OPERATING MANUAL
Pliant Technologies, LLC
205 Technology Parkway
Auburn, Alabama 36830 USA
Phone [phone]
Toll-Free 1.844.475.4268 or 1.844.4PLIANT
Fax [phone] www.plianttechnologies.com
COPYRIGHT © 2023 Pliant Technologies, LLC. All rights reserved. Pliant®, MicroCom®, and the Pliant “P” are trademarks of Pliant
Technologies, LLC. All other trademarks are property of their respective owners.
Document Reference: D0000683_A

CONTENTS
Introduction .........................................................................................................................................1
What’s Included with MicroCom HS900XR?.....................................................................................2
Controls ................................................................................................................................................3
Display Indicators ................................................................................................................................3
Headset Setup .....................................................................................................................................4
System Setup.......................................................................................................................................5
Battery .................................................................................................................................................7
Operation .............................................................................................................................................8
Menu Settings .....................................................................................................................................9
Device Specifications..........................................................................................................................11
Product Care and Maintenance .........................................................................................................14
Product Support..................................................................................................................................14
License Information.............................................................................................................................15
Pliant Warranty Statement ................................................................................................................17

1 / 18
INTRODUCTION
We at Pliant Technologies want to thank you for purchasing MicroCom HS900XR Wireless Headset.
MicroCom HS900XR all-in-one style system is a robust, two-channel, full-duplex, multi-user,
wireless intercom system that operates in the 900MHz frequency band to provide superior range
and performance, all without the need for a basestation. The MicroCom HS900XR all-in-one design
wireless headsets combines the great sound quality and excellent range of MicroCom XR with
the comfortable t, exceptional noise isolation, and ip-up microphone muting technology of
the SmartBoom PRO headset, but without the wire. In addition, the IP54-rated headset is built to
endure the wear and tear of everyday use, as well as the extremes in outdoor environments.
In order to get the most out of your new MicroCom HS900XR Wireless Headset, please take a
few moments to read this manual completely so that you better understand the operation of this
product. This document applies to models PMC-HS900XRS, PMC-HS900XRD, PMC-HS900XRS-
AN*, and PMC-HS900XRD-AN*. For questions not addressed in this manual, feel free to contact the
Pliant Technologies Customer Support Department using the information on page 14.
* PMC-HS900XR-AN is approved for use in Australia and New Zealand and operates within the 915–928
MHz frequency range.
PRODUCT FEATURES
• Robust, Two-Channel System
• Three Operating Modes for Challenging Environments
• Dual Listen
• Simple to Operate
• Up to 10 Full-Duplex Users
• Radio-to-Radio Communication
• Unlimited Shared Users
• Unlimited Listen-Only Users
• 900MHz Frequency Band
• Encrypted FHSS Technology
• Ultra Compact, Small, and Lightweight
• Rugged, IP54-Rated Headset
• Long Battery Life (7-Hour for Single, 14-Hour for Dual)
• Field-Replaceable Battery
• Available Drop-In Charger
• Single Ear or Dual Headset Options

2 / 18
WHAT’S INCLUDED WITH MICROCOM HS900XR?
• Headset
• Li-Poly Battery (Installed during shipment)
Note: Dual headset has two batteries.
• USB Charging Cable
• Quick Start Guide
• Product Registration Card
OPTIONAL ACCESSORIES
Part Number Description
MicroCom Accessories
PAC-USB6-CHG MicroCom 6-Port USB Charger
PBT-HSXRC-66 MicroCom XR Headset 6+6 Drop-in Charger
PAC-MCXR-5CASE IP67-rated MicroCom Hard Carry Case
PAC-MC-SFTCASE MicroCom Soft Travel Case
BT-12-PT Replacement Li-Poly Battery
SBP-PAD-EAR Ear Pad for SmartBoom PRO Headsets
SBP-PAD-HEAD Headband Pad for SmartBoom PRO Headsets
SBP-WS-10PK Microphone Windscreen-10 Pack for SmartBoom PRO Headsets
SBP-ES-10PK Ear Cushion Cover-10 Pack for SmartBoom PRO Headsets
PMC-REC-900 MicroCom XR Receiver

