Planet WDRT-1202AC User manual

1. Package Contents
2. Physical Introduction
– 1 – – 2 –
– 3 – – 4 –
3. Hardware Installation
Front Panel of WDRT-1202AC
Set your computer to get an IP address from the Wireless Router:
2011-E50340-000
Step 1: Locate the WDRT-1202AC in an optimum place, and adjust the
antenna for the best coverage.
WDRT-1202AC Quick Guide
Note
If there is any item missing or damaged, please contact the
seller immediately.
Thank you for choosing PLANET WDRT-1202AC. Before installing the
router, please verify the contents inside the package box.
WDRT-1202AC
Quick Installation Guide
1200Mbps 802.11ac Dual Band
Wireless Gigabit Router
– 5 – – 6 –
– 7 – – 8 –
Step 3: Follow the wizard to configure WAN, Wi-Fi and router
password.
Step 4: You can see the Web management UI of the WDRT-1202AC
after configuring this device.
4. Network Configuration (Windows 7) 5. Enter into the Web Management
1. Click the “Start” button located at the lower-left corner of your
computer.
2. Click “Control Panel”.
3. Double-click the “Network and Sharing Center” icon.
4. Click “Change Adapter Settings”.
5. Double-click “Local Area Connection”.
6. Select “Internet Protocol Version 4 (TCP/IPv4)” and click
“Properties”.
7. Select “Obtain an IP Address automatically” and “Obtain DNS
Server Address automatically”, and then click the “OK” button
twice to save the configuration.
Further Information:
The above steps introduce the simple installations and configurations of
the WDRT-1202AC. For further configurations of LAN, Wireless, Access
Control, etc, please refer to the user manual, which can be downloaded
from the website.
http://www.planet.com.tw/en/support/download.php?type1=4&model
=49025&type=3
If you have further questions, please contact the local dealer or
distributor where you purchased this product.
Power Adapter
Ethernet Cable
Step 2: Connect the Power Adapter provided in the package to the
WDRT-1202AC. The Power LED on the front panel will turn on
accordingly.
USB
5GHz
Power
Internet
2.4GHz
Rear Panel of WDRT-1202AC
ON/OFF
WPS
(press >5 seconds)
WLAN ON/OFF
(press 1~5 seconds)
Power
Reset (press 10 seconds)
USB LAN1~4 WAN
Power
Adapter
Power
Step 3: Follow the figure below to connect the network devices. It
depends on your network environment to connect the WAN
port to a Cable/xDSL modem, or the Ethernet directly in your
place.
Step 1: The Web management allows you to access and manage the
Wireless Router easily. Launch the Web browser and enter the
default IP address http://192.168.1.1
Step 2: When the login window pops up, please enter the User Name
and Password. The default User Name and Password are both
“admin”. Then click the “Log In” button to continue.
Default IP Address: 192.168.1.1
Default User Name: admin
Default Password: admin
Default SSID: PLANET_2.4G_XXXX
PLANET_5G_XXXX
(“X” means the last 4 digits of the MAC address.)
Phone
Jack
RJ11
PC
Cable/xDSL Modem
LAN Ports WAN Port
RJ45
RJ45
Power
Adapter
Power
