PIPER AIRCRAFT CORPORATION
PA.32R.3OI, SARATOGA SP
SECTION I
GENERAL
SECTION I
GENERAL
1.T INTRODUCTION
This Pilot's Operating Handbook is designed for maximum utilization
as an operating guide for the pilot. It includes the material required to be
furnished to the pilot by FAR/CAR. It also contains supplemental data
supplied by the airplane manufacturer.
This handbook is not designed as a substitute for adequate and
competent flight instruction, knowledge of current airworthiness directives,
applicable federal air regulations or advisory circulars. It is not intended to
be a guide for basic flight instruction or a training manual and should not be
used for operational purposes unless kept in a current status.
Assurance that the airplane is in an airworthy condition is the
responsibility of the owner. The pilot in command is responsible for
determining that the airplane is safe for flight. The pilot is also responsible
for remaining within the operating limitations as outlined by instrument
markings, placards, and this handbook.
Although the arrangement of this handbook is intended to increase its
in-flight capabilities, it should not be used solely as an occasional operating
reference. The pilot should study the entire handbook to familiarize himself
with the limitations, performance, procedures and operational handling
characteristics of the airplane before flight.
The handbook has been divided into numbered (arabic) sections each
provided with a "finger-tip" tab divider for quick reference. The limitations
and emergency procedures have been placed ahead of the normal
procedures, performance and other sections to provide easier access to
information that may be required in flight. The "Emergency Procedures"
Section has been furnished with a red tab divider to present an instant
reference to the section. Provisions for expansion of the handbook have
been made by the deliberate omission of certain paragraph numbers, figure
numbers, item numbers and pages noted as being intentionally left blank.
REPORT: VB'1080
l-l
ISSUED: NOVEMBER 8, 1979

SECTION I
GENERAL
PIPER AIRCRAFT CORPORATION
PA-32R-301, SARATOGA SP
12'11'
36',2
178.3
30.0
Wing Area (sq. ft.)
Min. Turning Radius (ft.)
(from pivot point to wing tip)
5',6"
REPORT: VB-r080
r-2
27'4"
THREE VIEW
Figure l-l
7' 1"
ll,r)Zl^
11',1"
d 'u" {'
o
7' 11"
ISSUED: NOVEMBER 8, 1979

PIPER AIRCRAFT CORPORATION
PA-32R-301, SARATOGA SP
SECTION T
GENERAL
I.3 ENGINE
2 BLADE PROPELLER
(a) Number of Engines
(b) Engine Manufacturer
(c) Engine Model Number
(d) Rated Horsepower
(e) Rated Speed (rpm)
(0 Bore (inches)
(g) Stroke (inches)
(h) Displacement (cubic inches)
(i) Compression Ratio
0) Engine Type
3 BLADE PROPELLER
(a) Number of Engines
(b) Engine Manufacturer
(c) Engine Model Number
(d) Rated Horsepower
(e) Rated Speed (rpm)
(0 Bore (inches)
(g) Stroke (inches)
(h) Displacement (cubic inches)
(i) Compression Ratio
ü) Engine Type
1.5. PROPELLER
2 BLADE PROPELLER
(a) Number of Propellers
(b) Propeller Manufacturer
2600
300
2700
5.t25
4.375
541.5
8.7: I
Six Cylinder, Direct Drive,
Horizontally Opposed, Air Cooled,
Fuel Injected
I
Lycoming
ro-540-KlG5D
300
2700
5.125
4.375
541.5
8.7:l
Six Cylinder, Direct Drive,
Horizontally Opposed, Air Cooled,
Fuel Injected
Hartzell
REPORT: VB-10t0
1-3
Max. Cont.
Power
I
Lycoming
ro-540-KlG5D
T.O. Power-
5 Min. Limit
294
ISSUED: NOVEMBER t, 1979

