Planet ADE-3100 User manual

ADSLModem Router
ADE-3100 / ADE-4100
User s Manual

Copyright
Copyright (C) 2005 PLANETTechnologyCorp. All rights reserved.
The products and programs described in this User sManual are licensed products of
PLANETTechnology,This User sManual contains proprietaryinformation protected by
copyright, and this User sManualand all accompanying hardware, software, and
documentation are copyrighted.
No part ofthis User sManual maybe copied, photocopied, reproduced, translated, or
reduced to any electronic medium or machine-readable form by any means by electronic or
mechanical. Including photocopying, recording, or information storage and retrieval
systems, for anypurpose other than the purchaser's personal use, and without the prior
express written permission of PLANETTechnology.
Disclaimer
PLANETTechnologydoes not warrant that the hardware will work properlyin all
environmentsand applications, and makesno warrantyand representation, either implied
or expressed, with respect to the quality,performance, merchantability,or fitness for a
particular purpose.
PLANEThas made everyeffort to ensure that this User sManual is accurate; PLANET
disclaims liabilityfor anyinaccuracies or omissions that mayhave occurred.
Information in this User sManual is subject to change without notice and doesnot
represent acommitment on the part ofPLANET.PLANETassumes no responsibilityfor
anyinaccuracies that maybe contained in this User sManual.PLANETmakes no
commitment to update or keep current the information in this User sManual, and reserves
the right to makeimprovements to this User sManual and/or to the products described in
this User s Manual, at anytime without notice.
If you find information in this manual that is incorrect, misleading, or incomplete, we would
appreciate your commentsand suggestions.
FCC Compliance Statement
Thisequipment generates and uses radio frequencyenergyand ifnot installed and used
properly,that is, in strictaccordance with the instructions provided with the equipment, may
cause interference to radio and TV communication. The equipment has been tested and
found to complywith the limits for aClass Acomputing device in accordance with the
specifications in Subpart BofPart 15 of FCC rules, which are designed to provide
reasonable protection against such interference in a residential installation. However, there
is no guarantee that interferencewill not occur in aparticular installation. Ifyou suspect this

equipment iscausing interference, turn your Ethernet Switch on and offwhile your radio or
TVis showing interference, ifthe interference disappears when you turn your Ethernet
Switch offand reappears when you turn it back on, there is interference being caused by
the Ethernet Switch.
You can tryto correct the interference byone or more ofthe following measures:
w Reorient the receiving radio or TV antenna where this maybe done safely.
w To the extent possible, relocate the radio, TV or other receiver awayfrom the Switch.
w Plug the Ethernet Switch into a different power outlet so that the Switch and the receiver
are on different branch circuits.
If necessary, you should consult the place ofpurchase or an experienced radio/television
technician for additional suggestions.
CE mark Warning
The is a class B device, In a domestic environment, this product maycause radio
interference, in which case the user maybe required to take adequate measures.
Trademarks
The PLANETlogo isa trademark of PLANETTechnology.This documentation mayreferto
numerous hardware and software products bytheir trade names. In most, ifnot all cases,
these designations are claimed as trademarks or registered trademarks bytheir respective
companies.
Revision
User s Manual for PLANETADSLModem Router:
Model: ADE-3100A/B,ADE-4100A/B
Rev: 4.0 (Feb 2005)
Part No.: EM-ADE4100_3100v4

TABLE OF CONTENTS
1. INTRODUCTION.............................................................................................................1
1.1 FEATURES ...................................................................................................................1
1.2 SYSTEM REQUIREMENTS ..............................................................................................1
2. KNOWING YOUR ROUTER...........................................................................................2
2.1 FRONT PANEL ..............................................................................................................2
2.2 REAR PANEL................................................................................................................3
3. LOGIN.............................................................................................................................4
4. STATUS PAGES.............................................................................................................5
4.1 HOME PAGE.................................................................................................................5
4.2 PPPPAGE...................................................................................................................6
4.3 ADSLPAGE.................................................................................................................7
5. CONFIGURATION PAGES.............................................................................................9
5.1 MODES........................................................................................................................9
5.2 WAN CONFIGURATION ...............................................................................................10
5.2.1 ATM...................................................................................................................11
5.2.2 DHCPClient......................................................................................................12
5.2.3 MAC Spoofing...................................................................................................12
5.2.4 Static IPSettings...............................................................................................12
5.3 LAN CONFIGURATION.................................................................................................13
5.3.1 DHCPServer.....................................................................................................13
5.3.2 Ethernet Mode Setting.......................................................................................14
5.4 PPPCONFIGURATION.................................................................................................15
5.4.1 PPPAccount Configuration...............................................................................15
5.4.2 PPPSession Configuration...............................................................................16
5.4.3 PPPDisconnect Timer Configuration................................................................17
5.4.4 PPPMiscellaneous Configuration.....................................................................19
5.5 NATCONFIGURATION PAGES......................................................................................20
5.6 VIRTUAL SERVER CONFIGURATION...............................................................................21
5.7 BRIDGE FILTERING......................................................................................................22
5.8 DNS CONFIGURATION ................................................................................................23
5.9 DYNAMIC DNS...........................................................................................................25
5.10 USER PASSWORD CONFIGURATION............................................................................25
5.11 SAVE SETTINGS / REBOOT ........................................................................................26
6. ADMIN PRIVILEGE.......................................................................................................27