3 / 18
CONTROLS
DISPLAY INDICATORS
LEDs
Power Button
Talk Button
Channel Button
USB Charger
Connection
Volume +/– Buttons
Mode Button
OLED Screen
Drop-In Charger
Connection/
Battery Access
PT Button
Master Pack Indicator
R Button
(No current function)
Master Pack Indicator
Battery Status
Mode Indicator
Talk Indicator
Lock Indicator
Signal Indicator
User Role
Active Channel
Volume Level
Dual Listen Indicator

4 / 18
HEADSET SETUP
1. Headset Adjustment: Use the slide adjustment on each side of the headband to achieve
proper t and size.
2. Mic Position: For best performance, it is recommended the microphone be positioned directly
in front of your mouth, sitting a nger’s width from your lips.
3. SmartBoom Mic Mute: During operation, swiveling the boom
up above the brow at approximately 45 degrees will mute the
microphone. To activate the microphone again, simply lower
the boom back down.
Note: To adjust the boom, swivel it so that the microphone is on the
preferred side (right or left).
Figure 1: Adjusting Headset Sizing
Figure 2: Correct Mic Position Figure 3: Incorrect Mic Position
Figure 4: SmartBoom Mute On/Off

5 / 18
SYSTEM SETUP
1. Power on. Press and hold the POWER button for two (2) seconds until the screen turns on.
2. Access the menu. Press and hold the MODE button for three (3) seconds until the screen
changes to <SETTING MODE>. Short-press MODE to scroll through the settings, and then scroll
through setting options using VOLUME +/−. Press and hold MODE to save your selections and
exit the menu.
a. Select a group. Select a group number from 00–51 (or 00-24 for PMC-HS900XR-AN model).
Important: Devices must have the same group number to communicate.
IF OPERATING THE HEADSET IN REPEATER MODE*
b. Select an ID. Select a unique ID number.
• Repeater Mode ID options: M (Master), 01–08 (Full Duplex), S (Shared), L (Listen).
• One device (all-in-one headset or beltpack) must always use the “M” ID and serve as
the Master for proper system function. An “M” indicator designates the Master on its
screen.
• Listen-only headsets must use the “L” ID. You may duplicate ID “L” on multiple devices in a
system.
• Shared headsets must use the “S” ID. You may duplicate ID “S” on multiple devices, but
only one shared device may talk at a time.
• When using “S” IDs, the last full-duplex ID (“08”) cannot be used in the Repeater Mode.
c. Confirm headset’s security code. Devices must use the same security code to work
together as a system.
*Repeater Mode is the default setting. See page 10 for information about changing mode.
IF OPERATING THE HEADSET IN ROAM MODE
b. Select an ID. Select a unique ID number.
• Roam Mode ID options: M (Master), SM (Submaster), 02-09, S (Shared), L (Listen).
• One device must always be “M” ID and serve as the Master, and one device must always
be set to “SM” and serve as the Submaster for proper system function.
• The Master and Submaster must be located in positions where they always have an
unobstructed line of sight to each other.
• Listen-only headsets must use the “L” ID. You may duplicate ID “L” on multiple devices.
• Shared headsets must use the “S” ID. You may duplicate ID “S” on multiple devices, but
only one shared device may talk at a time.
• When using “S” IDs, the last full-duplex ID (“09”) cannot be used in the Roam Mode.