SECTION I
GENERAL
PIPER AIRCRAFT CORPORATION
PA-32R-30r, SARATOGA SP
(c) Blade Model
(d) Number of Bladqs
(e) Ilub-Modet--
(f) Propeller Diameter (inches)
(l) Minimum
(2) Maximum
(g) Propeller Type
3 BLADE PROPELLER
(a) Number of Propellers
(b) Propeller Manufacturer
(c) Blade Model
(d) Number of Blades
(e) Hub Model
(f) Propeller Diameter (inches)
(l) Minimum
(2) Maximum
(g) Propeller Type
r.7 FUEL
AVGAS ONLY
(a) Fuel Capacity (U.S. gal.) (total)
(b) Usable Fuel (U.S. gal.) (total)
(c) Fuel Grade, Aviation
(l) Minimum Grade
(2) Alternate Fuels
REPORT: VB-1080
t-4
F8475D-4
2
HC-C2Y(K,R)-r( )F
78.5
80
Constant Speed,
Hydraulically Actuated
I
Hartzell
F7663R-O
3
HC-C3YR-r( )F
76
78
Constant Speed,
Hydraulically Actuated
107
102
100 - Green or I00LL - Blue
Aviation Grade
Refer to latest revision of
Lycoming Service Instruction 1070.
ISSUED: NOVEMBER 8. 1979
REVISED: SEPTEMBER 17, 1984

PIPER AIRCRAFT CORPORATION
PA.32R-301, SARATOGA SP
SECTION I
GENERAL
1.9 oIL
Capacity (U.S. quarts) 12
Specification Refer to latest issue of
Lycoming Service Instruction 1014.
Viscosity per Average Ambient Temp. for Starting
SINGLE MULTI
Above 60oF 50 40 or 50
30oF to 90oF 40 40
0o to 70oF 30 zl0 or 20W-30
Below l0oF 20 20W-30
I.T1 MAXIMUM WEIGHTS
(a) Oil
(b) oil
(c) Oil
(l)
(2)
(3)
(4)
(a) Maximum Takeoff Weight (lbs.)
(b) Maximum Landing Weight (lbs.)
(c) Maximum Ramp Weight (lbs.)
(d) Maximum Weights in Baggage
Compartments
(a) Compartment Volume (cubic feet)
(b) Entry Width (inches)
(c) Entry Height (inches)
1.I7 SPECIFIC LOADING
(a) Wing Loading (lbs. per sq. ft.)
(b) Power Loading (lbs. per hp)
ISSUED: NOVEMBER 8, 1979
REVISED: SEPTEMBER 17' 1984
3600
3600
361 5
AFT
FORWARD
100
FORWARD
7.0
16.0
22.0
100
I.I3 STANDARD AIRPI,ANE WEIGHTS
Refer to Figure 6-5 for the Standard Ernpty Weight and the Useful
Load.
r.15 BAGGAGE SPACE
AFT
t7.3
48.0
26.0
20.2
t2.0
REPORT: VB-10t0
1-5

PIPER AIRCRAFT CORPORATION
PA-32R-301, SARATOGA SP
SECTION 2
LIMITATIONS
SECTION 2
LIMITATIONS
2.1 GENERAL
This section provides the "FAA Approved" operating limitations,
instrument markings, color coding and basic placards necessary for
operation of the airplane and its systems.
Limitations associated with those optional systems and equipment
which require handbook supplements can be found in Section 9
(Supplements).
2.3 AIRSPEED LIMITATIONS
SPEED KIAS KCAS
Never Exceed Speed (Vr.rr) - Do not ex-
ceed this speed in any operation. 197 189
Maximum Structural Cruising Speed
(VNd - Do not exceed this speed
except in smooth air and then only
with caution.
Design Maneuvering Speed (Va ) - Do
not make full or abrupt control move-
ments above this speed.
At 3600 LBS. G.W.
At 2230 LBS. G.W.
154 150
134
105
t32
104
REPORT: VB-10t0
2-l
ISSUED: NOVEMBER 8, 1979