6.1 WAN STATUS ............................................................................................................27
6.2 ATM STATUS .............................................................................................................27
6.3 ADSLCONFIGURATION...............................................................................................28
6.4 ROUTE TABLE ............................................................................................................29
6.4.1 SystemDefault GatewayConfiguration.............................................................30
6.4.2 Route Configuration..........................................................................................30
6.5 LEARNED MAC TABLE ................................................................................................30
6.6 RIPCONFIGURATION..................................................................................................31
6.6.1 RIPPer Interface Configuration.........................................................................32
6.7 MISCELLANEOUS CONFIGURATION ...............................................................................33
6.8 TCPSTATUS .............................................................................................................35
6.9 ADMIN PASSWORD CONFIGURATION.............................................................................35
6.10 RESET TO FACTORY DEFAULT ....................................................................................36
6.11 DIAGNOSTIC TEST ....................................................................................................36
6.12 SYSTEM LOG ...........................................................................................................37
6.13 LOCAL CODE IMAGE UPDATE.....................................................................................37
APPENDIX A. COMPLIANCE STATEMENT....................................................................39
APPENDIX B. ENCAPSULATION MODE........................................................................40
APPENDIX C. TROUBLESHOOTING..............................................................................41
OVERVIEW.......................................................................................................................41
GENERAL PROBLEMS........................................................................................................41
CONFIGURATION AND INTERNET ACCESS ............................................................................41
APPENDIX D. SPECIFICATIONS.....................................................................................43

1
1. Introduction
This Router is a highlyintegrated,cost-effective solution. All setup and provisioning is accomplished viaa
simple intuitive Web interface which further enhances the user experience.
1.1 Features
l ADSLCompliance
n Compliant withADSLstandards
u Full-rateANSI T1.413 Issue2 and ITU G.dmt (G.992.1) standards
u Splitterless ITU G.lite (G.992.2) specification
u ADSLover POTS (AnnexA) andADSLover ISDN (Annex B)
n DMT modulation and demodulation
n Full-rate adaptive modem
u Maximumdownstreamrate of8 Mbps
u Maximumupstreamrate of1 Mbps
l ATM Protocols
n WANmode support: PPPover ATM (RFC 2364) and PPPover Ethernet (RFC 2516)
n LAN mode support: bridged/routedEthernet over ATM (RFC 1483) and Classical IPover ATM
(RFC 1577)
n ATM ForumUNI 3.1/4.0PVC
n Up to 8 VCs (Virtual Circuits)
l Bridge Mode
n Ethernet toADSLself-learning Transparent Bridging (IEEE 802.1D)
n Supports up to 128 MAClearning addresses
l Router Mode
n IProuting–RIPv2
n Static routing
n DHCP(Dynamic Host Configuration Protocol) Server and Client
n NAPT (NetworkAddress and Port Translation)
n NAT (NetworkAddress Translation)
n ICMP(InternetControl Message Protocol)
l Security
n User authentication for PPP
n PAP(Password Authentication Protocol)
n CHAP(ChallengeAuthentication Protocol)
n Password protected systemmanagement
1.2 System Requirements
l PentiumIII 266 MHz processor minimum
l 128 MB RAM minimum
l 20 MB offree diskspace minimum
l Ethernet NetworkInterface Controller (NIC) RJ45 Port
l Internet Browser
l Ethernet (CAT5) Cable

