Polaroid FLM-3232 User manual

32” LCD Television with NTSC/ATSC Tuner
FLM-3232

ENGLISHENGLISH
1
FCC
Federal Communications
Commission Statement
This equipment has been tested and found to comply with the limits of a class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
1. Reorient/Relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit which is different from what the receiver is
connected to.
4. Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the manufacturer
responsible for compliance could void the user authority to operate the
equipment.

2
Warnings and Precautions
Warnings and Precautions
To reduce the risk of re or electric shock, do not expose this equipment to rain or moisture.
This symbol is intended to alert the user to avoid the risk of electric shock.
This equipment must not be disassembled by anyone except qualied service personnel.
This symbol is intended to alert the user to the presence of important operating and
maintenance instructions in the literature accompanying the appliance.
▪ TO REDUCE THE RISK OF ELECTRIC SHOCK,
▪ DO NOT REMOVE COVER (OR BACK).
▪ NO USER-SERVICEABLE PARTS INSIDE.
▪ REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Use of controls, adjustments or performance of procedures other than those specied herein
may result in hazardous radiation exposure.
CAUTION
Important Safety Instructions
To prevent any injuries, the following safety precautions should be observed in the installation, use,
servicing and maintenance of this equipment.
Before operating this equipment, please read this manual completely, and keep it nearby for future
reference.
WARNING
▪ Do not place the equipment on any uneven or unstable carts, stands, tables, shelves etc.
The equipment may fall, causing serious injury to children or adults and serious damage
to the equipment itself.
▪ Use only a cart or stand recommended by the manufacturer. This equipment and
recommended cart or stand should be handled with care. Quick stops, excessive force,
and uneven surfaces may cause the equipment and cart/stand to overturn.
▪ Do not disable the 3-wire grounding type plug. The grounding pin on the 3-prong plug is
an important feature. Removing the grounding pin will increase the risk of damaging the
equipment.
▪ If you can not t the plug into the electrical outlet, contact an electrician to install a
grounding outlet.
▪ Always operate this equipment from the type of power source indicated on the rear of the
serial/model plate.
This symbol indicates caution points.
This symbol indicates actions that should not be done.
This symbol indicates actions that must be performed.

ENGLISHENGLISH
3
Warnings and Precautions
▪ Never overload wall outlets and extensions.
▪ Use and handle the power cord with care. Do not place any heavy objects on the AC
power cord.
▪ Do not pull the AC power cord. Do not handle the AC power cord with a wet hand.
▪ Do not touch the power cord and antenna cable during lightning.
▪ Remove the plug from the wall outlet, if the equipment will not be used for a long period
of time.
▪ Do not place, use or handle this equipment near water.
▪ Never expose the equipment to liquid, rain, or moisture.
Seek for service if any of the above is spilled into the equipment.
▪ Do not expose the equipment to extreme temperature or to direct sunlight, as the
equipment may heat up and suffer damage.
▪ Do not install the equipment near any heat sources such as radiators, heat registers,
stoves, or any other apparatus that might produce heat.
▪ Do not attempt to service the equipment yourself.
▪ Opening and removing the covers may expose you to dangerous voltage or other
hazards and may void your warranty. Refer service to qualied personnel.
▪ Do not place or drop any other objects on top.
▪ Do not insert anything into the ventilation holes of your equipment.
Inserting any metal or ammable objects may result to re or electric shock.
▪ Do not place the equipment on uneven or unstable carts, stands, tables, shelves etc. The
equipment may fall, causing serious injury to children or adults and serious damage to
the equipment itself.
Always place the equipment on the oor or on a surface that is sturdy, level, stable and
strong enough to support the weight of the equipment.
▪ Do not block any ventilating openings. Leave an open space around the equipment.
Never place the equipment :
on a bed, sofa, rug, or any other similar surfaces; too close to drapes/curtains/walls, in a
bookcase, built-in cabinet, or any other similar places that may cause poor ventilation.
▪ Always remove the power cord from the outlet before cleaning the equipment.
▪ Never use liquid or aerosol cleaners on the equipment.
Clean only with a soft dry cloth.

