iPORT™ CL-Ten Dual Medium
External Frame Grabber
User Guide

Copyright © 2013 Pleora Technologies Inc.
These products are not intended for use in life support appliances, devices, or systems where malfunction of these products can
reasonably be expected to result in personal injury. Pleora Technologies Inc. (Pleora) customers using or selling these products for
use in such applications do so at their own risk and agree to indemnify Pleora for any damages resulting from such improper use or
sale.
Trademarks
PureGEV, eBUS, iPORT, vDisplay, AutoGEV, AutoGen, and all product logos are trademarks of Pleora Technologies. Third party
copyrights and trademarks are the property of their respective owners.
Notice of Rights
All information provided in this manual is believed to be accurate and reliable. No responsibility is assumed by Pleora for its use.
Pleora reserves the right to make changes to this information without notice. Redistribution of this manual in whole or in part, by
any means, is prohibited without obtaining prior permission from Pleora.
Document Number
EX001-020-0001, Version 3.0, 11/4/13

i
Table of Contents
About this Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
What this Guide Provides . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Related Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
About the iPORT CL-Ten Dual Medium External Frame Grabber . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
The iPORT CL-Ten Dual Medium External Frame Grabber . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Model Variants . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Feature Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Selected GenICam Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
iPORT CL-Ten Dual Medium External Frame Grabber Connections . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Connector Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
GPIO and Serial Connector Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Mapping of Serial Communication Interfaces and Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Mapping of Camera Link Connector and GPIO Pinouts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Power Connector Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Signal Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
PLC Programming Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Installing the eBUS SDK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Installing the eBUS SDK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Installing the Driver and Configuring the NIC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Connecting to the External Frame Grabber and Configuring General Settings . . . . . . . . . . . . . . . . 27
Connecting the Ethernet Cables and Confirming Image Streaming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Configuring the Buffers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Providing the External Frame Grabber with an IP Address. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Configuring an Automatic/Persistent IP Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Configuring the External Frame Grabber’s Image Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Configuring a Camera Link Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Configuring Camera Link Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Supported Camera Link Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
About Tap Reconstruction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Supported Device Tap Geometries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Implementing the eBUS SDK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

ii iPORT CL-Ten Dual Medium External Frame Grabber User Guide
Network Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Unicast Network Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Required Items — Unicast Network Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
External Frame Grabber Configuration — Unicast Network Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Multicast Network Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Required Items — Multicast Network Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Connecting the Hardware and Power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Configuring the CL-Ten Dual Medium External Frame Grabber for a Multicast Network Configuration . . . . 48
System Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Troubleshooting Tips. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Reference: Mechanical Drawings and Material List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Mechanical Drawings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Material List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

About this Guide 1
Chapter 1
About this Guide
This chapter describes the purpose and scope of this guide, and provides a list of complimentary guides.
The following topics are covered in this chapter:
•“What this Guide Provides” on page 2
•“Related Documents” on page 2

2iPORT CL-Ten Dual Medium External Frame Grabber User Guide
What this Guide Provides
This guide provides you with the information you need to connect the iPORT CL-Ten Dual Medium
External Frame Grabber to two Camera Link® Medium cameras. In this guide you can find a product
overview, instructions for connecting the cables, installing the Pleora eBUS™ SDK, establishing an
Ethernet connection, performing general configuration tasks, and configuring the settings to properly
capture and display images from Camera Link cameras.
The last chapter of this guide provides Technical Support contact information for Pleora Technologies.
Related Documents
The iPORT CL-Ten Dual Medium External Frame Grabber User Guide is complemented by the following
guides:
•eBUS Player Quick Start Guide
•eBUS SDK C++ API SDK Help File
•eBUS SDK .NET API Help File
•eBUS SDK Programmer’s Guide
•GigE Vision Standard, version 2.0 available from the Automated Imaging Association (AIA) at
www.visiononline.org
•GenICam Standard Features Naming Convention available from the European Machine Vision
Association (EMVA) at www.emva.org.
•Camera Link® Standard, available from the Automated Imaging Association (AIA) at
www.visiononline.org
•iPORT Advanced Features User Guide

