pleomax MF210 User manual
HEADSET
MF210
WIRELESS
User Manual
MF210 Headset Ear hook USB Cable 3 dierent size ear bud User manual
(Small, Medium, Large)
ENCLOSURES
HEADSET OVERVIEW
-1- English
Charging Port
Multifunction Button
LED
Volume Button
Microphone
Ear Bud
Speaker
English
HOW TO USE
Before using your headset, charge the battery for at least 2 hours.
Charging the battery completely (and keeping it charged) will help you get
the longest possible talk and standby time out of the battery.
Don’t use if Headset is being charged.
POWER ON/ OFF
Power On : Press MFB for 3 seconds. (Blue LED blinks 3 times)
Power O : Press MFB for 4 seconds. (Blue LED blinks 4 times)
PAIRING
Before you use headset, please pair your headset with mobile phone rst.
1. Please check the Headset is turned o.
2. Press and hold Multi-function button for 5 seconds until blue LED turns on.
3. Search the headset via your phone and please follow the instruction of
your mobile phone.
4. When you nd your headset MF210,
please select it and conrm by“Yes”or“OK”
5. Enter PIN Number ‘0000’(4 zeros).
-2-
Input PIN Code
0000
Active Dev List
Model Name
MF210
4.reference 5.reference
EASY PAIRING: If you use headset for the rst time, headset will go
pairing mode directly.
Low Battery Warning : When Headset needs to charge, you can hear the
warning beep every 30 seconds, unless you don’t charge
within 30 minutes and headset will be power-o.
MAKING A CALL
Make a call from your mobile phone as usual; your phone should
automatically send the call to the headset. If it doesn’t, press and hold MFB
for 2 seconds to manually send the call to the headset.
ANSWERING A CALL
Press the Multi-function button briey to receive a call.
REJECT AN INCOMING CALL
Press and hold MFB for 2 seconds, when you hear a beep, release the button.
You can hear the ring melody for an incoming call. Press the MFB for 2 seconds
until you hear a beep to reject incoming call.
-3- English
ENDING A CALL
Press the MFB during the call or just the ending button on the phone to end
a call.
LAST NUMBER REDIAL
With the phone in standby, press MFB; the headset automatically dials the
last number dialed from the phone.
VOICE DIAL
Press MFB for about 2 seconds until you hear a beep. Voice dialing is activated
on the phone. If you want to cancelVoice dialing, press the MFB for 2 seconds
during the Voice dial mode.
[NOTE] Please make sure that the phone supports the Voice Recognition and save Voice Tag.
TRANSFERRING A CALL
1. From Headset to Phone : To transfer a call, press the MFB on the headset
during the call for 2 seconds until you hear the beep.
2. From Phone to Headset : To transfer a call, press the MFB on the headset
during the call for 2 seconds until you hear the beep.
-4- English
MULTIPOINT : Using the Headset with two phones
[NOTE] Some mobile phones are not available for Multipoint.
1. Multi-point Connect
Set the headset into pairing mode rst.
After then search headset from each mobile phones at the same time.
Please connect rst mobile phone. Once the connection is completed,
please connect the second mobile phones.
[NOTE] Some mobile phones needs to connection process at the same time.
2. Making a call [via the second mobile phone
Press the volume button twice shortly for last call-redialing from the second
mobile phone. Press the volume button for about 2 seconds to activate the
voice dialing of the second mobile phone.
[NOTE] Making a call via the rst mobile phones, please follow the same instruction as described on
“MAKING A CALL”.
3. Receiving a call
Please use the general rule as you receive calls
[NOTE] Each mobile phone plays dierent ring tones.
-5- English
VOLUME CONTROL & MUTE FUNCTION
Press the VOL button. There are 6 volume levels that cycle as you press the VOL
button. When the highest level is reached, the volume level cycles back down
to the lowest.
Press and hold volume down button for 2 seconds, then the MIC will be
muted with the melody every 5 seconds. If you press the volume down button
for 2seconds again, MIC mute will be deactivated.
MULTIPOINT FUNCTION
The Headset supports simultaneous connection with 2 mobile phones with
full control of each unit.
[NOTE] This feature may not be compatible with certain mobile phones.
1. Multi-Point Connect
Set the device into the pairing-mode rst and search the headset
individually from 2 mobile phones. Make sure one mobile phone is
connected properly to the unit before trying the other one.
You can check connection with the mobile phones through beep and
LED ashing.
-6- English
2. Making a phone call [To use the 2nd mobile phone]
Press the Volume button for twice until a beep sound is heard to make
an last number redial from the second mobile phone.
[NOTE] Making a phone call [To use the 1st mobile phone] Follow the same instruction in the
section of‘Making a call’.
3. Receiving a call
Press the Multi-Function button to receive incoming calls.
[NOTE] Each mobile phone plays dierent ring tones. When you are on the line with the mobile
phone, the connection with the other mobile phone will be disconnected. But it will be
automatically re-connected when you terminate the call and keep connection with 2
mobile phones.
RESET
Press the MFB and Volume button for 4 seconds. Then all device information
will be reset. (Please conrm the headset is connectable mode.)