4
Warnings and Precautions
Outdoor Antenna Safety Instructions
Antenna lead-in wire
Antenna discharge unit
(NEC section 810-20)
Grounding conductors
(NEC section 810-20)
Ground clamps
Power service grounding
(NEC Art250 part H)
Ground clamps
Electric service
equipment
NEC : National Electrical code
If an outdoor antenna is connected, follow the precautions below:
EXAMPLE OF OUTDOOR ANTENNA GROUNDING
Section 810 of National Electrical Code (NEC) provides information with respect to proper grounding of the
mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding
conductors, location of antenna discharge unit, connection to grounding electrodes, and requirements for
the grounding electrode.
▪ An outdoor antenna should not be located in any area where it could come in contact with
overhead power lines, or any other electric light or power circuits.
▪ When installing an outdoor antenna system, extreme caution should be taken to prevent
contact with power lines. Direct contact with power lines may be fatal and should be avoided
at all costs.

ENGLISHENGLISH
5
TABLE OF CONTENTS
Federal Communications Commission Statement .......................... 1
Warnings and Precautions
Important Safety Instructions....................................................................................... 2
Antenna Safety Instructions......................................................................................... 4
Chapter 1 Introducing the LCD TV
Key Features ............................................................................................................... 6
Package Contents ....................................................................................................... 7
Setting Up Your LCD TV.............................................................................................. 8
Your LCD TV.............................................................................................................. 10
Your Remote Control ................................................................................................. 12
Chapter 2 Installing the LCD TV
Connecting a TV Cable or an Antenna ...................................................................... 14
Connecting a VCR..................................................................................................... 18
Connecting a Video Camera or Play Station ............................................................. 19
Connecting a DVD Player.......................................................................................... 20
Connecting a Digital TV Cable Box or Digital Satellite Receiver ............................... 22
Connecting an AV Equipment with HDMI Connector................................................. 23
Connecting an AV Equipment with DVI Connector .................................................... 24
Connecting a PC........................................................................................................ 25
Connecting an Audio Receiver or a Dolby Digital 5.1 Sound System........................ 26
Chapter 3 USING THE FEATURES
Using Picture-In-Picture...................................................................................27
Wide Screen Viewing ......................................................................................29
Operating the Menu........................................................................................30
Setting up the HDTV Function ..........................................................................32
Customizing the VIDEO Settings ......................................................................35
Customizing the AUDIO Settings ......................................................................36
Customizing the SETUP Settings......................................................................37
Using the V-CHIP Settings ...............................................................................39
Using the Parental Settings.............................................................................. 41
Customizing the TV Settings............................................................................42
Specications......................................................................................................... 43
Chapter 4 Programming your Remote Control
Introduction................................................................................................................ A
Programming a Device ............................................................................................. A
Troubleshooting ......................................................................................................... B
Manufacturer’s Codes ............................................................................................... C

6
Chapter 1 Introducing the LCD TV
Various Audio/Video terminals for external equipment connection
▪ 2 set of composite A/V input terminals
▪ 1 set of S-VIDEO terminals
▪ 2 set of component Video input terminals
▪ 1 VGA/ Audio input terminal
▪ 1 HDMI/Auido input terminal
▪ 1 sets of Audio(L/R) output terminals
▪ 2 SPDIF output terminal (Optical x 1 /Coaxial x 1)
▪ 1 Headphone terminal
The built-in TV tuner to receive HD ATSC
▪ This function allows the reception of HD broadcasting without the addition of a set top
box.
High Definition Multimedia Interface (HDMI)
▪ High Denition Multimedia Interface (HDMI) is a small, user-friendly interconnect that
can carry up to 5 Gbps of combined video and audio in a single cable. This system
eliminates the cost, complexity and confusion of multiple cables used to connect
current A/V systems.
HDTV Component Video Inputs
▪ Offers the best video quality for DVD(480p) and digital set-top-box (HD1080i, 720p)
connections.
3D Digital Noise Reduction
▪ This function can digitally reduce image noise to provide better picture quality.
Film-Mode Detection (3:2 Reverse Pull Down)
▪ This function can automatically detect content derived from lm and adjust the
interlacer’s frame matching to provide a more natural-looking, clearer image of the
moving picture.
PIP Function
▪ Provides viewing of two programs simultaneously, in either picture-in-picture mode or
picture-on-picture (side by side) mode.
Chapter 1
Introducing the LCD TV
Key Features

