Polygroup TG76M2251D01 User manual

1
MODEL #: TG76M2251D01 SKU: 137-928
*Electrical Rating For The Tree
(For Indoor Use Only)
Input: 120V, 60Hz, 0.45A
Output: 29V DC 0.9A
Fig. B - Tree and Light Assembly
Tree top
Section 2
Section 1
Fig. A - Tree Stand Assembly
Unfold the legs and lay the
stand in a flat area.Then slide
the locking disc downward and
snap into place.
Adapter
To Be Plugged
Into Wall
Outlet
Insert Green
Label Extension
Cord into Adapter
Control box
Fig. C
Side view
Top view
3. Each tree section is numbered with a sticker. Please identify all sections before assembling.
4. Assemble the tree from bottom to tree top. Start with the bottom section and remove the protective cap before inserting into the assembled
stand. Make sure the pole is firmly inserted and secured into the stand.
5. Continue by inserting the upper tree section(s) to the lower section(s) until inserting the tree top.
6. Allow branches to fall into place or gently pull up and out. When adjusting branches, be sure that all wires are free of branch hinges.
7. Just plug the adapter (connecting with the tree power cord) into the wall outlet (See Fig. B), your entire tree should now be lit. If some
bulbs do not light or flickers, search for any loose plugs and/or broken, loose or missing bulbs.Replace bulbs promptly in order to
maintain the performance and life expectancy of your pre-lit tree.
8. Begin to shape the branches and tips working from the bottom to the top. Start with tips farthest from the pole and fan out one to the right,
one to the left and one at the center of the main stem. (See Fig. C)
Align both arrows
in a straight line
before sliding
down to insert
Open the
cap cover
Do Not Tamper
Internal Parts
TREE ASSEMBLY INSTRUCTIONS
NEED HELP?
DO NOT RETURN TO STORE. PLEASE VISIT US AT:
www.polygroupstore.com OR 1-888-919-0070
1. Before you start to assemble your tree, choose an appropriate location near a wall outlet.
2. Assemble the tree stand and place on a level surface. (See Fig. A)
Congratulations on purchasing your new tree from Polygroup®!
This tree comes with Quick Set® technology - allowing you to set up your tree and light it up in minutes!
Carefully follow the instructions below on how to quickly and easily set up your new tree.

2
1. Unplug adapter from the wall outlet first and then remove all ornaments and decorations.
2. Disassemble the tree from the top to the bottom. Start with the tree top and gently lift straight up to remove from section
below and fold all branches toward the pole.
3. Continue by gently lifting straight up each section(s) from the section
below and fold all branches toward the pole until the bottom section
is removed from the tree stand. Cover the protective cap on the poles
to avoid damaging the internal parts. (See Fig. D)
4. Carefully place all tree sections into shipping box and tape it shut.
5.When not in use, please store your tree in a cool, dry place away from sunlight.
Exposing your tree to excessive heat or humidity may damage your tree.
Fig. E
STORAGE INSTRUCTIONS
TROUBLESHOOTING TIPS
For Pre-lit Trees, If The Tree Does Not Illuminate
1. Please check to make sure that all plugs are properly connected and adapter is plugged into the wall outlet.
2.Turning the poles gently to make sure pole to pole are connected into place.
3. Check for loose connection between light string plugs and extension cords.
4. Please check for loose, broken or missing light bulbs and replace as needed.
Loose Hinge Pin
1. Extra hinge pins are included for repairing the hinges.
Place the branch into the slot of the bracket.
2. Insert a new hinge pin through the hole and secure
using the retainer washer. (See Fig. E)
9. After shaping the entire tree following the previous step, slightly upsweep all branch tips for a uniform look. Shift branches
to fill any gaps. Your Christmas tree is now complete and ready to be decorated.
Simply press the selector button to select from the following light functions:
(1) CLEAR - MULTI: FADING (2) CLEAR: FADING
(3) CLEAR - MULTI: ALTERNATING (4) CLEAR: STEADY
(5) CLEAR - MULTI: SLOW FADING (6) MULTI: STEADY
(7) MULTI: FADING (8) COMBINATION
DUAL COLOR LIGHT CONTROLLER & REMOTE CONTROL
Remote
Control Light
Controller
Selector Button
Insulation Tab
REMOTE CONTROL INSTRUCTIONS
1. Remove the insulation tab of the remote control.
2. Press either selector button and wait for a second to enjoy light effects in the following sequence
(see DUAL COLOR LIGHT CONTROLLER & REMOTE CONTROL).
2. Replace the used battery with a new CR2032 button cell battery (not included). Make sure that the battery is installed with
the correct polarity (+ and -).
3. Retighten the screw to close and secure the battery cover.
Cover
Battery
CR2032
BATTERY REPLACEMENT
1. Loosen the screw of the battery cover with a screwdriver (not included).
Fig. D

3
This tree includes hinge pins/washers and spare bulbs.
If extra parts are needed, please contact our customer service center.
SPARE PARTS
1. Dispose used battery properly. observe local regulations regarding disposal of hazardous waste.
2. Ensure the batteries are installed correctly with regard to polarity (+ and -).
3. This product is powered by a lithium battery. Due to their small size, lithium batteries can easily be swallowed by children.
Ingestion of such batteries has been known to cause death.
4. This product contains a lithium battery which if swallowed has been known to cause death.
5. Do not expose light set to moisture.
6. Remove batteries when not used for an extended period of time, or when depleted.
7. Clean the battery contacts prior to battery installation.
8. The external flexible cable or cord of this luminaire cannot be replaced; If the cord is damaged, the luminaire shall be destroyed.
9. Dispose of used batteries properly by following directions on batteries.
10. Use only CR2032 batteries for the remote controller.
11. DO NOT DISPOSE OF BATTERIES IN FIRE. BATTERIES MAY EXPLODE OR LEAK.
WARNING
Lamp Replacement
Step 1. Unplug from power source, by pulling out the adapter itself - do not pull on the power cord.
(For reference only)
Step 3. Replace with a new spare
LED lamp (included).
Step 2. Lift up the lamp lock tab,
and pull the bulb and its
plastic base straight out
from the lampholder.
CAUTION:
To reduce the risk of fire and electric shock:
a) Use only the power supply that was provided with this product. Using a different adapter will damage the lights and may
cause fire, or electrical shock hazards.
b) Do not install on trees having needles, leaves or branch covering of metal or materials which look like metal, and
c) Do not mount or support strings in a manner that can cut or damage wire insulation.
For any questions, assistance, or missing parts, Do Not Return To Place Of Purchase. Please contact us at 1-888-919-0070
or visit our website at www.polygroupstore.com. One of our customer service representatives will be happy to assist you.
CUSTOMER SERVICE FOR CHRISTMAS TREES
Tree ID#:
Tree UPC#:
Store Purchased:
Specify Problem:
Customer Name:
Address:(No P.O. Boxes)
City & State:
Zip Code:
Day Phone:
Date Purchased:
TREE ID# IS LOCATED ON END PANEL OF BOX.TREE ID# IS REQUIRED WHEN REQUESTING REPLACEMENT PARTS.
