Polaris Personalized Automated Control System User manual

Owner’s Manual
E
Personalized Automated Control System

Important Information
WARNING: RISK OF ELECTRICAL SHOCK.
•Read and follow operation and maintenance instructions carefully.
• Electrical work should be performed by a licensed electrician and conform to all national, state and
local codes.
• Do not have equipment serviced if precipitation is present or imminent.
• Always keep command center door closed when not accessing display panel.
• Do not allow children to handle this product.
• The Eos Wireless Remote requires a fully charged battery at startup. Charge battery for at least 5
hours before use. An inadequate charge can permanently damage the battery.
For customer service or support:
• Please mail Warranty Card immediately.
• For on-line support: www.polarispool.com
• To contact Polaris:
US and Canada
Customer Service
2620 Commerce Way
Vista, CA 92081-8438
1-800-822-7933

E
1
Congratulations on the purchase of your new automated control system and thank you for
choosing Polaris. Designed to provide easy and convenient control of most pool and spa
functions, the Polaris Eos Command Center:
• Controls pool and spa equipment, waterfalls, fountains, and lighting.
• Schedules regular pool and spa routines such as cleaning and circulation.
• Can be programmed to operate multiple devices with the touch of a single button.
• Components, options and functions can be expanded after installation is complete.
• Operates independently or can be remotely controlled from optional in-house wired
remotes, wireless remotes or the Shortcut spa-side remote.
• Remotely operates electric devices including household appliances with the
optional PLC (Power Line Carrier) Kit.
• Controls optional sanitation equipment including traditional chemical or salt
chlorination systems.
E
CommandCenter
Command Center
Command Center Open
with Deadfront Removed
1
E
SVC
GND
SNSR1
GND
SNSR2
GND
SNSR3
GND
SNSR4
GND
SNSR5
+
24VDC
GND
PRE
OUT
LP1 LP2LP3LP4 LP5LP6
VLV6VLV5 VLV4 VLV3 VLV2VLV1
2
E
SVC
GND
SNSR1
GND
SNSR2
GND
SNSR3
GND
SNSR4
GND
SNSR5
+
24VDC
GND
PRE
OUT
LP1LP2LP3LP4LP5LP6
VLV6VLV5VLV4VLV3VLV2VLV1
Command Center
Open with
Deadfront Removed
5
3
1
2
4
Pool Circulating Pump
4
1
3
5
1. Command Center Display
2. Command Center Keypad
3. Relays and Power Subpanel
4. Deadfront
5. Activator Circuit Board
Command Center Components
Introduction

Starting the Eos Command Center
To activate: Turn on circuit breaker (main power source) to power up the unit.
To disable or put in “Standby Mode”: Press and hold the Enter key for five seconds.
Press any key to reactivate.
To shut down: Turn off main power source to command center.
Display Overview
Display Symbols
Folders indicate that additional screens, menu or setup options are available
for an item.
Check Boxes are used to turn functions or devices on or off. Checked = On.
Up/Down Arrow indicates adjustment options are available for the field
next to it and the up/down arrow keys are used to select or enter the setting.
Item in reverse (white text on black box) indicates curser is over item or field.
Asterisk in front indicates a text field (blank line) that can be named by user.
Clock next to equipment status field means device is scheduled to be “on.”
Flame next to status field of heater means heater is firing.
Aug
*
Aug
*
2
E
System Overview
Device Setup
Scenes & Shortcuts
Owner Info
Polaris Info
Standby
Freeze Protection
Temperature Fahrenheit
Date Aug03, 2004
Time 02:04pm
Setup
Tue,Aug03 2:04 pm
ENTER
To adjust display settings,
press and together.
SVC
E
Use left or right
arrow keys to
change screens
Cursor Control
Item Select
CheckBox
(Device or function Off)
(Device or function On)
Folder
(Selected)
(Not Selected)
Screen Name
Up/Down Arrow
indicates adjustment
options are available.
Current Status and
Alarm Messages

