Plextalk POCKET PTP1 User manual

PLEXTALK®POCKET: Pocket Guide
PLEXTALK POCKET : Pocket Guide
1. Keys
2. Description of the PLEXTALK Pocket
• Speaker and microphone are at the top front.
• Below the speaker and microphone at the right side is the power key
and on the left side the record key.
• In the middle of the device is the play/stop key surrounded by the
navigation keys and, on the outer side, with function keys.
• A numeric keypad is on the front bottom of the Pocket.
• On the top edge are the headphone and line-in jack.
• On the right side edge are the volume adjustment and the key lock.
• On the bottom edge are the AC-adaptor and the mini-USB
connection.
• On the left side edge is the SD card slot.
3. Key Description
Power Key: Switch the Pocket on and off by pressing for 2 seconds. While
the Pocket is on, briefly press the power key to select the sleep timer with
intervals from 15 minutes to 2 hours.
Record Key: Briefly press to start the recording mode. By pressing again,
the unit starts recording on the SD card. The recording can be paused by
pressing the record key or finished by pressing the Play/Stop key. The
recording on the SD card is recognized as a DAISY book. Holding it
pressed enables the recording of voice memos which are stored in the
local memory of the Pocket.
Information
Power key
Title key
Play/Stop key
Record key
Bookmark key
GoTo key Menu key
Enter Cancel
Arrow keys
Backup
Help function
Speed or Tone
settings
1.Keys
PLEXTALK®POCKET: Pocket Guide
1.Keys

2. Description of the PLEXTALK Pocket
3. Key Description
• Speaker and microphone are at the top front.
• Below the speaker and microphone at the right side
is the power key and on the left side the record key.
• In the middle of the device is the play/stop key
surrounded by the navigation keys and, on the outer side,
with function keys.
• A numeric keypad is on the front bottom of the Pocket.
• On the top edge are the headphone and line-in jack.
• On the right side edge are the volume adjustment
and the key lock.
• On the bottom edge are the AC-adaptor and
the mini-USB connection.
• On the left side edge is the SD card slot.
Power Key: Switch the Pocket on and off by pressing for 2 seconds.
While the Pocket is on, briefly press the power key to select the sleep timer
with intervals from 15 minutes to 2 hours.
Record Key: Briefly press to start the recording mode. By pressing again,
the unit starts recording on the SD card. The recording can be paused by
pressing the record key or finished by pressing the Play/Stop key.
The recording on the SD card is recognized as a DAISY book. Holding it
pressed enables the recording of voice memos which are stored in
the local memory of the Pocket.

Play/Stop Key: To start and stop the playback and
also to confirm entries in the menu option.
Arrow Keys: To select the level, use the up and down key. Once
the level is determined, use the left or right key to select.
Example: In a DAISY book, select a page level by using the up or
down key, i.e. a book with page numbers. With the left key, you can
go one page back, with the right key you can go one page forward.
For audio, you can go to the previous track or the next track.
In a book or audio title, one can go back in time by hold-
ing the left key and forward by holding the right key. The time
skips are announced, i.e., the audio tracks are announced.
Bookmark Key: Press once to go to a bookmark. Press twice to create
a new bookmark. Press three times to remove a bookmark.
Menu Key: Press to activate the menu. You can choose from edit, recording
settings, playback settings, bookmark, voice memo, media management and,
system settings. Holding the menu key enables the key describer mode.
Title Key: You can select the SD card, USB, or voice memo. You can select
a title by using the left or right key on the selected media. Using the
up or down key, you can select a title by category, folder or title.
GoTo Key: Navigate directly to a page or heading in a DAISY book,
to a track or an album in audio or to a percentage in a text. This key
needs to be followed by a number and the Play/Stop key.

Numeric Keypads
Speed Setting: Press the 1 key once to set the speed,
then the up or down key to increase or decrease the reading speed.
Tone Setting: Press the 1 key twice to set the tone,
then the up or down key to increase or decrease the tone.
Information: With the 5 key, you can get information about the battery,
current title and so on. By holding the 5 key, the time
and date are announced.
Backup: Press the 9 key to start backup process from USB
media to SD card or vice versa. You need to select a title to back up.
Help Function: Press the 0 key to activate the help function.
This is the built-in manual which you can navigate through
as a DAISY book
Enter: Press the hash key to confirm entries in title selection,
bookmark, the menu option and so on.
Cancel: Press the star key to cancel entries in title selection,
bookmark, the menu option and so on.