About the iPORT CL-Ten Dual Medium External Frame Grabber 3
Chapter 2
About the iPORT CL-Ten Dual Medium External Frame
Grabber
This chapter describes the external frame grabber, including the product variants and key features.
The following topics are covered in this chapter:
•“The iPORT CL-Ten Dual Medium External Frame Grabber” on page 4
•“Model Variants” on page 5
•“Feature Set” on page 6
•“Selected GenICam Features” on page 7

4iPORT CL-Ten Dual Medium External Frame Grabber User Guide
The iPORT CL-Ten Dual Medium External Frame Grabber
Pleora’s iPORT™ CL-Ten External Frame Grabbers use a high performance GigE Vision® over 10 Gigabit
Ethernet (10 GigE) link to transmit video simultaneously from two Camera Link Base or Medium
cameras at their maximum data rates, with low, predictable latency. These external frame grabbers allow
designers to extend and aggregate system cabling, and integrate Camera Link cameras into a networked
environment.
CL-Ten External Frame Grabbers interact seamlessly with Pleora’s other products in networked or point-
to-point digital video systems. The frame grabbers also comply fully with the GigE Vision and
GenICam™ standards, enabling interoperation with third-party equipment in multi-vendor
environments. The GigE Vision and GenICam standards are agnostic to Ethernet link speed, which
means the CL-Ten can be designed into multi-speed systems alongside GigE Vision cameras operating at
1 Gb/s, with no software modifications. With these benefits, manufacturers and integrators can use the
CL-Ten to shorten time-to-market, reduce development and deployment risk, and lower design and
system costs.
The CL-Ten converts video data to packets and sends them over a 10 GigE link to receiving software or
hardware. The CL-Ten is compatible with industry-standard copper or fiber-based links via an SFP+
(small form-factor pluggable) connector, and can be easily connected to off-the-shelf 10 GigE
components such as network cards and switches.
The CL-Ten is bundled with Pleora’s feature-rich application toolkit, eBUS™ SDK.

5About the iPORT CL-Ten Dual Medium External Frame Grabber
Model Variants
The iPORT CL-Ten Dual Medium External Frame Grabber is supplied in these variants and is equipped
with these parts, as listed in the following table.
Table 1: Model Variants
iPORT CL-Ten Dual Medium Enclosed Quantity
iPORT CL-Ten Dual Medium Enclosed Quantityy
iPORT CL-Ten Dual Medium enclosed unit 1
iPORT CL-Ten Dual Medium Evaluation Kit Fiber Quantity
iPORT CL-Ten Dual Medium External Frame Grabber enclosed unit 1
10 gigabit Ethernet network interface card (NIC) 1
10 gigabit enhanced small form-factor pluggable (SFP+) module, short range 2
Multimode fiber optic cable, 2 meters 1
12V power supply 1
Pleora eBUS SDK, provided on CD or USB stick (includes eBUS Player sample
application)
1
iPORT CL-Ten Dual Medium Evaluation Kit Copper Quantity
iPORT CL-Ten Dual Medium External Frame Grabber enclosed unit 1
10 gigabit Ethernet NIC 1
SFP+ Direct-Attach cable (passive), 2 meters 1
12V power supply 1
Pleora eBUS SDK, provided on CD or USB stick (includes eBUS Player sample
application)
1
*Before assembly, ensure that all components are included in the selected package.

6iPORT CL-Ten Dual Medium External Frame Grabber User Guide
Feature Set
Key features
10 gigabit Ethernet-based. Supports IGMPv2 and ICMP.
Aggregation of two Camera Link Medium cameras over a single 10 gigabit Ethernet link*
Camera Link support:
• Compatible with Base and Medium mode cameras up to 85 MHz*
• Supports Power over Camera Link
(PoCL)
• Supports CLProtocol
• Supports 10GBASE-SR, -LR, and -LRM using linear or limiting SFP+ modules
• Supports SFP+ Direct-Attach copper (passive, 12m maximum length)
Supports key non-interlaced tap configurations
Supports interleaved 2-tap and 4-tap configurations
Supports 1, 2, or 4 tap configurations**
Software-controlled GPIO:
• 4 TTL (5V) general purpose inputs
• 2 TTL (5V) general purpose outputs
3 UARTs (2 LVDS on Camera Link interface and 1 RS-232 on GPIO connector) allow serial control of cameras and
other devices using a computer application over the network link
Compatible with GigE Vision Standard, version 2.0. Operates with GigE Vision and GenICam compatible applications.
Environmental and Physical
Storage temperature: -40° to 85°C
Operating temperature: 0° to 45°C
Dimensions (L x W x H):
• 117 mm x 100 mm x 83.5 mm
* Two Base mode cameras can be connected (using the Medium 1A and Medium 2A connectors).
** When using Base mode cameras, 1 and 2 tap configurations are available.

