About this Guide
This document explains installation of the Polycom SpectraLink 6000
System (MCS300) Remote T1 Module. The installation process
connects the SpectraLink 6300 MCU Primary Shelf in one location
with an Expansion Shelf in a remote location, via T1 facilities.
Polycom Model Numbers
This document covers the following registered model numbers:
JPI300, MCS300, RCC400, RCO400, RCU100, RCU200, RCU201
Related Documents
SpectraLink 6300 MCU: Facility Preparation (1725-36121-001)
SpectraLink 6300 MCU: Installation (1725-36122-001)
SpectraLink 6300 MCU: Maintenance and Diagnostics
(1725-36123-001)
SpectraLink 6300 MCU: Operator’s Console
(1725-36125-001)
Installing the Outdoor Base Station
(1725-36127-001)
Available at
http://www.polycom.com/usa/en/support/voice/900mhz/spectral
ink_6300_mcu.html
LinkPlus Interface Guide
(1725-361xx-001 where xx indicates a
number corresponding to the type of PBX)
.
Available at
http://www.polycom.com/usa/en/support/voice/wi-
fi/pbx_integration.html

SpectraLink 6300 MCU: T1 Remote Module Installation: SpectraLink 6000 System
PN: 1725-36126-001_K.doc
4
Customer Support
Polycom wants you to have a successful installation. If you have
questions please contact our Customer Support Hotline at
[phone]. The hotline is open Monday through Friday,
6 a.m. to 6 p.m. Mountain time.
For Technical Support: [email protected]
For Knowledge Base:
http://www.polycom.com/usa/en/support/voice/voice.html
For Return Material Authorization: [email protected]
Icons Used in this Document
This manual uses the following icons and conventions.
Caution! Follow these instructions carefully to avoid danger.
Note these instructions carefully.
Label This typeface indicates a key, label, or button on Polycom
hardware.

PN: 1725-36126-001_K.doc 5
Contents
0About this Guide ......................................................................3
Polycom Model Numbers..................................................................3
Related Documents.............................................................................3
Customer Support...............................................................................4
Icons Used in this Document ............................................................4
1Remote Installation Overview....................................................7
Remote Installation Steps (Overview) .............................................9
2Site Preparation......................................................................11
Required Materials Provided by Customer ..................................11
T1 Configuration Requirements .....................................................12
Check Components...........................................................................13
3Install T1 Remote Module at Local Site .....................................15
4Install System at Remote Site...................................................19
Survey Site..........................................................................................19
Install Shelves ....................................................................................19
Connect Power to Shelves................................................................20
Install Cards.......................................................................................20
Connect Cables to T1 Remote Module...........................................22
Connect Multiple Remote Shelves..................................................23
Connect Demarc Block RJ-21 Cables to Interface Modules .......25

SpectraLink 6300 MCU: T1 Remote Module Installation: SpectraLink 6000 System
PN: 1725-36126-001_K.doc
6
5Configure Remote System .......................................................27
Configure Remote Shelf ...................................................................27
Master Clock Configuration ............................................................28
Test System ........................................................................................29
6Site Certification .....................................................................31
7Installation Forms ...................................................................33
Site Preparation Checklist................................................................33
Base Station Location Worksheet....................................................35
Extension Assignments Worksheet................................................36
Customer Acceptance Form ............................................................37
8Safety and Regulatory Notices ................................................39
FCC Part 68 ........................................................................................40
9Index .....................................................................................43

PN: 1725-36126-001_K.doc
7
Remote Installation Overview
Networking the SpectraLink 6000 System allows installation of
expansion shelves at remote locations. T1 circuits are used to provide
the connection from the System Controller shelf to each Remote
Expansion shelf. As many as 19 expansion shelves may be supported
by the system, and up to 18 of these shelves may be installed in
remote locations from the System Controller shelf. The SpectraLink
6000 System (local site and remote site shelves) is administered as a
single system.
The following diagram shows an overview of a SpectraLink 6000
System with shelves at both a local and remote site.
1