SECTION 2
LIMITATIONS
PIPER AIRCRAFT CORPORATION
PA.32R.3OI, SARATOGA SP
CAUTION
Maneuvering speed decreases at lighter weight
as the effects of aerodynamic forces become
more pronounced. Linear interpolation may be
used for intermediate gross weights.
Maneuvering speed should not be exceeded
while operating in rough air.
SPEED
Maximum Flaps Extended Speed (Vrs) -
Do not exceed this speed with the flaps
extended.
Maximum Landing Gear Extension
Speed (Vlo) - Do not exceed this speed
when extending the landing gear.
Maximum Landing Gear Retraction
Speed (Vr-o) - Do not exceed this speed
when retracting the landing gear.
Maximum Landing Gear Extended
Speed (V'u) - Do not exceed this speed
with the landing gear extended.
2.5 AIRSPEED INDICATOR MARKINGS
MARKING
Red Radial Line (Never Exceed)
Yellow Arc
(Caution Range - Smooth Air Only)
Green Arc (Normal Operating Range)
White Arc (Flap Down)
REPORT: VB-1080
2-2
KIAS KCAS
n2 109
t32
il0 r09
t32 r30
IAS
I97 KTS
130
154 KTS to
60 KTS to
57 KTS to
I97 KTS
I54 KTS
I 12 KTS
ISSUED: NOVEMBER 8, 1979

PIPER AIRCR AI.-'t COR PORATION
I'A-32R-30I, SARATO(;A SP
SECTION 2
LIMITATIONS
2.7 POWUR PLANT LIMITATIONS
2 lll.ADE PROPEI-t-l:l(
(l) Numbcr of Engincs
(h) Enginc Manufacturcr
(c) Engine Model No.
(d) Enginc Operating [-imits
(l) Maximum Horse Power
(2) Maxinum Engine Speed
(RPM)
(3) Maximum Oil Temperature
('F)
(e) Oil Pressure
Minimum (red line)
Maximum (red line)
(f) Fuel Flow/ Pressure
Maximum (red line)
(g) Fuel (AVGAS ONLY)
(mininrum grade)
(h) Number of Propellers
(i) Propeller Manufacturer
0) Propeller Hub and Blade Model
(k) Propeller Diameter (inches)
Minimum
Maximum
(l) Blade Angle Limits
l-ow Pitch Stop
High Pitch Stop
lSSl-lED: NOvf,MBER 8. 1979
REVISED: SEPTEMBER 17, 1984
25 PSI
t00 PSt
35 gal/hr; 14 PSI
100 or l00LL
Aviation Grade
I
Hartzell
HC-C2Y(K,R)-r( )F/
F8475D-4
78.5
80
13.5o t 0.2"
34" t lo
REPORT: VB-10t0
2-3
Max. Cont.
Power
294
2600
245
I
Lycoming
r0-540-K rc5D
T.O. Power-
5 Min. Limit
300
2700
245

sEcTloN 2
LIMITATIONS
PIPER ATRCRAFT CORPORATION
PA.32R.3OI, SARATOGA SP
3 BLADE PROPEL.LER
(a) Number of Engines
(b) Engine Manufacturer
(c) Engine Model No.
(d) Engine Operating Limits
(l) Maximum Horse Power
(2) Maximum Rotation Speed (RPM)
(3) Maximum Oil Temperature (o F)
(e) Oil Pressure
Minimum (red line)
Maximum (red line)
(0 Fuel Flow/ Pressure
Maximum (red line)
(g) Fuel Grade (minimum grade)
(h) Number of Propellers
(i) Propeller Manufacturer
0) Propeller Hub and Blade Model
(k) Propeller Diameter (inches)
Minimum
Maximum
(l) Blade Angle Limits
Low Pitch Stop
High Pitch Stop
I
Lycoming
I0-540-KrG5D
2700
25 PSI
100 PSI
35 gal/hr; 14 PSI
100 - Green or
l00LL - Blue
Aviation Grade
I
Hartzell
HC-C3YR-l ( )F/
F7663R-0
12.4" ! 0.2"
32.0o t 1.0"
ISSUED: NOVEMBER t, 1979
REVISED: SEPTEMBER I, l9t6
300
245
I
76\
78
REPORT: VB-1080
2-4