ENGLISH
7
Chapter 1 Introducing the LCD TV
Make sure all of the above contents are included in the package. If you are missing
any items, please contact the Polaroid customer service department.
 LCD TV
Make sure all of the following contents are included.
 Power Cord
These items are all you need to set up and operate the LCD TV in its basic conguration.
Package Contents
 VIDEO Cable Remote Control/
AA Batteries x 2
 User’s Manual
 Bottom Stand /
Screw Driver and 6 Screws
 Component Cable
 Quick Start Guide
 AUDIO Cable  Warranty Card

8
Chapter 1 Introducing the LCD TV
Attach the Stand
If you prefer to mount your new Polaroid TV on a wall instead of attaching it to the stand, please reference
the instructions included in the wall mounting kit (not included).
IMPORTANT: Attach the Stand to the TV with the bottom foam packaging material still attached.
Read all instructions before continuing with the stand installation.
a) Lift foam packaging material from the top of the TV out of the box.
b) Lift TV out of box, with the bottom foam packaging material still attached, and place onto a stable surface.
c) Remove the protective bag from the LCD unit, but DO NOT remove the bottom foam packaging material.
d) Locate the place on the back of the TV to attach the stand. Secure the stand to the LCD with all six screws.
Setting Up Your LCD TV

ENGLISH
9
Chapter 1 Introducing the LCD TV
Do not use caustic cleaners (porcelain, stainless steel, toilet, or oven cleaner
etc.) on the remote, as it may suffer damage.
 Use a supplied antenna cable to connect the VHF/UHF signal to the LCD TV’s ANT. terminal
(refer to page17).
 Connect the AC power cord at the back of the TV and connect the power cord to wall outlet.
 Insert the 2 batteries supplied in remote control.
 Connect other an external A/V device (refer to page14-26).
Step1 Slide the back cover up to open the
battery compartment of the remote
control.
Step2 Insert two AA size batteries.
Make sure to match the (+) and
( - ) ends of the batteries with
the (+) and ( - ) ends indicated
in the battery compartment.
Slide the cover back into place.

L
R
VIDEO1 IN
VIDEO
AUDIO
10
Chapter 1 Introducing the LCD TV
Your LCD TV
LED
The LED light indicates when the LCD TV is
activated.
IR
Infrared
Receiver
MENU
Press once to display the OSD (on screen
display), press again to turn the OSD off.
VOLUME▲▼
Adjusts the volume up and down.
Selects the main-menu item and change
values for items when in the OSD mode.
Turns the LCD TV on and into standby mode.
CHANNEL▲▼
Scans up and down through channels.
Selects sub-menu item when in the OSD
mode.
INPUT
Chooses from different input signal sources.
Front/Right Side View and Controls
EARPHONE
Connects to the external
headhone for private
listening.
VIDEO1 IN
Connects to the composite
Video and Audio output jacks
on external video equipment.

