Piper Aircraft Corporation TWIN COMANCHE PA-39 User manual

AIRPLANE SERVICE MANUAL
CARD 1 OF 4
TWIN COMANCHE
PIPERAIRCRAFT CORPORATION
PART NUMBER 753 645
REVISED: OCT. 1,1998
1Al
Courtesy of Bomar Flying Service
www.bomar.biz

Published by
Technical Publications
O The New Piper Aircraft, Inc.
2926 Piper Drive
Vero Beach,
Florida 32960
U.S.A.
- -
-
- -
-
.- 2 +- Member
-
- E3 =a GeneralAviation
--
- -
- -
-
Manufacturers Association

PIPER TWIN COMANCHESERVICEMANUAL
AEROFICHE REVISION STATUS
Revisions to this service manual 753 645, originally published (on paper only) August 1, 1963 and
reissued (on paper only) December 29, 1972are
as follows:
Revisions Publication Date Aerofiche Card Effectivity
ORIGINAL (Paper only) August 1. 1963 None
COMPLETE REISSUE (Paper only) June 25, 1969 None
COMPLETE REISSUE (Paper only) December 29. 1972 None
1st January 31, 1974 None
2nd June 28. 1976 1.2and3
3rd October
6. 1977 land2
4th April 26, 1978 1.2and3
5th September 10. 1979 1and 2
6th April
6, 1981 1.2.3and4
7th October 28. 1982 1. 2. 3 and 4
8th* October 1. 1998 1, 2, 3, and 4
* Revisions appear in all four cards. Accordingly,
discard your existing card set and replace it with
these cards dated October
1,1998.
A. Consult the latest Piper Customer Service Information Catalog No. 1753-755 (Aerofiche) for
current revision dates for this manual.
B.
The General Aviation Manufacturers Association (GAMA) has developed specifications for
microfiche reproduction of aircraft publications. The information compiled in this Aerofiche
Service Manual will be kept current by revisions distributed periodically. These revisions will
supersede all previous revisions and will be complete Aerofiche card replacements and shall
supersede Aerofiche cards of the same number in the set.
C. Conversion of Aerofiche alphalnumeric grid code numbers:
First number is the Aerofiche card number.
Letter is the horizontal row reference per card
Second number is the vertical column reference per card.
Example:
2J 16 = Aerofiche card number two, row J, column 16.
D. To aid in locating information, a complete Preface containing the Section Index Guide, List of
illustrations and List of Tables for all fiche in this set is provided at the beginning of Card 1.Each
subsequent aerofiche card contains a partial Preface, displaying only those elements on that card.
IDENTIFYING REVISED MATERIAL
A revision to a page is defined as any change to the text or illustrations that existed previously. Such
revisions, additions and deletions are identified by a vertical black line (change bar) along the left-
hand margin of the page opposite only the text or illustration that was changed.
\
Changes in capitalization, spelling, punctuation, indexing, the physical location of the material or
complete page additions are not identified by revision lines.
\
Example
Revised: 1011198
PREFACE

PIPER TWIN COMANCHESERVICE MANUAL
EFFECTIVITY
This service manual is effective for all PA-30 and PA-39 airplanes as follows:
b3Qddbm M&!whlh Serial Numbers Model Yeag
Twin Comanche
PA-30 30-2 thm 30-901. less 30-853 1963 - 1965
Twin Comanche B and PA-30 30-853 and 30-902 thm 30-1744. 1966 - 1968
Twin Comanche Turbo B less 3C-1717
Twin Comanche C and PA-30 30-1717 and 30-1745 thru 30-2000 1968 - 1970
Twin ComancheTbrbo C
nin Comanche C/R and PA-39
Twin Comanche Turbo C/R
PARTS
This manual generally does not contain hardware callouts for installation. Hardware callouts are only
indicated where a special application is required. To confirm the correct hardware used. refer to the
PA-
30139 nin Comanche Part. Catalog P/N 753 646. and FAR 43 for proper utilization.
WARNINGS, CAUTIONS AND NOTES
These are used to highlight oremphasize important information.
- WARNING -
OPERATING PROCEDURES, PRACTICES, ETC., WHICHMAY RESULT IN
PERSONAL INJURY OR LOSS OF LIFE IF NOT CAREFULLY
FOLLOWED.
- CAUTION -
OPERATING PROCEDURES, PRACTICES, ETC., WHICH IF NOT
STRICTLY OBSERVED MAY RESULT IN DAMAGE TOEQUIPMENT.
- Note -
An operating procedure, condition, etc.. which is essential to emphasize
PREFACE
Added: 10IU98

PIPER TWIN COMANCHESERVICE MANUAL
I SECTIONINDEX GUIDE
SECTION SUBJECT
I PART I - Information Common to PA-30 and PA-39
I INTRODUCTION
I1 HANDLING AND SERVICING
111 INSPECTION
IV STRUCTURES
V SURFACECONTROLS
VI NOT USED
APPENDIX
I
CONTROL CABLE INSPECTION PROCEDURE
VII LANDING GEAR AND
BRAKE SYSTEM
VlII POWER PLANT (NORMALLY ASPIRATED)
VIIIA POWER PLANT (TURBOCHARGED)
IX FUEL SYSTEM
X INSTRUMENTS
XI ELECTRICAL SYSTEM
XI1 ELECTRONICS
XI11 HEATING AND VENTILATING SYSTEM
XIV ACCESSORIES AND UTILITIES
PART
U - Information Unique to PA-39
1 INTRODUCTION
I1 HANDLING AND SERVICING
IV STRUCTURES
V SURFACECONTROLS
VIlI POWER PLANT (NORMALLY ASPIRATED)
VIIIA POWER PLANT(TURBOCHARGED)
X INSTRUMENTS
XI ELECTRICAL SYSTEM
XI1 ELECTRONICS
Revised: 10/1/98
