point POVC112BLKIT User manual

Handheld 12 V. Wet & Dry Cleaner
With ultimate tool kit
POVC112BLKIT
User manual

2
Thank you for purchasing your new POINT Handheld Vacuum Cleaner.
These operating instructions will help you use it properly and safely. We
recommend that you spend some time reading this instruction manual
in order that you fully understand all the operational features it oers.
Read all the safety instructions carefully before use and keep this
instruction manual for future reference.
GB
Tack för att du har köpt din nya POINT handhållna dammsugare. Denna
bruksanvisning hjälper dig att använda den på ett säkert och korrekt
sätt. Vi rekommenderar att du tar dig tid att läsa igenom denna
bruksanvisning för att till fullo förstå alla driftfunktioner som den
erbjuder. Läs noga igenom alla säkerhetsinstruktioner före användning
och spara bruksanvisningen för framtida bruk.
SE
Tak fordi du har købt din nye Håndholdte Støvsuger fra POINT. Disse
brugsanvisninger hjælper dig med at bruge den korrekt og sikkert. Vi
anbefaler, at du læser denne brugsanvisning, så du får en fuld forståelse af,
hvordan alle funktionerne virker. Læs alle sikkerhedsinstruktioner nøje
før brug, og behold denne brugsanvisning til senere reference.
DK
Takk for at du kjøpte denne nye støvsugeren i POINT. Denne bruksanvisningen
hjelper deg med å bruke den ordentlig og sikkert. Vi anbefaler at du tar
deg tid til å lese gjennom hele bruksanvisningen for å bli fortrolig med alle
funksjonene den har. Les alle sikkerhetsanvisningene nøye før bruk, og
oppbevar bruksanvisningen for fremtidig referanse.
NO
Kiitos, kun valitsit uuden kannettavan POINT - pölynimurin. Nämä
käyttöohjeet opastavat sinua käyttämään laitetta oikein ja turvallisesti.
Suosittelemme, että vietät hetken tämän käyttöoppaan parissa, jotta
ymmärtäisit täysin kaikki laitteen tarjoamat toiminnalliset ominaisuudet.
Lue kaikki turvallisuusohjeet huolellisesti ennen laitteen käyttöä ja
säilytä käyttöopas myöhempää käyttöä varten.
FI

3
4 - 13
14 - 23
24 - 33
34 - 43
44 - 53
Instruction Manual - English ........................... page
Bruksanvisning - Norsk ................................... side
Käyttöohjeet - Suomi ..................................... sivu
Brugsanvisning - Dansk .................................. side
Bruksanvisning - Svenska ............................... side
GBFI
DK NOSE

4
IMPORTANT SAFETY INSTRUCTIONS
For your continued safety and to reduce the risk of injury
or electric shock, follow all the safety precautions listed
below.
1. Read all the instructions carefully before using the
appliance and keep them for future reference.
2. Retain the manual. If you pass the appliance onto a
third party make sure to include this manual.
3. This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision
or instruction concerning
use of the appliance in a
safe way and understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made
by children without supervision.
4. Only use the appliance with the supplied power
adaptor
or charger.
5. Check that the voltage marked on the rating label
matches your mains voltage.
6. This vacuum cleaner is intended for normal
household use only. Do not recharge and use the
appliance outdoors. Do not use the appliance for
other uses than its intended use.
7. Make sure the dust container is properly installed
before use. Never use the appliance without the
motor protection filter. This damages the motor and
shortens the life of the appliance.
8. Never vacuum up flammable substances and do not
vacuum up ashes until they are cold.

GB
5
9. To protect against electrical shock, do not immerse
the mains cable, mains plug or any part of the
appliance in water or other liquids.
10. Do not store the vacuum cleaner in areas with high
temperature, keep it away from heat sources such as
radiators or gas/electric fires.
11. If a blockage is found in the brushes, hoses or tubes, it
should be removed before use.
12. Do not continue to operate the appliance if you are in
any doubt about it working normally (e.g. abnormal
noise, smell, smoke), or if it is damaged in any way -
switch o, withdraw the mains plug and consult your
dealer.
13. Do not operate an appliance with a damaged mains
cable or mains plug, or in an abnormal state. If the
mains cable is damaged it must be replaced by the
manufacturer, its service agent, or similarly qualified
persons in order to avoid a hazard.
14. The use of accessories not recommended by the
appliance
manufacturer may cause injuries.
15. Never touch the power plug or the appliance itself
with wet hands.
16. Do not point the appliance at the eyes, ears or mouth
during operation.
17. Unplug the charger before cleaning or replacing the
filter. Allow the appliance to cool completely before
cleaning or storing.