HDMI IN
AUDIO
L R L R L R
L R
L
R
L R
L R
AUDIO
VGA IN
VIDEO2 IN
VIDEO AUDIO
S-VIDEO IN
S-VIDEO AUDIO
YPbPr1 IN
AUDIO OUT
STEREO DIGITAL
OPTICAL
COAXIAL
TV
CABLE
HDTV
AIR
VHF/UHF IN
Y Pb Pr AUDIO
YPbPr2 IN
Y Pb Pr AUDIO
ENGLISH
11
Chapter 1 Introducing the LCD TV
Rear View and Jacks
VHF/UHF IN-TV-CABLE
Connects RF input from VHF/UHF antenna or cable.
VGA IN
Connects the PC, or other AV equipment with VGA and
AUDIO(L/R) output jacks.
YPbPr1 IN/YPbPr2 IN
Connects to the DVD player, Digital Set-Top-Box, or other AV
equipment with component(YPbPr) video and audio output jacks.
VIDEO2 IN
Connects to the composite VIDEO and AUDIO(L/R) output jacks on external video equipment.
HDMI IN
Connects the all digital AV equipment with HDMI connector.HDMI supports enhanced,
high-denition video and two-channel digital audio. The AUDIO(L/R) of HDMI IN is for
DVI connection.
AC IN
Connects to the AC power cord.
S-VIDEO IN
Connects to the S-VIDEO and AUDIO(L/R) output jacks on external
video equipment.
AUDIO OUT-STEREO
Connects to the AUDIO(L/R) input jacks on AV equipment.
AUDIO OUT-DIGITAL-OPTICAL/COAXIAL
Connects to the OPTICAL AUDIO jack on the digital/standard 5.1
audio system.
VHF/UHF IN-HDTV-AIR
Connects RF input from VHF/UHF antenna or cable
to receive high/standard denition television.

12
Chapter 1 Introducing the LCD TV
Your Remote Control
Turns the LCD TV on and off.
SET Remote control universa code setup.For
more information on setting up your
remote control, please see the
“Programming Your Remote Control”
section.
TV Controls this LCD TV.
DVD Controls DVD player or Video player.
CBL Controls Cable Converter or Satellite
Receiver.
AUX Controls Audio Amplier
0-9/ENTER Pressing a number selects a channel.
Following selection, pressing ENTER
activates the channel, or channel
activates automatically in 3 seconds.
INPUT Pressing INPUT to display a source list,
use ▲▼buttons to select the video
equipment connected to the video inputs
of your LCD TV: TV/HDTV/VIDEO1/
VIDEO2/VIDEO3/VIDEO4/VIDEO5/
VIDEO6/COMPUTER.
▪ In HDTV mode, use with 0-9 and
ENTER buttons to select a digital
channels.
LAST Returns to previously selected channel.
CH+- Change channel up and down.
VOL+- Increases and decreases volume.
MUTE Pressing once mutes audio. Pressing
again restores audio.
2
5
6
7
8
1
4
9
3
10
This package includes a Polaroid remote that enables control of up to four devices.
To select a device, simply select one of the following device mode controls: TV, CBL/SAT, DVD/VCR,
or AUDIO.
1
2
2
3
2
4
2
5
2
6
2
7
2
8
2
9
10

ENGLISH
13
Chapter 2 Installing the LCD TV
Effective range:
The remote can control the LCD TV from up to 5m away, if pointed directly at the receiver.
MENU Displays the OSD menu on the screen.
INFO Pressing once displays a variety of
information such as the current channel
and the input source.
▲▼►◄,OK Cycles through OSD options and selects
individual menu items. OK conrms
option settings.
OK In HDTV mode, pressing OK to display a
digital channel list.
GUIDE In HDTV mode, pressing GUIDE
displays the Program Guide on the
screen.
EXIT Exits the OSD menu.
► Other device function keys
   
SLEEP Cycles through the LCD TV sleep time:
OFF/30/60/90/120 mins.
CAPTION Cycles through the Closed Caption:
OFF/CC1/CC2/CC3/CC4/TT1/TT2/TT3/
TT4.
ASPECT Cycles through Wide mode settings:
NORMAL/FULL/WIDE/ZOOM.
PIP Turns PIP/POP on and off.
11
14
18
17
12
13
15
16
20
19
11
12
13
14
15
16
17
18
19
20

