pizzi instruments Portable Readout Unit User manual

Instruments and Systems for Geotechnical and Structural Monitoring
Pizzi Instruments S.r.l.
Via del Fornaccio n°46, 50012 Bagno a Ripoli (FI), Italy Tel. [phone] –Fax [phone]
email: [email protected], web: www.pizzi-instruments.it
Portable Readout Unit
User Manual

User Manual –Portable Readout Unit
Rev.003 –09.05.20192/7
Pizzi Instruments S.r.l. reserves the right to change the information contained in this document without
notice.
No part of this document may be reproduced without the prior written consent of Pizzi Instruments S.r.l.
The instruments supplied by Pizzi Instruments S.r.l. are designed and optimized to be used and installed
with simplicity.
However, since they are performed at a high technical level, they must be installed and used by a trained
and qualified technical staff.
Before the installation of the supplied instrumentation, it is advisable to carefully read this manual and any
other related documents.
All rights reserved.
Pizzi Instruments S.r.l.
Warranty
Pizzi Instruments S.r.l. warrants its product against defects in materials for twelve (12) months from the
date of shipment unless otherwise specified on the relevant contract or purchase order.
Products considered to be defective should be returned to Pizzi Instruments factory properly identified,
complete with serial number, Returned Materials Authorization (RMA) and freight prepaid.
Pizzi Instruments’ obligation under this warranty is limited to repairing or replacing (at Pizzi Instruments’
discretion) defective products, which shall be the sole and exclusive solution under this warranty.
The Customer shall assume all costs of removing and shipping defective products to Pizzi Instruments and
the costs of reinstalling the repaired/substituted instruments.
The foregoing warranty shall not apply to any Pizzi Instruments products which have been subjected to
modification, misuse, misapplication, neglect, improper service or maintenance, improper installation.
Pizzi Instruments S.r.l. is not liable for any damage or loss caused to other equipment or person, whether
direct, indirect, incidental, special or consequential which the buyer may experience as a result of the
installation or use of the product.
The amount of any claim is limited to the net invoice value of the item in question.
In no case Pizzi Instruments S.r.l. will recognize and reimburse the costs incurred by the customer for
installations, maintenance, management, as well as for the uninstallation and reinstallation of the
instruments to be repaired or replaced under warranty.
While the information contained in the manual is assumed to be accurate, Pizzi Instruments neither assumes
responsibility for any omission or error that may appear or assumes liability for any damage or loss that
result from the use of products in accordance with the information contained in the manual.
Pizzi Instruments S.r.l.
Document Revision
Date
Rev.
Issued
Checked
Approved
10/01/2012
001
ANP
MPZ
FPZ
09/03/2015
002
ANP
MPZ
FPZ
09/05/2019
003
LUG
MPZ
FPZ

User Manual –Portable Readout Unit
Rev.003 –09.05.20193/7
Index
Use of this manual ........................................................................ Errore. Il segnalibro non è definito.
1. Introduction........................................................................................................................................ 5
2. Initial inspection ........................................................................ Errore. Il segnalibro non è definito.
2.1 Damage during shipment....................................................... Errore. Il segnalibro non è definito.
3. Storage ..................................................................................... Errore. Il segnalibro non è definito.
4. User Instructions................................................................................................................................. 5
4.1 Error messages .............................................................................................................................. 7
4.2 Electrical connections ..................................................................................................................... 7
5. Technical Assistance ........................................................................................................................... 7

User Manual –Portable Readout Unit
Rev.003 –09.05.20194/7
Use of this manual
This manual must be considered for the installation and use of the Portable Readout Unit.
Dangers and safety
Warning for the unpacking of the material:
Be careful when handling the packaging to avoid damage to property and / or people.
Handle with care every package before you open it.
Be sure to open every package without risking damage its contents.
Separate carefully each component of the package.
Warning for the installer:
Be careful in handling the heavy metal parts
Be careful when handling bulky packaging
Caution: Handle with care the bars of stainless steel and the bottom elements
Caution: Always use appropriate Personal Protective Equipment (PPE)
Be careful not to apply any shock to the instrument
Warnings for the disposal of the material
All material must be disposed in accordance with local regulations of the country where the equipment will
be installed and where it will be removed.

