PIXAPRO GLOWPAD 144SB User Manual
I Product Structure:
①
Power switch
②
Color Temperature Controls
③
Dimmer Controls
④
Angle Adjustment Screw
⑤
Hot Shoe Mount
⑥
Battery Mounting Plate
⑦
LED Light Panel
⑧
Battery Test Button & Indicator
⑨
DC input
⑩
Vertical Mount Thread
II Method of Application
1. Power input (Two Power input mode, but not both use)
2. Battery input: Compatible With Sony NP-F series Li-Ion Batteries
Tips: Mounting the lithium battery: Please Slide the battery
in the direction of the arrows shown on the Battery Plate.
Disconnecting the lithium battery: Please slide battery out
in the opposite direction, and then lift out.
3. DC adapter input: 6.8V-12V DC mains power adapter.
Attention: Do not use the battery and Mains DC power Adapter Simultaneously ！
2. LED Video Light Installation
a. To Camera/Video Hot Shoe:
Mount the LED light onto your Stills or Video Camera’s hot shoe, then tighten the nut.
b. To Light Stand/ Tripod:
There is a 1/4 inch thread in the bottom of the LED light hot shoe mount, which can be directly mounted
onto a light stand or tripod.
3. Power Switch
Turn the power switch ①to “on”, to switch on your Glowpad Led Light.
4. Dimmer Controls
Rotate the dimmer control dial ③to adjust brightness 0-100%.
5. Colour Temperature Controls
Rotate the colour temperature Control Dial ②to adjust colour temperature between 3200-5600K.
6. Battery Power Test
First shut off the power, and then press battery test button ⑧, to show the power indication lights. When all of the
power indication lights are lit, mean the battery power is full. If only one of the power indication lights are lit, it
means that the battery power is low. If none of the Power Indicator lights are lit, this means that the battery needs
to be recharged.

III Product Specification
LED Quantity
144 LEDs
Color Rendering
Index
≥93%
Max Output
15W
Color Temperature
3200-5600K
Size
288×148×28mm
Weight
360g
IV Troubleshooting
In using this product, you may meet the following problems
Description
Cause
Trouble-shooting
Nothing happens when unit is
switched on.
Low battery
Install new battery or charge
the batteries before use.
Circuit board damaged
Send for repair
Inadequate or low luminance at the
highest grade
Low battery
Install new battery or charge
the batteries before use.
Battery power test Inaccurate when
power switch is on
Display low battery when you
increase the brightness, Display
high battery when you lower
brightness
Battery capacity shown indicated the length
of time available for use in the current
luminance;
A high luminance requires more power and
shortens the length of time available for
use, so the battery capacity shown is lower.
Normal
PIXAPRO LTD.
Address: 50 Popes Lane, Oldbury, West-Midlands B69 4PA
Tel.: [phone]
Website: http://www.essentialphoto.co.uk
E-mail: [e-mail]
