PLEORA TECHNOLOGIES INC.
iPORT Analog-Pro IP Engine
User Guide

Copyright © 2014Pleora Technologies Inc.
These products are not intended for use in life support appliances, devices, or systems where malfunction of these products can
reasonably be expected to result in personal injury. Pleora Technologies Inc. (Pleora) customers using or selling these products for
use in such applications do so at their own risk and agree to indemnify Pleora for any damages resulting from such improper use or
sale.
Trademarks
PureGEV, eBUS, iPORT, vDisplay, and all product logos are trademarks of Pleora Technologies. Third party copyrights and
trademarks are the property of their respective owners.
Notice of Rights
All information provided in this manual is believed to be accurate and reliable. No responsibility is assumed by Pleora for its use.
Pleora reserves the right to make changes to this information without notice. Redistribution of this manual in whole or in part, by
any means, is prohibited without obtaining prior permission from Pleora.
Document Number
EX001-021-0001, Version 5.0, 30/10/14

i
Table of Contents
About this Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
What this Guide Provides . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Related Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
About the iPORT Analog-Pro IP Engine. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
The iPORT Analog-Pro IP Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Model Variants . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Feature Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Selected GenICam Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Hardware Deinterlacing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
iPORT Analog-Pro IP Engine Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Connector Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Making GPIO and Serial Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Mounting the GPIO and Serial Connector to an Enclosure Backplate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
GPIO and Serial Connector Pinouts — Adapter Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
GPIO and Serial Connector Pinouts — Daughter Card. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Power Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Installing the SDK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Installing the eBUS SDK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Installing the Driver and Configuring the NIC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Connecting to the iPORT Analog-Pro IP Engine and Configuring General Settings. . . . . . . . . . . . . . 27
Connecting the Ethernet Cables and Confirming Video Streaming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Starting GEVPlayer and Connecting to a Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Providing the IP Engine with an IP Address. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Unicast Network Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Multicast Network Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Configuring the Buffers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Configuring the Image and Deinterlacing Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Implementing the eBUS SDK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
System Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Troubleshooting Tips. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Changing to the Backup Firmware Load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Reference: Mechanical Drawings and Material List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Mechanical Drawings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Material List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61


2iPORT Analog-Pro IP Engine User Guide
What this Guide Provides
This guide provides you with the information you need to connect the iPORT Analog-Pro IP engine. In
this guide you can find a product overview, instructions for connecting the IP engine cables, installing the
Pleora eBUS™SDK, establishing an Ethernet connection, and performing general configuration tasks.
The last chapter of this guide provides Technical Support contact information for Pleora Technologies.
Related Documents
The iPORT Analog-Pro IP Engine User Guide is complemented by the following guides:
•
GEVPlayer Quick Start Guide
•
GEVPlayer User Guide
•
vDisplay HDI-Pro IP Engine User Guide

About the iPORT Analog-Pro IP Engine 3
Chapter 2
About the iPORT Analog-Pro IP Engine
This chapter describes the IP engine, including the product variants and key features.
The following topics are covered in this chapter:
•
“The iPORT Analog-Pro IP Engine” on page 4
•
“Model Variants” on page 5
•
“Feature Set” on page 6
•
“Selected GenICam Features” on page 7
•
“Hardware Deinterlacing” on page 8

4iPORT Analog-Pro IP Engine User Guide
The iPORT Analog-Pro IP Engine
The iPORT Analog-Pro IP engine allows for expansion of a GigE Vision video network to include high-
value analog cameras. Compact and simple to integrate, the IP engine transmits high-quality video from
analog cameras with low, predictable latency. Able to transmit video from up to two analog cameras
simultaneously, this video transmitter is ideal for systems integrators looking to realize the benefits of
networked video connectivity, while re-using high-value analog cameras.
The IP engine is compatible with the GigE Vision and GenICam™ standards for communication over a
Gigabit Ethernet link, which increases interoperability between products from different manufacturers,
while dramatically lowering system cost and complexity. With Gigabit Ethernet, cabling distances of up
to 100 m can be achieved using standard CAT5/6 cabling; by incorporating common, off-the-shelf
switches, cabling distances can be unlimited. Decreased cable size, increased flexibility, and a tighter cable
bend radius are a few of the additional benefits gained when using Gigabit Ethernet for video transfer.
The iPORT Analog-Pro IP engine provides software-controlled general purpose inputs and outputs
(GPIO), as well as two RS-232 ports to control external accessories, such as motorized wipers and pan/
tilt housings. Able to transmit video at full resolution at up to 30 frames per second with low, consistent
latency, the iPORT Analog-Pro IP engine is available as a compact, low-power OEM board set designed
for use in a variety of housings. Compatible with the Pleora Technologies vDisplay™ HDI-Pro IP engines,
as well as the Pleora Technologies feature-rich application toolkit, eBUS™ SDK, the iPORT Analog-Pro
IP engine enables analog cameras to become part of a complete networked video connectivity solution.
Product Formats: Board Set and Enclosed Unit
The iPORT Analog-Pro IP engine is available as either a compact board set designed for use in a variety
of housings, or as an enclosed unit, in a compact and rugged case that can be used in a variety of
applications as a stand-alone component within a simple point-to-point GigE network, or as part of a
larger switched GigE network.
The following images show the board set and the enclosed iPORT Analog-Pro IP engine.
iPORT Analo
g
-Pro Board Set Enclosed iPORT Analo
g
-Pro IP En
g
ine