Screen Overviews
Setup Screen
During installation, this screen is used to define and configure the system.
Adjustments to this screen will usually be minimal. For a complete
description of system setup and the associated screens, refer to the
Eos Installation and Operation Guide.
Device Setup is used to setup system equipment.
Scenes & Shortcuts can be established to start or stop
several devices with a single command.
Owner Info is used to input of owner name and address.
Serial number and service contact phone numbers can
be input in Polaris Info.
Checking the Standby box disables all automatic
control functions.
Freeze Protection should always be checked to protect
equipment from freezing conditions.
Temperature sets Fahrenheit or Celsius.
Sets Date by month, day and two-digit year.
Sets Time along with an am or pm designation.
Optional Device Control Screens
If a Watermatic pH/ORP controller or salt chlorinator is installed, additional control
screens become available.
Main Screen
Once setup is complete, the Main screen provides access to most commonly needed
measurements and functions. Most routine maintenance and adjustments can be made
from this screen.
E
3
Device Setup
Scenes & Shortcuts
Owner Info
Polaris Info
Standby
Freeze Protection
Temperature Fahrenheit
Date Aug03, 2004
Time 02:04pm
Left or right
arrow keys will
change screen
Setup
Tue,Aug03 2:04 pm
To adjust display settings,
press and together.
Air 60 Water 60
Pool Setpoint 71°
Spa Setpoint 100°
Pool Circulation Spa
Cleaner Pump Off
Pool Light Off
Pool Light Dim Off
PS Heater On
Suction Valve Off
Return Valve Off
Cleaner Valve Off
Music On
Table Lamp Off
Main
Tue, Aug 03 2:04 pm
To adjust display settings,
press and together.
Air 60° Water 71°
Indicates device list continues
on another screen
Select folder icon to
open the Device Manager
screen where scheduling
and other operational
functions are controled
Shows designated heater
(set point) temperture
Flame indicates
heater is firing
Indicates adjustable settngs
are available for the device
Clock indicates device
is scheduled to be “On”
Status field indicates
On/Off status of device
More
Shows current sensor
temperature readings and
alerts if any are present

Device Manager Screens
Each piece of equipment controlled by Eos has
amanager screen with specific settings for the
device.
From these screens equipment can be:
• Turned on or off
• Set for specific on or off durations
• Scheduled to be active at specific times
on specific days
Navigating the System
• Use the keypad arrow (cursor control) keys
to move through the screens and
menu options.
• When the cursor is over an item, it will appear darkened or in reverse (white on black
instead of black on white).
• Press the Enter key to select an item, open a folder, or activate/deactivate a feature
with a check box.
To set or adjust an item:
1. Use the keypad arrow keys to move the cursor over the item.
2. Press <Enter> to select the item. The item will flash.
3. Use the up/down keys to choose or enter the setting.
4. Press <Enter> to activate the setting.
Using text fields
1. Move cursor over the text field and press <Enter> to select.
2. Use the up/down arrow keys to move through the alpha-numeric options.
3. Use the right arrow key to move to the next position within the field.
4. Press <Enter> when the entry is complete.
Using nameable text fields
1. Move cursor over name field and press <Enter> to select. The last letter
of the name will blink.
2. Use the left arrow key to erase the item name.
3. Use the up/down arrow keys to access the alpha-numeric options.
4. Use the right arrow key to move to the next position within the field.
5. Press <Enter> when the entry is complete.
To change the item back to “None,” move to the asterisk and press <Enter>.
4
E
Use left/right
arrow keys to
change screens.
Status of device
Press <Enter>
to change
Select protection here
and on Setup screen
Tue, Aug 03 2:04 pm
PS Heater Manager
Duration Remaining
04h 00m 00h 00m
Manual Control
Schedules
PS Heater Off
Day Start Stop
off12:00p 12:00p
off12:00p 12:00p
off12:00p 12:00p
off12:00p 12:00p
Range 0
104
Heater Cool Down
Freeze Protect
Air 60Water 71

T
o adjust the brightness or contrast of the display, press the left and right arrow keys
simultaneously to open the Command Center Setup Screen.
Software Version provides access to information on the current software versions for
the command center and the various devices it controls.
Contrast controls readability of text, light or dark, on screen.
Backlight controls the illumination of screen.
Backlight Timeout sets a time limit for inactivity after which the light on the display
turns off. Hit any key to reactivate the display.
When checked, Audible Alarm enables the alarm within the Command Center that
sounds when an alert condition exists. (If remote devices are used to control the Eos,
the alarm for each device can be enabled or disabled independently.)
To set or adjust any of the display controls:
1. Use arrow keys to move the cursor over the
field to be adjusted. (Ex: )
2. Press <Enter> to select the item. The item will flash.
3. Use up arrow to increase or down arrow to decrease
screen effect until it is at desired setting.
4. Press <Enter> to activate setting.
Press the left arrow key to return to the Main screen.
E
5
Adjust
Using the Eos System
Command Center Setup
Tue, Aug 03 2:04 pm
Adjustment
is available
Name of feature
or control
Software Versions
Contrast Adjust
Backlight Adjust
Backlight Timeout 0min
Audible Alarm
Cursor is over
adjustable field

