Planet CAM-IR552 User manual

50 Meter Infrared Camera – CAM-IR552
Packet Content
CAM-IR552
Screw kit x 1
Quick Installation Guide x 1
Installation
1.PleasextheCAM-IR552toasuitablelocationwiththescrews.
2.Adjustthecameratothecorrectdirection.
3. Connect Video Output connector to your DVR.
4.ConnectaDC12VpoweradaptertothePowerInputconnector.
Note
Before connect power adapter to camera, please make sure the power output voltage is DC 12V (max.
±10%).Ifyoucannotsurethispart,wewillsuggesttouseaDC12VSwitchingpoweradapter.Itcan
providestablypoweroutput.
Specication
Image Pick-up Device SONY 1/3“ Color CCD
Effective Picture Elements NTSC:811(H)x508(V)
PAL:795(H)x596(V)
Horizontal Resolution 520horizontalTVlines
Minimum Illumination 0LUXwithbuilt-inIR-LED
S/N Ratio Morethan48dB
Auto Electronic Shutter NTSC:1/60s~1/100,000s
PAL:1/50s~1/110,000s
Gain Control Automatically
White Balance Automatically(2500K~9500K)
Gamma Characteristic 0.45
Lens Furnished BoardLens8.0mm/F2.0
View Angle Horizontal:33degree
Vertical:25degree
Synchronous System Internal,Negativesync.
Video Output 1Vp-pCompositeVideo/75Ohms
Power Supply 12VDC/100mA(IRon:450mA)
Operating Temp. -20to60degreeC
Water Resistance IP-66
IR LED 12Unitsof850nmIRLED
IR Project Distance 50 Meters
Dimensions 95x250mm(φxL)
Weight 925g

PLANET Technology Corp.
Quick Installation Guide
2011-L00010-000
www.planet.com.tw
IP Surveillance
IP Surveillance
CAM-IR552
50 Meter
Infrared Analog Camera
Supports Long Distance Application
