Planet ADN-4100 User manual

802.11n Wireless ADSL 2/2+ Router
ADN-4100
User's Manual

Copyright
Copyright©2010 by PLANET Technology Corp. All rights reserved. No part of
this publication may be reproduced, transmitted, transcribed, stored in a retrieval
system, or translated into any language or computer language, in any form or by
any means, electronic, mechanical, magnetic, optical, chemical, manual or
otherwise, without the prior written permission of PLANET.
PLANET makes no representations or warranties, either expressed or implied, with
respect to the contents hereof and specifically disclaims any warranties,
merchantability or fitness for any particular purpose. Any software described in
this manual is sold or licensed "as is". Should the programs prove defective
following their purchase, the buyer (and not this company, its distributor, or its
dealer) assumes the entire cost of all necessary servicing, repair, and any incidental
or consequential damages resulting from any defect in the software. Further, this
company reserves the right to revise this publication and to make changes from
time to time in the contents hereof without obligation to notify any person of such
revision or changes.
All brand and product names mentioned in this manual are trademarks and/or
registered trademarks of their respective holders.
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:

ii
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
4. Consult the dealer or an experienced radio technician for help.
FCC Caution
To assure continued compliance (example-use only shielded interface cables when
connecting to computer or peripheral devices). Any changes or modifications not
expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
Following two conditions: (1) This device may not cause harmful interference, and
(2) this Device must accept any interference received, including interference that
may cause undesired operation.
Federal Communication Commission (FCC) Radiation Exposure Statement
This equipment complies with FCC radiation exposure set forth for an uncontrolled
environment. In order to avoid the possibility of exceeding the FCC radio frequency
exposure limits, human proximity to the antenna shall not be less than 20 cm (8
inches) during normal operation.
R&TTE Compliance Statement
This equipment complies with all the requirements of DIRECTIVE 1999/5/EC OF
THE EUROPEAN PARLIAMENT AND THE COUNCIL OF 9 March 1999 on radio
equipment and telecommunication terminal Equipment and the mutual recognition
of their conformity (R&TTE)
The R&TTE Directive repeals and replaces in the directive 98/13/EEC
(Telecommunications Terminal Equipment and Satellite Earth Station Equipment)
As of April 8, 2000.

WEEE Regulation
To avoid the potential effects on the environment and human health as a
result of the presence of hazardous substances in electrical and electronic
equipment, end users of electrical and electronic equipment should
understand the meaning of the crossed-out wheeled bin symbol. Do not dispose of
WEEE as unsorted municipal waste and have to collect such WEEE separately.
Safety
This equipment is designed with the utmost care for the safety of those who install
and use it. However, special attention must be paid to the dangers of electric shock
and static electricity when working with electrical equipment. All guidelines of this
and of the computer manufacture must therefore be allowed at all times to ensure
the safe use of the equipment.
Energy Saving Note of the Device
This power required device does not support Standby mode operation.
For energy saving, please remove the power cable or push the power button to
OFF position to disconnect the device from the power circuit.
Without removing power cable or Power off, the device will still consuming power
from the power source. In the view of Saving the Energy and reduce the
unnecessary power consuming, it is strongly suggested to remove the power
connection for the device if this device is not intended to be active.
Revision
User’s Manual for 802.11n Wireless ADSL 2/2+ Router
Model: ADN-4100
Rev: 1.0 (Sep. 2010)
Part No. EM-ADN4100_v1
iii

i
Contents
1Overview………….............................................................................................. 1
1.1 Safety Precautions ................................................................................ 1
1.2 LEDs and Interfaces .............................................................................. 2
1.3 System Requirements ........................................................................... 4
1.4 Features ................................................................................................ 4
2Hardware Installation ......................................................................................... 6
3Web Configuration ............................................................................................. 8
3.1 Accessing the Device ............................................................................ 8
3.2 General Configuration ........................................................................... 9
3.2.1 Wizard....................................................................................... 10
3.2.2 Internet Setup ........................................................................... 16
3.2.3 Wireless Setup.......................................................................... 19
3.2.4 Local Network ........................................................................... 27
3.2.5 Time and Date .......................................................................... 31
3.2.6 Logout....................................................................................... 32
3.3 Advanced Configuration ...................................................................... 32
3.3.1 Advanced Wireless................................................................... 32
3.3.2 Port Forwarding ........................................................................ 40
3.3.3 DMZ .......................................................................................... 42
3.3.4 Parental Control........................................................................ 43
3.3.5 Filtering Options........................................................................ 47
3.3.6 QoS Config ............................................................................... 52
3.3.7 Firewall Settings ....................................................................... 56
3.3.8 DNS .......................................................................................... 57
3.3.9 Dynamic DNS ........................................................................... 58
3.3.10 Network Tools...................................................................... 60
3.3.11 Routing ................................................................................ 75
3.3.12 Schedules............................................................................ 79
3.3.13 Logout ................................................................................. 80
3.4 Management........................................................................................ 80
3.4.1 System...................................................................................... 80
3.4.2 Firmware Update ...................................................................... 82
3.4.3 Access Controls........................................................................ 83
3.4.4 Diagnostics ............................................................................... 87

ii
3.4.5 Log Configuration ..................................................................... 87
3.4.6 Logout....................................................................................... 88
3.5 Status................................................................................................... 89
3.5.1 Device Information.................................................................... 89
3.5.2 Wireless Clients ........................................................................ 91
3.5.3 DHCP Clients............................................................................ 91
3.5.4 Logs .......................................................................................... 91
3.5.5 Statistics.................................................................................... 92
3.5.6 Route information ..................................................................... 94
3.5.7 Logout....................................................................................... 94