6
E
Common Tasks
Changing the Heater (Setpoint)
Temperature Setting
On the Main screen:
1. Move the cursor to the Up/Down Arrow symbol next
to the pool or spa (setpoint) temperature setting.
2. Press <Enter> to select the item.
3. Push the up or down arrow key to change
the temperature setting.
Turning Equipment On or Off
On the Main screen or Device Manager screen:
1. Move the cursor to the Status field next to the device.
2. Press <Enter> to change the status, turn it on or off.
Customizing the Main Screen Display
Items can be reordered or devices grouped to make the system easier to work with.
To move an item up or down on the menu:
1. Move the cursor to the Status field of
the particular device.
2. Press and hold <Enter>.
3. Push the up or down arrow key to
move the device.
T
o insert a space between menu items:
1. Move the cursor to the Status field
of the device you want to insert a
line above.
2. Press and hold <Enter>.
3. Press the up and down arrow keys
simultaneously. A space will be
inserted above the item.
T
o delete the space, move the
item back up.
Pool Circulation Pool
PS Heater Off
Pool Setpoint 71°
Spa Setpoint 100°
Cleaner Pump Off
Pool Light Off
Pool Light Dim Off
Music On
Table Lamp Off
Main
Tue, Aug 03 2:04 pm
More
Circulation
Mode
Heater
Items
Pool
Items
PLC
(X-10)
Items
Indicates device
list continues on
another screen
Air 60° Water 71°
Pool Setpoint 71°
Spa Setpoint 100°
Pool Circulation Spa
Cleaner Pump Off
Pool Light Off
Pool Light Dim Off
PS Heater On
Suction Valve Off
Return Valve Off
Cleaner Valve Off
Music On
Table Lamp Off
Main
Tue, Aug 03 2:04 pm
To adjust display settings,
press and together.
Air 60° Water 71°

E
7
Setting the Time and Date
It is imperative that the date and time are set correctly to ensure proper function of the
equipment scheduling features.
The command center offers multiple start and stop times and the ability to set various
schedules. The built-in 365 day calendar clock accommodates multiple schedules without
monthly reprogramming.
Adjustments are made on the Setup screen.
To set or adjust the date:
1. Use the arrow keys to move
the cursor over the month field.
(Ex: )
2. Press <Enter> to select the item. The
item will flash.
3. Use the up or down arrows to select
the desired setting.
4. Press <Enter> to activate
the setting.
5. Use the same steps to set the
day and year.
To set or adjust the time:
1. Use the arrow keys to move
the cursor over the hour field
(Ex: ) first.
2. Press <Enter> to select the item. The
item will flash.
3. Use the up arrow to run through the
setting options, selecting the
appropriate hour with am or pm.
4. Press <Enter> to activate
the setting.
5. Use the same steps to set
the minutes.
When adjustments are complete, use the left
or right arrow key to return to the Main screen.
Left or right
arrow keys will
change screen
Setup
Tue, Aug 03 2:04 pm
To adjust display settings,
press and together.
Air 60° Water 60°
Month is
selected
Device Setup
Scenes & Shortcuts
Owner Info
Polaris Info
Standby
Freeze Protection
Temperature Fahrenheit
Date Aug 03, 2004
Time 02:04pm
Aug
02
Left or right
arrow keys will
change screen
Setup
Tue, Aug 03 2:04 pm
To adjust display settings,
press and together.
Air 60° Water 60°
Device Setup
Scenes & Shortcuts
Owner Info
Polaris Info
Standby
Freeze Protection
Temperature Fahrenheit
Date Aug 03, 2004
Time 02:04pm
Hour is
selected

8
E
Setting the Circulation Mode
The options available for the circulation pump are dependent on the type of pool, the
equipment installed, and the settings chosen at installation.
To set (manually activate) the circulation mode:
1. Move the cursor over the Status field
(Ex: ) and press <Enter> to select
the item. The item will flash.
2. Use the up/down arrow keys
to access the circulation
mode options.
3. Select the desired mode and
press <Enter> to activate
the selection.
When a circulation mode is entered, either manually or as a scheduled event, circulation
pumps as well as the appropriate valve actuators will activate.
When set manually, the selected mode will run for as long as the Manual Duration (found
on device manager screen) specifies, if no other schedules are set.
To schedule the circulation mode:
Move the cursor over the circulation
folder and press <Enter> to open the
Device Manager screen.
Pool Configuration Circulation Mode Additional Settings
Options With a Two-Speed Pump
Pool/Spa with Shared Pump
and Spillover Enabled Pool, Spa, Spill, Off Pool LS, Spa LS, Spill LS
Pool/Spa with Shared Pump
without Spillover Pool, Spa, Off Pool LS, Spa LS
Pool Only On, Off On, Low, Off
Spa Only On, Off On, Low, Off
Pool/Spa with Separate Pumps
Pool Circulation On, Off On, Low, Off
Spa Circulation On, Off On, Low, Off
Main
Tue, Aug 03 2:04 pm
Air 60° Pool 71° Spa 69°
More
Circulation Mode Off
PS Heater Off
Pool Setpoint 71°
Spa Setpoint 100°
Cleaner Pump On
Pool Light Off
Pool Light Dim Off
Music Off
Table Lamp Off
Circulation Mode Off
PS Heater Off
Pool Setpoint 71°
Spa Setpoint 100°
Cleaner Pump Off
Pool Light Off
Pool Light Dim Off
Music On
Table Lamp Off
Main
Tue, Aug 03 2:04 pm
More
Circulation Mode
separate
Heater and set points
Pool items
PLC (X-10) items
Air 60° Water 71°
Off