-7-
-8-
STATUS INDICATION
1. LED Indication
Speaker Status LED Indication
Power On Blue LED blinks 3 times
Power O Blue LED blinks 4 times
Pairing Mode Blue LED turns On
Connectable Mode Blue LED blinks 1 time every 5 seconds
Connected Mode Blue LED blinks 2 times every 5 seconds
Active Call Mode Blue LED blinks 3 times every 5 seconds
Charging in Progress Blue LED turns On
Charging Complete Blue LED turns O
2. Tone Indication
Speaker Status Tones Indication
Power On 4 Rising Beep
Power O 4 Falling Beep
Connect 4 Short Beep
Incoming Call Ring melody
Active Call 2 Rising Beep
Ending a Call 2 Falling Beep
Low Battery Low Battery Beep
SPECIFICATIONS
Model Name MF210
Bluetooth Core Spec Bluetooth Specication 2.0
Prole HFP, HSP
Carrier Frequency 2400 MHz to 2483.5 MHz
Modulation Method GFSK, 1Mbps, 0.5BT Gaussian
Maximum Data Rate Asynchronous : 723.2 kbps / 57.6 kbps
Synchronous : 433.9kbps / 433.9 kbps
Bluetooth Class Class 2
Hopping 1600 hops/sec, 1MHz Channel Space
Transmit Power 1 dBm
Coverage Range 10 Meters
Receiver Sensitivity -82 dBm / 0.1 % BER
Continuous Talk Time 5 hours
Standby Time 100 hours
Weight 9g
Dimension 9.65(H) *17.6(W) * 48.8(L) without Speaker
Charging Voltage DC 5.0 V
Charging Time 2 Hours
OperatingTemperature -10° to +50°C
Storage Temperature -20° to +85°C
Battery Lithium Polymer 3.7V 80mH
-9-
SAFETY AND GENERAL INFORMATION
1. Please read this guidebook carefully and follow the instruction.
2. To avoid any damage or malfunction of the unit, do not drop it from high place.
3. Keep away unit from humidity, water and any other liquid. And if the unit is exposed by water,
moisture and other liquid directly, then do not operate it normally to avoid any electrical shock,
explosion and damage of the unit.
4. Do not place or keep the unit near the heat sources such as direct sun light, radiators, stoves or other
apparatus which produce heat. It may cause explosion, degrade of performance and reduce
battery life.
5. Do not modify, repair & disassemble unit at discretion (especially battery: it may cause an explosion.
6. Do not place the heavy objects on the unit.
7. Use only supplied and approved charger.
8. Replacement or service must be done at a qualied service center or manufacturer.
9. Unplug this unit when unused for long period of time or during lightening storms.
[CAUTIONS] ELECTRIC SHOCK HAZARD
The battery used in this device may present a risk of re or chemical burn if mis-treated.
FCC WARNING
This equipment may generate or use radio frequency energy. Changes or modications to this equipment
may cause harmful interference unless the modications are expressly approved in the instruction
manual.The user could lose the authority to operate this equipment if an unauthorized change or
modication is made.
[NOTE] This equipment has been tested and found to comply with the limits for a Class B digital device,
purchant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit dierent from that to which the receiver
is connected.
Consult the dealer or an experienced radio/TV technician for help.”
FCC RF Radiation Exposure Statement
1. ThisTransmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
2. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment.
FCC Notice
Operation is subject to the following two conditions :
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation of the device.
EU
This product is CE marked according to the provision of the R&TTE Directive (99/5/EC).
Here by MOVON Corporation, declares that this product is in compliance with the essential
requirements and other relevant provisions of Directive 1999/5/EC. Please note that this product uses
radio frequency bands not harmonized within EU. Within the EU this product is intended to be used in
Austria, Belgium, Denmark, Finland, France,Germany, Greece, Ireland, Italy, Luxembourg, The Netherlands,
Portugal, Spain, Sweden, United Kingdom and within EFTA in Iceland, Norway and Switzerland. Bluetooth
is a trademark owned by the Bluetooth SIG, Inc.
WARRANTY
The condition of this warranty and our responsibilities under this warranty are as follows:
Supplier’s warranty is non-transferable. And this warranty is limited to the original purchaser only.
You must be able to prove the date of original purchase of the unit with a dated receipt.
The warranty is not applicable if the product has been subject to physical abuse, improper
installation, modication or repair by unauthorized third party.
The responsibility of supplier’s products shall be limited to the repair or replacement of the product
at it’s sole discretion.
Specically exempt from any warranty are limited-life consumable components subject to normal
wear and tear such as batteries, decorates and other accessories.
A supplier will not take any responsibility if the failure of the unit has resulted from accident, abuse,
misuse or any unauthorized repair, modication or disassemble.
Modication and repair of the unit should be done by authorized and qualied service personnel,
center or returned to the manufacturer.
This warranty gives you specic legal rights and you may also have other rights which vary under
local laws.
WEEE SYMBOL INFORMATION
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with separate collection systems)
This marking shown on the product or its literature, indicates that it should not be disposed with other
household wastes at the end of its working life.
To prevent possible harm to the environment or human health from uncontrolled waste disposal, please
separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of
material resources.
Household users should contact either the retailer where they purchased this product or their local govern-
ment oce, for details of where and how they can take this item for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract.
This product should not be mixed with other commercial wastes for disposal.
[IMPORTANT NOTE] To comply with RF exposure requirements, this device may not be co-located
with any other transmitter or antenna.