1
1 Overview
The ADN-4100 supports multiple line modes. It provides four 10/100Base-TX
Ethernet interfaces at the user end. The device provides high speed ADSL
broadband connection to the Internet or Intranet for high-end users, such as net
cafes and office users. It provides high performance access to the Internet,
downstream up to 24 Mbps and upstream up to 1 Mbps.
The device supports WLAN access. It can connect to the Internet through a
WLAN AP or WLAN device. It complies with IEEE 802.11, 802.11b/g/n
specifications, WEP, WPA, and WPA2 security specifications.
1.1 Safety Precautions
Refer to the following instructions to prevent the device from risks and damage
caused by fire or electric power:
Use volume labels to mark the type of power.
Use the power adapter packed within the device package.
Pay attention to the power load of the outlet or prolonged lines. An
overburden power outlet or damaged lines and plugs may cause electric
shock or fire accident. Check the power cords regularly. If you find any
damage, replace the power cords at once.
Proper space left for heat dissipation is necessary to avoid damage caused
by overheating to the device. The long and thin holes on the device are
designed for heat dissipation to ensure that the device works normally. Do
not cover these heat dissipation holes.
Do not put this device close to a place where a heat source exits or high
temperature occurs. Avoid the device from direct sunshine.
Do not put this device close to a place where it is over damp or watery. Do
not spill any fluid on this device.
Do not connect this device to any PCs or electronic products, unless our
customer engineer or your broadband provider instructs you to do this,
because any wrong connection may cause power or fire risk.
Do not place the device on an unstable surface or support.

1.2 LEDs and Interfaces
Front Panel
Figure 1 Front panel
The following table describes the LEDs of the device.
2
LED Color Status Description
On The device is powered on and the
initialization is normal.
Green
Off The power is off.
PWR
Red On The device is self-testing or self-testing is
failed.
Slow
Blinks No signal is detected.
Fast
Blinks
The device is handshaking with the physical
layer of the office.
Link Green
On The device is connected to the physical
layer of the office.
On
The Internet connection is normal in the
routing mode (for example: PPP dial-up is
successful), and no Internet data is being
transmitted.
Blinks Internet data is being transmitted in the
routing mode.
Green
Off The device is in the bridge mode.
Data
Red On
The Internet connection fails after
successful synchronization in the routing
mode (for example: PPP dial-up is failed).
On The LAN connection is normal.LAN4-1 Green
Blinks Data is being transmitted through the LAN
interface, or the Internet data is being

LED Color Status Description
transmitted in the bridge mode.
Off The LAN connection is not established.
On The WLAN connection has been activated.
Blinks Data is being transmitted through the
WLAN interface.
WLAN Green
Off The WLAN connection is not activated.
Blinks WPS is activated and the device is waiting
for negotiation with the clients.
WPS Green
Off WPS is not activated.
Rear Panel
Figure 2 Rear panel
The following table describes the interfaces and buttons of the device.
Interface/Button Description
LINE RJ-11 interface, for connecting the interface of the
telephone set through the telephone cable.
LAN1, LAN2,
LAN3, LAN4
RJ-45 interface, for connecting the Ethernet interface of a
computer or an Ethernet device.
POWER Power interface, for connecting the interface of the power
adapter.
RESET
Restore to factory defaults. To restore factory defaults,
keep the device powered on, push a paper clip into the
hole to press the button for over 3 seconds and then
release.
WPS/ WLAN
Press the button and hold it for 1 second, to enable
WLAN.
Press the button and hold it for 1 second to 3
3

4
Interface/Button Description
seconds, it does not take effect.
Press the button and hold it for 3 or more than 3
seconds, to initialize WPS negotiation.
ON/OFF Power switch, power on or off the device.
1.3 System Requirements
Recommended system requirements are as follows:
A 10Base-T/100Base-TX Ethernet card is installed on your PC.
A hub or switch is available for connecting one Ethernet interface on the
device and several PCs.
Operating system: Windows XP, Windows 2000, Windows ME, or Windows
98SE.
Internet Explorer V5.0 or higher, Netscape V4.0 or higher, or Firefox 1.5 or
higher
1.4 Features
The device supports the following features:
IEEE802.11b/g/n
Various line modes
External PPPoE dial-up access
Internal PPPoE and PPPoA dial-up access
1483 Bridged, 1483 Routed, and MER access
Multiple PVCs (up to eight) that can be isolated from each other
A single PVC with multiple sessions
Multiple PVCs with multiple sessions
Binding of ports with PVCs
802.1Q and and 802.1P protocol
DHCP server
NAT and NAPT
Static routing
Firmware upgrade through Web or TFTP