E
9
Setting Manual Controls and Scheduling
Each piece of equipment has a manager screen (accessed by selecting the folder
next to the item on the Main screen) with specific settings for the device. All manager
screens include:
Status
Indicates on/off status for most devices. For a pool/spa
circulation pump it also indicates the current circulation
mode (pool, spa, or spillover).
Manual Control
Specifies how long a device will be active when
turned on manually.
Some equipment is dependent on other equipment
to operate properly. The rules governing these
dependencies are referred to as Device Manager
Rules. Manually activated devices are subject to
these rules, meaning that even though a device
turned is “on,” it may not activate unless all the rules
are met. See Device Associations, Safety Delays
and Lockouts for further information.
Each device has a Duration default. When the
specified duration is complete, the device control
returns to the established schedules.
Remaining refers to how much longer the device will
be active under manual control.
Schedules
Scheduling is available for each device. Up to four schedules can be set based on date
and time. When scheduling, equipment associations and manager rules should again be
taken into consideration. For detailed information on equipment, review the original
manufacturer’s documentation or talk with a pool professional.
Day: Specifies day(s) of operation
(Sun, Mon, Tue, etc. or All)
(M-F = Monday thru Friday)
(S-S = Saturday and Sunday)
(MWF = Mon., Wed. and Friday)
Start: Specifies start time
Stop: Specifies stop time
Mode: For circulation pump only: specifies circulation mode (pool, spa, spillover)
Schedule priority is based on the order of the schedules from the top (highest priority)
to the bottom of the menu.
When a device is scheduled and active, a clock symbol will display next to it.
Freeze Protect
Enables or disables freeze protection for the specific device. Freeze Protect must be
specified for each device individually. Freeze Protection on the Setup screen must
also be checked.
Tue, Aug 03 2:04 pm
Cleaner Pump Manager
Duration Remaining
04h 00m 00h 00m
Manual Control
Schedules
Cleaner Pump Off
Day Start Stop
off12:00p 12:00p
off12:00p 12:00p
off12:00p 12:00p
off12:00p 12:00p
Off
Freeze Protect
Air 60Water 71

10
E
Circulation (Circ) Pump Manager
The same circulation options available on the Main screen are available on the manager
screens by selecting and adjusting the Status field.
When manually activated, the chosen mode will run as long as the Duration specifies.
T
o change Duration:
1. Move the cursor over the hours
(Ex: ) and press <Enter> to
select. The item will flash.
2. Use the up/down arrow keys
to select time.
3. Press <Enter> to activate
the selection.
4. Use right arrow to move to
minutes and set if desired.
Schedules can be set for different circulation modes. Schedule priority is based on the
order of the schedules, from the top (highest priority) to the bottom of the menu. Start
and Stop time is set in hours and minutes with am / pm designated by the hour.
To schedule circulation Mode:
1. Use the arrow keys to move the
cursor over the status field under
Day (Ex: ) and press <Enter>
to select. The item will flash.
2. Use the up/down arrow keys to
set the day. Press <Enter> to
activate the selection.
3. Move cursor to Start hour field
and press <Enter> to select.
Use the up/down arrow keys to
choose start time. Press <Enter>
to activate. Set minutes if desired.
4. Move cursor to Stop. Set stop
time, hours and minutes.
5. Move cursor to Mode, select
the circulation mode and press
<Enter> to activate.
6. Use the left arrow key to return
to the Main screen.
Manual Control
Circulation Mode Pool
Use left/right
arrow keys to
change screens.
Status
Field
Indicates adjustment options
PS Circ Pump Manager
Tue, Aug 03 2:04 pm
Day Start Stop Mode
off12:00p 12:00p Pool
off12:00p 12:00p Pool
off12:00p 12:00p Pool
off12:00p 12:00p Pool
Schedules
Off
Duration Remaining
03 h 00m 00h00m
Air 60° Water 71°
Duration Remaining
03h 00m 00h 00m
Manual Control
Circulation Mode Pool LS
Use left/right
arrow keys to
change screens.
Status
Field
Indicates adjustment options
PS Circ Pump Manager
Tue, Aug 03 2:04 pm
Schedules
Off
Day Start Stop Mode
off 12:00p 12:00p Pool
off12:00p 12:00p Pool
off12:00p 12:00p Pool
off12:00p 12:00p Pool
Air 60° Water 71°
off
03