PIPER AIRCRAFT CORPORATION
PA.32R.301, SARATOGA SP
SECTION 2
LIMITATIONS
2.9 POWER PLANT INSTRUMENT MARKINGS
(a) Tachometer
(l) 2 Blade Propeller
Green Arc (Normal Operating Range) 500 to 2600 RPM
Yellow Arc (5 Minute Limit) 2600 to 2700 RPM
Red Line (Maximum) 2700 RPM
(2) 3 Blade Propeller
Green Arc (Normal Operating Range) 500 to 2700 RPM
Red Line (Maximum) 2700 RPM
(b) Oil Temperature
Green Arc (Normal Operating Range) 75o to 245oF
Red Line (Maximum) 245"F
(c) Oil Pressure
Green Arc (Normal Operating Range) 60 PSI to 90 PSI
Yellow Arc (Caution Range) (ldle) 25 PSI to 60 PSI
Yellow Arc (Caution Range)
(Start and Warm Up) 90 PSI to 100 PSI
Red Line (Minimum) 25 PSI
Red Line (Maximum) 100 PSI
(d) Fuel Flow/ Pressure
Green Arc (Normal Operating Range) 0 gal/hr. to 34.9 gal/hr.
Red Line (Maximum) 35 gal/hr.: 14 PSI
2.IIWEIGHT LIMITS
(a) Maximum Weight
(b) Maximum Ramp Weight
(c) Maximum Baggage (100 lbs. each compartment)
NOTE
Refer to Section 5 (Performance) for maximum
weight as limited by performance.
3600 LBS.
3615 LBS.
2OO LBS.
REPORT: VB-1080
2-5
ISSUED: NOVEMBER t, 1979

SECTION 2
LIMITATIONS
PIPER AIRCRAFT CORPORATION
PA-32R-301, SARATOGA SP
2.I3 CENTER OF GRAVITY LIMITS
Weight
Pounds
3600
3200
2400 (and less)
REPORT: VB'1080
2-6
Forward Limit
Inches Aft of Datum
Rearward Limit
Inches Aft of Datum I
9t.4
83.5
78.0
95.0
95.0
95.0
NOTES
Straight line variation between points given.
The datum used is 78.4 inches ahead of the wing
leading edge at the intersection of the
untapered and tapered section.
It is the responsibility of the airplane owner and
the pilot to insure that the airplane is properly
loaded. See Section 6 (Weight and Balance) for
proper loading instructions.
2.I5 MANEUVER LIMITS
No acrobatic maneuvers including spins approved
2.I7 FLIGHT LOAD FACTORS
(a) Positive Load Factor (Maximum) 3.8 G
(b) Negative Load Factor (Maximum) inverted maneuvers
approved
(c) Positive Load Factor - Flaps Down (Maximum) 2.0G
(d) Negative Load Factor - Flaps Down (Maximum) No inverted
maneuvers approved
ISSUED: NOVEMBER 8' 1979