2
2. Knowing Your Router
When selecting the locationfor the Router,allowroomto access the connections on the rear panel. You will
want to place the Router sothat youwill beable to seethe LED indicators on the front panel. It maybe
convenient for youlocate the Router near the PC youintend to use for initial configuration ofthe Router.
2.1 Front Panel
PlacetheRouter in a location that permits an easyviewofthe LED indicators shown in the front panel
diagrambelow.
Front panel ofADE-3100
LED Indicators of ADE-3100:
LEDs Color Active Description
PWRGreen ON The power adaptor is connected to the Modem.
READYGreen BlinkThe systemis readyto use.
ADSL Green ON ADSLconnection is established.
ACTGreen BlinkTransmitting data or receiving data over Ethernetlink.
LAN
LNK Green ON The Ethernet connection is established.
TX Green BlinkTransmitting data viaADSLlink.
WAN
RX Green BlinkReceiving datavia ADSLlink.
Front panel ofADE-4100
LED Indicators of ADE-4100:
LEDs Color Active Description
PWRGreen ON The power adaptor is connected to the Modem.
READYGreen BlinkThe systemis readyto use.
ADSL Green ON ADSLconnection is established.
WAN
ACTGreen ON Ifdata is being transferred via ADSLlink.
1
2
3
LAN
4
Green ON The Ethernet connection is established. Blin
kifdatais being
transmitted or received over Ethernet link.

3
2.2 RearPanel
The rear panel ofthe Router provides access to the power adapter cordconnection as well as theport
connections.
Rear panel ofADE-3100
Rear panel ofADE-4100
RESET button: The Router comes witharesetbuttonbuilt into the rear panel. Use this buttonto restore the
factorydefaultsettings. If you need to reset theRouter, press the reset buttonfor 2-3 seconds and then
release it. The ADSLLED will stopblinking temporarilyand then blinkagain in about 15 seconds. It means
the Router finish rebooting.

4
3. Login
There are twolevels ofaccess rights/privileges for the Router:
l Administrator: User name admin, the administrator account has completeread/write access on all
pages (Status, Configuration andAdmin Privilege).Admin account alsohas FTPserver access.
l User: User name user, theUser account has read/write access to pages under the Status and
Configuration sections.
The following stepswill enable you tolog into the Router:
1. LaunchtheWeb browser (InternetExplorer,Netscape,etc.).
2. Enter the LANport default IPaddress (default gateway) http://10.0.0.2 in the address bar.
3. Entryofthe username and password will be prompted. Enter the default login User Name and Password:
The default login User Nameofthe administrator is admin,and thedefault login Password is epicrouter.The
default loginUser Name for the non-administrator is user, and the default login Password is password.
4. Remembermy password checkbox: Bydefault,this box is not checked. Users can checkthis box so
that Internet Explorer will remember the User name and Password for future logins. It is recommended
to leave this box unchecked for securitypurposes.
Admin andUser passwordscan bechanged after login. Refer to Section 5.10 for User Password
configuration andSection 6.9 for Admin Password configuration for further instruction.

5
4. Status Pages
The links under the Status column are associatedwiththe pages thatrepresent the status ofsystem
(computer and Router) and interfaces (connections). This includes LAN, WAN, DHCP, PPP, andADSL status.
These pages canbe viewed and modified byboth user and admin accounts.
4.1 Home Page
The Home page shows thefirmware versions; LAN,WAN, and DHCPinterface status; and Ethernet
connection status.
Firmware Version: It is thedefaultversion number,which is not changeable.
Customer Software Version: It is theversion ofthe firmware that is controllable bytheADSL
Modem/Router manufacturer.
WAN and LAN: It displays the IPaddress, Subnet Mask and MAC address for the WAN (ADSL) and LAN
interface.
Total Number ofLANInterfaces: Itdisplaysthe total number ofavailable interfaces for the LAN interface.
The total number ofavailable interfaces is the amount ofcomputers that areable to hookup to the DHCP
Server.
Number of Ethernet Devices Connected to the DHCPServer: It displaysthe DHCPclient table with the
assigned IPaddresses andMACaddresses.
?Note
Ifthere are no devices connected to the DHCPserver,then a table will not appear, otherwise
a table listing all devices connected to DHCPserver will appear on the bottomofthe page.
Ethernet Link Status: It displaysthe linkup or down for the Ethernet connection(up ifconnected, down if
not connected).
USB LinkStatus (reserved function): It displays the linkup or down for the USB connection (up if
connected, downifnot connected).