7About the iPORT CL-Ten Dual Medium External Frame Grabber
Selected GenICam Features
The iPORT CL-Ten Dual Medium External Frame Grabber supports the mandatory GenICam features
along with additional features, some of which are shown in the following table. The full list of features
can be seen in the Device Control dialog box of Pleora’s eBUS Player application.
Table 2: Selected GenICam Features
Feature Description
Width* Specifies the width of the image (in pixels).
Height* Specifies the height of the image (in pixels).
OffsetX Specifies the horizontal image offset (in pixels).
OffsetY Specifies the vertical image offset (in pixels).
PixelFormat* Specifies the format of the pixel provided by the device. Available pixel formats
are:
• Monochrome pixel formats, 8 to 16 bits
• Bayer pixel formats, 8 to 16 bits
• RGB pixel formats, 8 to 12 bits per component
DeviceReset Resets the external frame grabber to its power up state.
ActionUnconditionalMode** Enables the unconditional action command mode where action commands are
processed even when the primary control channel is closed.
ActionDeviceKey** Provides the device key that allows the device to check the validity of action
commands.
ActionQueueSize** Indicates the size of the scheduled action commands queue. This number
represents the maximum number of scheduled action commands that can be
pending at a given point in time.
ActionSelector** Selects to which Action Signal further Action settings apply.
ActionGroupMask** Provides the mask that the device will use to validate the action on reception of
the action protocol message.
ActionGroupKey** Provides the key that the device will use to validate the action on reception of
the action protocol message.
ClConnectorSelector Selects the Camera Link interface to configure.
ClSafePowerActive Controls whether the SafePower protocol is active. SafePower is a protocol to
prevent the External Frame Grabber from attempting to supply power to a
conventional (non-PoCL) cable or camera.
ClSafePowerStatus Reports the status of the SafePower controller.
SourceCount* Controls the number of sources supported by the device.
DeviceScanType* Specifies the sensor scan type, such as areascan or linescan.

8iPORT CL-Ten Dual Medium External Frame Grabber User Guide
* These features are interrelated. When you change any of these values, the external frame grabber may automatically adjust the
other values to ensure the configuration is valid.
** For information about using the action command and IEEE1588 features, see the iPORT Advanced Features User Guide, available
on the Pleora Support Center at www.pleora.com.
DeviceTapGeometry* Describes the geometrical properties characterizing the taps of a Camera Link
camera as seen from the frame grabber or acquisition card. This device tap
geometry feature is specific to Camera Link.
Available tap geometries are:
• Geometry_1X_1Y
• Geometry_1X2_1Y
• Geometry_1X
• Geometry_1X2
• Geometry_1X4_1Y
• Geometry_1X4
• Geometry_1X8
• Geometry_2X2E
GevIEEE1588** Enables the IEEE 1588 Precision Time Protocol to control the timestamp
register.
GevIEEE1588ClockAccuracy** Indicates the expected accuracy of the device clock when it is the grandmaster,
or in the event it becomes the grandmaster.
This feature maps to the IEEE 1588 clockAccuracy attribute.
GevIEEE1588Status** Provides the state of the IEEE 1588 clock.
SensorDigitizationTaps* Specifies the number of digitized samples that are simultaneously output by the
camera A/D conversion stage.
DigitizedImageWidth* Width of the image provided by the Camera Link camera (in pixels).
DigitizedImageHeight* Height of the image provided by the Camera Link camera (in pixels).
Table 2: Selected GenICam Features (Continued)
Feature Description

iPORT CL-Ten Dual Medium External Frame Grabber Connections 9
Chapter 3
iPORT CL-Ten Dual Medium External Frame Grabber
Connections
This chapter describes the external frame grabber connections. It also includes pinouts for the GPIO,
serial, and power connector.
The following topics are covered in this chapter:
•“Connector Locations” on page 10
•“GPIO and Serial Connector Pinouts” on page 11
•“Mapping of Serial Communication Interfaces and Connectors” on page 12
•“Mapping of Camera Link Connector and GPIO Pinouts” on page 13
•“Power Connector Pinouts” on page 14

