE ABOVE LIMITATION MAY NOT
APPLY TO YOU.
Pioneering Technology’s entire liability and your exclusive remedy shall be at Pioneering
Technology’s option, either (a) return of the price paid for the product or (b) repair or
replacement of the product that does not meet Pioneering Technology’s Limited
Warranty and which is returned to Pioneering Technology. In no event shall Pioneering
Technology’s liability exceed the purchase price of the product.
