PMT EVO 2.0 EW User manual

EVO 2.0 EW
ASSEMBLY INSTRUCTIONS
ONLY FIVE STEPS
TO THE COMPLETE SYSTEM

2PMT EVO 2.0 EW
General Safety Instructions
• For all information regarding ballasting,
dimensions of the module area and the roof
area, the current project report must be used!
• It is possible to build over a pitch change
at the peak of the roof up to a roof pitch of
1.5° without additional components. The
prerequisite for this is that the transition from
base to connecting floor profile runs exactly
above the peak and can act as a “joint”.
• Peaks with a pitch >1.5° must be built over
using ridge connectors or be left free. Low
points must not be built over. Otherwise the
roof cladding may be damaged. In the event
of noncompliance, PMT reserves the right to
exclude liability.
• Before installation, the compatibility of the
system with the roof must be determined.
• Systems may only be installed and
commissioned by persons who, due to their
professional qualification (e.g. training or
activity) or experience, can guarantee that
they are carried out in accordance with the
regulations.
• Before installation, verify whether the product
meets the static requirements applicable on
site. For roof systems, also check the load-
bearing capacity of the roof. National and
local building regulations, standards, and
environmental protection regulations must be
complied with.
• For roof pitches greater than 1°, it is strongly
recommend that the system be connected to the
roof structure in order to prevent a “caterpillar
effect” caused by thermal linear expansion. For
roof pitches of 5° and above, it is imperative
that the system must be structurally fixed to the
roof.
• Occupational safety and accident prevention
regulations, corresponding standards, and
trade association regulations must be complied
with.
• The module manufacturers' assembly
instructions must be complied with.
• In the event of non-compliance with our general
safety instructions or assembly instructions
or not using all system components, including
installation and upgrading using components
that have not been supplied by us, we accept no
liability for resulting defects and damages and
warranty is rendered void in this instance.
Please not that our general safety instructions
must be complied with.

3PMT EVO 2.0 EW
Components
AEdge profile
BMain profile
CBase
DMain profile connector
FCross and ballast strut,
Screw M8 x 30
ETower
GCross strut conector
HBallast stone
IMiddle and end clamp

4PMT EVO 2.0 EW
Required Tools
1Tape measure 2Chalk line
4Distance gauge3Torque wrench with attachment
SW 5 mm allen key socket

5PMT EVO 2.0 EW
1
CLICK!
A
B
C
D
Lay out and connect main profiles
A, B, Dand Base C
Attention!
Check the latching connection for proper
fitting.
PMT-Tip
Set up the rows of main profiles with the spacing
specified in the planning documents. Use the
supplied spacing gauge between the insides of
the main profiles.
Adjustment: Module length – 95 mm

6PMT EVO 2.0 EW
2
Place and mount Tower E
E
2.1 2.2
CORRECT!
CLICK!
CLICK!
INCORRECT!

7PMT EVO 2.0 EW
3
3.1 3.2
G
F F
F
M8x30
10 Nm
Minimum
15 mm
F
Secure cross and ballast strut F
to cross strut connector G

8PMT EVO 2.0 EW
1 Ballast stone
Place 1 ballast stone in the middle of the-
main profile, push it to the base and secure
it using the end clamp.
2 Ballast stones
Place 2 ballast stones in the middle
of the main profile and use the
middle clamp to secure them.
4
Position ballast stone H
3 – 4 Ballast stones
Secure ballast stones 1+2 as described using
middle clamps. Put on ballast stones 3+4 and
push them towards the tower.
Maximum 135 kg
per ballast strut arrangement.
Always refer to the relevant project
report for the number, positions and
weights of the ballast stones required.
H
F
Ballast stones
on the double cross struts: Mount cross
- and ballast struts as described in Step
3 on both tower sides. Place the stones
evenly distributed on the the braces.

9PMT EVO 2.0 EW
5
Mount middle and end clamps Iand
screw on the modules
INCORRECT!
Assembly on the Tower
CORRECT!
Assembly on the Base
Middle clamp I
Minimum
20 mm
10 Nm
CLICK!
End clamp I
10 Nm
DONE!
CORRECT!
INCORRECT!
