PODOBLOCK OPU ProbeHolder Operator's manual

INNOVATIVE VETERINARY SOLUTIONS
PODOBLOCK
™
User Instruction Manual
OPU ProbeHolder
www.podoblock.com

OPU ProbeHolder
After sales correspondence
All correspondence relating to the after sales service of Podoblock B.V.
to be addressed to:
NL Customers
Podoblock B.V.
Verlengde Nijverheidsweg 10
9482 WT Tynaarlo
The Netherlands
Tel: [phone]
Fax: [phone]
Overseas Customers
Contact your local distributor. In case of doubt please contact
Podoblock B.V.
For further information visit www.podoblock.com
Trade marks
Podoblock ™ is a trademark of Podoblock B.V.
INNOVATIVE VETERINARY SOLUTIONS
PODOBLOCK
™
1

Please read this preliminary information carefully and note ALL of the warnings,
cautions and safety notes contained within these instructions for use before using
the OPU ProbeHolder. Keep these Instructions For Use (IFU) close at hand at all times
for reference.
The ProbeHolder must only be used as detailed within this “handbook”.
Failure to do so could result in injury to patients or users, or (also) damage to the
equipment. Podoblock does not take any responsibility for improper handling of the
OPU ProbeHolder.
Warning !
The instruction for use should always be readily accessible for reference and be
referred to for details of the OPU ProbeHolder.
Sections marked with the symbol provide guidance to possible actions that
could lead to injury of the patient or user, or damage to the ProbeHolder.
Ensure all warnings in the handbook are strictly complied with.
Section 3 Operation provides information detailing how to use the
ProbeHolder.
The OPU ProbeHolder is compatible with most Ultrasound source.
Never use the OPU ProbeHolder without first carefully reading this manual.
Correct handling may prevent damage to the product or harm the user.
Misuse, abuse of the OPU ProbeHolder will not be covered by the given
warranty,neither will warranty cover the damage because of accident or high
impact.
INNOVATIVE VETERINARY SOLUTIONS
PODOBLOCK
™
2
1Preliminary Information

INNOVATIVE VETERINARY SOLUTIONS
PODOBLOCK
™
3
2Description
OPU Probe Holder for equine ultrasounds and
is compatible with most ultrasound device
brands on the market.
With the ProbeHolder, you have an innovation
that makes equine OPU ultrasound processes
simpler, faster and more comfortable for both
vet and horse.
The unique construction, material and size of
this innovative product are the attributes that
make it valuable. It comes equipped with an
integrated needle chamber which can be
(optional) supplied with a stainless steel
needle guide.
Placing your Ultrasound probe is quick and
easy and requires only one locking screw
through the handle with integrated magnets
secure it all.
Packaging
The OPU ProbeHolder is
packaged and transported in
a hardcover protective case
and cushioned with
protective foam. Protective Foam
OPU ProbeHolder
Needle Pouches
Protective Hard Case

INNOVATIVE VETERINARY SOLUTIONS
PODOBLOCK
™
4
3Operating Instructions
2. Unscrew the red knob screw by turning it
counter-clockwise
Turn Knob counter-clockwise
3. Slide the complete handle grip backwards
Slide Back Handle grip
4. Open the ProbeHolder by placing finger in
the desired notches. Both halves are
secured by 2 magnets
Notches
5. Carefully insert the needle through the
needle guide and close the probe holder by
clapping the two halves together and screw
back on the red screw to lock the
probe holder securely
6. The black removable handgrip can be placed
in three (x3) positions (removed by turning
round by hand)
Position 1
Position 2
Position 3
1. Check carefully that all parts are included in the hardcase:
ProbeHolder
Needle Guide (Optional)
Needle
Needle
Guide
Follow the instructions below

Podoblock B.V.
Verlengde Nijverheidsweg 10
9482 WT Tynaarlo
The Netherlands
[email protected]
0031 50 8200 257
fax: [phone]