SpectraLink 6300 MCU: T1 Remote Module Installation: SpectraLink 6000 System
PN: 1725-36126-001_K.doc
8
1 2 3 4 5 6 7 8 9 10 11 12
T1 Remote Module
Shelf Controller Card
1 2 3 4 5 6 7 8 9 10 11 12
T1 Remote Module
Shelf Controller Card
Interface Module Interface Module Interface Module Interface Module Interface Module
Interface Module
Interface Module Interface Module Interface Module Interface Module
Interface Module Interface Module Interface Module Interface Module Interface Module Interface Module Interface Module Interface Module Interface Module Interface Module
1 2 3 4 5 6 7 8 9 10 11 12
Empty - (Future Use)
Shelf Controller Card
Interface Module Interface Module Interface Module Interface Module Interface Module Interface Module Interface Module Interface Module Interface Module Interface Module
1 2 3 4 5 6 7 8 9 10 11 12
System Controller Card
Interface Module Interface Module Interface Module Interface Module Interface Module Interface Module Interface Module Interface Module Interface Module
T1 Remote Module
Shelf 1 - Primary Shelf
Shelf 2 - Expansion Shelf
Shelf 3 - Expansion Shelf
Shelf 20 - Expansion Shelf
Intershelf Junction Panel
Location A - Local Location B - Remote
1 2 3 4 5 6 7 8 9 10 11 12
T1 Remote Module
Shelf Controller Card
Interface Module Interface Module Interface Module Interface Module Interface Module
Interface Module
Interface Module Interface Module Interface Module Interface Module
Shelf 4 - Expansion Shelf
T 1
T 1
T 1
T 1
CSU CSU
CSU CSU
CSU
CSU
CSU
CSU

Remote Installation Overview
PN: 1725-36126-001_K.doc 9
Remote Installation Steps (Overview)
Follow these steps to install the T1 Remote Module. Detailed
instructions for each of these steps are contained in this document and
other relevant documents in the SpectraLink 6300 MCU System
documentation.
1. Prepare site and check components.
2. Install T1 Remote Module at the local site (location where the
Primary Shelf is located.)
3. Connect T1 Remote Module at the local site to the Intershelf
Junction Panel and T1 facilities.
4. Install Expansion Shelf at remote site.
5. Install T1 Remote Module, Shelf Controller, and Interface
Modules at remote site. Note that GPS timing may be required
when remote and main shelves are within 600 to 800 feet of one
another.
6. Connect T1 Remote Module at the remote site to the Shelf
Controller and T1 Facilities.
7. Install any additional Expansion Shelves at remote site, and
connect Expansion Shelves at the site.
8. Connect RJ-21 cables for telephone lines and Base Stations to
Interface Modules at remote site.
9. Configure remote system and register handsets.

PN: 1725-36126-001_K.doc 11
Site Preparation
The following steps must be completed before installing the system
hardware. If the steps are not already completed refer to each
individual section for details.
1. At the local site, install and test Primary Shelf and Expansion
Shelves. Refer to
SpectraLink 6300 MCU: Installation for
information.
2. At the remote site:
a. Install a two pair cable to each Base Station as designated on
the building floor plans.
b. Terminate the Base Station wiring with RJ-45 crimp-on plugs
at the designated Base Station locations.
c. Terminate the Base Station wire at the appropriate cross-
connect demarc blocks.
d. Terminate the analog or digital phone extensions from the
phone system at the appropriate cross-connect demarc block,
and label the block.
Required Materials Provided by Customer
Rack The shelves are designed to fit into a 19” mounting rack.
Each shelf measures 15” high x 19” wide x 9” deep, and weighs
approximately 35 pounds fully loaded. See Chapter 4 Site
Preparation - Prepare Location for Shelves, in the SpectraLink 6300
MCU: Installation document.
Backboard space As an alternative to rack mounting, the shelves
can be wall mounted to 3/4” plywood securely screwed to a wall.
Screws Required to mount the shelves to the wall, or to secure it
in the rack. For wall mount, six #10-5/8” panhead wood screws
(or similar device) are required. For rack mount, screws required
are determined by the rack requirements; typically 10-32 or 1/4-
20.
2

