PlayMakar MVPmini QUIETVYBE MVP-500 User manual

1
Instruction Manual
Model # MVP-500
Percussion Massage System
WITH QUIETVYBE™TECHNOLOGY
MVP

3
TABLE OF CONTENTS
Description............................................................... 4
Warnings .................................................................. 5
Contents................................................................... 6
Features ................................................................... 7
Application............................................................... 8
Charging the Battery .............................................. 9
Operating Instructions........................................... 10
Maintenance & Storage......................................... 10
Technical Specications ....................................... 11
Product Warranty.................................................... 12
Registering Your Device ........................................ 13
Warranty Registration Card .................................. 14

4
PlayMakar® MVPmini Percussion Massage System
The MVPmini Percussion Massage System featuring
QUIETVYBE™ Technology and our patent-pending
ProTips™ is a lightweight, ultra-compact device designed
to loosen knots, reduce fatigue, and melt away stress.
It comes with four ProTips™ interchangeable massage
heads to enhance your treatment.
What is Percussion Massage?
Percussion massage delivers a barrage of short rapid
strokes penetrating deep into the muscle tissue to
release lactic acid, pain, and tension. It helps improve
blood circulation, increase range of motion, stimulate
muscle growth, enhances recovery, and decrease stress.
What is Vibration Massage?
Vibration massage uses a stroke that presses and
releases in an up and down movement on a group of
muscles. It can be effective in soothing or stimulating
soft tissues depending on the applied speed and
level of pressure.

5
IMPORTANT SAFETY INSTRUCTIONS
• The MVPmini is intended for adult use only and should be
used as instructed in this manual.
• Do not use the MVPmini on children or infants.
• This device is for use on soft tissues areas. It should not be
used on the head, spine, or other bony parts.
• The MVPmini should be used on clean, dry body parts only.
• If you experience pain, discomfort, or bruising, discontinue
use immediately.
• Do not use the MVPmini on contusions, rashes, irritated skin,
bruised, or injured areas of skin.
• Keep the device away from your hair to avoid entanglement.
• Avoid using the MVPmini under a pillow or blanket to avoid
excessive heating.
• Never immerse the device in water.
• Keep ventilation opening free of dust and debris.
• Do not attempt to disassemble, dismantle, alter, or remove
the battery from the MVPmini. Doing so could result in
damage to the device and will void the warranty.
• The MVPmini should only be charged using the USB-C cable
supplied with this device.

6
CONTENTS
• PlayMakar® MVPmini Percussion Massager
• USB-C Charging Cable
• ProTips™ with EchoFlex™ Technology:
݇Shoc™ Absorption & Reverberation Massage Head
݇EchoBall™ 1.5” Absorption & Reverberation Massage Head
݇ImpactBall™ 2” Massage Head
݇AcuTrigger™ Acupressure Massage Head

7
FEATURES
1
56
2
3
4
1Powerful brushless motor
2Low noise treatment with QUIETVYBE™ Technology >45db
37 mm Stroke length
4 Ergonomic grip built for comfort
5 2600mAh Lithium battery for up to 5 hrs. of therapy per charge
6 5 Adjustable Speeds (1800, 2100, 2400, 2700, & 3000 RPMs)

8
APPLICATION
Shoc™Absorption & Reverberation
Massage Head
The Shoc™Head replicates the deep pressure of a
thumb while the patent-pending air transfer pocket
absorbs impact and reverberates for a more
comfortable experience. It is ideal for sore, tender,
or bony areas, and overall use.
EchoBall™Absorption & Reverberation
Massage Head
The 1.5” EchoBall™Head is provides a medium to
high impact treatment to sore, achy muscles. It is
perfect for use on dense muscle groups.
ImpactBall™2” Massage Head
The 2” ImpactBall™Head is designed for general use
on large and small muscle groups. It covers a larger
surface area and delivers a lower impact than the
EchoBall™Head for a broader treatment option.
AcuTrigger™Acupressure Massage Head
The AcuTrigger™Head simulates acupressure
therapy for painful trigger points. It is also ideal for
use on smaller muscle areas including the hands,
elbows, and feet.