E
11
Using Manager Screens
Access any manager screen from the Main screen by selecting the folder next to the item.
Heater Manager
An adjustable high and low operating Range is
available for heaters. Defaults are 0° and 104° F.
Range can be used to set multiple heaters to
heat to different temperatures. For example:
two heaters can be set to heat together up to a
certain temperature, such as 95° F, with only
the second continuing to heat to the maximum.
Heater Cool Down is a safety feature that
provides a two-minute delay in turning off the
circulation pump after the heater has completed
its firing cycle. This allows the heater to cool down.
If Freeze Protect is disabled (unchecked), the
heater will not fire during “Freeze Alert.” If enabled,
the heater will fire if the water temperature drops
to 34° F or the air temperature drops to 36° F.
Spa Dep Valve Manager
If a Spa Dependent Valve is installed on
the pool, use Spa Mode Position to set the
valve position, open or closed, when
the system is in circulation mode “Spa.”
1. Use the arrow keys to move the
cursor over the Spa Mode Position
field. (Ex: )
2. Press <Enter> to select On or Off.
Solar Valve Manager
Solar Priority, available on the Solar Valve
Manager and Solar Pump Manager screens,
sets solar heating to have priority over all
other heaters.
When checked (default), the solar heater
has priority over other heaters until the water
temperature gets within 5 degrees of the Solar
Panel Temp. Then, solar heating will shut off and
the other heater(s), if activated, will continue to
heat until the setpoint is reached.
Solar Panel Temp displays the current reading
from the temperature sensor on the solar panel.
Use left/right
arrow keys to
change screens.
Status of device
Press <Enter>
to change
Select protection here
and on Setup screen
Tue, Aug 03 2:04 pm
PS Heater Manager
Duration Remaining
04h 00m 00h 00m
Manual Control
Schedules
PS Heater Off
Day Start Stop
off12:00p 12:00p
off12:00p 12:00p
off12:00p 12:00p
off12:00p 12:00p
Range 0
104
Heater Cool Down
Freeze Protect
Air 60Water 71
Use left/right
arrow keys to
change screens.
Status of device
Press <Enter>
to change
Select protection here
and on Setup screen
Tue, Aug 03 2:04 pm
Solar Valve Manager
Duration Remaining
04h 00m 00h 00m
Manual Control
Schedules
Solar Valve Off
Day Start Stop
off12:00p 12:00p
off12:00p 12:00p
off12:00p 12:00p
off12:00p 12:00p
Solar Priority
Freeze Protect
Solar Panel Temp 60
Duration Remaining
04h 00m 00h 00m
Manual Control
Schedules
Day Start Stop
off12:00p 12:00p
off12:00p 12:00p
off12:00p 12:00p
off12:00p 12:00p
Ranges 0
104
Heater Cool Down
Freeze Protect
Air 60Water 71
Use left/right
arrow keys to
change screens.
Status of device
Press <Enter>
to change
Select protection here
and on Setup screen
Tue, Aug 03 2:04 pm
Spa Dep Valve Manager
Duration Remaining
04h 00m 00h 00m
Manual Control
Schedules
Spa Dep Valve Off
Day Start Stop
off12:00p 12:00p
off12:00p 12:00p
off12:00p 12:00p
off12:00p 12:00p
Spa Mode Position
Off
Freeze Protect
Air 60Water 71
Off

Setting Scenes and Shortcuts
Scenes and Shortcuts establish one touch control of multiple devices. They can control
groups of equipment routinely used together. For example: a Shortcut can turn on the
pool light, porch light and landscape lighting. Or they can be used to create a particular
mood for entertaining or relaxing.
Scenes
A Scene is a “snapshot” of the entire system operation that can be recalled to play
at any time.
Scenes can be scheduled to run at specific times or activated manually.
Up to five Scenes can be set up, but only one Scene can be played at a time. If a Scene
is “in play” and another is recalled (either manually or by a schedule), the latter Scene
takes priority.
To set a Scene:
1. Turn on any equipment that you want to
operate during the Scene. Setpoints can
be part of the Scene.
On the Main screen, move the cursor to
the Status field of the each device and
press <Enter> to select the setting.
In this example: circulation mode is
Spa, Spa setpoint is 103°, Pool Light
is On, Spa Light is dimmed to 60%,
and Music is On.
2. Use the left arrow key to move to
the Setup screen.
3. Move cursor to the Scenes & Shortcuts
folder. Press <Enter> to open the
Scenes & Shortcuts screen.
4. Move the cursor to the first available text
field under My Scenes.
5. Press <Enter> to select the field and use
the arrow keys to name the Scene.
(Ex: )
6. Move the cursor to the folder next to the
newly named Scene and press <Enter> to
open the My Scene Manager screen.
12
E
Pool Setpoint 78°
Spa Setpoint 103°
PS Heater On
Circulation Mode Spa
Cleaner Pump Off
Pool Light On
Spa Light Dim 60%
Suction Valve Off
Return Valve Off
Cleaner Valve Off
Music On
Main
Tue, Aug 03 2:04 pm
To adjust display settings,
press and together.
Current Temperature
Readings
Select folder icon
to open the Device
Manager screen.
Designated Heater
Temperture
Status Field indicates
status of device.
Press
<Enter> to change.
Flame indicates
heater is firing
Adjustable settngs
available for device operation
Clock indicates device
is scheduled to be “On”
Air 60° Water 71°
Setup
Tue, Aug 03 2:04 pm
To adjust display settings,
press and together.
Air 60° Water 60°
Hour is
selected
Device Setup
Scenes & Shortcuts
Owner Info
Polaris Info
Standby
Freeze Protection
Temperature Fahrenheit
Date Aug 03, 2004
Time 02:04pm
My Scenes
1
2
3
4
5
My Shortcut
1
2
3
4
5
Scenes & Shortcuts
Tue, Aug 03 2:04pm
Spa Night
Spa Night