4. Examples • Insert the SD card into the Pocket.
• Press the Play/Stop key and the book starts to play.
• If you want to play another DAISY book in the SD card,
press the Title key and select the title by the left or right key.
• Press the Play/Stop key to stop the playback.
• Press and hold the right key to forward in time.
• Press and hold the left key to rewind in time.
• Press the up or down key to slect the navigation level then left or
right key to move back or forward in the selected level
• Press the title key, then the left or right key to select the audio
followed by the Play/Stop key. And use the left or right key
to select the track.
• You can also go directly to an album or track. Press the GoTo key
and press the 7 key then press the Play/Stop key
to play the 7th track in an album.
• Copy the file from a PC system to the SD card.
• Select the text file with the Title key.
• Press the Play/Stop key to play the file.
• The text to speech synthesizer reads the file. This can be
done with either of the 2 voices, set in the System Settings
of the menu option.
• You can navigate the file by sentence, word, character
and so on when pressing the four arrow keys.
To play a DAISY book from the SD card
To play audio
To play plain text file or MS Word DOC file

• Press the Record key briefly. This is the test recording mode.
• You can set the recording parameters by use of
the menu. To start with the default setting,
press the Record key again. The sound is recorded on the SD card.
• To pause the recording, push the Record key again.
• To stop the recording, press the Play/Stop key.
• Hold the Record key and speak into the microphone.
Voice memos are saved in the internal memory of the Pocket.
• Connect the USB flash memory using the
short USB cable delivered with the Pocket.
• Select the title to backup on the SD card.
• Press the 9 key to start the backup. Follow the audio instructions.
• Select the USB device by using the title key.
• Select the title on the USB device.
• Press the 9 key to start the backup to the SD card and follow
the audio instructions.
To record a voice (class, conference, etc.)
To create a voice memo (max 1 minute for one voice memo)
To make a backup from the SD card to USB flash memory
To make a backup from USB flash memory or CD player to the SD card

5. Menu Hierarchy
EDIT:
Set heading
Cancel heading
Remove section
RECORDING SETTINGS:
Select recording mode
Default
Conference
Audio
Analogue cassette
Radio
Custom
Then select sound quality from below.
PCM 44.1kHz stereo
PCM 22.05kHz mono
MP3 256kbps 44.1kHz stereo
MP3 128kbps 44.1kHz stereo
MP3 64kbps 44.1kHz mono
MP3 32kbps 22.05kHz mono
Turn guidance on or off when recording
Guidance on
Guidance off
Select external audio input jack
Microphone mode
Line in mode
Auto gain control
Auto gain control on
Auto gain control off
PLAYBACK SETTINGS (DAISY and Text):
Shuffle and repeat settings
Standard play
Repeat title
Reading audio file name
Read audio file name
Read audio track number
PLAYBACK SETTINGS (Audio):
Shuffle and repeat settings
Standard play
Repeat track
Repeat album
Repeat entire albums
Shuffle repeat
Reading audio file name
Read audio file name
Read audio track number
BOOKMARK:
Playback setting for Voice Bookmark
Voice Bookmark on
Voice Bookmark off
Clear all bookmarks in current title
VOICE MEMO:
Delete the selected voice memo
Delete all voice memos
MEDIA MANAGEMENT:
Media title information
Delete SD card
Create a new title
Delete the selected title (album)
Prepare for editing
Build book
Network Folder
SYSTEM SETTINGS:
System properties
System version
Serial number
Installed key (if obtained.)
Select guide volume
Select the text to speech voice
Voice 1
Voice 2
Select the waiting sound
Waiting sound 1
Waiting sound 2
No waiting sound
Select the key press confirmation sound
Key press confirmation sound on
Key press confirmation sound off
Set the system date and time
Set the text to speech pitch
Network setting
Confirm Network setting
Load Network setting
Initialize all settings to default