10 iPORT CL-Ten Dual Medium External Frame Grabber User Guide
Connector Locations
The following figure and table describe the external frame grabber connectors.
Table 3: External Frame Grabber Connectors
Connector Type Description
Medium Mini Camera Link Transmits images from a Camera Link camera to the external frame
grabber through a Camera Link cable. You can connect two Medium
mode cameras to the external frame grabber (connect one camera to
the connectors labeled Medium 1 and connect the other camera to the
connectors labeled Medium 2).
If PoCL is enabled, 4W at 12V is supplied to the camera, as outlined in
the PoCL specification.
Note: To use the external frame grabber in a Base Camera Link
configuration, you can connect two Base mode cameras to the external
frame grabber (connect one camera to the Medium 1A connector and
connect the other camera to the Medium 2A connector).
Power 6-pin connector Receives 12V of unfiltered DC input.
The power consumption of the external frame grabber is approximately
11.5W (when using fiber optic cabling) and approximately 10W (when
using Direct-Attach copper cabling). Values exclude PoCL power
consumption.
Ethernet SFP+ cage Interfaces the external frame grabber to Ethernet networks, as
specified in IEEE 802.3.
The Ethernet interface operates at 10 gigabits per second (Gbps), and
supports Internet Protocol Version 4 (IPv4).
GPIO/Serial 12-pin connector Provides external signals, such as serial communication and GPIO, to
the external frame grabber.

11iPORT CL-Ten Dual Medium External Frame Grabber Connections
GPIO and Serial Connector Pinouts
The GPIO and serial pinout descriptions on the 12-pin female connector are listed in the following table.
The mating connector is a Hirose 12-pin connector, part number HR10A-10P-12P(73).
Table 4: 12-Pin Connector — Pinout Descriptions
Pin Type Notes
1 GPIO output Protected by ESD suppressors to IEC61000-4-2, Level 4 (+/-8 kV contact, +/-15 kV
air discharge)
2GPIO input ESD information is the same as pin 1.
This pin is mapped to CC2 on the Medium1A connector. See Table 6 on page 13
for the mapping of camera control and GPIO pins.
3 GPIO output ESD information is the same as pin 1.
4GPIO input/
output
ESD information is the same as pin 1.
This pin is mapped to CC1 on the Medium2A connector. See Table 6 on page 13
for the mapping of camera control and GPIO pins.
5Ground Ferrite bead 0.3A, 600 Ohm @ 100 MHz to DGND of the daughter card.
6GPIO input/
output
ESD information is the same as pin 1.
This pin is mapped to CC2 on the Medium2A connector. See Table 6 on page 13
for the mapping of camera control and GPIO pins.
7GPIO input/
output
ESD information is the same as pin 1.
For second generation CL-Ten External Frame Grabber models, this pin is reserved.
8GPIO input/
output
ESD information is the same as pin 1.
For second generation CL-Ten External Frame Grabber models, this pin is reserved.
93.3 V power
output
Maximum 100 mA, protected by 0.2A resettable fuse.
10 GPIO input ESD information is the same as pin 1.
This pin is mapped to CC1 on the Medium1A connector. See Table 6 on page 13
for the mapping of camera control and GPIO pins.

12 iPORT CL-Ten Dual Medium External Frame Grabber User Guide
Mapping of Serial Communication Interfaces and Connectors
The mapping of the signals from the Camera Link connector to the bulk interfaces of the camera is
provided in the following table.
Table 5: Mapping of Serial Communication Interfaces and Connectors
Connector Serial communication interface
Medium 1A Bulk0
Medium1B N/A
Medium 2A Bulk1
Medium2B N/A
GPIO Bulk4
When using a Base mode configuration, the camera connected to the Medium 1A connector is mapped to
Bulk0. The camera connected to the Medium 2A connector is mapped to Bulk1.
11 RS232_RX0
(BULK4 Rx)
Protected by ESD suppressors to IEC61000-4-2, Level 4 (+/-8 kV contact, +/-15 kV
air discharge)
12 RS232_TX0
(BULK4 Tx)
ESD information is the same as pin 1.
The GPIO pins on the 12-pin connector are mapped to GpioIn0 through GpioIn3 and GpioOut0 through
GpioOut1 of the DigitalIOControl\LineSelector feature in the device’s XML file. For information about
configuring the external frame grabber with eBUS Player, see “Connecting to the External Frame Grabber
and Configuring General Settings” on page 27.
Table 4: 12-Pin Connector — Pinout Descriptions (Continued)
Pin Type Notes

