Pittsburgh Automotive 95979 Assembly instructions

Visit our website at: http://www.harborfreight.com
Email our technical support at: [email protected]
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference. 22j
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright©2022 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.

Page 2 For technical questions, please call 1-888-866-5797. ITEM
95979 & 95980
SAVE THIS MANUAL
Keep this manual for the safety
warnings and precautions, assembly,
operating, inspection, maintenance and
cleaning procedures. Write the product’s
serial number in the back of the manual near
the assembly diagram (or month and year of
purchase if product has no number). Keep
this manual and the receipt in a safe and dry
place for future reference.
IMPORTANT SAFETY
INFORMATION
In this manual, on the labeling,
and all other information
provided with this product:
This is the safety alert
symbol. It is used to alert you
to potential personal injury
hazards. Obey all safety
messages that follow this
symbol to avoid possible injury
or death.
DANGER indicates a
hazardous situation
which, if not avoided, will result
in death or serious injury.
WARNING indicates a
hazardous situation
which, if not avoided, could
result in death or serious injury.
CAUTION, used with
the safety alert
symbol, indicates a hazardous
situation which, if not avoided,
could result in minor or
moderate injury.
NOTICE is used to
address practices
not related to personal injury.
CAUTION, without the
safety alert symbol,
is used to address practices not
related to personal injury.
WARNING Read all safety
warnings and instructions.
Save all warnings and
instructions for future
reference.
1. Study, understand, and follow all
instructions before operating this device.
2. Wear eye protection that meets ANSI/
ISEA Z87.1 and OSHA standards.
3. Do not exceed rated capacity.
4. Make sure setup is stable and secure
before performing any work.
5. Failure to heed these markings may
result in personal injury and/or property
damage.
6. No alterations or modifications shall be
made to this product.
7. Only components supplied with this kit
shall be used with this kit.
WORK AREA
1. Keep your work area clean and well lit.
Cluttered benches and dark areas invite
accidents.
2. Keep children and visitors away while
operating rams. Distractions can cause
you to lose control.
PERSONAL SAFETY
Stay alert. Watch what you are doing, and
use common sense when operating a ram.
Do not use a ram while tired or under the
influence of drugs, alcohol, or medication.
A moment of inattention while operating
rams may result in serious personal injury.

Page 3For technical questions, please call 1-888-866-5797.ITEM
95979 & 95980
RAM USE AND CARE
1. Do not force the ram. Use the correct
ram for your application. The correct
ram will do the job better and safer at
the rate for which it is designed. Do not
force the ram and do not use the ram for
a purpose for which it is not intended.
2. Store idle rams out of reach of children
and other untrained persons. Rams are
dangerous in the hands of untrained
users.
3. Maintain rams with care. Keep
rams clean. Properly maintained
rams are less likely to bind, break or
malfunction. Do not use a damaged
ram. Tag damaged rams “Do not use”
until repaired.
4. Check for misalignment or binding of
moving parts, breakage of parts, and
any other condition that may affect
the ram’s operation. If damaged,
have the ram serviced before using.
Many accidents are caused by poorly
maintained rams.
5. Check all hydraulic connections and
hoses before applying pressure to the
Ram.
6. Do not leave the ram unattended when
it is pressurized. Release pressure on
the ram before leaving work area.
7. Do not exceed working pressure.
8. If lifting, support load properly when
finished.
9. Follow hydraulic pump instructions.
10. Do not use for aircraft purposes.
SERVICE
1. Ram service must be performed only by
qualified repair personnel. Service or
maintenance performed by unqualified
personnel could result in a risk of injury.
2. When servicing a ram, use only identical
replacement parts. Follow instructions
in the “Inspection, Maintenance, And
Cleaning” section of this manual. Use
of unauthorized parts or failure to follow
maintenance instructions may create a
risk of electric shock or injury.
3. Maintain labels and nameplates on the
ram. These carry important information.
If unreadable or missing, contact
Harbor Freight Tools for a replacement.
4. Repairs or adjustments to hydraulic
systems should only be performed by a
qualified technician.

Page 4 For technical questions, please call 1-888-866-5797. ITEM
95979 & 95980
UNPACKING
When unpacking, check to make sure
that the item is intact and undamaged. If
any parts are missing or broken, please call
Harbor Freight Tools at the number shown
on the cover of this manual as soon as
possible.
ASSEMBLY INSTRUCTIONS
1. Using appropriate, grade 8 hardware
(not supplied) bolt Base either to the
machinery to be moved or against a
fixed surface with the piston facing the
machinery.
2. If mounted to a fixed surface, that
surface and hardware must be able
to withstand the force exerted without
failing.
SPECIFICATIONS
Model 95979 95980
Capacity 10 Ton 20 Ton
Ram Diameter 38 mm 50 mm
Working Pressure 9250 PSI 9250 PSI
Ram Travel 7/16″ 7/16″
Height Range 1.73″ – 2.16″ 2.05″ – 2.48″
Mounting Hole
Diameter 0.2″ 0.35″
Dimensions 4 1/2″ L x 2 1/4″ W 5 11/16″ L x 3″ W

Page 5For technical questions, please call 1-888-866-5797.ITEM
95979 & 95980
OPERATION INSTRUCTIONS
Piston
Coupler
Mounting
Holes
FIGURE A
1. Connect the high pressure hydraulic
hose connector to the Coupler.
2. Check the connections between the
hydraulic hose, the power source,
and Coupler for tightness. These
connections must be tight before using
the Ram.
3. To operate, apply proper amount of
hydraulic pressure to the Ram.
4. When the machinery has moved to the
desired location, remove the pressure.
5. After use, wipe with a clean cloth.
INSPECTION, MAINTENANCE,
AND CLEANING
1. Before performing any maintenance, be
certain that all hydraulic pressure has
been removed and any machinery is
turned OFF.
2. Before each use, inspect the general
condition of the Ram. Check for
misalignment or binding of moving
parts, cracked or broken parts, and any
other condition that may affect its safe
operation. If abnormal noise or vibration
occurs, have the problem corrected
before further use. Check for leaks from
the Ram during operation. Do not use
damaged equipment.

Page 6 For technical questions, please call 1-888-866-5797. ITEM
95979 & 95980
Part Description QTY
1 Nut 1
2 Ram 1
3 Seal Washer 1
4 O-ring 1
5 Cylinder Base 1
Part Description QTY
6 Coupling Ring 1
7 Coupling Bolt 1
8 O-ring 1
9 Dust Cap 1
PARTS LIST AND ASSEMBLY DIAGRAM
1
2
3
4
56
9
8
7

Page 7For technical questions, please call 1-888-866-5797.ITEM
95979 & 95980
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND
ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER
THE MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR
WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO
MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO
REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR
DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS
SHOULD BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT
BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF
HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT
PARTS THERETO.
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not available
individually as replacement parts. Parts may not be interchangeable.
Specify UPC number when ordering:
10 Ton: Item 95979, UPC 792363959797
20 Ton: Item 95980, UPC 792363959803