6
4.2 PPP Page
The PPPStatus pageshows the status ofeach PPPsession for each PPPinterface. This page contains
information thatis dynamic and will refresh every8 seconds.
?Note
PPPinterfaces can be created, modified, and deleted in thePPPConfiguration page. Refer
to Section 5.4 for further information.
PPP(Point-to-Point Protocol): The table displays thefollowingfields:
l Connection Name: This is user defined. User defined connections for PPP canbecreatedin PPP
Configuration page.
l Interface: States theinterface that is being used(PVC0 ... PVC7).
l Mode: There are twoavailable modes for the connection:
PPPover Ethernet (PPPoE)
PPPover ATM (PPPoA)
l Status: States whether PPPconnection is Connected or Not Connected.
l PacketsSent: Number ofpackets sent bya particularPPP Connection.
l Packets Received: Number ofpackets received bya particular PPPConnection.
l Bytes Sent: Number ofbytes sent byaparticular PPP Connection.
l Bytes Received: Number bytes receivedbya particular PPPConnection.
Connect andDisconnect: It allows youtomanually connect/disconnect thePPP connectionfor eachPPP
interface. Inother words, each PPPsession can be connected and disconnected individually.
l Connection #: Specifies the PPPsessionto be connected/disconnected.
l Connect/Disconnect Execute: Press this button to either connect or disconnect.
Connection status dialogwill be displayedbelowthe Execute button after itis pressed.
Sample dialog with explanation:
l PPPX: Connecting... This is displayedwhile the PPPsession is attempting to connect to the ISP.
l PPPX: Connect ERROR This is displayedwhena connection cannotbe made due toan error.
l PPPX: iscurrentlynot connected This is displayed when a disconnect attempt is made on a
session that is not currently connected.
l PPPX: doesnot exist! This is displayed when a connect or disconnect attempt is made on a
session number thatdoes not exist.

7
4.3 ADSL Page
The ADSL Status page shows theADSLphysical layer or linkstatus. The informationdisplayed onthis page
is either inherent to the Router or set bytheADSLCentral Office (CO) DSLAM, neither ofwhichcannot be
changed bythe user.This page contains information that is dynamic and will refresh every2seconds.
Restart/Stop Execute: It allowsyou to stop or restart the ADSLconnection byselectingtheappropriate
actionand clicking Execute.
Showtime Firmware Version: It displaystheADSLdata pump firmware version.
ADSL Line Status: It displays theADSLconnection process and status. The different states for this field
are as follows:
l Activation: The Router is in this state when it is attempting tostart theactivationprocess.
l Initialization: The Router is initializing handshake with theCO.
l Training: It is a part ofthe handshake process with the CO.
l Channel Analysis: It is a part ofthe handshake process with the CO.
l Exchange: It is a partofthe handshake process with the CO.
l Down: It indicates that theADSLconnection is down.
l Showtime: It indicates thata connection has been establishedbetween the Router and the CO.
ADSL Modulation: It displays theADSLmodulation status, which caneither be G.dmt or T1.413.
ADSL Annex Mode: It displaystheADSLannex mode, whichcan either beAnnex Aor Annex B.
ADSL Startup Attempts: Itdisplaysthe number ofADSLconnection attempts after loss ofshowtime. A
connection attempt is recorded onlyifshowtime is attained.
ADSL Max TX Power: It displaysthe transmit output power level ofthe CPE (Customer Premise
Equipment), which is the transmit output power level of the Router.
ADSL CO Vendor: ItdisplaystheCentral Office (CO) DSLAM vendor name, ifavailable. Ifthe Router is
not connected to anADSLvendor,then ‘UNUSED_VENDOR_0 will appear in thisfield.
Elapsed Time: It displays the time ofthe Router has been in operation. This is theamount oftime the
Router is on,notthe amount oftime it is connected to the PC or in showtime status.
Atable contained the information of SNR Margin, LineAttenuation, Errored Seconds, Loss of Signal,
Loss of Frame, CRCErrors, Data Rate, and Latency is also available.
SNR Margin: Signal to Noise Ratio (SNR) is the measure ofsignalintensityrelative to the background