13iPORT CL-Ten Dual Medium External Frame Grabber Connections
Mapping of Camera Link Connector and GPIO Pinouts
This section only applies to earlier releases of the external frame grabber. With the introduction of our next
generation PLC, the CC and GPIO signals are no longer linked. The CC signals are now outputs to the PLC
and the GPIO_In signals are inputs to the PLC. If you have upgraded your external frame grabber to version
2.0.0 (or later) and you want to drive the CC lines with the GPIO_In lines, you must program the PLC to
perform this task. For more information about the PLC, see the iPORT Advanced Features User Guide,
available at the Pleora Support Center. Embedded camera interfaces with version 2.0.0 (or later) firmware
have the next generation PLC.
The GPIO pins on the 12-pin circular connector allow an external signal to control a Camera Link
camera (typically, to trigger a camera). For example, triggers can be used to synchronize image capture
from multiple cameras or to synchronize image capture with an external device.
The mapping of the GPIO signals from the 12-pin circular connector to the Camera Link connector are
provided in the following table.
Table 6: Mapping of Camera Link Connector and GPIO Pinouts
Camera Control (CC) Pin GPIO Pin
Base 1/Medium 1A
CC4 0/unused
CC3 0/unused
CC2 Line1 (GPIO_IN1)
CC1 Line0 (GPIO_IN0)
Base 2/Medium 2A
CC4 0/unused
CC3 0/unused
CC2 Line3 (GPIO_INOUT1)
CC1 Line2 (GPIO_INOUT0)

14 iPORT CL-Ten Dual Medium External Frame Grabber User Guide
Power Connector Pinouts
The power connector receives 12V of unfiltered DC input. The external frame grabber’s power
consumption is approximately 11.5W (when using fiber optic cabling) and approximately 10W (when
using Direct-Attach copper cabling). Values exclude PoCL power consumption.
The power connector is a Hirose 6-pin connector, part number HR10A-7R-6P(73).
Table 7: Power Connector Pinout Descriptions
Pin Name
1 V
in
11V to 13V regulated
2 V
in
11V to 13V regulated
3 V
in
11V to 13V regulated
4Ground
5Ground
6Ground

Signal Handling 15
Chapter 4
Signal Handling
The CL-Ten Dual Medium External Frame Grabber includes a programmable logic controller (PLC) that
lets you control external machines and react to inputs. By controlling your system using the PLC, you can
make functional changes, adjust timing, or add features without having to add new hardware.
The PLC in the iPORT CL-Ten Dual Medium External Frame Grabber routes signals through a
sophisticated PLC control block.

16 iPORT CL-Ten Dual Medium External Frame Grabber User Guide
PLC Programming Signals
For an introduction to the PLC and for detailed information about how PLC signals are handled, see the
iPORT Advanced Features User Guide, available on the Pleora Support Center at www.pleora.com.
The following table lists the PLC input and output programming signals that are specific to the iPORT
CL-Ten Dual Medium External Frame Grabber, and indicates the pins on which they are available.
Table 8: PLC Signal Usage
Signal name PLC equation usage
Pb0Fval Input
Pb0Lval Input
Pb0Dval Input
Pb0Spare Input
Pb1Fval Input
Pb1Lval Input
Pb1Dval Input
Pb1Spare Input
GpioIn0 Input
GpioIn1 Input
GpioIn2 Input
GpioIn3 Input
BufferWM0 Input
BufferWM1 Input
Grb0AcqActive Input
Grb1AcqActive Input
PlcCtrl0 Input
PlcCtrl1 Input
PlcCtrl2 Input
PlcCtrl3 Input
Pb0CC0 Input, output
Pb0CC1 Input, output
Pb0CC2 Input, output
Pb0CC3 Input, output
Pb1CC0 Input, output