6
PRODUCT OVERVIEW
1. Dust container
2. Outer filter
3. Inner filter
4. Seal ring
5. Dust container release button
6. Battery/ Charging indicator
7. ON/OFF switch
8. Carpet brush
9. Squeegee
10. Crevice tool
11. Bed brush
12. Connector
13. Extra long crevice
14. Wide brush
8
9
10
11
13
14
15
16 17
18
12
19
1
2
3
7
456
15. Upholstery
16. Wide nozzle
17. Flexible hose
18. Car plug
19. Charger

GB
7
BEFORE USE
It is recommended to charge the vacuum cleaner for at least 16 hours
before use.
When the suction power is low during operation, this indicates it is
time to recharge the battery. Only charge the appliance with the
supplied power adaptor.
NOTE: Extreme weather (too hot or too cold) is dangerous and not
good for the battery do not charge the battery in temperatures above
40°C, or below 0°C.
1. Switch o the vacuum cleaner by using the ON/OF switch.
2.
Connect the power adapter directly to the vacuum cleaner to the
power socket, or charge the vacuum cleaner by using the 12V car plug.
3. The charging indicator will illuminate to indicate that the vacuum
cleaner is being charged.
HINT: It is recommended to charge the vacuum cleaner for at least 16
hours before use.
NOTE: The vacuum cleaner is designed for continuous-charging,
therefore it is normal that the charging indicator will not go o even if
charging is completed.
CHARGING THE VACUUM CLEANER

8
It is normal that the battery in the vacuum cleaner gets warm
during use. Allow approx. 30 min for the battery to cool completely
before charging.
Carpet Brush:
Insert [8] Carpet Brush into the Handheld unit, it is a small brush
for cleaning hairy surfaces, like carpets.
Squeegee:
Insert [9] Squeegee into the Handheld unit, it is for sucking liquid
or cleaning the wet surfaces. Place the rubber head of Squeegee
onto the liquid or wet surface, sliding and pulling along the surface
to clean. Liquid in the dust container must not exceed the “MAX”
line.
IMPORTANT FOR CHARGING
APPLICATION OF ACCESSORIES
OPERATION
1. Unplug the charger adapter. Press the ON/OFF switch on the vacuum
cleaner. The vacuum cleaner will start to work.
2. Vacuum the surface in any direction until the area is clean.
3. Cleaning attachments are provided. Ensure to turn o the vacuum
cleaner before attaching the attachments. For details refer to the
next section “APPLICATION OF ACCESSORIES”.
4. Press the ON/OFF switch to turn o the vacuum cleaner. Slightly
lift the vacuum cleaner head upward to avoid dust falling out from
the dust container before switching o.
5. Empty the container before doing any more vacuuming and clean it
before putting it away.
6. Connect the charger adapter after use. The charging indicator
will illuminate to indicate that the vacuum cleaner is being charged.

GB
9
HINT: Before vacuuming up liquids, empty the dust container first.
Make sure the filter is assembled. Hold the vacuum cleaner with the
squeegee pointing downwards during use. Empty the dust container
immediately after use.
Crevice tool:
Insert [10] Crevice tool into the Handheld unit, it is a small and
handy tool for various surface.
The Accessory Kit is a full range accessory set for different cleaning
conditions, it is specially designed for POVC112BL handheld unit.
Insert [12] Connector into the Handheld unit, connect [17] Flexible
Hose as optional extension tool. Hold firmly and pull out the
accessories to disassemble.
Bed Brush:
The rotary shaft of [11] Bed Brush is specially designed for textile,
bedding tools and pillows. Slide the Bed Brush along the surface to
clean.
Wide Brush:
Insert and slide [14] Wide Brush into [16] Wide Nozzle. The Wide
Brush is applicable for cleaning uneven surfaces, such as hair,
fibers, carpets, etc.
Upholstery:
Insert and slide [15] Upholstery into [16] Wide Nozzle. The Upholstery
is applicable for cleaning textile surface, such as shirts, curtain,
bedding, etc.
Extra Long Crevice:
Connect [13] Extra Long Crevice is for cleaning small areas which
are difficult to reach, such as corners, gaps, holes, etc.

10
MAINTENANCE / CLEANING
˙ Dirt and liquid in the dust container should be emptied after each use
or at the time when the dust exceeds the maximum dust marking.
˙Always switch o the vacuum cleaner before cleaning.
1. Hold the vacuum cleaner vertically with the air-intake (nozzle end)
pointing downwards to avoid spillage. Press the release button on
the top of the vacuum cleaner and release the dust container over a
rubbish bin and remove the filter bracket from the dust container.
2. Remove the filters by holding the two lips on the outer filter and
pull them out from the dust container.
3. Empty the contents of the dust container into a rubbish bin.
