PNI SafeHome PT720MW User manual

PNI SafeHome PT720MW
Smart video door phone / Интелигентен видеодомофон / Intelligente
Video-Türsprechanlage / Videoportero inteligente / Interphone vidéo
intelligent /Okos videó kaputelefon / Videocitofono intelligente / Slimme
videodeurtelefoon / Inteligentny wideodomofon / Interfon video inteligent
EN User manual ......................................................... 3
BG Ръководство за употреба ............................. 20
DE Benutzerhandbuch .............................................. 37
ES Manual de usuario ............................................... 54
FR Manuel utilisateur ............................................... 71
HU Használati utasítás .............................................. 88
IT Manuale utente .................................................. 105
NL Handleiding ........................................................ 122
PL Instrukcja obsługi ............................................... 139
RO Manual de utilizare ............................................. 155

3User manual
English
Tuya Smart APP
Download the application Tuya Smart by accessing Google Play or the App Store
or scan the QR codes below:
Android iOS
Add device in Tuya Smart application
1. Open the application, create an account and log in.
2. Add your device by pressing the +icon in the upper right corner of the screen
or by pressing the Add device (this button appears when you do not have any
devices added to the application).
3. Select the option Video surveillance on the left side of the screen.
4. From the list of devices on the right side of the screen, select Smart Doorbell
5. In the next interface, select the option Ap Mode from the upper right corner.
6. Then tick Make sure the indicator is flashing quickly or a prompt tone is heard.
Click Next.
7. Select the WiFi network you want to connect to and add the password.
8. Enter the door phone settings menu in System - Network settings - WiFi
settings and select AP Mode. The door phone will close and restart.

User manual 4
English
Note: to access the door phone settings menu, press the wheel on the upper right side of
the door phone . Move the wheel up and down to navigate the menu.
9. Enter the WiFi settings of the phone and connect to the network SmartLife-
Doorbell.
10. Return to the application. The app will start scanning the devices.
11. Once your device was identified, you will receive the confirmation Added
Successfully.
12. To finish, click the Done button.

5User manual
English

User manual 6
English
Device control from the application
Options:
1. Image capture: takes an image and saves it in the phone’s memory
2. Intercom: press to talk to the person in front of the door
3. Recording: press to record video. The recording will be saved in the phone
memory.
4. Unlock the lock 1
5. Channel change
6. Unlock the lock 2
7. View files saved on the SD card inserted in the door phone
8. View photos and videos saved in the phone memory

7User manual
English
Indoor unit description
1. Power LED
2. Led door 1
3. Led door 2
4. TFT screen
5. Touch buttons
6. Microphone
7. Loudspeaker
8. Settings menu button
9. Micro SD card slot
10. Volume +
11. Volume -

User manual 8
English
Symbols description
Access the menu
Confirmation
Up/Down
In the standby mode, press this button to
enter the settings menu.
Once you access the menu, push this button
up or down to navigate the menu.
Press this button to enter a specific menu
item and confirm a setting.
In Intercom mode, press this button to stop/
restart recording. If you are in capture mode,
press this button to capture an image.
While playing audio, video or photo files, press
this button to Stop or Play.
In playback mode, long press this button to
adjust the volume. The volume bar will appear
on the screen.
Volume +/Volume - Turn this knob up and down to adjust the
volume of the indoor unit.
Call transfer
Internal call
Image settings
Refresh
In the standby mode, press and hold to make
an internal call.
During an external call, press to transfer the
call.
In Intercom mode, press to make the following
settings: brightness, contrast, saturation,
volume (adjust the sound from the external
unit).
Refresh: when connecting to the indoor unit
PAL/NTSC CCTV cameras or the included
outdoor camera and a CVBS/AHD CCTV
camera or only the included outdoor camera
and no image appears on the monitor, press
the “R” symbol on the screen.
Monitor Select the video source.
Talk Click to talk to the visitor

9User manual
English
Unlock Click to allow visitor access, unlocking the
lock.
Hang up
Back
Exit
Click to end the conversation with the visitor.
Back to the previous page (when you are in
the settings menu).
Exit the settings menu, return to standby
mode.