5About the iPORT Analog-Pro IP Engine
Model Variants
The iPORT Analog-Pro IP engine is supplied in these variants and is equipped with these parts, as listed
in the following table.
Table 1: Model Variants
*Before assembly, ensure that all components are included in the selected package.
iPORT Analog-Pro IP engine package variants*
iPORT Analog-Pro OEM Kit Quantity
iPORT Analog-Pro Board Set 1
12-pin circular connector for GPIO and serial communication 1
Adapter board for 12-pin circular to 20-pin FFC connector 1
20-pin FFC cable 1
2-pin power connector with open wires 1
iPORT Analog-Pro Enclosed Quantity
iPORT Analog-Pro enclosed unit 1
iPORT Analog-Pro Development Kit Quantity
iPORT Analog-Pro enclosed unit 1
Gigabit Ethernet network interface card (NIC) 1
Ethernet cable 1
Power supply with 12V power adapter 1
Pleora eBUS SDK CD (includes GEVPlayer sample application) 1

6iPORT Analog-Pro IP Engine User Guide
Feature Set
The iPORT Analog-Pro IP engine provides the features and functions listed in the following table.
Table 2: iPORT Analog-Pro IP Engine Feature Summary
Key features
NTSC, PAL, CCIR, and RS-170 video signal support
Full resolution and frame rate for each supported video format
Two RS-232 serial ports to control external accessories
Software-controlled GPIO:
• 4 TTL (5V) general purpose inputs
• 3 TTL (5V) general purpose outputs
Compact form factor, low power consumption
OEM board set or enclosed unit
Low, consistent latency
Deinterlacing capability provides field insertion (weaving) and line duplication
Mono8 and YUV422Packed pixel formats
Compatible with Automated Imaging Association (AIA) GigE Vision specification 1.2; operates with GigE Vision and
GenICam compatible applications
Environmental and Physical
Storage temperature: -40° to 85°C
Operating temperature: 0° to 40°C (higher if using thermal pads between FPGA/PHY/DDR and chassis)
Dimensions:
•OEM. 105 mm X 52 mm X 42 mm
•Enclosed. 113 mm x 82 mm x 51 mm

7About the iPORT Analog-Pro IP Engine
Selected GenICam Features
In addition to the mandatory GenICam features for any compliant GigE Vision device, the iPORT
Analog-Pro IP engine provides a number of additional features. Selected GenICam features are listed in
the following table.
To view the description of a setting in GEVPlayer, click the feature. A brief description appears at the bottom
of GEVPlayer.
Table 3: Selected GenICam Features
Feature Description
InputVideoFormat Defines the video format accepted by the IP engine, either CompositeNTSC or
CompositePAL.
Note: For RS-170 or CCIR, select CompositeNTSC or CompositePAL,
respectively.
Width Width of the image.
Height Height of the image.
OffsetX Horizontal image offset.
OffsetY Vertical image offset.
PixelFormat Available pixel formats are:
• Mono 8
• YUV422Packed
DeviceReset Resets the IP engine to its power up state.
Interlaced Configures the IP engine to decode the video coming from the camera as
interlaced video.
Deinterlacing Performs Line Duplication or Weaving.
After you change the InputVideoFormat, Interlaced, and Deinterlacing features, you may need to adjust
the Width, Height, or image offset (as the settings may now be invalid).