8
noise. The SNR Margin is the amount ofincreased noise that can be tolerated while maintaining the
designatedBER (bit error rate). The SNR Margin is set byCentral Office DSLAM. Ifthe SNRMargin is
increased, bit error rate performance will improve, but the data ratewill decrease. Conversely,ifthe SNR
Margin is decreased, bit error rate performance will decrease, but the datarate will increase.
Line Attenuation: Attenuation is the decrease in magnitude oftheADSLlinesignal between the
transmitter (Central Office DSLAM) and the receiver (ClientADSLBridge/Router), measured in dB. It is
measured bycalculating the difference in dB between the signal power level receivedat the ClientADSL
Bridge/Router andthereference signal power level transmitted fromthe CentralOffice DSLAM.
Errored Seconds: During Showtime, ifanygiven second contains a CRC error,then that second will be
declared and recorded as an ErroredSecond.
Loss of Signal: Loss ofsignal refers to theADSLBridge/Router losing anADSLsignal, not the computer
losing a signal with the modem. Loss ofSignal event is onlyrecorded ifthe signal is lost while theADSL
Bridge/Router is in showtime status. This field displaysthe count ofADSLsignal loss events.
Loss of Frame: A frameis a unit ofdatain ATM. This fielddisplaysthe count ofADSLframeloss events. A
Loss ofFrame event is only recorded ifthe signal is lost while theADSLBridge/Router is in showtime
status.
CRC Errors: Cyclic RedundancyCheck(CRC) is a method for checking errors indata transmissions. This
field displays the number oftransmit data frames containing CRC errors.
Data Rate: This field displaystheADSLdata rateinkbps.
Latency: Latency, synonymouslydelay,is the amount oftime it takes for a packet ofdata to get fromone
designated point to another.This field displays the two mapping modes for latency (fast and interleaved).

9
5. Configuration Pages
The links under Configuration column are associated to the pages that represent the configurations of
systemand interfaces. These pages can beviewed and modified byboth user and admin accounts.
?Note
When anysettings are changed, please go to theSave Settings page to save thenew
setting(s) and reboot the Router. Changes will not take effect until the settings are saved and
the Router is rebooted. Ifpower is lost before saving, all new configurations sincethe last
save will be lost, even iftheyweresubmitted.
5.1 Modes
Table 5-1 lists themode configurations.
Table 5-1 ModeConfiguration
WAN
Configuration
Bridge Mode Router Mode
(PPPoA/PPPoE)
Router Mode
(Dynamic IP)
Router Mode
(Static IP) Half Bridge
IP Address N/A Automatically
assigned byISP Automatically assigned byISP
Provided byISP Automatically
assigned byISP
Subnet Mask N/A Automatically
assigned byISP Automatically assigned byISP
Provided byISP Automatically
assigned byISP
Gateway N/A Automatically
assigned byISP Automatically assigned byISP
Provided byISP Automatically
assigned byISP
Encapsulation
1483Bridged IP
LLC, 1483
Bridged IP
VC-Mux
PPPoA
LLC/VC-Mux,
PPPoE
LLC/VC-Mux
1483
Bridged/Routed
IPLLC,1483
Bridged/Routed
IPVC-Mux,
Classical IPover
ATM
1483
Bridged/Routed
IPLLC,1483
Bridged/Routed
IPVC-Mux,
Classical IPover
ATM
PPPoA
LLC/VC-Mux,
PPPoE
LLC/VC-Mux
Bridge Enabled Disabled Disabled Disabled Disabled
PPPService N/A Provided byISP N/A N/A Provided byISP
PPPUser Name
N/A Provided byISP N/A N/A Provided byISP
PPPPassword
N/A Provided byISP N/A N/A Provided byISP
DHCPClient
Enable Unchedked Unchedked Checked Unchedked Unchedked
PPPHalf Bridge
Disabled Disabled Disabled Disabled
DHCPServer Disabled Enabled Enabled Enabled
NAT Disabled Enabled (Dynamic
NAPT) Enabled (Dynamic NAPT)
Enabled
(Dynamic NAPT)
Disabled
DNS Proxy Disabled Enabled Enabled Enabled Disabled
Bridge Mode: BridgeMode is usedwhen there is one PC connected to the LAN-side Ethernet port. IEEE
802.1D method oftransportbridging is used to bridge between the WAN (ADSL) side and the LAN
(Ethernet) side, i.e., to store and forward.
Router Mode: Router Mode is usedwhen there is more than one PC connected to theLAN-side Ethernet
port. This enables theADSLWAN access to be sharedwith multiple nodes on the LAN. NetworkAddress
Translation (NAT) is supported so that oneWAN-side IPaddress can be shared among multiple LAN-side
devices. DHCPis used toserve each LAN-side device and IP address.