E
13
7. Move the cursor to Save and
press <Enter> to capture
the Scene.
The Scene “Spa Night” is
now saved.
It can be manually activated
or scheduled just like any
other device.
Use the left arrow key to
return to the Main screen.
8. The Scene is now displayed,
just like a device, and can be
recalled (activated) at any time
by changing the Status to On.
The device manager for the
Scene can be accessed by
selecting the folder next to it.
Shortcuts
Shortcuts are also “snapshots” of system operation. Unlike Scenes that turn devices on or
off to set the scene, Shortcuts are only able to turn devices on.
Up to five Shortcuts can be set up and run simultaneously.
Shortcuts can run within a Scene, but Scenes cannot run within a Shortcut.
T
o set a Shortcut:
1. Turn on any equipment that you
want to operate during the Shortcut.
On the Main screen, move the
cursor to the Status field of each
device and press <Enter> to select
the setting.
In this example: Pool Light is
On, Spa Light is dimmed to
60%, Porch Light is On, and
LS (Landscape) Lighting is On.
To adjust display settings,
press and together.
Day Start Stop
off12:00p 12:00p
off12:00p 12:00p
off12:00p 12:00p
off12:00p 12:00p
Duration Remaining
04h 00m 00h 00m
Manual Control
Schedules
Tue, Aug 03 2:04 pm
My Scene Manager
Spa Night Off
Save
Air 60 Water 71
Pool Setpoint 78°
Spa Setpoint 103°
PS Heater On
Circulation Mode Spa
Cleaner Pump Off
Pool Light On
Spa Light Dim 60%
Suction Valve Off
Return Valve Off
Cleaner Valve Off
Music On
Spa Night On
Main
Tue, Aug 03 2:04 pm
To adjust display settings,
press and together.
Current Temperature
Readings
Select folder icon
to open the Device
Manager screen.
Designated Heater
Temperture
Status Field indicates
status of device.
Press
<Enter> to change.
Flame indicates
heater is firing
Adjustable settngs
available for device operation
Clock indicates device
is scheduled to be “On”
Air 60° Water 71°
Pool Setpoint 78°
Spa Setpoint 100°
PS Heater Off
Circulation Mode Off
Porch Light On
LS Lighting On
Spa Light 60%
Suction Valve Off
Return Valve Off
Cleaner Valve Off
Music Off
Main
Tue, Aug 03 2:04 pm
To adjust display settings,
press and together.
Current Temperature
Readings
Select folder icon
to open the Device
Manager screen.
Designated Heater
Temperture
Status Field indicates
status of device.
Press
<Enter> to change.
Flame indicates
heater is firing
Adjustable settngs
available for device operation
Clock indicates device
is scheduled to be “On”
Air 60° Water 71°

