Polk Audio AMR 90 Guide

Polk Audio Limited Warranty
Polk Audio, Inc. warrants to the original pur-
chaser only that this Polk Audio Loudspeaker
Product (the "Product") will be free from
defects in materials and workmanship for a
period of one (1) year from the date of orig-
inal retail purchase from a Polk Audio
Authorized Dealer. However, this Warranty
will automatically terminate prior to the expi-
ration of the one (1) year if the original retail
purchaser sells or otherwise transfers the
Product to any other party. The original retail
purchaser shall hereinafter be referred to as
“you.” To allow Polk Audio to offer the best
possible warranty service, please fill out the
Product Registration Card(s) and send it to
the Factory, at the address provided on the
Product Cards(s) within ten (10) days of the
date of purchase.
Defective Products must be shipped, together
with proof of purchase, prepaid insured to
the Polk Audio Authorized Dealer from
whom you purchased the Product, or to the
Factory at 2550 Britannia Boulevard, Suite
D, San Diego, California 92173. Products
must be shipped in the original shipping con-
tainer or its equivalent; in any case the risk
of loss or damage in transit is to be
borne by you.
If upon examination at the Factory or Polk
Audio Authorized Dealer it is determined
that the unit was defective in materials or
workmanship at any time during this
Warranty period, Polk Audio or the Polk
Audio Authorized Dealer will, at its option,
repair or replace this Product at no addition-
al charge, except as set forth below. All
replaced parts and Products become the
property of Polk Audio. Products replaced or
repaired under this warranty will be returned
to you, within a reasonable time, freight pre-
paid.
This warranty does not include service or
parts to repair damage caused by accident,
disaster, misuse, abuse, negligence, inade-
quate packing or shipping procedures, com-
mercial use, voltage inputs in excess of the
rated maximum of the unit, cosmetic appear-
ance of cabinetry not directly attributable to
Positioning Your Speakers for Best Performance
Placing the Subwoofer close to a wall or in a corner
reinforces Subwoofer response.
AMR90: Position the four Satellite speakers around your
usual sitting position: one speaker on each side of your com-
puter monitor, and two rear Satellites behind you. The rear
surround speakers come with brackets for wall mounting.
Adjusting and Setting Volume
Amplification for the AMR is in the Subwoofer. Select the
setting at which there is the perfect amount of bass response
for your taste:
Turn the system ON using the Master Power switch
on the Subwoofer.
Turn the on/off, volume knob to ON on the right
Satellite speaker.
Using a music CD, set the subwoofer volume with the
Subwoofer Volume knob.
AMR90 HOOKUP OPTIONS
FOLLOW ALL COLOR CODING
AMR90
High Performance
Surround Sound
Computer Speaker System

Adjusting and Setting Volume (continued)
Once this position is set, you can then use the Volume
Control located on the right Satellite to adjust system
volume and turn the system on and off.
Set the front/rear balance with the Fader knob (located
behind the volume control) on the Right Satellite speaker.
Troubleshooting
Weak sound, no sound, bad sound?
Is the Green LED light (located on the right Satellite
speaker) ON? Make sure the speakers are connect-
ed to the AC adapter and the power button is
pressed ON.
Is there output from the soundcard? Connect the
speakers to an alternate audio source, such as the
headphone jack of a CD player or radio. If the speakers
produce sound, the problem is probably with your sound-
card. Recheck your soundcard installation and setup
procedure. Consult the soundcard’s manual.
Check the “mute”and “volume”controls on your
soundcard or media player software and keyboard.
Are the speakers connected properly? Make sure
the plugs are securely connected in the proper location
according to their colorcoding and the diagram on
the front of this manual. Make sure the speaker wires
with the white stripes are connected to the (+) speaker
terminals on the subwoofer.
Polk Audio, Inc.
5601 Metro Dr 1-800-377-7655
Baltimore, MD 21215 www.polkaudio.com
Have questions? Call the friendly Customer Service Representatives at Polk Audio, the Speaker Specialists:1-800-377-7655. To speak to someone, call between 9am and 6pm EST. After hours, leave us
a message, and we’ll (really) call you back. Or, email us at [email protected]. Log on to www.polkaudio.com to register your new speakers, join Club Polk, get on the mailing list for the Polk Audio
quarterly newspaper, and pick up some nifty Polk logowear and stuff. Let us know what you think about these speakers!
Frequency response 40 Hz–18 kHz
Input sensitivity for maximum output (volts) 0.50
S/N ratio >90 dB
Max SPL @ 0.5 m 100 dB
defect in materials or workmanship, or
service, repair, or modification of the
Product which has not been authorized or
approved by Polk Audio. This warranty
shall terminate if the Serial number on the
Product has been removed, tampered with
or defaced.
This warranty is in lieu of all other
expressed Warranties. If this Product is
defective in materials or workmanship as
warranted above, your sole remedy shall
be repair or replacement as provided
above. In no event will Polk Audio, Inc. be
liable to you for any incidental or conse-
quential damages arising out of the use or
inability to use the Product, even if Polk
Audio, Inc. or a Polk Audio Authorized
Dealer has been advised of the possibility
of such damages, or for any claim by any
other party. Some states do not allow the
exclusion or limitation of consequential
damages, so the above limitation and
exclusion may not apply to you.
All implied warranties on this Product are
limited to the duration of this expressed
Warranty. Some states do not allow limita-
tion on how long an implied Warranty lasts,
so the above limitations may not apply to
you. This Warranty gives you specific legal
rights, and you also may have other rights
which vary from state to state.
This Warranty applies only to Products pur-
chased in the United States of America, its
possessions, and U.S. and NATO armed
forces exchanges and audio clubs. The
Warranty terms and conditions applicable
to Products purchased in other countries are
available from the Polk Audio Authorized
Distributors in such countries.
Safety Warning: Electrical equipment may be hazardous if misused.
An adult must always supervise operation of this product. Use only the
AC adapter specifically designed for your AMR System. Polk Audio, Inc
cannot be responsible for damage caused by other AC adapters. Pro-
tect speakers from dampness and liquids. Do not access the interior of
any electrical product, and do not permit children to handle any cables.