SpectraLink 6300 MCU: T1 Remote Module Installation: SpectraLink 6000 System
PN: 1725-36126-001_K.doc
12
RJ-45 Cable For network clocked T1 facilities, an RJ-45 cable is
required to connect the designated Master Clock T1 Module to the
Intershelf Junction Panel.
T1 Configuration Requirements
T1 circuits will connect expansion shelves directly to the System
Controller shelf via the Polycom provided Intershelf Junction Panel.
The Intershelf Junction Panel is always co-located with the system
controller shelf.
The following configuration requirements apply to the T1 lines
connecting the SpectraLink 6300 MCU local and remote shelves.
•All T1 circuits for networking the SpectraLink 6000 System must
be Extended Superframe Format (ESF).
•T1 circuits must be a full T1 (not fractional).
•T1 circuits must be 64 Kbps (not 56 Kbps) per channel.
•Line coding for the T1 circuits must be Bipolar 8-bit Zero
Substitution (B8ZS).
•T1 circuits should be terminated as close to the SpectraLink 6300
MCU shelves as possible, at both the System Controller site and
the Expansion Controller site(s).
•One or two T1 circuits are required per remote SpectraLink 6300
MCU Expansion Shelf.
•One T1 circuit is required for the first five Interface Module cards
in a Remote Expansion shelf.
•Two T1 circuits are required for six or more Interface Module
cards installed in the remote expansion shelf. Note that 1 to 10
Interface Module cards may be installed in any expansion shelf.
•The T1 circuit must be activated and verified to be in proper
working order at least one week in advance of the networked
SpectraLink 6000 System scheduled installation.
•Channel Service Unit (CSU)
•A Channel Service Unit (CSU) must be installed at each end of the
T1 circuit.
•The ADC Kentrox T-SERV II or other comparable CSU models are
satisfactory.

Site Preparation
PN: 1725-36126-001_K.doc 13
•From the CSU, the T1 circuit must be provided to the SpectraLink
system on an RJ-48C modular connector.
•The CSU must have an independent power supply, per
manufacturer specifications.
Check Components
The following items should be at the installation site.
Cables Two 12-foot RJ-45 cables with each Expansion Shelf
Controller (CSC300). RJ-45 cable to connect multiple shelves (one
for each shelf).
Interface Modules The correct number and type of Interface
Modules to connect the handsets and the Base Stations to the
telephone system. Interface Modules can support analog
(CPA316), Universal digital (CPU316), Mitel (CPM316), Executone
(CPB316), Panasonic (CPP316), and select four-wire (CPF316)
interfaces.

PN: 1725-36126-001_K.doc 15
Install T1 Remote Module at Local
Site
Before installing the hardware at the remote site, the Primary shelf at
the local site must have a T1 Remote Module (CRC301) installed.
Install one Remote Module for each remote shelf to be installed.
Slide the Remote Module into slot 1 or slots 3 through 12 of any shelf,
until the card clicks into place. Tighten the screws at the top and
bottom of the card to secure it. The Remote Module can go in any slot,
in any shelf of the system, except slot 2.
Cards contain components that may be damaged by electrostatic
discharge. Before handling any of the cards, the installer must
attach the grounding strap (included in the Administration Kit) to his
or her wrist, and attach the other end of the strap to ground. Only
handle the cards by their edges. Do not touch connector contact
areas, do not lift cards by any of the components, and do not lay
cards down on their component sides. When laying a card down,
place it component side up on top of the anti-static bag in which it
was shipped.
Connect Intershelf Junction Panel
Connect two RJ-45 cables from the System Controller ports in the T1
Remote Module to the corresponding shelf ports on the Intershelf
Junction Panel (JPI300). Be sure the RJ-45 cable in Connector Aon the
Remote Module goes to the Aconnector on the JPI300, and that
Connector Bgoes to the B Connector.
The following diagram outlines the ports on the JPI300.
3