10
PPPHalf Bridge: Althoughthe Router mode is capable ofterminatingthePPPin the modemand hence
does not require PPPoE client software on the host PC, thereare some disadvantages to Router mode
when onlysingle-user support is required. For instance, Router mode uses NAT which requiresALG
support. PPPHalfBridge also terminates the PPPin the modemand does notrequire aPPPoE client on
the PC.However,PPP HalfBridgedoes notuseNATand is notlimited byALGs. PPP HalfBridgewill work
with Ethernetinterface to the PC.
Single-User Mode: Onlyone computer is connected at the LAN side through Ethernet.
Multi-User Mode: Multiple computers are connectedat the LANsidethrough Ethernet.
5.2 WAN Configuration
The WANconfiguration page allowsyou to set the configuration for the WAN/ADSLports. Before you
enter the WANConfiguration page, youwill be asked to select an adapter (PVC0 throughPVC7) first.
Once you select the adaptor, then following page will appear.
Virtual Circuit: Select Enable to activate the current PVC configuration. The current PVC is displayed at
the top ofthe page in parenthesis. Default is Enabledfor PVC0 and Disabled for PVC1-PVC7.
Bridge: Enable to connect the LAN to theWAN (bridge thetwo connections). This is available in Bridge
Modeonly(see Table 5-2). Default is Disabled.

11
IGMP: IGMP(Internet Group Management Protocol) relay/proxyspecification and environment, default is
Disabled.IGMPis availablein all modes and all encapsulations. Support IGMPproxy/relayfunction for
Router, based on the following requirement and cases:
l On CO side, there must be at least one IGMPquerier (router) present. IGMP querier will send
IGMPquerypacket. The Router is responsible to relay these IGMPqueries toEthernet.
l End-user multicast application device sends IGMPreport while receiving IGMPqueryor being
activated bythe user.The Router should be responsible to proxy(thatis, change source IPto
Router sWAN IP) the IGMPreport toADSLWAN side, including all PVCs. The same case is for
IGMPleave packet.
l Not necessaryto relaymulticast routing between twoADSLPVCs or twointerfaces in LAN side.
l Special purpose multicast packet (such as RIP2 packet) should run withoutInterference.
Table 5-2. Packet Process
Rx Entity Packet Class TTL Action
IGMPquery1Relayto Ethernet
IGMPreport 1Ignore
IGMPleave 1Ignore
ADSL
General Multicast IP -Relayit to Ethernet
IGMPquery1Ignore
IGMPreport 1Relayto all ADSLPVCs
IGMPleave 1Relayto all ADSLPVCs
Ethernet
General Multicast IP -Ignore
?Note
Before the IGMPmode is enabled;please go to the Miscellaneous Configuration page to
enable the IGMPproxy. Otherwise, the IGMPselectionwill not be valid.
Q. Where can I downloadthe free softwareto test IGMP?
Answer: Please go to this link http://manimac.itd.nrl.navy.mil/MGEN/.
Encapsulation: The different types ofencapsulation include PPPoAVC-Mux, PPPoALLC, 1483 Bridged
IPLLC,1483 Routed IPLLC, 1483 Bridged IPVC-Mux, 1483Routed IPVC-Mux,Classical IPover ATM,
PPPoE VC-Mux, PPPoE LLC, and PPPoENone.
5.2.1 ATM
VPI: VirtualPath Identifier is a virtual path used for cell routing that is identified byan eight bit field in the
ATM cell header.The VPI field specifies this eight bit identifier for routing.
Range: 0-255Default: 0
VCI: AVirtual Channel Identifier is a virtual channel that is identified bya uniquenumerical tag that is
definedbya 16-bit field in the ATM cell header.The purpose ofthe virtual channel is to identifywherethe
cell should travel. The VCI field specifies this 16 bit numerical tag that determines the destination.
Range: 0-65535 Default: 35
Service Category: This field allowsyou to select fromthe following servicecategories.
l UBR (default): When configured as UBR(Unspecified BitRate), traffic is deliveredwith best
efforts but with no guarantee. This allows for fluctuation in times of temporaryincrease ofavailable
bandwidth. For example, ifaPVC with CBR is temporarilyinactive, the PVC(s) withUBR will utilize
that bandwidth while it is available. UBR is intendedfor applications thatdo not require any
maximumbound on the transfer delay.
l CBR: When a PVC is specified as a CBR (ConstantBitRate), that PVC is guaranteed a certain
bandwidth, characterizedbythe PeakCell Rate (PCR). The CBR does nothave to transmit with a
peakcell rate, and when it does, it is onlywhen the bandwidth specified by the PCRis guaranteed.
l VBR-nrt: An PVC enabled with VBR-nrt (Variable Bit Rate - non real time) can transmit a cell only
ifthe PVC has a token available. The PVC accumulates tokens at the rate oftheSustainable Cell