PIPER AIRCRAFT CORPORATION
PA-32R-30r, SARATOGA SP
SECTION 2
LIMITATIONS
2.I9 TYPES OF OPERATIONS
The airplane is approved for the following operations when equipped in
accordance with FAR 9l or FAR 135.
(a) Day V.F.R.
(b) Night V.F.R
(c) Day I.F.R.
(d) Night I.F.R.
(e) Non icing
2.21 FUEL LIMITATIONS
(a) Total Capacity IO7 U.S. GAL.
(b) UnusableFuel.. .....5U.S.G4L.
The unusable fuel for this airplane has been determined as 2.5
gallons in each wing in critical flight attitudes (2.5 gallons is the
total per side, each side having two interconnected tanks).
(c) Usable Fuel . . .. I02 U.S. GAL.
The usable fuel in this airplane has been determined as 5l gallons in
each wing (51 gallons is the total per side, each side having two
interconnected tanks).
2.23 NOISE LEVEL
The corrected noise level of this aircraft is 77.6 d B(A) for two bladed
propeller installations and 78.4 d B(A) for three bladed propeller
installations.
No determination has been made by the Federal Aviation
Administration that the noise levels of this airplane are or should be
acceptable or unacceptable for operation at, into, or out of, 4ny airport.
The above statement notwithstanding the noise level stated above has
been verified by and approved by the Federal Aviation Administration in
noise level test flights conducted in accordance with F.A.R.36, Noise
Standards - Aircraft Type and Airworthiness Certification. This aircraft
model is in compliance with all F.A.R. 36 noise standards applicable to this
type.
REPORT: VB-1080
2-7
ISSUED: NOVEMBER 8' 1979

SECTION 2
LIMITATIONS
PIPER AIRCRAFT CORPORATION
PA-32R-301, SARATOGA SP
2.25 FLIGHT WITH REAR CABIN DOOR OR REAR CABIN DOOR
AND CARGO DOOR REMOVED
The following limitations must be observed in the operation of this
airplane with the rear cabin door or rear cabin door and cargo door
removed:
(a) The airplane may be flown with the rear cabin door or rear cabin
door and cargo door removed. Flight with the front door removed
is not approved.
(b) Maximum speed - 147 KIAS
(c) No smoking.
(d) All loose articles must be tied down and stowed.
(e) Jumper's static lines must be kept free of pilot's controls and
control surfaces.
(0 Operation approved VFR flight conditions only.
REPORT: VB-I080
2-8
ISSUED: NOVEMBER 8, 1979

PIPEN AIRCRAFT CORPORATION
PA-32n-3{[, SARATOGA SP
SECTION 2
LIMTTATIONS
2.29 PLACARDS
In full view of the pilot:
THIS AIRPLANE MUST BE OPERATED AS A
NORMAL CATEGORY AIRPLANE IN COM.
PLIANCE WITH THE OPERATING LIMII'AI-IONS
STATED IN THE FORM OF PLACARDS,
MARKINGS AND MANUALS. NO ACROBATIC
MANEUVERS INCLUDING SPINS, APPROVED.
THIS AIRCRAFT APPROVED FOR V.F.R., I.F.R.,
DAY AND NIGHT NON.ICINC FLIGHT WHEN
EQUIPPED rN ACCORDANCE W|TH FAR el OR
FAR I35.
ln full vicw of thc pilot, thc following takeoff and landing checklists will
bc installed:
TAKEOFF CHECKLIST
Fuel on Proper Tank
Electric Fucl Pump On
Enginc Gages Chcckcd
Alternate Air Closed
Scat Backs Erect
Mixture Set
Propeller Set
Fastcn Belts/ Harness
Flaps Sct
Trim Tab Set
Controls Free
Doors Latchcd
Air Conditioner Off
Fuel on Proper Tank
Seat Backs Erect
Fasten Beltsi Harness
Electric Fuel Pump - On
LANDING CHECKLIST
Mixture - Rich
Propcller - Set
Cear Down
Flaps Set (White Arc)
Air Conditioner Off
The "AlR CONDITIONER OFF" item in the above takeoff and
landing checklists is mandatory for air conditioned aircraft only.
REPORT: VB-1080
2'9
ISSUED: NOVEMBER t, 1979