6 / 18
c. Access the roaming menu. Select one of the roaming menu options listed below for each
headset.
• Auto – Allows the headset to automatically log in to the Master or Submaster depending
on the environment and the headset’s proximity to either.
• Manual – Allows the user to manually select whether the headset is logged in to the
Master or Submaster. Press the MODE button to select Master or Submaster.
• Master – When selected, the headset is locked into only logging into the Master.
• Submaster – When selected, the headset is locked into only logging into the Submaster.
d. Confirm headset’s security code. Devices must use the same security code to work
together as a system.
**When in Roam Mode, the two-way radio Top Button menu options and the Dual Listen function will
not be available. See page 10 for information about changing mode.
IF OPERATING THE HEADSET IN STANDARD MODE
b. Select an ID. Select a unique ID number.
• Standard Mode ID options: M (Master), 01–09 (Full Duplex), S (Shared), L (Listen).
• One device must always use the “M” ID and serve as the Master for proper system
function. An “M” indicator designates the Master on its screen.
• Listen-only headsets must use the “L” ID. You may duplicate ID “L” on multiple devices.
• Shared headsets must use the “S” ID. You may duplicate ID “S” on multiple devices, but
only one shared device may talk at a time.
• When using “S” IDs, the last full-duplex ID (“09”) cannot be used in the Standard Mode.
c. Confirm headset’s security code. Devices must use the same security code to work
together as a system.

7 / 18
BATTERY
CHANGING BATTERY
The batteries are housed within the earcups of the headset. To
remove, press the latch/button and pull the battery sled from
the earcup. Hold the headset upright for the battery sleds to
slide out easier.
CHARGING TIME
The rechargeable Lithium-poly battery is installed in the device. To recharge the battery, either
1) plug the USB charging cable into the device USB port or 2) connect the device to the drop-in
charger (PBT-HSXRC-66 sold separately). The charging LED in the right top corner of the device will
illuminate solid red while the battery is charging and will turn off once the battery is fully charged.
The battery charge time for the single headset model is approximately 4 hours from empty
(USB port connection or drop-in charger). The battery charge time for the dual headset model is
approximately 6 hours from empty (USB port connection or drop-in charger). The battery charge
time for a single battery is approximately 4 hours from empty (drop-in charger).

8 / 18
OPERATION
• LED Modes - LED is blue and double blinks when logged in and
single blinks when logged out. LED is red when battery charging is
in progress. LED turns off when charging is complete.
• Lock - To toggle between Lock and Unlock, press and hold the
TALK and MODE buttons simultaneously for three (3) seconds. A
lock icon appears on the OLED when locked. This function locks
the TALK and MODE buttons, but it does not lock headset volume
control, the POWER button, or the PT button.
• Volume Up and Down - Use the +and −buttons to control the
headset volume. “Volume” and a stair-step indicator display the
headset’s current volume setting on the OLED. You will hear a
beep in your headset when the volume is changed. You will hear a
different, higher-pitched beep when maximum volume is reached.
• Talk - Use the TALK button to enable or disable talk for the device.
“TALK” appears on the OLED when enabled.
»Latch talking is enabled/disabled with a single, short press of the
button.
»Momentary talking is enabled by pressing and holding the button
for two (2) seconds or longer; talk will remain on until the button
is released.
»Shared users (“S” ID) can enable talk for their device with the
momentary talking function (press and hold while talking). Only
one Shared user can talk at a time.
• Mode - Short-press the MODE button to toggle between the
channels enabled on the headset. Long-press the MODE button to
access the menu.
• Dual Listen - When Dual Listen is on, users will be able to hear
both Channel A and B while talking only on the currently selected
channel.
• Out of Range Tones - The user will hear three quick tones when
the headset logs out of the system, and they will hear two quick
tones when it logs in.
OPERATING MULTIPLE MICROCOM SYSTEMS IN ONE LOCATION
Each separate MicroCom system should use the same Group and Security Code for all devices in
that system. Pliant recommends that systems operating in proximity to one another set their Groups
to be at least ten (10) values apart. For example, if one system is using Group 03, another system
nearby should use Group 13.
Figure 6: Lock Indicator
Figure 7: Volume Setting
Figure 8: Talk Indicator
Figure 9: Channel Indicator
Figure 10: Dual Listen Indicator
