PLT PLTS-11953 User manual

Rev: A0
Rotatable Wallpack
LED Luminaire Instruction
Warning：
1. Do not use an electric generator to test this fixture;
2. This luminaire must be installed in accordance with your local electrical codes and requirements;
3. Do not install the luminaire on rainy days, to avoid lightning strike and damage to luminaire.
Installation notice：
1. This luminaire must be installed by a qualified electrician to avoid electric shock and fire accident;
2. Wear gloves before installation in order to avoid injury;
3. Turn off the power immediately when there is smoke and fire during installation, ensure electrical
professionals make necessary corrections;
4. This luminaire is suitable for outdoor use.
Step 1：Use a screwdriver to loosen the screws connecting the lamp base so as to remove the lamp
base cover（Figure 1 & Figure 2）;
Installation :
Figure 1 Figure 2
Standard wire:
L/live wire：Black\Brown；
N/null wire:White\Blue；
Ground wire：Green\Yellow-green.
Note: To meet the requirements of DLC certification, lamps are limited to the same side of the
light-emitting use (see Figure 1), not in different directions of irradiation use (see Figure 2/3).
Warning/Advertisement：
SUITABLE FOR WET LOCATIONS
CAUTION – RISK OF SHOCK
DISCONNECT POWER BEFORE SERVICING
CAUTION – RISK OF FIRE
MIN 75 °C SUPPLY CONDUCTORS
SUITABLE FOR OPERATION IN AMBIENT NOT EXCEEDING 113°F
CONVIENT AUX EMPLACEMENTS MOUILLÉS
ATTENTION – RISQUE DE CHOC
COUPER L’ALIMENTATION AVANT L’ENTRETIEN
ATTENTION – RISQUE D’INCENDIE
LES FILS D’ALIMENTATION 75 °C MIN
PEUT ÊTRE UTILISÉ À UNE TEMPÉRATURE AMBIANTE N’EXCÉDANT PAS 45 °C
Any further questions or interests, please visit Any further questions or interests, please visit
InstallationInstruction InstallationInstruction

Step 3：Drill holes on the wall according to the
locating plate（Figure 5）;
Step 2：Drill installation holes at the bottom of light, apply the EVA mat（Figure 3 & Figure 4）;
Figure 3 Figure 4
Step 5：Align the holes on the lamp base with the holes on the wall, and tighten the screws (Figure 7）;
Figure 7
Figure 5
Step 4：Fix rubber plugs into holes
（Figure 6）;
Figure 6
Step 7：Aligh the fixture and tighten the screws of the lamp base（Figure 10 & Figure 11）.
NOTE：Lamp color temperature and power can be adjusted as needed before locking the back cover.
Step 6：Buckle the rotating shaft of the lamp base from the back of the cover and connect the wires
properly（Figure 8 & Figure 9）;
Figure 8
Figure 11
Figure 9
Figure 10
