Polaroid XGA 360 User manual

Polaroid
Polaview
XGA 360
Super-Bright
Portable
LCD Projector
Full-featured,
universal
presentations
with XGA clarity.

The Polaroid XGA 360 defines
a unique new class of projectors
that produces the brightest
presentations available in the
portable XGA market. As our
most full-featured model to date,
the XGA 360 outperforms the
competition with a Universal
model, Digital Keystone
Correction, image magnification
and panning for sharp, clear
images. This amazing new
addition to the award-winning
Polaroid line boasts an acclaimed
set of features, unwavering
reliability and easier-than-ever
set-up and operation.
Universal Model for
International Presentations
The advanced Universal model
of the XGA 360 gives you the
flexibility to bring your
presentations with you whenever
you travel internationally. With
a seven language universal manual
and three power cords, you can
present with clarity and style
worldwide. And because of its
13 pound compact portability,
you can carry it on to most airlines,
protecting it from rough handling
or extreme temperature changes.
Our Brightest Projector
to Date with Advanced
Sharpness and Clarity
Featuring 2000 lumens, the
Polaroid XGA 360 is bright
enough for virtually any
presentation environment.
With a 190 watt UHB Ultra
High Performance lamp and a
high-efficiency optical system,
your presentation will have an
advanced level of brightness and
improved image quality. And
with its 1024 x 768 resolution,
you’ll get true XGA clarity and
sharpness with a 1:1 match to
XGA computer monitors.
Our specially designed optics
provide you with more vibrant
colors, superior focus and
sharper, brighter images than
ever before.
Full-Featured Presenting
Our most full-featured projector,
the XGA 360 lets you adapt your
presentation to any viewing
situation. The magnification,
panning, picture-in-picture and
video remote freeze functions,
give you the capability to meet
all your presentation needs.
The XGA 360 has the only
power zoom and focus to date,
and with a projection distance
from 3.6 to 36 feet, you can
magnify areas of interest for
closer viewing.
Unique Digital Keystone
Correction
The Polaroid XGA 360 provides
you with a unique Digital
Keystone Correction mechanism.
With its advanced image
compensation you’ll get
distortion free images so that each
image is captured accurately. And
it eliminates the need to raise and
lower the projector to obtain a
uniform image that fits the screen.
So regardless of projection screen
or surface, your images will
remain sharp and consistent in
size from start to finish.
Ready for any Type of
Presentation
The Polaroid XGA 360
Projector’s superior quality,
high brightness and portability
make it ideal not only for sales
presentations, training and
work group sessions, but for
presentations to large groups as
well. Great for business, hotels,
sales, education, scientific and
much more, you’ll find that the
XGA 360 is designed to increase
the productivity of work groups
and the effectiveness of presenters.
Specifications
Display Technology
1.3" TFT Polysilicon Panel X3
Resolution
1024 x 768 (XGA)
Aspect Radio
4:3
Brightness
2000 Lumens
Colors
16.7 Million
Contrast Radio
200:1
Lens
f1.7-2.3
Power Zoom: 1:1.3
Power Focus: 49-64mm
Image Size
2.5 ft. to 25 ft. (0.76m to 7.6m)
Projection Distance
3.6 ft. to 36 ft. (1.1m to 11m)
Keystone Correction
Digital +/- 10°
Projector Lamps
Type 190 watt UHB
Input Signal
VGA, SVGA, XGA, SXGA,
MAC13", MAC16", NTSC,
NTSC 4.43, PAL, M-Pal,
N-PAL, SECAM, S-Video,
Composite Video
Scanning Rates
Horizontal Sweep Frequency:
25 to 80 kHz
Vertical Frequency: 56-120 Hz
Speakers
1.2 watts (2 Stereo Speakers)
Remote Control
Wireless infrared remote
with laser pointer
Audible Noise
40 db Maximum
Weight
13 Pounds (5.9 Kg)
Dimensions (W X H X L)
11.4" x 4.7" x 13.6"
(289mm x 119mm x 345mm)
Power Source
AC 100V-240V,50/60 Hz
Rated Input
320 watts
Safety Approvals
US: UL, FCC; Canada: C-UL;
Europe: CE, TUV
Limited Warranty
Standard parts and labor.
Refer to regional Polaroid office
for warranty period (does not
include lamp replacement).
Specifications subject to change without notice.
PID 109794 “Polaroid” and “XGA 360” are registered trademarks of Polaroid Corporation, Cambridge Mass. 02139. All other products may be trademarks of their respective owners. © 2000 Polaroid Corporation.
Printed in U.S.A. 2/00.
Features-at-a-glance
• 2000 lumen brightness
• 1024 x 768 XGA resolution
• 16.7 million colors
• Plug & Play RGB input (VESA
DDC 1/2B Compatible)
• Digital Keystone Correction
• Digital zoom (Image Magnification)
• Panning in image magnification
mode (display area moves)
• Freeze function on video image
• Picture-in-picture
• Power zoom and power focus
• Displays VGA, SVGA, XGA,
SXGA input signal
• USB jack for mouse
• Compatibility with all popular
Macintosh and Windows
based computers
• Portability (13 pounds) with
small footprint
• Remote control with
laser pointer
Polaroid XGA 360 Super-Bright Portable LCD Projector
The XGA 360’s control
panel makes full-featured
presentations fast and simple.
For More Information
Polaroid backs the XGA 360
Projector with a comprehensive
warranty and a customer
assistance toll-free number
(extended warranties available).
To learn more about this
projector, or the complete family
of Polaroid digital products,
including cameras, digital film
printers and digital film scanners,
call your authorized Polaroid
representative or dealer. Call us
or visit Polaroid on the Internet
at www.polaroid.com.