SECTION 2
LIMITATTONS
PIPER AIRCRAFT CORPORATION
PA-32R-301, SARATOGA SP
On the instrument panel in full view of the pilot:
Ve 134 KIAS at 3600 LBS.
(See A.F.M.)
On the instrument panel in full view of the pilot:
DEMO X-WIND 17 KTS
ln full view of the pilot: (For operations with the rear door removed)
FOR FLIGHT WITH THE DOOR
REMOVED, SEE THE LIMITATIONS
AND PROCEDURES SECTIONS OF THE
AIRPLANE FLIGHT MANUAL.
ln full view of the pilot:
Vro 132 DN, I l0 UP
Vre t32 MAX
Near emergency gcar lever (aircraft equipped with lever release):
EMERGENCY DOWN
Near emergency gear knob (aircraft equipped with cable releasc):
EMERGENCY GEAR EXT PULL
Near emergency gear lever (aircraft equipped with backup gear extender):
OVERRIDE ENGAGED
TO ENGAGE OVERRIDE:
LEVER UP, LATCH DOWN
TO RELEASE OVERRIDE:
I,EVER -I.^ULL UP & RELEASE
On gear override latch (aircraft equipped with backup gear extender):
GEAR OVERRIDE LATCH
Near gear selector switch:
t
REPORT: VB-10t0
2-10
I IO KIAS MAX
I32 KIAS MAX
ISSUED: NOVEMBER t, 1979
REVISED: DECEMBER 10. t98lt
GEAR UP
DOWN

PIPER AIRCRAFT CORPORATION
PA-32R.30I, SARATOGA SP
SECTION 2
LIMITATIONS
Adjacent to upper door latch (front and rear doors):
ENGAGE LATCH BEFORE FLICHT
ln full view of the pilot:
WARNING TURN OFF STROBE
LIGHTS WHEN IN CLOSE PROXIMITY
TO GROUn-D OR DURINC FLIGHT'
THROUGH CLOUD, FOG OR HAZE.
ln full view of the pilot, in the area of the air conditioner controls when
the air conditioner is installed:
WARNING __ AIR CONDITIONER MUST
BE OFF TO INSURE NORMAL TAKEOFF
CLIMB PERFORMANCE.
On the inside of the forward baggage compartment:
MAXIMUM BAGGAGE THIS COMPART-
MEn-T 100 LBS. SEE THE LIMITATIONS
SECTION OF THE AIRPLANE FLIGHT
MANUAL.
On aft baggage closeout
MAXIMUM BAGGAGE THIS COMPART-
MENT IOO LBS. N.O HEAVY OBJECTS ON
HAT SHELF.
On storm window:
DO NOT OPEN ABOVE I29 KIAS
ISSUED: NOVEMBER 8, 1979
REVISED: OCTOBER ll' 1983
REPORT: VB-I080
2-tt

SECTION 2
LIMITATIONS
PIPER AIRCRAFT CORPORATION
PA.32R.3OI, SARATOGA SP
On executive writing table
CAUTlOlr.- THIS TABLE MUST BE
STOWED DU RING TAKEOFF AND
LANDIT-G.
On the face of the tachometer (2 blade propeller only)
AFTER 5 MIt'r".
REDUCE POWER TO
2600 RPM
Adjacent to fuel tank filler caps
FUEL - IOO OR IOOLL
AVIATIOn- GRADE
Adjacent to fuel tank filler caps (serial numbers 32R-83 13010 and up):
AVGAS OIIILY
ss
GRADE
IOOLL
GRADE
too
REPORT: VB-1080
2-t2 ISSUED: NOVEMBER 8, 1979
REVISED: OCTOBER ll, 1983