9
CHARGING THE BATTERY
1. Plug the cable into the opening located near the bottom of
the MVPmini.
2. Plug the USB-C connector into a USB port to begin charging.
3. A green light by the charging port will illuminate to indicate
the device is charging.
4. Charging is complete when the green light shuts off.
Important: Please allow ~3 hours for the MVPmini to fully
charge before use.
BATTERY CAPACITY INDICATORS
> 30% Blue light
< 30% Red light
< 5% Red light will blink 5 times

10
OPERATING INSTRUCTIONS
1. Attach the desired massage head securely to the device.
2. Press the ( I ) button on the bottom of the device for 2-3
seconds to start your massage treatment on the lowest
intensity level.
3. Press and release the ( I ) button to increase the intensity to
the next level. Repeat until the desired intensity is reached.
Important: The number of blue lights indicates the level of
intensity from 1 - 5.
4. The device will shut off automatically after 10 minutes of
use. Restart the device to continue your treatment.
5. Press the ( I ) button through all 5 intensity levels to turn off
the device.
MAINTENANCE & STORAGE
• Use a dampened cloth to wipe the device after each use.
• Do not use harsh cleaning on the device or accessories.
• The device should be stored in a dry, ventilated environment.
• Charge the battery once a month when storing the
device for long periods.

11
TECHNICAL SPECIFICATIONS
Vibration Frequency: 1800-3000 RPM
Stroke Displacement: 7 mm
ProTips™ with EchoFlex™: 4
Battery Indicator Mode: LED Display
Level RPM
(Revolutions Per Minute)
11800
22100
32400
42700
53000
RPM BY INTENSITY LEVEL:
BATTERY SPECIFICATIONS
Battery Type: 18650 Power Type 3C
Rated Voltage: 11.1V
Charging Time: ~2-3 hrs.
Cycle Life: 800 cycle (>80%;/ (Capacity > 80%)
CHARGER SPECIFICATIONS
Model Number: MX24W1-2401000U
Input Voltage: 100/240V AC
Output Voltage: 12V DC
Rated Power: 25 W
Charging Current: ~1000mA

12
WARRANTY
This PlayMakar® MVPmini Massager comes with a 1-year
warranty from the date of purchase. If the product fails due to
a defect in material or workmanship, PlayMakar will repair or
replace the product or necessary components.
An extended warranty is provided for devices registered at
PlayMakar.com/register
Consumable items such as massage heads and AC adapters
are guaranteed to be free from defects at the time of delivery.
The warranty does not apply to damage resulting from
failure to follow the operating instructions, accidents, abuse,
alterations, or disassembly by unauthorized individuals.
PlayMakar® reserves the right to replace or repair the unit at
our discretion.
PlayMakar, Inc.
Attn: Warranty
5825 Park Vista Circle
Fort Worth, Texas 76244
www.PlayMakar.com
Phone: 833-PLAY-MAKAR or 833-752-9625
Email: [e-mail]

13
THANK YOU FOR PURCHASING
We appreciate you choosing the PlayMakar® MVPmini
Massager. We believe our product is the best device on the
market and think you will, too. Our team is passionate about
sports, tness, and helping athletes of every level meet their
performance goals with our exceptional products.
Your satisfaction is important to us. If you have questions
please contact our Customer Service Representatives.
They can be reached by phone at 833-752-9625 between
8 a.m. to 4 p.m. CST, Monday through Friday, or by email at
[e-mail].
REGISTERING YOUR DEVICE
Please register your device within 14 days of purchase to
receive product offers, discounts, and instructional videos.
Registration may be completed online or by mailing the
attached Warranty Registration Card.
Go to PlayMakar.com/register to register your product online.
Use the following information to complete your registration:
Model Number: MVP-500
Serial Number: Located on the bottom of your device

14
Warranty Registration Card
Please return this completed card in a stamped envelope
within 14 days of purchase to receive additional offers and
product information.
Mail to: PlayMakar® Products
5825 Park Vista Circle
Fort Worth, Texas 76244
Product Name Model Number
Date of Purchase Place of Purchase
Serial Number
Name
Address 1
Address 2
City State Zip
Country
Phone
Email
How did you hear about PlayMakar?
Why did you choose your PlayMakar product?

15
This page intentionally left blank.

16
5825 Park Vista Circle
Fort Worth, TX 76244
[phone]
[e-mail]
www.PlayMakar.com
Version: 0422-1