2. On the Setup screen, move the
cursor to the Scenes & Shortcuts.
folder. Press <Enter> to open the
Scenes & Shortcuts screen.
3. Move the cursor to the first
available text field under
My Shortcuts.
4. Press <Enter> to select the field
and use the arrow keys to name
the Shortcut. (Ex: )
5. Move the cursor to the folder
next to the newly named
Shortcut. Press <Enter> to
open the My Shortcut
Manager screen.
6. Move the cursor to Save and press
<Enter> to capture the Shortcut.
The Shortcut “Night Lights” is
now saved.
It can be manually activated
or scheduled just like any
other device.
Use the left arrow key to
return to the Main screen.
7. The Shortcut is now displayed, just
like a device, and can be recalled
(activated ) at any time by changing
the Status to On.
The device manager for the Shortcut
can be accessed by selecting the
folder next to it.
14
E
Setup
Tue, Aug 03 2:04 pm
To adjust display settings,
press and together.
Air 60° Water 60°
Hour is
selected
Device Setup
Scenes & Shortcuts
Owner Info
Polaris Info
Standby
Freeze Protection
Temperature Fahrenheit
Date Aug 03, 2004
Time 02:04pm
Scenes & Shortcuts
Tue, Aug 03 2:04pm
Air 60° Water 71°
My Scenes
1
2
3
4
5
My Shortcut
1
Night Lights
2
3
4
5
To adjust display settings,
press and together.
Day Start Stop
off12:00p 12:00p
off12:00p 12:00p
off12:00p 12:00p
off12:00p 12:00p
Duration Remaining
04h 00m 00h 00m
Manual Control
Schedules
Tue, Aug 03 2:04 pm
My Shortcut Manager
Night Lights Off
Save
Air 60 Water 71
Pool Setpoint 78°
Spa Setpoint 103°
PS Heater On
Circulation Mode Pool
Porch Light On
Pool Light On
Spa Light 60%
Night Lights On
Suction Valve Off
Return Valve Off
Cleaner Valve Off
Main
Tue, Aug 03 2:04 pm
To adjust display settings,
press and together.
Current Temperature
Readings
Select folder icon
to open the Device
Manager screen.
Designated Heater
Temperture
Status Field indicates
status of device.
Press
<Enter> to change.
Flame indicates
heater is firing
Adjustable settngs
available for device operation
Clock indicates device
is scheduled to be “On”
Air 60° Water 71°
Night Lights

E
15
Freeze Protection
Freeze protection is activated when the air
temperature drops to 36° F or the water
temperature drops to 34° F. Manual activation
or scheduled operation of Spa Mode will
override freeze protection.
During freeze protection, “Freeze Alert” will flash
on the bottom of the display screen.
The Freeze Protection check box on the Setup
screen should always be checked (enabled) to
protect equipment from freeze damage. The
circulation pump is covered by freeze protection
as long as this check box is checked.
For all other equipment, Freeze Protect must
also be specified on the individual device
manager screen. Some devices default to
freeze protect.
By default, heater freeze protect is unchecked;
the heater will not fire during a freeze alert. If
freeze protection is checked, the heater will fire
when the water temperature drops to 33° F.
During Freeze Alert:
• In the pool/spa combo and pool/spa
separate configurations, the system will
alternate between activating the spa and
the pool equipment every 15 minutes.
• In spa only and pool only configurations,
the equipment will alternate for 15 minutes
on and 15 minutes off.
•Blowers will run for five minutes every
half hour.
• No lighting (pool, spa, landscape, etc.)
will activate.
Understanding Eos System Functions
Device Setup
Scenes & Shortcuts
Owner Info
Polaris Info
Standby
Freeze Protection
Temperature Fahrenheit
Date Aug 03, 2004
Time 02:04pm
Left or right
arrow keys will
change screen
Setup
Tue, Aug 03 2:04 pm
To adjust display settings,
press and together.
Air 60 Water 60
Tue, Aug 03 2:04 pm
Cleaner Pump Manager
Duration Remaining
04h 00m 00h 00m
Manual Control
Schedules
Cleaner Pump Off
Day Start Stop
off12:00p 12:00p
off12:00p 12:00p
off12:00p 12:00p
off12:00p 12:00p
Off
Freeze Protect
Air 60Water 71

Alerts and Alarms
The following alert conditions will sound the audible alarm in addition to flashing the alert
message at the bottom of the display screen.
The following Alerts are flashing messages only.
Device Associations, Safety Delays and Lockouts
Some equipment is dependent on other equipment for proper operation. The rules that
govern these dependencies or associations are referred to as Device Manager Rules.
Manually activated devices are subject to these rules, meaning that even though a device
turned is “on,” it may not activate unless all the rules are met. The device manager rules
and other safety functions are listed below.
Heater
When activated (turned on manually or by a schedule), the heater will only fire
(indicated by flame on display) if the circulation pump is on and the temperature
setpoint is above the current temperature reading.
There is a 45-second operational delay at initial startup of the heater. Once the heater
is active and the desired temperature is reached, the heater will turn off and remain
off until the temperature falls two degrees below the setpoint. This prevents the heater
from short cycling (i.e., turning on and off in rapid succession).
16
E
Alert
Pool High Temperature
Pool Low Temperature
Spa High Temperature
Spa Low Temperature
Wireless Remote Battery Low
WM#1 High PH Alert
WM#1 Low PH Alert
WM#1 High ORP Alert
WM#1 Low ORP Alert
WM#1 PH Overfeed
WM#1 ORP Overfeed
WM#1 Feeder Empty
Alert
WM#2 High PH Alert
WM#2 Low PH Alert
WM#2 High ORP Alert
WM#2 Low ORP Alert
WM#2 PH Overfeed
WM#2 ORP Overfeed
WM#2 Feeder Empty
Alert
Freeze Alert
WM#1 No Flow
WM#1 2 Minute Flow Delay
WM#1 Clean PH Sensor
WM#1 Cal PH Sensor
WM#1 Clean ORP Sensor
WM#2 No Flow
WM#2 2 Minute Flow Delay
WM#2 Clean PH Sensor
WM#2 Cal PH Sensor
WM#2 Clean ORP Sensor
Solar Purge Delay
Solar Panel Temp Too Low
Spa Has Reached Set Temp
Alert
Cleaner Requires Pool Mode
Standby Mode
CPC-ACT Comm Failure (Cable/Activator)
CPC-WM1 Comm Failure (Watermatic)
CPC-WM2 Comm Failure
SCB Comm Failure
X10 Comm Failure
Valves Turning
Heater Cooling Down
91 Check Salt
92 Chlorinator No Flow
Check Chlorinator