SpectraLink 6300 MCU: T1 Remote Module Installation: SpectraLink 6000 System
PN: 1725-36126-001_K.doc
16
Network clocked T1 facilities
If the T1 facilities are Network Clocked, one T1 Remote Module must
be designated as the Master Clock Source. Connect the Sync IN port on
this T1 Remote Module to AUX port A on the Intershelf Junction Panel.
Note, this shelf must also be designated as the Master Clock in the
system configuration.
Connect T1 facilities
Connect the RJ48C jack from the CSU port at the local end to the DS1 A
and DS1 B ports on the T1 Remote Module. Port Acontrols slots 3
through 7 on the remote module at the far end. Port Bcontrols slots 8
through 12.
The following diagram shows the T1 Remote Module connections at
the LOCAL site.

Install T1 Remote Module at Local Site
PN: 1725-36126-001_K.doc 1
7
ALARM
1
2
3
4
5
CRC-301
TIMING
MASTER
IN
SYNC
OUT
A
B
SYSTEM
CONTROLLER
SC/A
SC/B
EXPANSION
SHELF
CONTROLLER
DS1 A
LOS
LIKOK
DS1 B
LOS
LIKOK
RJ45 to Intershelf Junction Panel
T1 connection Module 3-7
on remote
T1 connection Module 8-12
on remote
To AUX Port on Intershelf
Junction Panel for Net Clocked T1

PN: 1725-36126-001_K.doc 19
Install System at Remote Site
Survey Site
Check the site to be sure pre-installation work has been completed
correctly. This includes:
Location chosen for the shelves is adequate.
Rack (if rack mounted) is properly secured or backboard (if wall
mounted) is properly prepared.
Power is available.
Wiring to Base Station locations has been pulled and correctly
terminated.
Phone lines for the Wireless Telephones are installed and properly
terminated.
Telephone system administrator is available to program the
existing telephone system.
Install Shelves
Rack mount
To install shelves in the rack, slide the shelves into the rack and secure
them to the rack using eight screws, 1/4” minimum length.
Wall mount
At this point in the installation process, there should be a backboard
securely fastened to the wall and mounting screws partially inserted
into the backboard. See
SpectraLink 6300 MCU: Installation for more
information.
4

SpectraLink 6300 MCU: T1 Remote Module Installation: SpectraLink 6000 System
PN: 1725-36126-001_K.doc
20
To attach the shelves to the wall:
1. Remove all cards from the shelf. Do not mount the shelf with
cards installed.
Cards contain components that may be damaged by electrostatic
discharge. Before handling any of the cards, attach the grounding
strap (included in the Administration Kit) to your wrist, and attach
the other end of the strap to ground. Handle cards only by their
edges. Do not touch connector contact areas. Do not lift cards by
any of the components. Do not lay cards down on their component
sides. When laying a card down, place it component side up, on top
of the anti-static bag in which it was shipped.
2. Position the MCS300 so that the six mounting screws are aligned
with the six keyhole openings in the back of the shelf.
3. Slide the shelf down onto the screws to lock the shelf into place.
Check that all six screws are properly locked.
4. Tighten all six screws fully.
Do not install cards until power is connected.
Connect Power to Shelves
Polycom recommends that a licensed electrician install the -48V DC
power supply and connect power to the shelves.
See
SpectraLink 6300 MCU: Installation - Connect Power to Shelves, for
more information.
Install Cards
The shelf diagram below shows a fully loaded Expansion Shelf. Any
type of Interface Module can be installed in slots 3 through 12.
