PNI House 910 WiFi User manual

PNI House 910 WiFi
Smart video door phone/Умен видеодомофон/Intelligente Video-
Türsprechanlage/Videoportero inteligente/ Interphone vidéo
intelligent/Okos videó kaputelefon/ Videocitofono intelligente/
Slimme videodeurtelefoon/Inteligentny wideodomofon
Interfon video inteligent
cu releu comanda yala electromagnetica

EN User manual ......................................................... 3
BG Ръководство за употреба ............................. 19
DE Benutzerhandbuch .............................................. 36
ES Manual de usuario ............................................... 54
FR Manuel utilisateur ............................................... 69
HU Használati utasítás .............................................. 87
IT Manuale utente .................................................. 103
NL Handleiding ........................................................ 119
PL Instrukcja obsługi ............................................... 135
RO Manual de utilizare ............................................. 151

User manual - 3
Safety warnings
»The installation and any intervention on the door phone-
doorbell system must be performed by authorized personnel
»Do not use any voltage other than that recommended by
the manufacturer to power the intercom and doorbell
»The door phone terminals must be protected from water or
any other liquid
»Do not short-circuit the electrical components of the video
door phone components
»The batteries, optionally connected to the intercom, must
be replaced if faulty or discharged.
Main features
»Video door phone WiFi 2.4GHz
»The door phone can be powered by the included 230V -
12V 2A power supply, with 18650 batteries (not included)
or by a micro USB - USB cable
»Water resistance class IP44
»Viewing angle 110°
»Possibility of recording on micro SD card (not included)
»PIR motion detection function
»Possibility to adjust motion sensitivity (3 levels)

4 - User manual
»Tamper alarm function
»Wireless connection with the doorbell
Installation
1. Fix the door phone’s bracket with 3 screws , 1.4-1.6 meters
from the ground.
2.Connect the door phone to the power supply and to the
electric lock according to the connection diagram below
3.Fix the door phone into the wall bracket and tighten the
screw at the bottom
Notes:
Make sure that the PIR sensor is not under the action of the
sun’s rays

User manual - 5
Do not install the door phone in areas with frequent trac
Make sure you install the intercom close enough to the router,
otherwise the video quality may be aected.
Connection diagram
Connect the power supply to the door phone.
The configuration illustrated below allows the connection of an
electric lock without connecting any additional power supply.
DC12V AC100-240V
50Hz/60Hz
DC power supply
for electric lock
Output: 12V / ≤1A

6 - User manual
Note: If you power supply the door phone with batteries, the
output for the electric lock will not work, as the batteries do not
provide the necessary voltage.
The door phone
Light sensor
(LDR)
PIR
Video camera
Call button
Microphone
LED lights

User manual - 7
Power supply connector
Micro USB port
Micro SD card slot
Electric lock connector
Tamper button
Batteries compartment
RESET
LED indicator
»Red and green lights alternate - batteries are charging
»The red light flashes - the door phone is waiting for network
configuration
»The green light flashes often - network configuration in
progress
»Stable green light - the door phone is in normal operation
condition

8 - User manual
»Yellow light (red and green light at the same time) - the
door phone is powered from an external power source or
batteries fully charged or no batteries. Note: If no batteries
have been installed, the light will be yellow
»The LED is o - the door phone is in standby mode (low
power consumption)
The doorbell
Speaker
Melody
Operation mode
Volume control
selection
(38 melodies)
(4 levels)

User manual - 9
Usage instructions
Press the button to select the working mode. Three
options are available:
1. Without sound, the LED flashes
2. Sound only, no LED
3. Sound and LED
LED indicator
»When the doorbell is in normal operation condition, the red
LED flashes.
»When the battery voltage is lower than 3.3V, the red LED
remains constantly lit.
Pairing
1. Insert 3 AA batteries into the doorbell.
2. Press for 3 seconds the button
The doorbell will ring Ding-Dong to indicate the pairing status
3. Press the call button on the door phone.
4. The selected song will sound in the doorbell and the
indicator LED will flash.
5. Pairing ended successfully.

10 - User manual
Delete pairing
Press the key for 5 seconds on the doorbell. You will
hear a Ding-Dong, Ding-Dong sound. Now the two units are
no longer paired.
Download the mobile app
Download the Tuya Smart app by accessing Google Play or
the App Store or scan the QR codes below:
