Pocons SH-100 User manual

SH-100 Stereo Bluetooth Headset Speaker Specification
Basic Specifications
■Size: 31×28×9mm
■Weight: 17.2g（Net Weight）
■Charging port: Micro USB
■Keys: 5 (MFB button, volume+ button, volume- button, backward button, forward
button)
■Battery: Rechargeable lithium polymer battery 3.7V; 120mAh
■Charger output: 5V/0.5~1.0A
■Charge indicator: Red LED light (Charging) / Blue LED light (Charging completed)
■Standby time: about 200 hours
■Talk time: about 8 hours
■Music time: about 6 hours
■Charging time: about 2 hours
■Indicator for charge in working stage: Battery voltage lower than 3.3V（the stage of
battery lower than 15%)，there will be a warning tone; battery voltage lower than 3.1V
( the stage of battery lower than 5%), the headset will power off directly.
Speaker and MIC parameters
■Speaker specifications / mode: Φ9mm
■Impedance: 32Ω/ typ
■Frequency(Hz): 20Hz～20KHz
■MIC Style: capacitive
Bluetooth Parameters
■ Bluetooth version: 4.0
■ Support Profile: HSP, HFP, A2DP, AVRCP
■ The remote control to speaker: MFB (Power ON / Power Off / Play / Pause); Vol+, Vol-,
Previous song, Next song.
■ Device Name: SH-100
■ Pass: 0000
■ RF transmitter: class II (-6dBm ~ +4 dBm)
■ Transmission Range (Hz): 2.402GHz ~ 2.480GHz

■ Transmission distance: 10m
Mechanical Reliability
■ Button: 10 thousand times
■ Charging Port（Micro USB）: plug 5000 times
■ LED: luminance/light-leaking luminosity must remain the same
Operating Instructions
Power On
When the headset is off, press and hold the multi-function Button (MFB) for 2 seconds. The
LED indicator will flash for one second in blue. At this time you will hear the words “Power
ON” from the headset. The headset will be paired with the last connected Bluetooth device
or mobile phone automatically when turned on.
Power Off
When the headset is on, press and hold the MFB for 3 seconds. The LED indicator will flash
once slowly in red. At this time, you will hear the words “Power Off” from the headset. The
headset will disconnect from your phone devices when turned off.
Pairing Mode
When the headset is off, press and hold MFB for 5 seconds until the LED indicator f
lashes red and blue in alternating colors. At this time, you will hear the words “Pairin
g” from the headset.
※If you release the MFB before the headset goes into pairing mode, it will power on and
connect with the last paired device. If you want to pair the headset with a new phone device,
please power off the headset. or press the vol+ and vol- button concurrently to go into
pairing mode again.
Easy connection function
If the headset doesn’t connect with any phones when it is on, you can enter into speed
pairing mode by pressing the vol+ and vol- button concurrently and connect with your
phone.

Answering calls
If a call comes in when listening to music or headset is standing by, press the MFB to
answer the incoming call. You will hear the words “Call Answered”form the speaker of the
headset. If the music is playing, it will pause automatically during the call, the music will start
playing automatically.
Reject Calls
If a call comes in, press and hold the MFB button for 2 seconds to reject the incoming call.
You will hear the words “Call Rejected”from the speaker of the headset.
End Calls
Press the MFB to terminate when you finished your call, you will hear the words “Call
Terminates”.
Volume
To adjust the volume when talking on the phone, press the vol+ and vol- to make volume do
up and down. When you reach the max/min volume, you will hear a warning tone.
Last Number Redial
When listening to music or headset is standing by, double click MFB to redial the last
number. You will hear the words “Last Number Redial”from the speaker of the headset. If
you are listening to music, it will pause automatically during the call.
Mute
When talking on the phone, press and hold vol+ or vol- for 2 seconds to mute your phone.
You will hear the caller, but the caller will not hear you. There will be a warning tone every 10
seconds, reminding you that you are in mute mode.
Quit Mute
Press and hold vol+ or vol- for 2 seconds to exit mute mode.
Switching Between Your Mobile Phone and Headset

When talking on the phone, double-click the MFB to switch the voice from your headset to
your mobile phone. By double-click the MFB again, the voice will switch back to the headset.
You will hear the reminding tone.
Reconnect
When the headset is disconnected from your mobile phone, you will hear the words “Your
headset is disconnected”. If you press the MFB, it will reconnect. You will hear the words
“Your headset is connected”from the headset.
※Some mobile phone may have a prompt screen, that will ask you if you would like to pair
your device.
Voice-Command Dial
If your mobile phone supports this function, press and hold vol+ or vol- for 2 seconds to
activate voice command. You will hear “voice dial”from the headset. By re-pressing and
re-holding vol+ or vol- for 2 seconds during the voice dial mode, voice dial will be canceled.
※Please refer to the manual of your mobile phone for voice-command dial support.
Connect with 2 mobile phones
A. First disconnect the Bluetooth device from your phone if it is already connected.
B. Press vol+ and vol- concurrently to put the headset in pairing mode.
C. Turn on and search Bluetooth device on your second phone until you find “SH03B”and
select to begin pairing.
D. Please reconnect with your first mobile phone device.
E. Now you should have two mobile phones connected with the headset.
Transfer Calls
When you are talking on the phone and receive another incoming call, press the MFB for 2
seconds to reject the incoming call. If you click vol+ and vol- concurrently(with the reminding
tone), you will answer the incoming call. Your first call will be placed on hold. When you click
vol+ and vol- concurrently again, you will transfer back to your first call. You should hear a
beep. During this time your second call will be placed on hold. You can also end the call by
clicking the MFB.
Music Play Operating
Music Play

Operate on the phone or Click MFB of the headset. (Music will play automatically on
some mobile phones when it connect with Bluetooth device)
Pause and Restart Music
When listening to music, click MFB to pause music and click MFB again to restart music.
Volume
To adjust the volume when listen music, press the V+ or V- to adjust the volume up or down.
When you reach the max/min volume, you will hear a warning tone.
Play Previous Song
Press backward button.
Play Next Song
Press forward button.
Fast forward
Long press forward button.
Fast backward
Long press backward button.

LED Indicator Status
Notes:
It will turn off automatically after 5 minutes if without any connection with mobile phone
when it turns on.
Pairing time: 3 minutes. It will quit the pairing mode automatically after 3 minutes if
without any connection with mobile phone when it is in the state of pairing.
In addition, it can show the battery state on Apple devices.
Charging
Red LED Light
Charging Complete
Blue LED light
Power ON
Blue LED light flashes for one second
Power Off
Red LED light flashes once slowly
Pairing Mode
LED light flashes in red and blue alternately
Power On (Not Connected)
Blue LED light flashes once every 2 seconds
Power On (Connected)
Blue LED light flashes twice every 2 seconds
Power On (Talking)
Blue LED light flashes twice every 3 seconds
Power On (Dial Call)
Blue LED light flashes continuously
Power On (Incoming Call)
Blue LED light flashes continuously
Power On (Play Music)
Blue LED light flashes twice every 3 seconds
Battery Low
Red LED light flashes once every 20 seconds with reminding
tone “battery low”

FCC Warning:
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