User manual 10
English
Connection diagram 1
Power adapter AC/DC
for camera not included
Power adapter AC/DC
for camera not included
)External power source
(AC100V-240V)--optional
)
Power adapter AC/DC
(not included)
Power adapter
Lock (not included)
(not included)
AC/DC
included)
Lock(not
DOOR1 DOOR2

11 User manual
English
Note:
The system supports the connection of a Normal Open (NO) electromagnetic lock. This
means that in standby mode, the relay is open and the lock is closed. When the Unlock
button on the internal unit is pressed, the relay closes and the lock opens.
Power the indoor unit with the power adapter included in the package.
Connection diagram 2
4C4C 4C
4C
4C
4C
4C
CAM1
Alarm
Alarm
CAM2
Cable connections recommendations
For connections, use the below cable types:
1. Standard insulated and uninsulated type cable 4C.
Distance ≤28 m (4x0.2mm2)
Distance ≤50 m (4x0.3mm2)
Distance ≤80 m (4x0.5mm2)
2. Standard uninsulated cable type 3C + video cable (75-3)
Distance ≤100 m

User manual 12
English
3. Uninsulated CAT5 network cable (not recommended)
Distance ≤50 m
Video door phone usage
1. The visitor presses the call key on the outdoor unit of the door phone.
2. The ringtone will be heard on both the indoor and outdoor units. The default
maximum call duration is 30 seconds.
3. Immediately, the visitor’s image appears on the indoor unit screen (image taken
by the camera on the outdoor unit).
4. To talk to the visitor, press the key Talk . The ringtone is interrupted. The
maximum talk time is 120 seconds.
Note: If no one answers the call, the visitor will hear the message Please leave a message
and will have a maximum of 60 seconds to leave a message.
5. If you want to allow the visitor access, press the key Unlock . The lock will
unlock.
6. Press the key Hang up to end the conversation.
Note: After pressing Hang up key, both the voice and the image of the visitor will
be heard for another 20 seconds. This feature allows the host to ensure that the visitor
has entered on site.
If you have inserted a micro SD card into the indoor unit, the whole process will be
recorded on the card or images will be captured (depending on the settings made).
Access the menu Mode - Record mode and select Video or Snapshot.

13 User manual
English
Notes:
During a conversation, you will not be able to press the button Monitor to change
the video source.
During a conversation, if a call comes in from another connected camera, the indoor unit
will emit a “du .. du .. du ..” warning sound.
Video source
Press the key Monitor to change the video source:
DOOR1 - will display the image taken by the camera connected to the input
DOOR1
CAM1 - will display the image taken by the camera connected to the input CAM1
DOOR2 - will display the image taken by the camera connected to the input
DOOR2
CAM2 - will display the image taken by the camera connected to the input
CAM2
STANDBY - the date and time will be displayed on the screen for a few seconds,
after which the monitor will turn o.
Note: If you have connected only one camera, you can deactivate the other outputs in
the setup menu.
Call transfer
This function requires at least two indoor units and one outdoor unit, connected to
each other.
1. The visitor presses the call button on the external unit.
2. The image taken by the camera immediately appears on the monitor.
3. Long press the button Transfer call until the icons below appear on the
screen:
2 3 4 5 6

User manual 14
English
4. Rotate the wheel up and down until you reach the indoor unit to which you
want to transfer the call. Press the button to confirm the transfer.
5. The selected indoor unit will get the call.
6. Press Talk key to talk with the visitor, Unlock to open the door and Hang up to
end the conversation.
Internal call
In standby mode, press and hold the button Transfer call until the icons below
appear on the screen:
2 3 4 5 6
1. Rotate the wheel up and down until you reach the indoor unit to which you
want to communicate with. Press the button to confirm the call.
2. The selected indoor unit will ring.
3. Press Talk to talk and Hang up to end the conversation.
Settings menu
In standby mode, either the date and time or the photos saved on the micro SD card
can appear on the indoor unit screen (the mode Photo frame must be activated; for
this access the menu System).
Important:
Specialized folders must be created on the SD card:
• “ring” - where the audio files will be saved and where the ringtone will be
downloaded from
• “user” - where photos will be saved and where photos will be taken from for
standby mode
• “music“ - where the audio (music) files will be saved
• “update“ - where the firmware update file will be saved