12
Rate, and the PVC can only accumulate amaximumofthe value specifiedby MaximumBurst Size
tokens.
When a PVC has a token available, it can transmit cells at the rate ofPCR.After acell is transmitted, the
PVCloses the token it has accumulated.
In the case ofmultiple PVCs, CBR specified PVCs will have higher priority than PVCs with UBR.
For example, the CBRPVCs will take their bandwidth and the remaining bandwidth will be split among
the UBR PVCs. In the caseoftotal PVC CBR bandwidth exceedingADSLupstream, the total upstream
bandwidthwill be sharedproportionallyto the bandwidth allocated for eachCBR PVC.
Peak Cell Rate: This value specifies themaximum, and insome cases guaranteed, cell ratefor CBR and
VBR-nrt. PeakCell Rates are typicallymeasured inCells/Second, however,theuser entered value is in
kbps and is then converted bythe firmware.
Range: 0-32767 Default: 0
SustainableCellRate: Itis the sustainedrate at which a PVCenabled withVBR-nrt can transmit ATM
cells. SustainableCell Rate(SCR) can be considered as the true reserved bandwidth for a PVC.
Range: 0-32767 Default: 0
Max Burst Size: It is thenumber ofcells a PVC enabled with VBR-nrt can transmit continuouslyat peak
cell rate (PCR).
Range: 0-32767 Default: 0
5.2.2 DHCP Client
DHCP Client: It is to enable or disable (default) theRouter WAN as aDHCP client,where the ISP would be
the DHCPserver. DHCPClientis generallyused in thefollowingencapsulations: 1483 BridgedIPLLC,
1483Routed IPLLC, 1483 Bridged IPVC-MUX, 1483 Routed IPVC-Mux, and Classical IPover ATM. This
option is for non-static (dynamic) IPaddresses.
Host Name: When DHCPClient is Enabled, copytheISPrecognized Host Name here. The Host Name
can be up to 19 characters.
5.2.3 MAC Spoofing
MAC Spoofing: Enable MAC Spoofing to make a different MACAddress appearon the WAN side. This is
also used tosolve the scenario where the ISPonlyrecognizes oneMAC Address. Systemdefault is
Disable.
MACAddress: When MACSpoofing is enabled,copythe ISP-recognized MAC address here. Format for
MAC address is six pairs ofhexadecimal numbers (0-9, A-F) separatedbycolons. Systemdefault is:
00:00:00:00:00:00.
5.2.4 Static IP Settings
Static IPSettings are for users who have a Static IP Address (WAN side) fromtheir ISP.
IP Address: It is the static IPAddress given bythe ISP.
Range: x.x.x.y,where 0 ≤x≤255 and 1 ≤y≤254Default: 192.168.241.101
Subnet Mask: It is the subnet maskgiven bythe ISP.
Range: x.x.x.x, where 0 ≤x≤255Default: 255.255.255.0
Gateway: It is theGateway givenbythe ISP.

