POL-EKO SMART User manual

Page 1/ 5
Quick Start Guide SMART ver. 1.21
Full manual is available on the website https://www.pol-eko.com.pl/download-english/
1. First boot
During the first boot, the screen (Figure 1) will display information about saving the "Download" folder (with instruction
manual in pdf format) on the USB flash drive. In order to do it, insert the USB flash drive and wait a second for
hardware detection, then press . If you press you quit downloading the folder. The window will appear again during the next
boot. You can tick „Don’t show again” so that the window will not be displayed after switching on the device.
Figure 1 Downloading the files
After copying the data to the USB flash drive, before removing it from the USB socket, it should be unmounted by
pressing the icon in the top drop-down list (Figure 2).If the pendrive is not unmounted after
connecting to the computer, a message about pendrive damage may be displayed with a repair proposal,
when actually the pendrive is not damaged.
Figure 2 Unmounting USB flash drive
The folder “Download” can be downloaded from the submenu „Info”. To do it, go to the main menu and press the icon . In
order to save the full version of the instruction manual on the USB flash drive, press the icon . After inserting the flash drive into
USB port wait few seconds until the information “Flashdrive connected” will appear on the display.
Before removing USB flash drive from the USB socket, it should be unmounted.

Page 2/ 5
2. Main screen
After switching on the device, the main screen (Figure 3) appears. It contains the information about the device status.
After starting the program, additional information appears on the screen (Figure 4).
Rys.3. Main screen
Figure 4 Main screen –running program
current tempe-
rature in the
chamber
side-scrolling
information
panel
alarm bar
set
temperature
main
menu
start/stop
program
quick change of
fan efficiency
segment du-
ration time
program
status
active
panel
current
date/hour

Page 3/ 5
3. Quick Program
Quick program allows you to quickly start the program from the main screen position without having to enter to the menu .
Quick program has several features that guarantee its uninterrupted operation:
•you can not set the duration of the program - time is always set to infinity,
•if the display fails, the program continues,
•after the power supply is resumed (after its failure), the program continues,
•to prevent the program from stopping accidentally, the STOP button was removed from the main window.
In order to go to Quick program click the icon in the main screen. By clicking the appropriate icon you can set (Figure 5):
−temperature
−fan efficiency (for CL, IL, SR, SL with forced air convection (W))
−degree of opening of the air-flap (for CL, SR, SL)
Clicking the icon starts the program in continuous mode (time set to infinity).
Figure 5 Starting the Quick Program
Press
Set temperature
Set fan efficiency
(if possible/necessary)
Set degree of opening of the air-
flap (if possible/necessary)
Start

Page 4/ 5
Stopping a Quick program has been made difficult on purpose (this prevents the program from being stopped accidentally) –to
stop a program, you have to:
1. go to the menu ,
2. click the program window ,
3. keep pressing STOP button for 5 seconds.
4. Creating and starting a program
Press the main menu icon .
Press . In the programs panel, you can start the selected program, add a new one,
edit it or delete it.
To create a program, press .
Set the parameters of the program (with more parameters the panel can be scrolled up and
down).
Press and go to the program segments.
Using the side keypad, set the segment parameters: temperature, time (the number of
parameters depends on the device and additional options). In order to reach the set
temperature as quickly as possible, set the ramp time to 0.
The navigation between: segments, program parameters and summary is done by swiping
your finger to the side or by touching the icon .
After setting the parameters for all segments, a summary window appears.
This window shows all the segments with the entered settings. If everything is correct, move
the window down and press .

Page 5/ 5
The saved program is automatically highlighted in the list. To start it, press .
To stop a running program, press .
5. Quick starting / stopping a program
In the main screen press:
- to start a program
- to stop a program
6. Additional information
The full version of the user manual is saved in the memory of the controller. To download the user manual, see Section 1.
All CE declarations of conformity are in the full version of the user manual.
Manufacturer:
POL-EKO-APARTATURA sp.j.
A. Polok-Kowalska, S. Kowalski
ul. Kokoszycka 172 c, 44-300 Wodzisław Śląski
tel. [phone], fax [phone]
e-mail: [e-mail]
internet: www.pol-eko.com.pl