15 User manual
English
10:50
Monday
07-08-2017
Standby mode with date and time Standby mode with picture
If the user does not perform any operation for 60 seconds, the monitor will return
to standby mode for another 60 seconds after which it will turn o.
1. In standby mode, press to access the menu.
2. Rotate the wheel up and down to navigate the menu.
3. Press the wheel to enter the selected sub-menu options.
4. Press the button to exit the menu.
1. System
Select the menu System. It includes Language, Time, System info, Ringtone,
Volume and Network settings.
Language - select the menu display language: English, Russian, German, Polish.
Time - select date and time.
System info - displays firmware version, processor model, micro SD card space

User manual 16
English
(system supports up to 32GB), ID and MAC.
Ringtone - select the ring bell for the indoor unit Door1 and Door2:
Default or Custom (select one of the songs saved on the micro SD card).
Note: Save the audio files in the “ring” folder on the micro SD card. Name the files:
ring_1 .. ring_12.
Volume - you can set the ring duration and ring volume intensity in three dierent
time periods.
Network settings - access this sub-menu when you want to pair the intercom with
the Tuya Smart application.
2. Photo frame
Access this menu to activate the standby mode with picture.
Note:
Photos must be saved in the “user” folder on the micro SD card.
If you have the Photo frame function activated, the Motion detection function will not
work.
3. Mode
Options:
Set machine ID - from 01 ltoa 06. 01 is the Master indoor unit. 02 - 06 are the
Slave indoor units.
Door 2 status - enable or disable the output on Door 2.
Door 1 unlock time - between 02 - 10 seconds. Set how long the lock will stay open.
Door 2 unlock time - between 02 - 10 seconds. Set how long the lock will stay open.
Record mode - set the recording mode: video or snapshot.
Motion detection - Options: Closed, Door 2, Door 1, Camera 2, Camera 1. You
can activate the motion detection function on a single channel. When motion is

17 User manual
English
detected, the system will start video recording or will capture images (depending on
the setting from the previous option, Record mode.)
Message - enable/disable messages.
4. Alarm
• Alarm record
Options:
Video (when motion is detected, the system will start the video recording which will
be saved on the micro SD card).
Snapshot (when motion is detected, the system will capture images that will be
saved to the micro SD card).
• Sensor type 1 - Options: NO (Normal open) and NC (Normal Close)
• Cam 1 - enable/disable output Cam 1.
• Cam 1 ring time - between 02 - 20 seconds
• Sensor type 2 - Options: NO (Normal open) and NC (Normal Close)
• Cam 2 - enable/disable output Cam 2
• Cam 2 ring time - between 02 - 20 seconds
5. Media
Access this menu to play audio (music) and image (photos) files on the micro SD
card.
Note: save the audio files in the “music” folder on the micro SD card, and the image files

User manual 18
English
in the “user” folder.
6. Record center
• Video info - includes video recordings from the external unit.
• Photo info - includes images captured by the external unit.

19 User manual
English
Technical specifications
System Supports 6 indoor units + 2 outdoor units +
2 CCTV cameras
Input video signal CVBS, CVI, TVI, AHD2.0
Monitor 7 inch
Monitor resolution 1024 x 600 px
Camera resolution 800TVL
IR LEDs 3 pcs.
IR distance up to 1.5 m
View angle 95°
Recorder video file extension .avi
Waterproof class IP65
WiFi frequency 2.4GHz
WiFi transmission power 100mW
Motion detection Yes
Call mode Intercom/Duplex
Maximum capacity of micro SD
card 32GB, Classe 10
Power supply 230V (with the power adapter included)
12V (external power source)
Current max. 300mA
Working temperature -26°C ~ +80°C

Ръководство за употреба
Български
20
Tuya Smart APP
Изтеглете приложението Tuya Smart, като влезете в Google Play или App
Store или сканирайте QR кодовете по -долу:
Android iOS
Добавете устройство в приложението Tuya Smart
1. Отворете приложението, създайте акаунт и влезте.
2. Добавете вашето устройство, като натиснете иконата + в горния десен
ъгъл на екрана или като натиснете Add device (този бутон се появява,
когато нямате добавени устройства към приложението).
3. Изберете опцията Video surveillance от лявата страна на екрана.
4. От списъка с устройства в дясната страна на екрана изберете Smart
Doorbell
5. В следващия интерфейс изберете опцията Ap Mode от горния десен
ъгъл.
6. След това поставете отметка Make sure the indicator is ashing quickly
or a prompt tone is heard. Щракнете Next.
7. Изберете WiFi мрежата, към която искате да се свържете, и добавете
паролата.
8. Влезте в менюто за настройки на домофона в System - Network sengs