User Manual –Portable Readout Unit
Rev.003 –09.05.20195/7
Symbols and abbreviations
Highlights important information
The Caution Symbol highlights the presence of a potential danger.
CAUTION: of instrument damage. All conditions specified in the associated text must be
fully known and understood before proceeding
This symbol indicates that the product at the end of its useful life must be collected
separately from other waste. The operator must therefore send the equipment to the
appropriate centers for collection of electronic and electrotechnical waste
1. Introduction
The portable readout unit is an instrument capable to give power to the sensors and to display the data
coming from them. It is generally used when the data coming from the transducers are not required or
cannot be automatically and continuously acquired (by means of a remote acquisition unit). To speed up the
reading operations, sometimes the signals of two or more sensors are grouped in centralization panels from
which, by connecting with the portable reading control unit using the cable provided and with the simple use
of a channel selector, it is possible to display data coming from all the installed sensors.
2. Initial inspection
All the instruments have been carefully inspected, both mechanically and electrically, before they leave the
factory.
Please check if all received items correspond with the packing list, your order confirmation and if the list of
components (chapter 4.1) corresponds to the material effectively present.
In case of discrepancy, please contact Pizzi Instruments or your local Representative.
NOTE: All instruments are thoroughly checked both electrically and mechanically before leaving
the factory.
Damage during shipment
If requested at the moment of the order, all instruments can be insured prior to shipment. If you receive a
damaged shipment and shipping insurance was previously arranged you should:
Report the damage to your shipper immediately
Inform Pizzi Instruments or your local representative immediately
Keep all packaging and shipping documents

User Manual –Portable Readout Unit
Rev.003 –09.05.20196/7
NOTE: All shipments must immediately opened upon delivery and the content must be
checked, in quality and quantity, on the base of the packing list sent together with the goods.
No claims for shortages, damages or errors will be considered valid if no writing form to our
office within 3 days of receipt of goods will be sent.
Attention: insurance claims may be void if the above procedure is not followed.
3. Storage
Keep the material in a proper site to avoid its deterioration before the installation and to protect it from any
possibility of shocks.
Do not place weights on top of the instrumentation
Do not store the equipment in places where it could cause damage to persons or property
Be careful during the storage not to bend or crush the steel parts
4. User instructions
IMPORTANT:: the portable readout unit, when turned on, continuously outputs the measurement input.
Switch on the portable readout unit only after having connected the banana plugs in the measurement
bushings.
Avoid the contacts of the banana plugs while the portable readout unit is turned on.

User Manual –Portable Readout Unit
Rev.003 –09.05.20197/7
To turn on the readout unit, press the ON / OFF button: the display will initially show an information screen
(with the hardware and firmware version) after which, if the whole system is correctly connected, the
current measurement value will be displayed.
The unit of measurement is indicated at the bottom of the display.
To switch off the control unit, simply hold down the ON / OFF button for 2 seconds. In order to preserve the
battery, the PDA is equipped with the automatic switch-off function which automatically switches the
instrument off after 3 minutes of inactivity.
The other keys are not accessible to the end user as they are used for the factory configuration of the
instrument.
The battery is located on the bottom of the instrument. To replace it, open the cover by pressing the two
side buttons simultaneously. Replace the battery respecting the polarity and close the cover.
4.1 Error Messages
"Memory error" –this message appears whenever the memory parameters are damaged
"OVR. POS. error" –this message appears whenever the entered value exceeds the 10% of the portable readout unit
full scale.
"OVR. NEG. error" –this message appears whenever the entered value is less than the 10% of the portable readout
unit full scale.
"Low battery" –this message appears whenever the voltage of the battery goes under 7,3 Volt; the portable readout
unit is still functioning but the read value couldn’t be correct.
4.2 Electrical Connections
NOTE: Always see the wiring diagram provided in the certificate supplied with the portable readout unit
5. Technical Assistance
Pizzi Instruments S.r.l. has a wide range of service as phone assistance, installation, training, calibration,
reparation and maintenance.
For any additional information you can directly contact our technicians at the following addresses
[e-mail]
T: [phone]
F: [phone]
PIN CONNETTORE 8 POLI COLORE CONDUTTORE COLLEGAMENTO ELETTRICO
2 rosso alimentazione +15 Vcc
5 nero GND
6 giallo ingresso segnale (0-10 V)
