PITH & STEM DropTop Classic User manual

1
www.pithandstem.com
DropTop.™ Classic Instructions.

2
2
DropTop.™ Classic and Pro wall
mounting Instructions
Fittings Packs
Tools
Power cable supplied with your DropTop
will vary based on your order.
8910
Brick/Concrete Wall
Fixings Plasterboard Wall Fixings
DropTop.™
Single & Max DropTop.™ Duo
x5x3 x3 x5
x8
x5
x5 x8
DropTop.™
Duo
DropTop.™
Single & Max
UK PLUG EU PLUG USA PLUG AU / NZ PLUG Tilt Monitor Mount

3
3
DropTop.™ Single & Max Parts.
No Monitor Integrated Monitor

4
4
DropTop.™ D o.
No Monitor Integrated Monitor

5
5
12
Included with your No Monitor option
DropTop.™ is a Tilt Monitor Mount.
DropTop.™ Pro & Duo 2 x Monitor Mounts.
DropTop.™ Single 1x Monitor Mount.
DropTop.™ Max 1x Monitor Mount.
Install your monitor before mounting the
DropTop on the wall.
Attach the screen mount to your monitor using
the provided screws.
Monitor Back
View
Tilt Monitor Mount
x 4
No monitor option DropTop.™
Installing your monitor.

6
3
Place your monitor into your DropTop.™ and loosely
screw the monitor bolts into the screen mount.
Adjust the screen mount to the desired height
then proceed to tighten the bolts.
4
Front View
Back View
x2

7
Mo nting the Wall plate.
The height to install the wall plate is measured
from above the desired desk height to the top of
recess of the wall plate.
Your DropTop.™ can be tted at any height to best
suit you.
Depending on your personal preference you can
install your DropTop.™ on the wall between
65cm-80cm for sitting position.
Height of the
DropTop.™ worktop
can be tted between
65cm-80cm from the
oor.
49cm
DropTop.™ Single
Wall plate height.
The height to install
the wall plate is
measured from above
the desired desk
height to the top of
recess of the wall plate.
Worktop Height
Floor
Wall plate Height

8
56cm
DropTop.™ Duo
Wall plate height.
The height to install the wall plate is measured
from above the desired desk height to the top of
recess of the wall plate.
The height to install the wall plate is measured
from above the desired desk height to the top of
recess of the wall plate.
54cm
DropTop.™ Max
Wall plate height.

9
x8
Installing on a brick and concrete wall.
DropTop™ Single
DropTop.™ Max
DropTop™ Duo
x6
Use the wall plate as a guide and mark the
position of the xing holes with a pencil.
The height to install the wall plate is measured from
above the desired desk height to the top of recess
of the wall plate.
DropTop.™ Single Wall plate 49cm.
DropTop.™ Max Wall plate 54cm.
Droptop.™ Duo Wall plate 56cm.
12
Drill 8 x 8mm sized holes.
Drill 6x 8mm sized holes.

10
DropTop™ Single
DropTop.™ Max
DropTop™ Duo
4
x6
3
Fittings Pack #9
x8
Fittings Pack #9
Lock yo r DropTop.
Safely mount your DropTop on to the wall plate.

11
5The securing screws in ttings pack #8
will prevent your DropTop.™ from
accidentally lifting off its wall mount.
Front View
While the DropTop.™ is on the wall, use a
long thin tool or pencil and mark then
position of the mirror screw holes. Lock yo r DropTop.
Safely remove the DropTop.™ off the wall.
6

12
87
x2
Fittings Pack #9
Drill 2 x 6mm holes previously marked for
the mirror screws and insert the wall plugs.
Lock yo r DropTop.
Safely mount your DropTop on to the wall plate.

13
Fittings Pack #8
910
The detachable power cable
is connected from the base
of the DropTop.™
Screw the mirror screw
caps.
x2
UK PLUG EU PLUG USA PLUG AU / NZ PLUG

14
Use the wall plate as a guide and mark the
position of the xing holes with a pencil.
The height to install the wall plate is measured from
above the desired desk height to the top of recess
of the wall plate.
DropTop.™ Single Wall plate 49cm
DropTop.™ Max Wall plate 54cm
Droptop.™ Duo Wall plate 56cm
Installing on Plasterboard/Drywall.
DropTop™ Single
DropTop.™ Max
DropTop™ Duo
12
Drill 3 x 25mm hole
centred on the top row
of your wall plate pencil
markings for Geex.
Drill 5 x 8mm holes for
wall plugs.
Drill 3 x 25mm hole
centred on the top row
of your wall plate pencil
markings for Geex.
Drill 3 x 8mm holes for
wall plugs.

15
DropTop™ Single
DropTop.™ Max
DropTop™ Duo
x6
Fittings Pack #10
x8
Fittings Pack # 10
Assemble your GeeFix wall anchor system by
threading the supplied pullcord through the
round wall plug, the curved back plate, and
back through the wall plug.
While holding onto the pullcord, feed the
curved back plate into the hole and centre
on the 1″ hole.
While keeping light tension on the pullcord
slide the wall plug into the 1″ hole to align
with the holes on the back plate.
While keeping rm tension on the pullcord,
screw the large screw into the centre hole
until the GeeFix becomes rm, but do not
over tighten. Keeping tension on the
pullcord will keep the back plate in place
during installation.
GeeFix Fixings
Pull out the pullcord but do not discard. You
can use the same pullcord on additional
GeeFix.
Screw in the 2 smaller screws on either side
of the large screw and tighten until the
GeeFix is rmly secured but do not over
tighten.
Remove the centre screw
3 4

16
56The securing screws in ttings pack #8
will prevent your DropTop.™ from
accidentally lifting off its wall mount.
Front View
While the DropTop.™ is on the wall, use a
long thin tool or pencil and mark the
position of the mirror screw holes.
Lock yo r DropTop.
Safely mount your DropTop on to the wall plate.

17
78
x2
Fittings Pack #8
Drill the 2 x 6mm holes previously marked
for the mirror screws and insert the wall
plugs.
Lock yo r DropTop.
Safely remove the DropTop.™ off the wall.

18
Fittings Pack #8
910
x2
Screw the mirror screw
caps.
Lock yo r DropTop.
Safely mount your DropTop on to the wall plate.

19
10
The detachable power cable
is connected from the base
of the DropTop.™
UK PLUG EU PLUG USA PLUG AU / NZ PLUG

20
www.pithandstem.com