E
17
After the heater shuts down, it enters a 2-minute cool down period. Heater Cooling
Down will be displayed on the screen. If the filter pump is shut down during the cool
down, the pump will remain on until the delay is finished and an hourglass will be
displayed next to the pump on the screen.
Cleaner Booster Pump
The pool cleaner will only activate when the system is in the pool mode (i.e., water
circulating to the pool) as it requires water circulation to function correctly. Cleaner
Requires Pool Mode is displayed if cleaner schedule requires circulation mode
adjustment.
There is a 1-minute prime delay to ensure the water is flowing to the booster pump.
The display will read Prime Delay during this delay.
If the filter pump is turned off while the cleaner booster pump is running, the
controller will automatically shut down the booster pump. The system recognizes that
the booster pump cannot run without the circulation pump.
If the booster pump cleaner is active and spa or spa spillover mode is entered the
booster pump will shut down and be locked-out. When the spa or spa spillover mode
is cancelled, the booster pump schedule will resume.
Spa Drain
The spa drain can only be activated on the Service screen.
Valves
Valves Turning is displayed whenever a valve (pool to spa, spa to spillover, solar,
etc.) is signaled to rotate. There is a 15 second delay during which the filter pump is
shut off. The pump is reactivated when the valves have stopped turning.
Solar Heating Systems
When solar heating is initiated and there is a booster pump cleaner on the system,
the booster pump will shut down and be locked-out for a 2-minute Solar Purge Delay
to allow water to be purged from the solar collectors. When the delay is complete, the
booster pump is reactivated.
When equipment is manually activated:
Existing schedules will be overridden. Remember to shut down the equipment, otherwise,
the equipment will continue to run until the next scheduled shut down or time-out
specified in the device setup.
If spa mode is not turned off, only the water in the spa will be filtered and the pool cleaner
will be disabled.
Turning off the filter pump does not reset valves to pool mode. The valves will
automatically return to pool mode after 6 hours.
Communication Failures
Communication failure messages (CPC-ACT Comm Failure, X10 Comm Failure, etc.)
are displayed when there is a communications failure between the command center and
the system components. Check connections or reposition the remote or antenna
and try again.

With the basic system in place, optional components such as remote controls, sanitizing
controllers, lighting controls, and even home appliance controls can be added at any time
to customize the pool or expand the system capabilities.
Remote Controls
Eos can be controlled remotely by the Eos Wireless Remote or the In-House Panel
remote. Limited system control is also available with the Shortcut remote which can be
mounted spa-side or as an in-house panel.
Each remote has its own Setup screen where display adjustments can be made. To
access this screen for either the Wireless or In-house Panel remote, press the left and
right arrow keys of the remote keypad simultaneously.
Wireless Remote
Battery charge level and signal
reception are indicated at the top of
the display screen. The battery must be
charged for at least five hours before the
initial use. To ensure a full charge, always
store the remote on the charger when not
in use. An animated scrolling battery
symbol on the display indicates the
battery is charging.
Software Version provides access to
current system software information.
Remote device settings, including the
unique remote channel setting, are listed
on the Network Settings screen
Shutdown turns off the remote. Useful to
conserve battery life. Press any key to
reactivate.
When checked, Audible Alarm enables the
alarm in this remote device to signal when
an alert condition exists.
If Spa Temp Notify is checked, “Spa Has
Reached Set T
emp” will be displayed when
the water temperature in the spa reaches
its designated setpoint.
Access Code is a security feature
available on the remote control devices.
When activated, system change
capabilities are limited to authorized users.
18
E
Using Optional Components
Wireless Remote Setup
Software Versions
Network Settings
Shutdown
Audible Alarm
Spa Temp Notify
Access Code
Contrast Adjust
Backlight Adjust
Sleep Timeout 3 min
Signal
Strength
Full Battery
Charge