13
Range: x.x.x.y,where 0 ≤x≤255 and 1 ≤y≤254Default: 0.0.0.0
5.3 LAN Configuration
The LAN configurationpage allowsyou to set the configuration for the LANport.
LANIP Address & SubnetMask: The LAN IP Address is what the computer uses to identifyand
communicate with the Router (this is the address you enter in the address bar ofInternetExplorer to
access these pages). You can change this to another private IPaddress and subnet mask, such as
192.168.1.2 and255.255.255.0.
Range: x.x.x.x, where 0 ≤x≤255
Default is 10.0.0.2 and 255.0.0.0(respectively)
5.3.1 DHCP Server
Dynamic Host Configuration Protocol (DHCP) is a communications protocol that allows network
administrators to manage and assign IPaddresses tocomputers within the network. DHCPprovides a
unique address to a computer in the networkwhichenables it to connect totheInternet through Internet
Protocol (IP). DHCPis controlled bythe DHCPServer. The following settings allowyou to configure the
DHCPserver.
DHCPServer: Select Enabled (default) to activate DHCPServer.
DHCP Address Pool Selection: Two types ofAddress Pool selections are available, with System
Allocated as the default.
l SystemAllocated: The DHCPaddress pool is basedon LAN port IPaddress plus 12 IPaddresses.
For example, when the LAN IPaddress is 10.0.0.2; the DHCPaddress pool the rangefrom10.0.0.3
to 10.0.0.14.
l User Defined: When User Defined is selected, the DHCPaddress pool starts at the User Defined
Start Address and ends at the User Defined EndAddress. The maximumpool sizecan be253 IP
addresses: 255 total IPaddresses - 1 broadcast address - 1 LAN port IPaddress.
User Defined Start Address: It is the starting IPaddress ofthe DHCPpool for User Defined DHCP

14
Address Pool Selection.
Range: x.x.x.x, where 0 ≤x≤255Default: 10.0.0.4
User Defined End Address: It is the last IPaddress in theDHCPpool for User Defined DHCP Address
PoolSelection.
Range: x.x.x.x, where 0 ≤x≤255Default: 10.0.0.15
DHCPGatewaySelection: The default setting for theDHCPGatewaySelection is Automatic. You can
select User Defined and specify User Defined Gateway Address.
The DHCPserver will issuethe User Defined Gateway Address to the LAN DHCPclients.
User Defined Gateway Address: The purpose for the User DefinedGatewayAddress is to have two
gatewayaddresses, as the LAN IPAddress atthetop ofthe LAN Configuration page is also a gateway
address.
Lease time: The Lease time is the amount oftime a networkuser will beallowed to connect with DHCP
server. Ifall fields are0, theallocated IPaddresses will be effective forever.
Rangesfor LeaseTime fields: Days0-36500,Hours 0-23,Minutes 0-59,Seconds0-59,defaultvalueis 1
days0 hours 0 minutes 0 seconds.
User mode: Under the Single User mode, the DHCP server onlyallocates one IP address to a local PC.
Under the Multiple User mode (default), the DHCPserver allocates the IPaddresses specified bythe
DHCPaddress pool.
Save Configuration: Clicking this will link you to the Save Settings / Reboot page.
5.3.2 Ethernet Mode Setting
The Ethernet Modeconfigurationpage allowsyou to set the LAN port into the following modes:
l AutoSense (default): The Router will automatically sense which mode to use,selectingbetween100
Mbps Full Duplex, 100 Mbps HalfDuplex, 10 Mbps Full Duplex, and 10 Mbps HalfDuplex.
l 100 Mbps Full Duplex: Data can be transferred and received simultaneouslyat the transfer rate of
100 Mega-bits per second.
l 100 Mbps Half Duplex: Data cannot be transferred and received at the same time. For example,
data can besent, andoncethe transmission is complete, data canbe received.This is doneat a
transfer rate of100 Mega-bits per second.
l 10 Mbps Full Duplex: Data can be transferred and received simultaneouslyat the transfer rate of10
Mega-bits per second.
l 10 Mbps Half Duplex: Data cannot be transferred and received at the same time. For example, data
can be sent, and once the transmission is complete,data can be received. This isdone at a transfer
rate of10 Mega-bitsper second.

15
5.4 PPP Configuration
The PPPConfiguration page allowsyou to configure multiple PPPsessions for each PVC. MultiplePPP
sessions enables youto setup different connection settings and beable totoggle/choose those settings for
each PVC. The Router can support upto totalof16 PPP sessions, andeach PVC can support up to 8 PPP
sessions. The multiple PPP sessions maybe configuredwith anycombination over 8 PVCs.
5.4.1 PPP Account Configuration
To begin PPPSession configuration, you must first go to the PPP Account Configuration page (below) to
set up an account. The linkto this page can be found on the PPPConfiguration page. On the PPP
Account Configuration page, youmust configure theAccount ID, User Name and Password.
Account ID: It allowsyoutocreate an account ID tohelp distinguish different accounts, up to16 maximum.
The Account ID can be up to 31 characters.
User Name: Enter thePPP user name(providedby theISP). The User Namecanbe upto 127characters.
