Planeta BHW Series User manual

Installation and Operation Manual for:
Manual ope Winch
PLANETA – BHW
GB
IMPO TANT - EAD P IO TO USE!
© Reproduction of any kind, only with written authorisation of der PLA ETA-Hebetechnik GmbH
04-02-01-0713-0001-00
BHW-1200
BHW-1800
BHW-2600

–2–
Manual Instruction for:
PLANETA Brake Winch
BHW-1200, BHW-1800, BHW-2600
I. Features
A high quality, multi-purpose winch. Frame is one-piece design, plastic
handle grip, high strength alloysteel gear of one peace design, welded reel.
Baked enarnel and plated finish. Automatic brake the ensures suspension of load.
II. Important indications
1. Read instruction and make it available to operators on the device before
using it.
2. Operator must be instructed properly with the device. Never leave the device
under load unattended!
3. Never exceed carrying capacity indicated on the name plate. Do not draw any
pull and lifting ropes or chains respectively over angles.
4. Do not transport persons or loads with the product over areas below which
persons could be staying.
5. Device must be checked once a year by a technical expert, in case of
harder operating conditions more often. Ask your retailer or PLANETA.
The enterpriser is liable in case of damages and has to provide test
certificates.
6. Check the device regarding damages, unfastened screws or twists before
using it and eliminate failures.
7. Repair works on PLANETA hoisting devices shall only be carried out by the
manufacturer or an instructed repair shop respectively by using PLANETA
spare parts.
8. Check load carrying constructions, load securing devices, mountings, cross
beams etc. regarding load carrying capacity and condition of the required
loads by a technical expert.
9. Non-observance of the instruction, improper use, and corrosion by in
sufficient protection or product alterations without authority result in the expiry
of the warranty.

–3–
10. Risk of corrosion in case of continuous contact with unfavourable atmospheric
conditions as for example high humidity or harmful environmental influences
as for example atmospheres with acid vapours, corrosive gases or high dust
concentration cause early wear. This effectuates no claim under warranty.
11. Further information or spare part lists will kindly be provided by us or your
specialist dealer.
III. Security advices
1. Never apply load on winch with cable fully extended. Keep at least three full
turns of cable on the reel.
2. Operate with hand power and with crank included in the equipment only.
This winch should not be operated with a motor of any kind.
3. If the winch cannot be cranked easily with one hand, it is probably over-
loaded
4. Do not oil or grease brake mechanism.
IV. Assembly advices before initiation
1. Insert the rope from A to B and through C of the hole of the Fixing Device.
2. Completely tighten the screw of the Fixing Device
3. - BHW-1200, BHW-1800: Rope circle the drum to go from below drum
(please refer figure 1)
- BHW-2600: Rope circle the drum to go from above drum
(please refer figure 2)
Figure 1 Figure 2

–4–
DECLARATION OF CONFORMITY
in the sense of 2006/42/EC Guidelines,
Appendix II A, 2004/108/EG, Appendix I and 2006/95/EG, Appendix III
We herewith declare that the,
Manual Rope Winch, Type BHW
in payload range 550 kg - 1.200 kg
which was developed for lifting and lowering of loads, in the standard version,
including load capacity control and meets the basic requirements for the following
EC directives, as applicable for the delivered scope:
EC Machine directive 2006/42/EC
Delivered as complete machine and carried out by
PLANETA-Hebetechnik GmbH, Resser Straße 17, D-44653 Herne
Authorized for the compilation of the relevant technical documentation:
Dipl.-Ing. Matthias B. Klawitter, CE-Koordinator,
PLANETA-Hebetechnik GmbH, Resser Straße 17, D-44653 Herne
Herne, 28.08.2015 PLANETA-Hebetechnik GmbH
Dipl.-Ök. Christian P. Klawitter
(General Manager)
For the completion, installation and commissioning according to the operating instructions
is responsible:
Location: .................................................................... Date: ...........................................
Person in charge: ....................................................................................................................
Company: ................................................................................................................................

–5–
EC INSTALLATION DECLARATION
Declaration for the installation of an incomplete machine according to EC directives
2006/42/EC, Addendum II B, 2004/108/EC, Addendum I and 2006/95/EC, Addendum III
We,
PLANETA Hebetechnik GmbH, Resser Straße 17, D-44653 Herne
hereby declare that the incomplete machine
Manual Rope Winch, Type BHW
in payload range 550 kg - 1.200 kg
which was developed for lifting and lowering of loads, in the standard version, including load
capacity control, is intended for installation in a machine and meets the basic requirements
for the following EC directives, as applicable for the delivered scope:
EC Machine directive 2006/42/EC
In addition, we declare that the technical documentation has been created according to
addendum VII Part B of the directive 2006/42/EC. We commit to supply the special
documentation of the hoist gear to the individual national agencies upon justified request.
The transmission will be made electronically.
This declaration applies only to the hoist gear. Commissioning is prohibited until it has been
established that the crane, in which the hoist gear is installed, meets the regulations of the
above stated EC directives.
Authorized for the compilation of the relevant technical documentation:
Dipl.-Ing. Matthias B. Klawitter, CE-Koordinator,
PLANETA Hebetechnik GmbH, Resser Straße 17, D-44653 Herne
Herne, 28.08.2015PLANETA-Hebetechnik GmbH
Dipl.-Ök. CHristian P. Klawitter
(General Manager)
For the completion, installation and commissioning according to the operating instructions
is responsible:
Location: .................................................................... Date: ...........................................
Person in charge: ....................................................................................................................
Company: ................................................................................................................................

– 6 –
Annual inspections
The aforementioned winch was again inspected:
Test date Kind of test Name/Signature Test result

–7–
Note