14
Chapter 2 Installing the LCD TV
Chapter 2
Installing the LCD TV
Refer to the owner’s manual of any external equipment to be connected.
When connecting any external equipment, do not connect any AC power cords to wall outlets
until all other connections are completed.
Antenna Connection
The antenna requirements for good color TV reception are more important than those for a black &
white TV reception. For this reason, a good quality outdoor antenna is strongly recommended.
The following is a brief explanation of the type of connection that is provided with the various antenna
systems.
75-ohm coaxial cable (round)
F-type connector
300-ohm twin-lead cable (flat)
■ A 75-ohm system is generally a round cable (not included) with F-
type connector that can easily be attached to a terminal without
tools.
■ A 300-ohm system is a flat twin-lead cable (not included) that can
be attached to a 75-ohm terminal through a 300-75-ohm adapter
(not included).
Connecting a TV Cable or an Antenna

ENGLISH
15
Chapter 2 Installing the LCD TV
OUT IN
300-ohm twin-
lead cable
300-ohm twin-
lead cable
75-ohm
coaxial cable
UHF
Antenna
VHF
Antenna
Combiner
(not included)
A. Combination VHF/UHF antenna
300-ohm twin-
lead cable
75-ohm
coaxial cable
VHF/UHF
Antenna
VHF/UHF
Antenna
300/75-ohm adapter
(not included)
B. Separate VHF and/or UHF antennas
Use one of the following two diagrams when connecting an outdoor antenna.
A: Shows how to use a VHF/UHF combination outdoor antenna.
B: Shows how to use a separate VHF and/or UHF outdoor antenna.

16
Chapter 2 Installing the LCD TV
This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the
National Electrical Code (NEC) that provides guidelines for proper grounding and, in particular,
species that the cable ground shall be connected to the grounding system of the building
accurately, or as close to the point of cable entry as possible. Use of this TV for other than
private viewing of programs broadcasted on UHF, VHF or transmitted by cable companies for
the use of the general public may require authorization from the broadcast/cable company, and/
or program owner.
A
IN
B
OUT
Cable TV Line
2 set signal
splitter
(not included)
RF switch
(not included)
Cable TV converter/
descrambler
(not included)
Cable TV (CATV) Connection
■ The RF switch (not included) is required to provide two inputs (A and B). Setting
the RF switch to position A allows viewing of all unscrambled channels by using
the TV channel keys.
■Setting the RF switch to position B allows viewing of all scrambled channels via
the converter/descrambler by using the converter channel keys.
■ A 75-ohm coaxial cable connector is built into the set for easy hookup.
When connecting the 75-ohm coaxial cable to the set, connect the 75-
ohm cable into the ANT. terminal.
■ Some cable TV companies offer premium pay channels. Since the
signals of these premium pay channels are scrambled, a cable TV
converter/descrambler is generally provided to the subscriber by the
cable TV company.
This converter/descrambler is necessary for normal viewing of scrambled channels.
(Set your TV to channel 3 or 4, typically one of these channels is used. If this is unknown,
consult your cable TV company.)
For more specic instructions on installing cable TV, consult your cable TV company.
One possible method of connecting the coverter/descrambler provided by your cable TV
company is shown in the diagram below.
VHF/UHF IN