8iPORT Analog-Pro IP Engine User Guide
Hardware Deinterlacing
Deinterlacing requires a receiver to buffer two fields and recombine them into full frames. The IP engine
supports field-type combination deinterlacing for video captured from analog cameras. Two types of
field-type deinterlacing are line insertion (weaving) and line duplication:
•
Weaving is a method of deinterlacing that inserts the odd horizontal scanning lines of one field between
the even horizontal scanning lines of another field. Artifacts associated with this video deinterlacing
method are combing, and for this reason it is recommended for images with restricted motion.
•
Line duplication is a method of deinterlacing that adds repeated horizontal lines of both the odd and
even horizontal scanning fields. For example, lines 1 and 3 of one field are duplicated, and produce lines
2 and 4, respectively. There is a loss of vertical resolution associated with this deinterlacing method and
it can introduce the video artifact referred to as “bobbing”. This method is suitable for images with larger
amounts of motion.

iPORT Analog-Pro IP Engine Connections 9
Chapter 3
iPORT Analog-Pro IP Engine Connections
This chapter describes the IP engine connections. It also includes pinouts for the power, GPIO and serial
connectors.
The following topics are covered in this chapter:
•
“Connector Locations” on page 10
•
“Making GPIO and Serial Connections” on page 11
•
“Mounting the GPIO and Serial Connector to an Enclosure Backplate” on page 11
•
“GPIO and Serial Connector Pinouts — Adapter Board” on page 13
•
“GPIO and Serial Connector Pinouts — Daughter Card” on page 14
•
“Power Pinouts” on page 15

10 iPORT Analog-Pro IP Engine User Guide
Connector Locations
The following figure and table describe the IP engine connectors.
Table 4: IP Engine Connectors
ID Location Type Description
J1, J5 Daughter card BNC video
connector
Accepts standard NTSC, PAL, CCIR, and RS-170 video. J1
corresponds to Source1 and J5 corresponds to Source2 in
the GEVPlayer sample application.
J2, J3 Daughter card 50-pin connector Allows communication between the daughter card and the
main board.
J6 Daughter card 20-pin connector Provides external signals, such as serial communication and
GPIO, to the IP engine.
J7 Daughter card 2-pin connector Receives 5V to 16V of unfiltered DC input.
The IP engine power circuitry is most efficient with 5V
unfiltered DC input.
The IP engine’s power consumption is approximately 4W (with
both channels in use) temperature and input voltage
dependent.
J4, J5 Main board 50-pin connector Allows communication between the daughter card and the
main board.
J1 Main board RJ-45 Ethernet
connector
Interfaces the IP engine to Ethernet networks, as specified in
IEEE 802.3.
The Ethernet interface can operate at 10, 100, or 1000
Mbps, and supports Internet Protocol Version 4 (IPv4).
J1
Daughter card J7 J6
J3 J1J2J4J5
Main board
J5
(on main board)
(on daughter card)
(on daughter card)
(on main board)

11iPORT Analog-Pro IP Engine Connections
Making GPIO and Serial Connections
The IP engine supports the connection of GPIO and serial devices, such as motorized wipers and pan/
tilt housings. This section provides details on making GPIO and serial connections, mounting the 12-pin
GPIO and serial connector to the backplate of a client-sourced enclosure, and provides connector
pinouts.
To make GPIO and serial connections
•
Connect the 20-pin FFC cable at J6 of the daughter card to the adapter board.
The metallic side of the cable ends should be oriented towards the circuit board in both cases.
Mounting the GPIO and Serial Connector to an Enclosure
Backplate
The removable 12-pin GPIO and serial circular connector and the corresponding adapter board are
suitable for mounting to a client-sourced enclosure.
To mount the GPIO and serial connector to an enclosure backplate
1. Insert the 12-pin connector through the external side of the backplate.
2. Secure with washer and hex nut.
Adapter board
12-pin connector

12 iPORT Analog-Pro IP Engine User Guide
3. Connect the adapter board (12 holes) to the base pins of the 12-pin connector through the internal
side of the backplate.
4. Assemble the 12-pin GPIO and serial circular connector to the adapter board by lining up the pins
with the adapter board.
5. Solder the pins of the connector to the adapter board for a secure connection.
12-pin female connector
Insertion
Lock washer
Hex nut
Adapter board
Pins (soldered to adapter board)
20-pin FFC
Enclosure interior
Backplate of client-sourced enclosure
When oriented correctly, the tab on the 12-pin connector aligns with the arrow marker on the adapter
board. The following figures show the pin locations, and also show the tab and arrow marker.
Arrow
Tab
12-pin female connector
Adapter board and 12-pin
Tab location
12-pin female
marker
female connector (assembled)
connector
Adapter board (unassembled)
Arrow
marker
(approximate)