5
Restore to the factory defaults
DNS
Virtual server
DMZ
Three-level user accounts
Web user interface
Telnet CLI
System status displaying
PPP session PAP, CHAP, and MS-CHAP
IP filter
IP QoS
Remote access control
Line connection status test
Remote management through telnet or HTTP
Backup and restoration of configuration file
Ethernet interface supports crossover detection, auto-correction and
polarity correction
UPnP
PPTP VPN
IPSec VPN

2 Hardware Installation
Step 1 Connect the LINE interface of the device and the Modem interface of
the splitter with a telephone cable. Connect the phone set to the
Phone interface of the splitter through a telephone cable. Connect the
input cable to the Line interface of the splitter.
The splitter has three interfaces:
Line: Connect to a wall phone interface (RJ-11 jack).
Modem: Connect to the LINE interface of the device.
Phone: Connect to a telephone set.
Step 2 Connect the LAN interface of the device to the network card of the PC
through an Ethernet cable (MDI/MDIX).
Note:
Use the twisted-pair cable to connect the hub or switch.
Step 3 Insert one end of the power adapter to the wall outlet and connect the
other end to the POWER interface of the device.
Connection 1: Figure 3 shows the connection of the device, PC, splitter, and
telephone sets, when no telephone set is placed before the splitter. This type of
connection is recommended.
6

Figure 3 Connection diagram (without a telephone set before the splitter)
Connection 2: Figure 4 shows the connection of the device, PC, splitter, and
telephone sets, when a telephone set is placed before the splitter.
As illustrated in the following figure, the splitter is installed close to the device:
Figure 4 Connection diagram (with a telephone set before the splitter)
Note:
When connection 2 is used, the filter must be installed close to the telephone
cable. See Figure 4. Do not use a splitter to replace the filter.
Installing a telephone directly before the splitter may lead to failure of connection
between the device and the central office, failure of Internet access, or slow
connection speed. If you need to add a telephone set before the splitter, you must
add a microfilter before the telephone set. Do not connect several telephones
before the splitter or connect several telephones with the microfilter.
7

3 Web Configuration
This chapter describes how to configure the device by using the Web-based
configuration utility.
3.1 Accessing the Device
The following describes how to access the device for the first time in detail.
Step 1 Open the Internet Explorer (IE) browser and enter http://192.168.1.1
in the address bar.
Step 2 The LOGIN page as shown in the following figure appears:
In this page, enter the user name and the password. Then, click login.
The user name and the password of the super user are admin and admin
respectively.
The user name and the password of the normal user are user and user
respectively.
If you log in as the super user successfully, the page as shown in the following
figure appears:
8

If the login information is incorrect, the page as shown in the following figure
appears:
Click OK to log in again.
Note:
In the LAN, you can use either of the following two levels of user accounts
(displayed in the user name/password format) to access the device:
admin/admin and user/user.
In the WAN, you can use one of the following three levels of user accounts
(displayed in the user name/password format) to access the device:
admin/admin, user/user, and support/support.
3.2 General Configuration
9

3.2.1 Wizard
Wizard helps you to fast and accurately configure Internet connection and other
important parameters. The following sections describe these various
configuration parameters.
When subscribing to a broadband service, be aware of the Internect connection
mode. The physical WAN device can be Ethernet, DSL, or both. Technical
information about properties of Internet connection is provided by your Internet
service provider (ISP). For example, your ISP should inform you whether you are
connected to the Internet using a static or dynamic IP address, and the protocol,
such as PPPoA or PPPoE, that you use to communicate on the Internet.
Step 1 Choose Setup > Wizard. The page as shown in the following figure
appears:
Step 2 Click Setup Wizard. The page as shown in the following figure
appears:
10

There are four steps to configure the device. Click Next to continue.
Step 3 Set the time and date. Then, click Next.
Step 4 Configure the Internet connection.
Select the protocol and the encapsulation mode. Set the VPI and the
VCI.
If the Protocol is set to PPPoE or PPPoA, the page as shown in the
following figure appears:
11

You need to enter the user name and password for PPPoE or PPPoA
dialup.
If the Protocol is set to Dynamic IP, the page as shown in the
following figure appears:
12

If the Protocol is set to Static IP, the page as shown in the following
figure appears:
You need to enter the information of the IP address, subnet mask, and
gateway.
If the Protocol is set to Bridge, the page as shown in the following
figure appears:
13

If you click Scan, the system automatically searches the available
PVCs.
After the searching is complete, the result appears next to the Scan
button.
14