PIPER AIRCRAF'T CORPORATION SECTION 3
PA..]2R..]OI, SARATO(;A SP T]MERGEN('Y PROCEDURES
SECTION 3
EMERGENCY PROCEDURES
3.I GENERAL
The recommended procedures for coping with various types of
emergencies and critical situations are provided by this section. All of the
required (FAA regulations) emergency procedures and those necessary for
operation of the airplane as determined by the operating and design features
of the airplane are presented.
Emergency procedures associated with those optional systems and
equipment which require handbook supplements are provided in Section 9
(Supplements).
The first portion of this section consists of an abbreviated emergency
checklist which supplies an action sequence for critical situations with little
emphasis on the operation of systems.
The remainder of the section is devoted to amplified emergency
procedures containing additional information to provide the pilot with a
more complete understanding of the procedures.
These procedures are suggested as a course of action for coping with the
particular condition described, but are not a substitute for sound judgment
and common sense. Pilots should familiarize themselves with the
procedures given in this section and be prepared to take appropriate action
should an emergency arise.
Most basic emergency procedures, such as a power off landings, are a
normal part of pilot training. Although these emergencies are discussed
here, this information is not intended to replace such training, but only to
provide a source of reference and review, and to provide information on
procedures which are not the same for all aircraft. lt is suggested that the
pilot review standard emergency procedures periodically to remain
proficient in them.
ISSUED: NOVEMBER 8' 1979
REVISED: SEPTEMBER 17' l9t4
REPORT: vB'10E0
3-l

SECTION 3 PIPER .TIRCRAFT CORPORATION
EMERGENCY PROCEDURES PA.32R.]OI, SARATOGA SP
3.3 EMERGENCY PROCEDURES CHECKLIST
ENGINE FIRE DURING START
Starter
Mixture ..
Throttle
Electric fuel pump
Fuel selector'.. .. .
Abandon if fire continues
ENGINE POWER LOSS DURING TAKEOFF
lf sufficient runway remains for a normal landing, leave gear down and land
straight ahead.
lf area ahead is rough, or if it is necessary to clear obstructions:
Gear selector switch UP
Emergency gear lever (aircraft equipped with
backup gear extender). .. . . .. . . latched in OVERRIDE
ENGAGED position
If sufficient altitude has been gained to attempt a restart:
Maintain safe airspeed
Fuel selector switch to tank
containing fuel
Electric fuel pump check ON
Mixture ..check RICH
. OPEN
... as required
Emergency gear lever.
lf power is not regained, proceed wit h power off landing.
crank engine
. idle cut-off
open
OFF
OFF
Alternateair....
REPORT: VB-1080
3-2
ISSUED: NOVEMBER t, 1979
REVISED: Sf,PTEMBER I' l9tb

PIPER AIRCRAFT CORPORATION SECTTON 3
PA-32R.30I, SARATOGA SP EMERGENCY PROCEDURES
ENGINE POWER LOSS IN FLIGHT
Fuel selector.... switch to tank
containing fuel
... oN
Electric fuel pump
Mixture .. RICH
Alternate air .. ' . OPEN
Engine gauges . . . check for indication
of cause of power loss
lf no fuel flow is indicated, check tank selector position to be sure it is on a
tank containing fuel.
When power is restored:
Alternateair...
Electric fuel pump
Fuel selector
Mixture
Flaps .
lgnition
Master switch ..
Seat belt and harness
TSSUED: NOVEMBER t, 1979
REVISED: SEPTEMBER I' 1966
REPORT: VB-1080
3-3
CLOSED
.... oFF
Mixture .. . adjust as necessary
lf power is not restored prepare for power off landing.
POWER OFF LANDTNG
On aircraft equipped with the backup gear extender, lock emergency gear I
lever in OVERRIDE ENGAGED position before airspeed drops to 106 |
KIAS to prevent landing gear from inadvertently free falling. I
Trim for 80 KIAS
Locate suitable field.
Establish spiral pattern.
1000 ft, above field at downwind position for normal landing approach.
When field can easily be reached extend full flaps for shortest landing.
Touchdowns shoutd normally be made at lowest possible airspeed with full
flaps.
When committed to landing:
Landing gear selector . .. .. DOWN
Throttle ...... oFF
...... oFF
. idle cut-off
. set
OFF
OFF
tight