13iPORT Analog-Pro IP Engine Connections
GPIO and Serial Connector Pinouts — Adapter Board
The GPIO and serial pinout descriptions (J1, which is the 12-pin female connector, assembled to the
adapter board) are listed in the following table.
The mating connector is a Hirose 12-pin connector, part number HR10A-10P-12P(73).
Table 5: GPIO and Serial Connector Pinout Descriptions (J1 on the Adapter Board)
Pin Name Function Type Line Notes
1 GPIO_OUT0 TTL_OUT0 GPIO output Line4 Protected by ESD suppressors to
IEC61000-4-2, Level 4 (+/-8 kV contact,
+/-15 kV air discharge)
2 GPIO_IN1 TTL_IN1 GPIO input Line1 ESD information is the same as pin 1
3 GPIO_OUT1 TTL_OUT1 GPIO output Line5 ESD information is the same as pin 1
4 GPIO_IN2 TTL_IN2 GPIO input Line2 ESD information is the same as pin 1
5 GND Ground Ground n/a Ferrite bead 0.2A, 600 Ohm @ 100 MHz
to DGND of the daughter card
6 GPIO_OUT2 TTL_OUT2 GPIO output Line6 ESD information is the same as pin 1
7 GPIO_IN3 TTL_IN3 GPIO input Line3 ESD information is the same as pin 1
8 RS232_RX1 RS-232 Input n/a Protected by ESD suppressors to
IEC61000-4-2, Level 4 (+/-8 kV contact,
+/-15 kV air discharge)
9 RS232_TX1 RS-232 Output n/a ESD information is the same as pin 8
10 GPIO_IN0 TTL_IN0 GPIO input Line0 ESD information is the same as pin 1
11 RS232_RX0 RS-232 Input n/a ESD information is the same as pin 8
12 RS232_TX0 RS-232 Output n/a ESD information is the same as pin 8
Shell GND_CHASSIS Chassis
Ground
Ground n/a For the purpose of EMI prevention,
provide good electrical contact between
the connector shell and the enclosure
box.
The GPIO pins on the 12-pin connector are mapped to Line0 through Line6 of the
DigitalIOControl\LineSelector feature in the Device Control dialog box in the GEVPlayer sample application.
Line7 is mapped to GPIO_OUT3, which is only exposed on connector J6 (20-pin FFC connector). For
information about configuring the IP engine with GEVPlayer, see “Connecting to the iPORT Analog-Pro IP
Engine and Configuring General Settings” on page 27.

14 iPORT Analog-Pro IP Engine User Guide
GPIO and Serial Connector Pinouts — Daughter Card
The GPIO and serial pinout descriptions (J6 on the daughter card) are listed in the following table.
Table 6: GPIO and Serial Connector Pinout Descriptions (J6 on the Daughter Card)
Pin Name Function Type
1 RS232_TX1 RS-232 Output
2 RS232_TX1 RS-232 Output
3 RS232_TX1 RS-232 Output
4 RS232_RX1 RS-232 Input
5 RS232_RX1 RS-232 Input
6 RS232_RX1 RS-232 Input
7 GND Ground Ground
8 GPIO_IN0 GPIO Input
9 GPIO_OUT0 GPIO Output
10 GPIO_IN1 GPIO Input
11 GPIO_OUT1 GPIO Output
12 GPIO_IN2 GPIO Input
13 GPIO_OUT2 GPIO Output
14 GPIO_IN3 GPIO Input
15 GPIO_OUT3 GPIO Output
16 N/C No connect N/A
17 N/C No connect N/A
18 RS232_TX0 RS-232 Output
19 RS232_RX0 RS-232 Input
20 GND Ground Ground

15iPORT Analog-Pro IP Engine Connections
Power Pinouts
The power connector receives 5V to 16V of unfiltered DC input. The IP engine power circuitry is most
efficient with 5V unfiltered DC input. The IP engine’s power consumption is approximately 4W (with
both channels in use), temperature and input voltage dependent.
Power Pinouts — Board Set
The pinouts of the 2-pin header (J7 on the daughter card) are listed in the following table.
Table 7: Power Connector Pinout Descriptions — Board Set
Pin Name
1 PWR
2 RET
Pin 1
Pin 2
Daughter card

16 iPORT Analog-Pro IP Engine User Guide
Power Pinouts — Enclosed IP Engine
The pinouts of the 6-pin female power connector are listed in the following table.
The mating connector is a Hirose 6-pin connector, part number HR10A-7P-6S(73).
Table 8: Power Connector Pinout Descriptions — Enclosed IP Engine
Pin Name
1V
in
5V to 16V regulated
2 V
in
5V to 16V regulated
3V
in
5V to 16V regulated
4Ground
5 Ground
6Ground
Table of contents
Popular Network Hardware manuals by other brands

Checkpoint
Checkpoint QUANTUM SMART-1 6000-L/6000-XL instruction manual

HIK VISION
HIK VISION DS-7600NXI-K1 Series user manual

Black Box
Black Box Multi Quick Check RJ-11 manual

Q-See
Q-See QC814 Specifications

Multitech
Multitech Multi-Tech RouteFinder SOHO RF820 reference guide

High Sec Labs
High Sec Labs FT10N-N user manual