ENGLISH
17
Chapter 2 Installing the LCD TV
 METHOD A:
Use a supplied antenna cable to connect the NTSC signal to the LCD TV’s TV CABLE
terminal.
METHOD B:
Use a supplied antenna cable to connect the ATSC signal to the LCD TV’s
HDTV AIR terminal.
 Connect the AC power cord at the back of the TV and connect the power cord to wall
outlet.
 Press the button on the remote to turn on the LCD TV.
Always disconnect the LCD TV from the main voltage when the LCD TV will
not be used for a long period of time. The POWER button on the front panel
is only used for switching the LCD TV into standby, it does not disconnect
the device from the main voltage. To completely disconnect the main
voltage, please remove the power plug from the socket.
 Press the Input button on the remote to
display the Input List. Use the ▲► buttons to
select TV( METHOD A), or HDTV (METHOD
B), and press the OK button.
TV
CABLE
HDTV
AIR
VHF/UHF IN
A
B
TV
CABLE
HDTV
AIR
VHF/UHF IN
Input
TV(CABLE/AIR) 
HDTV (CABLE/AIR)
VIDEO1 (SIDE)
VIDEO2 (REAR)
VIDEO3 (S-VIDEO)
VIDEO4 (YPbPr1)
VIDEO5 (YPbPr2)
VIDEO6 (HDMI)
COMPUTER (VGA)

A B
HDMI IN
AUDIO
L R L R L R
L R
L
R
L R
L R
AUDIO
VGA IN
VIDEO2 IN
VIDEO AUDIO
S-VIDEO IN
S-VIDEO AUDIO
YPbPr1 IN
AUDIO OUT
STEREO DIGITAL
OPTICAL
COAXIAL
TV
CABLE
HDTV
AIR
VHF/UHF IN
Y Pb Pr AUDIO
YPbPr2 IN
Y Pb Pr AUDIO
Rear of TV
AUDIO Cable
S-VIDEO Cable
AV Cable
18
Chapter 2 Installing the LCD TV
METHOD A:
Use a composite cable to connect the VCR’s composite video/audio jacks to the LCD TV’s
VIDEO2 IN jacks.
METHOD B:
Use an audio cable to connect the VCR’s audio output jacks to the LCD TV’s audio
inputs. Use a S-Video cable to connect the VCR’s s-video output jack to the LCD TV’s
S-VIDEO IN input jack.
Connect all AC power sources, before turning on the power switch of the LCD TV or
other connected equipment.
Press the button on the remote to turn on the LCD TV.
To watch a videotape, press the Input button on the remote to select
VIDEO2( METHOD A), or VIDEO3 (METHOD B).
Connecting a VCR

A
B
HDMI IN
AUDIO
L R L R L R
L R
L
R
L R
L R
AUDIO
VGA IN
VIDEO2 IN
VIDEO AUDIO
S-VIDEO IN
S-VIDEO AUDIO
YPbPr1 IN
AUDIO OUT
STEREO DIGITAL
OPTICAL
COAXIAL
TV
CABLE
HDTV
AIR
VHF/UHF IN
Y Pb Pr AUDIO
YPbPr2 IN
Y Pb Pr AUDIO
Rear of TV
L
R
VIDEO1 IN
VIDEO
AUDIO
Right Side
or
AUDIO Cable
S-VIDEO Cable
AV Cable
ENGLISH
19
Chapter 2 Installing the LCD TV
METHOD A:
Use a composite cable to connect the video camera’s or play station’s composite video/
audio jacks to the LCD TV’s VIDEO2 IN jacks or VIDEO1 IN jacks.
METHOD B:
Use an audio cable to connect the video camera’s or play station’s audio output jacks to
the LCD TV’s audio inputs. Use a S-Video cable to connect the video camera’s or play
station’s s-video output jack to the LCD TV’s S-VIDEO IN input jack.
Connect all AC power sources, before turning on the power switch of the LCD TV or
other connected equipment.
Press the button on the remote to turn on the LCD TV.
To watch a video vis camera or play station, press the Input button on the remote to
select VIDEO2/VIDEO1( METHOD A), or VIDEO3 (METHOD B).
Connecting a Video Camera or Play Station
Not all cameras have the ability to connect to a TV. Please check your video camera
user guide for compatibility.
PLAY STATION
